9

DTMF MEMORY ENCODER

■ DTMF TX speed

The transmitting speed of DTMF code can be set to ac-
commodate your operating needs.
q Hold down [ ] for 1 second to turn OFF the power.
w While holding down [LOCK] (SET) and [ ] for 1
second, to turn ON the power to enter the Initial Set
mode.
e Push [SET] or [MONI] until "DTD" appears.
r Rotate [DIAL] to select the desired transmitting
speed, as shown in the table below.
t Push [ ] to exit the Initial Set mode.
DISPLAY INTERVAL
DTD- 1 100 milliseconds
DTD- 2 200 milliseconds
DTD- 3 300 milliseconds
DTD- 5 500 milliseconds
cps=characters/second
MUTE
NAR
MID
LOW
LOCK
S ET
SPEED
5.0 cps
2.5 cps
1.6 cps
1.0 cps
38
The display shows the
DIGITAL PRIO AO BUSY
fastest DTMF speed is
selected.
ANM DUP T-SCAN PRIO SCAN
MONI LOW TONE M/CALL V/MHz
