8
Figure 3. DVI-I Ports
To connect VGA monitors:
1.
Turn off power to the computer and to the monitors.
2.
Connect the 15-pin VGA connector on each monitor cable to the VGA end of a DVI-VGA
adapter (see Figure 4).
3.
If you are connecting a single monitor, connect the DVI-I end of the DVI-VGA adapter to the
Primary DVI-I port (see Figure 3).
4.
If needed, connect the DVI-I end of the DVI-VGA adapter for a second monitor to the
Secondary DVI-I port.
NOTE
Multiple monitor support is available only under Windows 2000. If you are
connecting two monitors to the Wildcat 4210, see Chapter 3, "Using the Wildcat
4210, " for information about configuring dual displays.
Figure 4. DVI-I to VGA Adapter
5.
Turn on power to the computer and to the monitors. If the monitors' Power On LEDs do not
illuminate or the monitors do not display, refer to Chapter 4, "Troubleshooting."
