14

OPTIONS

• BP-263
BATTERY CASE
Battery case for LR6 (AA) × 6 alkaline batteries.
• BP-264 -
NI MH BATTERY PACK
7.2 V/1400 mAh (Minimum)/1420 mAh (Typical) Ni-
MH battery pack. Battery life: 13 hours (approximately;
FM, high power, Tx : Rx : Standby = 5:5:90)
• BP-265 L -
I ION BATTERY PACK
7.4 V/1900 mAh (Minimum)/2000 mAh (Typical) Lith-
ium Ion battery pack. Battery life: 19 hours (approxi-
mately; FM, high power, Tx : Rx : Standby = 5:5:90)
• BC-191
DESKTOP CHARGER
For rapid charging of the Ni-MH battery pack. An AC
adapter may be supplied with the charger, depending
on the version.
Charging time: approximately 2 hours for the BP-264.
• BC-192
DESKTOP CHARGER
For regular charging of the Ni-MH battery pack. An AC
adapter may be supplied with the charger, depending
on the version.
Charging time: approximately 16 hours for the BP-264.
• BC-193
DESKTOP CHARGER
For rapid charging of the Li-ion battery pack. An AC
adapter may be supplied with the charger, depending
on the version.
Charging time: approximately 2.5 hours for the BP-265.
• CP-23L
CIGARETTE LIGHTER CABLE
Allows charging of the battery packs through a 12 V
cigarette lighter socket. (For only BC-191/BC-193)
• OPC-515L
DC POWER CABLE
Allows charging of the battery packs using a 12 V DC
power source instead of the AC adapter. (For all char-
gers)
• MB-124
BELT CLIP
Exclusive alligator-type belt clip.
• MB-130
VEHICLE CHARGER BRACKET
Vehicle mounting bracket for the BC-191, BC-192 and
BC-193 battery chargers.
• FA-B2E/FA-B2F
VHF ANTENNA
The same antenna that is supplied with IC-V80/IC-V80E.
Antenna length: FA-B2E: Approximately 167 mm; 6.6 in
FA-B2F: Approximately 150 mm; 5.9 in
• FA-B70C
UHF ANTENNA
The same antenna that is supplied with IC-U80/IC-U80E.
+BC-123S
AC ADAPTER
+BC-147S
AC ADAPTER
+BC-123S
AC ADAPTER
• HM-153L
EARPHONE
Ideal for hands-free operation: clip the HM-153L (with
integrated PTT switch) to your lapel or breast pocket.
• HM-158L/HM-159L
Combination speaker-microphone that provides con-
venient operation while hanging the transceiver on
your belt.
• HS-94/HS-95/HS-97
+OPC-2004
PLUG ADAPTER CABLE
HS-94 : Ear hook type
HS-95 : Neck & arm type
HS-97 : Throat microphone
OPC-2004 : Allows you to connect the HS-94/HS-95/
HS-97 to the transceiver. After connect-
ing, the VOX function can be used.
• SP-27
TUBE EARPHONE
Provides clear audio in noisy environments.
• CS-V80/CS-U80
CLONING SOFTWARE
+OPC-478/OPC-478UC
Provides quick and easy programming of such settings
as memory channels and Set modes contents.
• OPC-474
CLONING CABLE
For transceiver-to-transceiver cloning.
Some options may not be available in some countries.
Please ask your dealer for details.
Approved Icom optional equipment is designed for
optimal performance when used with an Icom trans-
ceiver.
Icom is not responsible for the destruction or damage
to an Icom transceiver in the event the Icom trans-
ceiver is used with equipment that is not manufac-
tured or approved by Icom.
48
-
MICROPHONE
-
SPEAKER MICROPHONE
HEADSET
CLONING CABLE
