Intense3D Wildcat 4110
User's Guide
October 1999
D1AV00070

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Intense3D Wildcat 4110 and is the answer not in the manual?

Questions and answers

Related Manuals for Intergraph Intense3D Wildcat 4110

Summary of Contents for Intergraph Intense3D Wildcat 4110

  • Page 1 Intense3D Wildcat 4110 User’s Guide October 1999 D1AV00070...
  • Page 2 Intergraph Corporation, Huntsville AL 35894-0001 Notice Information in this document is subject to change without notice and should not be considered a commitment by Intergraph Corporation. Intergraph Corporation shall not be liable for technical or editorial errors in, or omissions from, this document.

  • Page 3: Table Of Contents

    Contents Preface ............................. v About This Document........................v Document Conventions........................v Operating System Information......................vi Hardware Information........................vi Customer Support ..........................vi World Wide Web ......................vi 1 Introduction ..........................1 Features............................. 1 External Connectors.......................... 4 2 Setup ............................. 5 Preparing for Installation ........................
  • Page 4 Dimensions ............................. 20 Slots Required ..........................20 Power Requirements ........................20 B Connectors..........................21 Stereo Sync Output ......................... 22 Analog Video Output........................22 DVI-I Output ..........................22...

  • Page 5: Preface

    Preface The Intense3D Wildcat 4110 User’s Guide contains information on the setup and use of the Intense3D Wildcat 4110 video card, as well as troubleshooting information, connections, and specifications. If you purchased this card as part of a system, the card was factory installed and configured in your system prior to shipment.

  • Page 6: Operating System Information

    Operating System Information You must have Microsoft Windows NT 4.0 with Service Pack 4 or later installed. The appropriate operating system was installed on your computer prior to shipment if you bought the Wildcat 4110 video card as part of a system. For more detailed information on the operating system, refer to the printed and online documentation delivered with the system.

  • Page 7: Introduction

    NOTE If you purchased the Intense3D Wildcat 4110 video card as part of a system, it was preconfigured to in your system operate before shipment. No other modifications are necessary. Also, your system’s video drivers were installed before shipment and are operative when you receive the system.
  • Page 8 NOTE Supported refresh rates, monitor resolutions, aspect ratios, and color depths depend on your type of monitor, and whether or not you have multisampling selected. See Appendix A, “Specifications,” for a list of supported resolutions and refresh rates. NOTE To display at a specific resolution with the desired refresh rate, both the video card and monitor must support it.
  • Page 9 2D/3D points, vectors, and polygons Texture mapping: point, bilinear, trilinear, and multiple internal formats 24- and 32-bit depth buffering Dithering Fast window clears Window clipping Fast window-mode double buffering Masking Frame-sequential and interlaced stereo support Stencil operations Matrix transformations OpenGL Extensions Imaging: pixel buffer, color table, color matrix, convolution Blend: color, minmax, function separate Fog: fog function, fog offset...

  • Page 10: External Connectors

    Onboard texture memory with full mipmapped trilinear interpolated texture processing Digital Video Interface (DVI)-I digital flat panel display support External Connectors The Intense3D Wildcat 4110 video card has three standard external connectors (see Figure 1): 3-Pin, MiniDIN stereo sync output connector 15-Pin, D-sub analog video output connector DVI-I output connector Figure 1.

  • Page 11: Setup

    If you purchased your Intense3D Wildcat 4110 video card as part of a system, it was installed before shipment, along with its driver software. The instructions in this chapter are necessary only if you purchased a customer kit or need to reinstall your video card or its driver software.

  • Page 12: Take Anti-Static Precautions

    AGP Pro50 or AGP Pro expansion slot, identifying Peripheral Component Interconnect (PCI) expansion slots, and adding expansion cards. To install the Intense3D Wildcat 4110 video card: Turn off power to the computer and to the monitor, and disconnect the cables from the computer.

  • Page 13: Connecting The Monitor

    Figure 2. Wildcat 4110 Video Card Use the screws you removed previously to secure the card to the computer’s chassis. Close the workstation and reconnect the power cord. See “Connecting the Monitor” in this chapter for instructions on connecting a display device to the Wildcat 4110 video card. Connecting the Monitor To connect the monitor: Make sure the power to the computer is turned off.

  • Page 14: Installing The Software

    Installing the Software If you are installing an Intense3D Wildcat 4110 video card or reinstalling its driver software, take the following steps. Refer to the Microsoft Windows NT documentation and online Help for more information on installing drivers and software application programs.

  • Page 15: Verify The Default Video Display Driver

    From the operating system Start menu, go to Settings/Control Panel/Display, and click the Settings tab. Click Display Type, then verify that Intense3D Wildcat 4110 is listed under Adapter Type. This indicates that the appropriate driver is installed. Click Cancel to dismiss the Adapter Type list without making any changes.

  • Page 16: Check The Video Image

    NOTE Do not select the VGA version of the operating system. The video display runs in VGA mode when the Intense3D Wildcat 4110 graphics driver is not running. Click OK to close the System dialog box. Check the Video Image...

  • Page 17: Using The Video Card

    Using the Video Card This chapter contains instructions for configuring the video display and enabling the stereo display. NOTE If you ordered this video card with a system, it was configured for use prior to shipment. The following instructions apply only if you purchased the card as an upgrade or add-on.
  • Page 18 To use the Intense3D Monitor tab: On the Display Properties dialog box, click the Intense3D Monitor tab (see Figure 6). This tab contains commands for adjusting the resolution, color depth, and refresh rate. See the steps under “Intense3D Configuration Tab” to open the Display Properties dialog box. Figure 6.

  • Page 19: Enabling Stereo Display

    On the Intense3D Monitor Display Properties dialog box, click Configure Monitor to change the display mode, select a monitor type, and change the resolution/refresh rate (see Figure 8). Once you have made the changes you require, click OK to accept the new configuration and dismiss the Configure Monitor dialog box.
  • Page 20 To enable stereo display: Make sure your stereo display device is properly connected to the stereo output port on the Wildcat 4110 card. See Chapter 2, “Setup,” for more information. On the Intense3D Monitor tab under Display Properties, click Configure Monitor. The Configure Monitor dialog box displays (see Figure 8, above).

  • Page 21: Troubleshooting

    Troubleshooting This chapter describes common problems and solutions, how to get a usable video resolution, how to reinstall the video driver software, and how to get help. Common Problems and Solutions Monitor Checks Problem Cause Solution Display is black, not Display properties are not Use the Last Known Good synchronized, or distorted...

  • Page 22: Diagnostics

    Color balance is wrong Monitor settings may be Refer to your monitor’s configured improperly. documentation for instructions on adjusting the color display. There is no picture Improper software setup or Verify that the display hardware problem. properties are configured correctly for the monitor type.

  • Page 23: Restarting The System In Vga Mode

    README If you are reinstalling the Intense3D Wildcat 4110 driver, you must remove the current driver prior to installing the update. To remove the existing Intense3D Wildcat 4110 driver: Log on to Windows NT using an account that has administrative privileges.

  • Page 24: Getting Help

    On the Add/Remove Programs Properties Install/Uninstall tab, highlight the Intense3D Display Driver and click Add/Remove. Click Yes when prompted to confirm the driver removal, and follow the prompts. On the Add/Remove Programs Properties Install/Uninstall tab, highlight the Intense3D Display Driver and click Add/Remove. Click Yes when prompted to confirm the driver removal, and follow the prompts.

  • Page 25: A Specifications

    Specifications General Manufacturer—Intense3D Model number—Wildcat 4110 Functional System—If you ordered this video card with a system, it was preinstalled and configured for use in your system before shipment. Interface—AGP Pro50 and AGP Pro Graphic controller—High-speed Wildcat chipset technology DAC speed—220 MHz Data width—Frame buffer 128 bits;...

  • Page 26: 3D Performance

    3D Performance Performance numbers reflect maximum hardware rate. Numbers may vary depending on the application. 3D Gourad-shaded triangles, Z-buffered, 15-pixel—6.0 M tri/sec 3D Gourad-shaded triangles, Z-buffered, 25-pixel—4.3 M tri/sec 3D Vectors, solid color, 10-pixel—12.0 M vec/sec Dimensions Height—1.01 inches Length—13.34 inches Width—4.25 inches Slots Required One AGP Pro50 or one AGP Pro slot...

  • Page 27: B Connectors

    Connectors The Intense3D Wildcat 4110 is an AGP Pro50 card designed for systems that have a 50-Watt AGP Pro50 slot or a 110-Watt AGP Pro slot. NOTE The Intense3D Wildcat 4110 cannot plug into a standard AGP slot. NOTE If you ordered this video card with a system, it was installed and configured for use prior to shipment.

  • Page 28: Stereo Sync Output

    Figure 11. Connectors Stereo Sync Output The stereo port (female, 3-pin, mini-DIN connector) provides connection to a LCD shutter glasses emitter module or to other stereo shutter devices. Analog Video Output The video port (female, 15-pin, D-SUB connector) provides connection to an analog CRT display. DVI-I Output The Digital Video Output Port uses a DVI-I receptacle with 29 signal contacts as specified by the Digital Visual Interface Revision 1.0 specification.
