Display Of Warnings From Sip Headers - Polycom SIP 3.1 Administrator's Manual

Administrator's Guide SoundPoint IP / SoundStation IP
Note

Display of Warnings from SIP Headers

4 - 72
dns.cache.NAPTR.1.preference="1"
dns.cache.NAPTR.1.flag="s"
dns.cache.NAPTR.1.service=" SIP+D2U"
dns.cache.NAPTR.1.regexp=""
dns.cache.NAPTR.1.replacement="_sip._udp.sipserver.example.com"
dns.cache.SRV.1.name="_sip._udp.sipserver.example.com "
dns.cache.SRV.1.ttl= "3600"
dns.cache.SRV.1.priority="1"
dns.cache.SRV.1.weight="1"
dns.cache.SRV.1.port="5075"
dns.cache.SRV.1.target="primary.sipserver.example.com"
dns.cache.SRV.2.name="_sip._udp.sipserver.example.com "
dns.cache.SRV.2.ttl= "3600"
dns.cache.SRV.2.priority="2"
dns.cache.SRV.2.weight="1"
dns.cache.SRV.2.port="5075"
dns.cache.SRV.2.target="secondary.sipserver.example.com
dns.cache.A.1.name="primary.sipserver.example.com"
dns.cache.A.1.ttl="3600"
dns.cache.A.1.address="172.23.0.140"
dns.cache.A.2.name="secondary.sipserver.example.com"
dns.cache.A.2.ttl="3600"
dns.cache.A.2.address="172.23.0.150"
The reg.1.server.1.port, reg.1.server.2.port,
reg.1.server.1.transport, and reg.1.server.2.transport values in this
example are set to null to force NAPTR lookups.
The Warning Field from a SIP header may be used to cause the phone to
display a three second "pop-up" to the user. For example, this feature can be
used to inform the user of information such as the reason that a call transfer
action failed (bad extension entered, for example). (For more information,
refer to Header Support
These messages are displayed in any language supported by the phone for
three seconds unless overidden by another message or action.
on page B-4.)
