DVI-I Out Ports

The primary and secondary digital video output ports are DVI-I receptacles with 29 signal contacts

as specified by the Digital Visual Interface specification (Revision 1.0). These ports support pixel

rates up to 112 MHz using the SII150 A PanelLink device from Silicon Image. The ports are fully

compliant with the DVI specification, and support digital and analog displays.

This port is a 75-ohm male BNC connector that is used to connect to a 75-ohm coaxial cable

terminated with a female BNC connector. The port allows video timing to be synchronized to an

external timing source. The port provides a periodic signal to the display system to lock vertical

refresh rate.

This port is a female, 3-pin, mini-DIN connector. The port provides connection to the emitter

module for LCD shutter glasses or to other stereo shutter devices.

These ports are two 6-pin modular jack connectors. They allow Multiview support for frame

locking and rate locking of multiple computers.
