10
SET MODES
■ Set mode programming (continued)
• VOX gain
• Microphone gain
• VOX delay
• VOX time-out timer
• DTMF TX key
• Passband width
Set the VOX gain.
To turn OFF the VOX function, select "VOX.OF."
Set the microphone sensitivity.
Set the VOX Delay.
Set the VOX time-out timer.
To turn OFF the function, select "Vto.OF."
Select the method to transmit
a DTMF code sequence.
Set the operating mode to FM or FM-N.
:
:
p. 39
p. 39
p. 39
p. 39
p. 39
p. 39
NOTE: When the display type setting is set to "CH" in the Initial
Set mode, and accessing the Set mode from the memory
mode, most of the Set mode items do not appear.
37
