Local Web Server
(if enabled)
Local Phone User
Interface

Idle Display Animation

Central Configuration file:
sip.cfg
(boot server)

Ethernet Switch

Set the basic SNTP and daylight savings settings.
Navigate to: http://<phoneIPAddress>/coreConf.htm#ti
Changes are saved to local flash and backed up to <Ethernet
address>-phone.cfg on the boot server. Changes will permanently
override global settings unless deleted through the Reset Local
Config menu selection and the <Ethernet address>-phone.cfg is
removed from the boot server.
The basic SNTP settings can be made in the Network Configuration
menu.
For more information, refer to
page 3-2.
The user can edit the time and date format and enable or disable the
time and date display under the Settings menu.
Changes are saved to local flash and backed up to <Ethernet
address>-phone.cfg on the boot server. They will permanently
override global settings unless deleted through the Reset Local
Config menu selection.
All phones except the SoundPoint IP 301 can display a customized animation
on the idle display in addition to the time and date. For example, a company
logo could be displayed (refer to
Configuration changes can performed centrally at the boot server:
To turn idle display animation on or off.
• For more information, refer to
To replace the animation used for the idle display.
• For more information, refer to
<IP_330/>, <IP_400/>, <IP_500/>, <IP_600/>, <IP_4000/>, and
<IP_7000/>
To change the position of the idle display animation.
• For more information, refer to
<IP_330>, <IP_400/>, <IP_500/>, <IP_600/>, <IP_4000/>, and
<IP_7000/>
The SoundPoint IP phones contain two Ethernet ports, labeled LAN and PC,
and an embedded Ethernet switch that runs at full line-rate. The SoundStation
IP phones contain only one Ethernet port, labeled LAN. The Ethernet switch
allows a personal computer and other Ethernet devices to connect to the office
LAN by daisy chaining through the phone, eliminating the need for a
stand-alone hub. The SoundPoint IP switch gives higher transmit priority to
packets originating in the phone. The phone can be powered through a local
DHCP or Manual TCP/IP Setup
Adding a Background Logo
Indicators <ind/>
Animations <anim/> <IP_300/>,
on page A-81.
Graphic Icons <gi/> <IP_300/>,
on page A-83.
Configuring Your System
on
on page C-6).
on page A-80.
4 - 15
