Name
device.set
device.xxx.yyy.set
device.net.ipAddress
device.net.subnetMask
device.net.IPgateway
device.net.vlanId
device.net.cdpEnabled
device.dhcp.enabled
device.dhcp.offerTimeout
device.dhcp.
bootSrvUseOpt
device.dhcp.bootSrvOpt
device.dhcp.
bootSrvOptType
device.dhcp.
dhcpVlanDiscUseOpt
device.dhcp.
dhcpVlanDiscOpt
This flash attributes are defined as follows:
Possible Values
0 or 1
default = 0
0 or 1
default = 0
dotted-decimal IP address
dotted-decimal IP address
dotted-decimal IP address
Null, 0 to 4094
0 or 1
0 or 1
1 to 600
0 to 3
128 to 254 (Cannot be the
same as VLAN ID Option)
0 or 1
0 to 2
128 to 254 (Cannot be the
same as Boot Server
Option)
Description
If set to 0, do not use any device.xxx.yyy fields to
set any parameters. Set this to 0 after the initial
installation.
If set to 1, use the device.xxx.yyy fields that have
device.xxx.yyy.set = 1. Set this to 1 for the initial
installation only.
If set to 0, do not use the device.xxx.yyy value.
If set to 1, use the device.xxx.yyy value.
For example, if device.net.ipAddress.set = 1,
then use the contents of the device.net.ipAddress
field.
Phone's IP address.
Note: This field is not used when DHCP client is
enabled.
Phone's subnet mask.
Note: This field is not used when DHCP client is
enabled.
Phone's default router / IP gateway.
Note: This field is not used when DHCP client is
enabled.
Phone's 802.1Q VLAN identifier.
Note: Null = no VLAN tagging
If set to 1, the phone will attempt to determine its
VLAN ID through the CDP.
For description, refer to
DHCP or Manual TCP/IP
Setup
on page 3-2.
Number of seconds the phone waits for secondary
DHCP Offer messages before selecting an offer.
For descriptions, refer to
Configuration Files
DHCP Menu
on page 3-7.
A - 125
