microSAMPLER
4. PATTERN SEQUENCER section
a. [PATTERN] dial
Use this to select a pattern location in the pattern sequencer.
b. [MUTE] button
This allows you to prevent the sample of the selected key from sound-
ing. ( ☞ p.34 "Using the mute function")
c. [PLAY/STOP] button
Starts and stops the pattern sequence.
d. [REC] button
This switches the pattern sequencer between record-ready, start, and
stop.
5. SAMPLING section
a. [SAMPLING TYPE] switch
This specifies the type of sampling.
b. [INPUT SELECT] button
This selects the sampling source.
c. [SAMPLING] button
This switches between sampling setup, pause, start, and end.
d. [AUDIO IN LEVEL] LED
This will light green when there is input from the AUDIO IN [L/
MONO] and [R] jacks or from the AUDIO IN [
red if the input is overloaded.
6. AUDIO IN [
MIC] jack
You can connect the included gooseneck or other dynamic microphone
here.
To use a mic to this jack, set the rear panel AUDIO IN [
to the "
" position. Use the rear panel AUDIO IN [GAIN] knob to
adjust the input level.
7. SAMPLE STATUS buttons
These buttons indicate and specify the state of the following three sam-
ple parameters for the current sample ( ☞ p.18).
a. LOOP ( ☞ p.28 "PLAY.TYPE")
b. REVERSE ( ☞ p.28 "REVERSE")
c. FX SW ( ☞ p.30 "FX SW")
10
8. [ENTER/SHIFT] button
Press this button to execute the setting you specified.
You can execute SHIFT functions by holding down this button and
pressing another button. ( ☞ p.64 "Shift functions")
9. [EXIT] button
This button stops sampling, or cancels a save operation or utility opera-
tion.
10. Main display
This shows the information such as the currently selected parameter and
its value, or messages.
MIC] jack. It will light
a.
b.
c.
d.
/LINE] switch
e.
f, g. These areas indicate the bank and sample, or the page and parame-
h.
11. [WRITE] button
Press this to save banks, samples, or performances you've recorded in
the pattern sequencer.
To edit sample parameters other than the above, use the [EDIT] button
to select the "SAMPLE" page. ( ☞ p.28 "2. Sample parameters")
a b
f
g
h
Battery indicator
Edit indicator
Global indicator
If there are multiple pages or parameters, "
will be shown to indicate that there are additional pages or param-
eters at the left or right.
Sampling level meter
ter.
Cursor, bank number, etc.
c d
e
" or "
" symbols
