Page 1 SANbox 6142 Intelligent Storage Router User’s Guide FI0054601-00 C...
Page 2: Document Revision History
QLogic Corporation reserves the right to change product specifications at any time without notice. Applications described in this document for any of these products are for illustrative purposes only. QLogic Corporation makes no representation nor warranty that such applications are suitable for the specified use without further testing or modification.
Page 3 Removed reference to SANsurfer application Section 4 installation from a CD; replaced CD installation procedures with steps for downloading software from the QLogic website Corrected information about when the Configura- Section 4 tion Wizard launches automatically Corrected information on LED diagnostics to iden-...
Page 4 SANbox 6142 Intelligent Storage Router User’s Guide Notes Page iv FI0054601-00 C...
Page 5: Table Of Contents
Table of Contents Introduction Intended Audience ..........Related Materials .
Page 6 SANbox 6142 Intelligent Storage Router User’s Guide Heartbeat LED (Green) ........Input Power LED (Green) .
Page 7 SANbox 6142 Intelligent Storage Router User’s Guide Installation Site Requirements ..........Management Workstation .
Page 8 SANbox 6142 Intelligent Storage Router User’s Guide Removal/Replacement SFP Transceiver Removal and Replacement ..... . . Router Removal and Replacement ....... Removal .
Page 9 SANbox 6142 Intelligent Storage Router User’s Guide iSCSI Discovered Targets ........7-38 Information Tabbed Page .
Page 10 SANbox 6142 Intelligent Storage Router User’s Guide Password Command ........A-24 Ping Command .
Page 11 SANbox 6142 Intelligent Storage Router User’s Guide Show Stats Command ........A-76 Show System Command .
Page 12 SANbox 6142 Intelligent Storage Router User’s Guide Configuring CHAP CHAP Definition ..........Configuring CHAP Using CLI .
Page 13 SANbox 6142 Intelligent Storage Router User’s Guide List of Figures Figure Page SANbox 6142 Router ..........Remote SAN Island Connectivity .
Page 14 SANbox 6142 Intelligent Storage Router User’s Guide 7-31 iSCSI Presented Target List Tabbed Page....... . 7-37 7-32 iSCSI Discovered Targets Tabbed Pages .
Page 15 SANbox 6142 Intelligent Storage Router User’s Guide 7-76 Confirm Mapping Dialog Box ......... . 7-79 7-77 Local Password Dialog Box .
Page 16 SANbox 6142 Intelligent Storage Router User’s Guide FCIP—Informational Log Messages ........TOE—Informational Log Messages.
Page 17: Introduction
Introduction This manual describes the features and installation of the QLogic SANbox 6142 Intelligent Storage Router (iSR-6142), also referred to as the SANbox 6142 router or simply router. Intended Audience This guide is for users who are responsible for installing, managing, and servicing the SANbox 6142 router and the storage area network (SAN) equipment to which it is attached.
Page 18: Safety
1 – Introduction Safety SCSI-3 Fibre Channel Protocol (SCSI-FCP), X3.269:1996 Fibre Channel Physical and Signaling Interface (FC-PH), X3.230:199 Fibre Channel 2nd Generation (FC-PH-2), X3.297:1997 Third Generation Fibre Channel Physical and Signaling Interface (FC-PH-3), X3.303:1998, Fibre Channel-Arbitrated Loop (FC-AL-2), working draft, revision 6.4, August 28, 1998 Fibre Channel Fabric Loop Attachment Technical Report (FC-FLA) NCITS/TR-20:1998, Fibre Channel-Private Loop Direct Attach Technical...
Page 19: Federal Communications Commission (Fcc) Class A Statement
1 – Introduction Communications Statements Federal Communications Commission (FCC) Class A Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 20: Ce Statement
1 – Introduction Communications Statements CE Statement The CE symbol on the equipment indicates that this system complies with the EMC (Electromagnetic Compatibility) directive of the European Community (89/336/EEC) and to the Low Voltage (Safety) Directive (73/23/EEC). Such marking indicates that this system meets or exceeds the following technical standards: EN60950-1, A11:2004 –...
Page 21: Vcci Class A Statement
1 – Introduction Laser Safety Information VCCI Class A Statement This is a Class A product based on the standard of the Voluntary Control Council For Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.
Page 22: Accessible Parts
Small form-factor pluggable (SFP) optical transceivers License Agreements Refer to the QLogic Software End User License Agreement for a complete listing of all license agreements affecting this product. General Public License QLogic SANbox routers are powered by the Linux operating system. A machine-readable copy of the Linux source code is available upon written request to the following address.
Page 23: Terms And Conditions For Copying, Distribution And Modification
1 – Introduction General Public License When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new programs, and that you know you can do these things.
Page 24 1 – Introduction General Public License translation is included without limitation in the term "modification".) Each licensee is addressed as "you". Activities other than copying, distribution and modification are not covered by this License – they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if tis contents constitute a work based on the Program (independent of having been made by running the Program).
Page 25 1 – Introduction General Public License Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program.
Page 26 1 – Introduction General Public License You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance.
Page 27 1 – Introduction General Public License This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyright interfaces, the original copyright holder who places the Program under this License may add an explicit geographical distribution limitation excluding those countries, so that distribution is...
Page 28 1 – Introduction General Public License ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Page 29: How To Apply These Terms To Your New Programs
1 – Introduction General Public License How to Apply These Terms to Your New Programs If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it free software which everyone can redistribute and change under these terms.
Page 30: Technical Support
Technical Certification courses include installation, maintenance and troubleshooting QLogic SAN products. Upon demonstrating knowledge using live equipment, QLogic awards a certificate identifying the student as a Certified Professional. The training professionals at QLogic may be reached by email at tech.training@qlogic.com. Contact Information...
Page 31 1 – Introduction Technical Support North American Region Email support@qlogic.com Phone +1-952-932-4040 +1 952-974-4910 Europe, Middle East, and Africa Region Email emeasupport@qlogic.com Phone Numbers by Language +353 1 6924960 - English +353 1 6924961 - Français +353 1 6924962 - Deutsch +353 1 6924963 - Español...
Page 32 1 – Introduction Technical Support 1-16 FI0054601-00 C...
Page 33: General Description
General Description This section describes the following features and capabilities of the SANbox 6142 router: Router Capabilities (see page 2-2) Licensed Features (see page 2-2) Remote SAN Island Connectivity (see page 2-4) Local SAN Island Connectivity (see page 2-6) FCIP - Fibre Channel over IP (see page 2-6)
Page 34: Router Capabilities
2 – General Description Router Capabilities Router Capabilities The SANbox 6142 is a bi-directional FC-to-iSCSI router. It supports the following topologies: Two remote SAN islands (single or multi-vendor fabrics) (see page 2-4) Local connectivity (see page 2-6) FC SAN islands (single or multi-vendor fabrics) iSCSI Servers to FC SAN FC servers to iSCSI SAN FCIP –...
Page 35: Additional Server/Ports
2 – General Description Licensed Features Provides failover and failback between two gigabit ethernet links. Allows data compression. This is very useful when data round-trip latencies between two routers exceed more than 50 ms or long distance link rate is equal or less than 4500 Mbits/sec (DS-3 line rate) SmartWrite is an optional feature which requires the purchase of a license key.
Page 36: Remote San Island Connectivity
2 – General Description Remote SAN Island Connectivity Remote SAN Island Connectivity The SANbox 6142 Intelligent Router supports inter-connecting remote SAN islands (see Figure 2-2). Figure 2-2 Remote SAN Island Connectivity This configuration has the following additional requirements: At least one FC Port of SANbox 6142 connected to FC SAN. Accessibility between the iSCSI/ GE (GE identifies Gigabit Ethernet ports on the router) Port IP addresses of remote router and iSCSI/GE port IP addresses of local routers.
Page 37: Local San Island Connectivity
2 – General Description Remote SAN Island Connectivity To map remote FC devices to local SAN: If the remote router is not already associated with a local router, use either the SANsurfer Add Remote Router wizard (see page 7-68) or the CLI command remotepeer add (see page A-32) to associate the two routers...
Page 38: Local San Island Connectivity
2 – General Description Local SAN Island Connectivity Local SAN Island Connectivity You can use either the SANsurfer Map Local Initiator/Target wizard (see page 7-55) or the CLI localmap add command (see page A-20) to map any of the following connections: iSCSI Server to an FC Device (Target) FC server to an iSCSI Device (Target) FC Server from one SAN to FC target on another SAN...
Page 39: Chassis Leds
2 – General Description Chassis LEDs Chassis LEDs The chassis LEDs shown in Figure 2-4 provide information about the router’s operational status. These LEDs include the input power LED, heartbeat LED, and the system fault LED. To apply power to the router, plug the power cord into the router AC power receptacle and into a 100 VAC to 240 VAC, 50 Hz to 60 Hz power source.
Page 40: Chassis Controls
2 – General Description Chassis Controls Chassis Controls The maintenance button shown in Figure 2-5 is the only chassis control. Pressing this button resets the router or recovers the router if it has become disabled. Figure 2-5 Chassis Controls Maintenance Button The maintenance button is a multifunction momentary switch on the front panel.
Page 41 2 – General Description Chassis Controls Reset and Select Boot Image You can reset the router using either the primary or secondary boot image: Primary Image – To reset the router and select the primary boot image, use a pointed, nonmetallic tool to press and hold the maintenance button until the heartbeat LED flashes once, then release the button.
Page 42: Fibre Channel Ports
2 – General Description Fibre Channel Ports Erases all presentations. Erases all discovered initiators and targets. Fibre Channel Ports The SANbox 6142 router has two Fibre Channel ports, labeled FC1 and FC2, as shown in page 2-10. Figure 2-6 Fibre Channel LEDs Each port is served by a small form-factor pluggable (SFP) optical transceiver and is capable of 1-Gbps or 2-Gbps transmission.
Page 43: Fibre Channel Sfp Transceivers
2 – General Description Fibre Channel SFP Transceivers Table 2-2. Port LEDs Activity Amber LED Green LED Yellow LED Online 3 seconds ON Flashes OFF once Link established at 1Gbit Activity at 1 Gbps 3 seconds ON Flashes OFF once Online 3 seconds ON Flashes OFF twice...
Page 44: Iscsi/Gigabit Ethernet Port Leds
2 – General Description iSCSI/Gigabit Ethernet Port LEDs iSCSI/Gigabit Ethernet Port LEDs The iSCSI/gigabit Ethernet ports shown in Figure 2-7 are RJ-45 connectors that provide connection to an Ethernet SAN through a 10/100/1000 Base-T Ethernet cable. The ports are labeled GE1 and GE2. These ports have two LEDs –...
Page 45: Serial Port
2 – General Description Serial Port Serial Port The SANbox 6142 router is equipped with an RS-232 serial port for maintenance purposes. Figure 2-9 shows the serial port location. It is labeled IOIOI. You can manage the router through the serial port using the CLI. Figure 2-9 Serial Port The serial port connection requires a standard, eight-wire Ethernet cable and the RJ45-to-DB9F adapter (supplied) to convert the Ethernet RJ45 connector to a...
Page 46 2 – General Description Serial Port Table 2-4. RJ-45 to DB-9 Adapter Pin Identification RJ-45 DB-9F DB-9 DB-9 Pin Number Pin Definition Pin Number Pin Definition Transmit data (TxD) Signal ground (GND) Receive data (RxD) Data carrier detect (DCD) Data set ready (DSR) Clear to send (CTS) Ring indicator (RI) 2-14...
Page 47: Planning
Planning This section describes how to plan for using the SANbox 6142 router. This includes the following considerations: Devices (see page 3-1) Device Access (see page 3-2) FC Performance (see page 3-2) iSCSI/Gigabit Ethernet Performance (see page 3-3) Performance Tuning (see page 3-3)
Page 48: Device Access
3 – Planning Device Access Device Access Consider device access needs within the FC and iSCSI SANs. Access to an FC device is controlled by mapping FC device to specific iSCSI initiators. FC devices may be mapped to more than one initiator. Giving multiple initiators access to an FC device requires access management.
Page 49: Bandwidth
3 – Planning iSCSI/Gigabit Ethernet Performance Bandwidth Bandwidth measures the amount of data transmitted over a channel or network. A 1-Gbps/2-Gbps FC port can transmit or receive at nominal rates of 1- or 2-Gbps, depending on the device to which it is connected. This corresponds to actual bandwidth values of 106 MB and 212 MB, respectively.
Page 50 3 – Planning Performance Tuning Table 3-1. T1 / DS-1 – 1.554 Mbits/Sec Round Trip delay Total Window Size Scaling Factor (ms) (bytes) 32 K 32 K 32 K 32 K 32 K 32 K 1 or less 32 K Table 3-2.
Page 51 3 – Planning Performance Tuning Table 3-3. DS-5 – 400 Mbits/Sec (Continued) Round Trip Delay Total Window Size Scaling Factor (ms) (bytes) 1 MB 1 MB 1 MB 1 MB 512 K 256 K 128 K 1 or less 64 K Table 3-4.
Page 52 3 – Planning Performance Tuning Table 3-5. OC-3 – 150 Mbits/Sec Round Trip Delay Total Window Size Scaling Factor (ms) (bytes) 1 MB 1 MB 1 MB 512 K 512 K 256 K 256 K 128 K 64 K 32 K 1 or less Table 3-6.
Page 53: Topology
3 – Planning Topology Topology The SANbox 6142 supports two distinct topologies: interconnecting local SANs (see Figure 3-1) and interconnecting remote SANs (see Figure 3-2). Figure 3-1 LAN Topology - Local SAN Interconnect Figure 3-2 WAN Topology - Remote SAN Interconnect FI0054601-00 C...
Page 54: Fibre Channel Switch Ports And Zoning Requirements
3 – Planning Fibre Channel Switch Ports and Zoning Requirements Fibre Channel Switch Ports and Zoning Requirements The SANbox 6142 FC ports are configured as loop ports. Therefore, the FC switch port, (where SANbox 6142 FC port is connected) must be configured to support a loop topology such as fibre loop port (FL-Port) or generic port (G-Port).
Page 55: Services
3 – Planning Services Save the router’s configuration (as a new file) after every configuration change, because you may: Want to revert to a previous configuration Need to configure a replacement router Save the router’s mappings (as a new file) after every mapping change, because you may: Want to revert to a previous mapping Need to map a replacement router...
Page 56 3 – Planning Security Notes 3-10 FI0054601-00 C...
Page 57: Site Requirements
Installation This section describes how to install and configure a SANbox 6142 router. It also includes firmware installation instructions. This includes the following topics: Site Requirements (this page) SANbox 6142 Router Installation (see page 4-2) Firmware Installation (see page 4-11) Site Requirements The requirements in the following sections must be met when installing a SANbox 6142 router:...
Page 58: Power Requirements
4 – Installation SANbox 6142 Router Installation Table 4-1. Management Workstation Requirements Item Description Processor 500 MHz or faster Hardware CD-ROM drive, RJ-45 Ethernet port, RS-232 serial port (optional) Internet browser One of the following: Microsoft Internet Explorer 5.0 and later Netscape Navigator®...
Page 59: Sanbox 6142 Router And Accessories
4 – Installation SANbox 6142 Router Installation Figure 4-1 SANbox 6142 Router and Accessories To install the SANbox 6142 router: Complete the pre-installation checklist (see page 4-4). Mount the router (see page 4-4). Install the transceivers (see page 4-5). Connect the management workstation to the router (see page 4-5).
Page 60: Pre-Installation Check List
You can place the router on a flat surface or mount it in a standard 19-inch Electronic Industries Association (EIA) rack. See the product specification for weight and dimensions. Rack mounting requires a QLogic rack mounting kit (Part No. ISR614X-RACKKIT). Contact QLogic for more information.
Page 61: Install The Transceivers
4 – Installation SANbox 6142 Router Installation Install the Transceivers The router supports a variety of SFP transceivers. To install a transceiver, insert the transceiver into the port and gently press until it snaps in place. To remove a transceiver, gently press the transceiver into the port to release tension, then pull the release tab or lever and remove the transceiver.
Page 62: Setting The Workstation Ip Address
4 – Installation SANbox 6142 Router Installation Setting the Workstation IP Address The IP address of a new router is 10.0.0.1. To ensure that your workstation is configured to communicate with the 10.0.0 subnet, refer to the following instructions for your workstation: Steps for different versions of Windows vary.
Page 63: Install Sansurfer Iscsi/Fc Router Manager
SANsurfer iSCSI/FC Router Manager. Windows Installation Perform the following steps to install the SANsurfer iSCSI/FC Router Manager application from the QLogic website to a PC workstation: Close all programs currently running. Go to the QLogic download site: http://support.qlogic.com/support/drivers_software.aspx Select the Intelligent Storage Routers icon.
Page 64: Linux Installation
4 – Installation SANbox 6142 Router Installation Linux Installation Perform the following steps to install the SANsurfer iSCSI/FC Router Manager application from the QLogic website to a Linux workstation: Go to the QLogic download site: http://support.qlogic.com/support/drivers_software.aspx Select the Intelligent Storage Routers icon.
Page 65: Connect The Router To Ac Power
4 – Installation SANbox 6142 Router Installation Connect the Router to AC Power WARNING!! This product is supplied with a 3-wire power cable and plug for the user’s safety. Use this power cable in conjunction with a properly grounded outlet to avoid electrical shock.
Page 66: Configure The Router
4 – Installation SANbox 6142 Router Installation Configure the Router You can configure the router using the SANsurfer iSCSI/FC Router Manager application or the command line interface (CLI). The SANsurfer Router Manager provides a Configuration Wizard you can use to configure the GE ports.
Page 67: Cable Devices To The Router
Installing new firmware disrupts the router connectivity since you must reboot the router to activate the new firmware. he reboot may result in the transfer of incorrect data between devices connected to the router. QLogic recommends that you suspend activity on the interfaces before activating the new firmware.
Page 68: Using The Cli To Install Firmware
Type quit. The firmware image has been transferred to the router. Log on to the router as an administrator. (none) login – guest Password – password ****************************************************** QLogic Router Command Line Interface (QRCLI) * ****************************************************** QRouter#> admin start Password – config QRouter (admin) #>...
Page 69 4 – Installation Firmware Installation Type the following command from the router, where x stands for the firmware image name: image unpack isr-6142-2_2_0_x.bin The following message displays: Unpack Completed. Please reboot the system for FW to take affect. Type reboot. The following message displays: Are you sure you want to reboot the System (y/n): Type y to reboot the system.
Page 70 4 – Installation Firmware Installation Notes 4-14 FI0054601-00 C...
Page 71: Diagnostics And Troubleshooting
Diagnostics and Troubleshooting Diagnostic information about the router is available through the chassis LEDs and the port LEDs. Diagnostic information is also available through the SANsurfer iSCSI/FC Router Manager and CLI event logs and error displays. This section provides the following diagnostic information: Chassis Diagnostics (this page) Power-On Self-Test Diagnostics...
Page 72: Input Power Led Is Off
5 – Diagnostics and Troubleshooting Power-On Self-Test Diagnostics Input Power LED is Off The input power LED lights up to show that the router logic circuitry is receiving proper voltages. If the input power LED is off, do the following: Inspect power cord and connectors.
Page 73: Led Blink Patterns
5 – Diagnostics and Troubleshooting LED Blink Patterns LED Blink Patterns Heartbeat and System Fault LEDs show the operational status of the router. When the POST completes with no errors, the heartbeat LED will blink once every second. When the router is in maintenance mode, the Heartbeat and System Fault LEDs are on continuously.
Page 74: Management Port Ip Address Conflict Blink Pattern
5 – Diagnostics and Troubleshooting LED Blink Patterns Management Port IP Address Conflict Blink Pattern The System Fault LED generates a four-blink pattern (once per second) followed by a two second pause when the router detects an IP address conflict on the management Ethernet port.
Page 75: Recovering A Router
5 – Diagnostics and Troubleshooting Recovering a Router Recovering a Router You may have to recover a router for one of the following reasons: The password was changed and has been forgotten. The router’s management IP address is unknown. To recover the router’s password, reset the password to the default by using the maintenance button (see page 2-8).
Page 76 5 – Diagnostics and Troubleshooting Recovering a Router Notes FI0054601-00 C...
Page 77: Removal/Replacement
Removal/Replacement This section describes the removal and replacement procedures for the following field replaceable units (FRU): SFP transceivers The router (see page 6-2) SFP Transceiver Removal and Replacement You can remove and replace the SFP transceivers while the router is operating without damaging the router or the transceiver.
Page 78: Router Removal And Replacement
6 – Removal/Replacement Router Removal and Replacement Router Removal and Replacement Before you can remove and replace the router, you must turn off the power to the router and disconnect its power cable. The router will lose all the Fibre Channel and iSCSI connections.
Page 79: Introduction
SANsurfer iSCSI/FC Router Manager Introduction The SANbox 6142 management application is a graphical user interface consisting of menus, buttons, and windows that you can use to manage SANbox 6142s from a workstation on Linux® and Windows® platforms. You can view and change network, port, security, and mapping configuration for one or more SANbox 6142s.
Page 80: Sansurfer Iscsi/Fc Router Manager Introduction
7 – SANsurfer iSCSI/FC Router Manager Introduction Figure 7-1 SANsurfer Router Manager Main Window Table 7-1. SANsurfer Router Manager Main Window Sections Item Description Menu Bar The menu bar provides access to system func- tions and Wizards. Tool Bar The tool bar buttons provide quick access to the common application functions: Connect, View Logs, and Refresh.
Page 81: Menu Bar
7 – SANsurfer iSCSI/FC Router Manager Menu Bar Table 7-1. SANsurfer Router Manager Main Window Sections Item Description System Tree Located on the on the left side of the display, the system tree shows the connected systems and their components. An entry handle located to the left of an entry in the tree shows that you can expand that entry.
Page 82: File Menu
7 – SANsurfer iSCSI/FC Router Manager Menu Bar File Menu Figure 7-3 shows the File menu. The following paragraphs describe it. Figure 7-3 File Menu Save FRU – Saves the router’s configuration and persistent data to a file. Restore FRU – Restores the router’s configuration and persistent data from a file.
Page 83: Wizards Menu
7 – SANsurfer iSCSI/FC Router Manager Menu Bar Figure 7-6 Broadcast Settings Menu Enable Broadcast – Enables broadcast messages sent to locate routers in the IP subnet. Enable Auto Connect – Enables the SANsurfer Router Manager to automatically connect with routers discovered by the broadcast. Broadcast Interval –...
Page 84 7 – SANsurfer iSCSI/FC Router Manager Menu Bar Map Local Initiator/Target Wizard – Launches the Map Local wizard, which allows you to map a local initiator to a local target (see page 7-55). Unmap Local Initiator/Target Wizard – Launches the Unmap Local wizard, which allows you to delete a local initiator from a local target mapping (see page 7-63).
Page 85: Help Menu
7 – SANsurfer iSCSI/FC Router Manager Tool Bar Help Menu Figure 7-8 shows the Help menu. The following paragraphs describe it. Figure 7-8 Help Menu Set Browser Location – Allows you to specify the browser that launches when you view the online help for the SANsurfer iSCSI/FC Router Manager. Browse Contents –...
Page 86: Action Menu
7 – SANsurfer iSCSI/FC Router Manager Tool Bar Action Menu The action menu provides short cuts to actions and wizards available elsewhere in the SANsurfer iSCSI/FC Router Manager. To open this menu, right-click anywhere within the router’s node in the system tree window. Figure 7-10 illustrates the action menu and the following paragraphs describe each available option.
Page 87 7 – SANsurfer iSCSI/FC Router Manager Tool Bar Add Remote Router Wizard – Launches the Add Remote Router Wizard, which allows you to assign local router to a remote router as peers (see page 7-68). Remove Remote Router Wizard – Launches the Remove Remote Router Wizard, which allows you to remove a local-to-remote router peer assignment (see...
Page 88: System Tree Window
7 – SANsurfer iSCSI/FC Router Manager System Tree Window System Tree Window Figure 7-11 shows the system tree window. The following sections described it. Figure 7-11 System Tree Window The left most window pane shows the system tree. The system tree includes the connected SANbox 6142 routers and the following components for each router: FC Ports (see...
Page 89: Component Information
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Figure 7-12 Component Information Component information displayed for a selected router includes router information, configuration details, router status, and lists of connected or discovered devices. FI0054601-00 C 7-11...
Page 90: Sanbox 6142 Router
7 – SANsurfer iSCSI/FC Router Manager System Tree Window SANbox 6142 Router The top of the router tree displays the router system configuration and status. It contains the following tabs: Information Tab (see page 7-12) SNMP Management Tab (see page 7-17) Features Tab (see...
Page 91: Management Information Vertical Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Hardware Version – Identifies the router hardware version number. Software Version – Identifies the version of firmware loaded on the router. iSCSI Port Count – Identifies the number of iSCSI ports (2). Fibre Channel Port Count –...
Page 92 7 – SANsurfer iSCSI/FC Router Manager System Tree Window IPv4 Management Info – Select this check box to use IPv4 (Internet Protocol version 4, 32-bit addressing), then use the radio buttons to identify whether to use either a dynamic or static IP address. IP Address –...
Page 93: Ntp Server Information Vertical Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window IPv6 Default Router – Use this address to set the default router for the IPv6. The system can also set the IPv6 default router dynamically depending on your network configuration. IPv6 Local Link – This field contains the IPv6 link local address of the port.
Page 94: Security Vertical Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window NTP Server 2 – Displays the IP address of the second NTP server to be queried by the router when setting its time and date. This server is used only if the first NTP server did not respond. NTP Server 3 –...
Page 95: Snmp Management Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window SNMP Management Tab The SNMP Management tabbed page consists of two sections: SNMP Configuration and SNMP Trap Receivers. The Save button saves any SNMP management changes. For more information, see Appendix Figure 7-17 shows the SNMP Management tabbed page.
Page 96 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Read Community – Enter a password that authorizes an SNMP management server to read information from the router. This is a write-only field. The value on the router and the SNMP management server must be the same.
Page 97: Features Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Features Tab Figure 7-18 shows the Features tabbed page that displays the routers licensed features and lets you apply additional license features. The following paragraphs described the page. Figure 7-18 Features Tabbed Page License Information –...
Page 98: Topology Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Topology Tab Figure 7-19 shows the Topology tabbed page that displays the routers, as shown in the following example. Figure 7-19 Topology Tabbed Page FC Ports When you select an FC port in the system tree, the system displays the FC Port Information tabbed page (see Figure 7-20).
Page 99: Fc Port Information Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window FC Port Information Tab The FC Port Information tab provides the following parameters: Node Name – Displays the world-wide node name (WWNN) assigned to the FC port. Port Name – Displays the world-wide port name (WWPN) assigned to the FC port.
Page 100: Fc Port Performance Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Frame Size – Displays a drop-down list that lets you set the frame size: 2048, 1024, or 512 bytes. The default is 2048. If you change this setting, you must click Save (at the bottom of the page) for the change to take effect. Execution Throttle –...
Page 101: Iscsi Ports
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Target Write – Shows the target’s write performance through the selected FC port. iSCSI Ports When you select an iSCSI port in the system tree, the window displays the Information, Advanced Configuration, and Statistics tabbed pages to the right of the tree (see Figure 7-23).
Page 102: Information Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Information Tab The Information tabbed page consists of three areas: Port Information, iSCSI Port Network Settings, and iSNS. The following paragraphs describe the information displayed in these sections. iSCSI Port Information The iSCSI Port Information area provides the following parameters: Base Name –...
Page 103: Iscsi Port Network Settings
7 – SANsurfer iSCSI/FC Router Manager System Tree Window iSCSI Port Network Settings Port Status – When the port link is up, you can enable or disable the port using this drop-down list. IPv4 Address – When using an IPv4 address scheme, define the following fields: IP Address –...
Page 104 7 – SANsurfer iSCSI/FC Router Manager System Tree Window VLAN ID IPv6 – When VLAN IPv6 is enabled the VLAN ID IPv6 contains an identification value in the range 0 to 4094. You can configure VLAN from this window. Priority IPv6 – When VLAN IPv6 is enabled, this field defines the priority assigned to this VLAN IPv6.
Page 105: Advanced Configuration Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Advanced Configuration Tab The Advanced Configuration tabbed page allows you to configure the router’s port parameters, security settings, and CHAP settings. The information displayed in these sections is illustrated in Figure 7-24 and described in the following paragraphs.
Page 106 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Target TCP Port Number – Identifies the TCP port number the router uses to receive iSCSI target commands. The iSCSI community uses TCP port number 3260 by default any change to this TCP port number requires a corresponding change in all iSCSI initiators connecting to this iSCSI target port.
Page 107 7 – SANsurfer iSCSI/FC Router Manager System Tree Window CHAP Settings Enable CHAP – Enables or disables CHAP (Challenge Handshake Authentication Protocol) support. Select the check box to enable this option; clear the check box to disable it. When you change this setting, you must click Save (at the bottom of the page) for the change to take effect.
Page 108: Statistics Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Statistics Tab The Statistics tabbed page consists of a scrollable table of parameters and values. The table is divided into two sections: the first section contains statistics that are port specific, and the second section contains shared statistics (common to both iSCSI ports).
Page 109: Discovered Iscsi Initiators
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Discovered iSCSI Initiators Selecting the Discovered iSCSI Initiators branch on the system tree does not provide any information in the right window. Select a discovered iSCSI initiator in the system tree to display the Information and LUN List tabbed pages to the right of the system tree, which are shown in Figure 7-26 and described in the following...
Page 110: Local Presented Target Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window The CHAP Settings section provides the following parameters: Enable CHAP – Enables or disables CHAP (Challenge Handshake Authentication Protocol) support. Select the check box to enable this option; clear the check box to disable it. CHAP Secret –...
Page 111: Remote Presented Target Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Port – Displays information provided by the target LUN as a result of issuing a SCSI Inquiry command. Protocol – Identifies the target name. For FC targets, the name is the WWPN.
Page 112: Fc Discovered Targets
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Status – Displays information provided by the target LUN in response to the router issuing a SCSI Inquiry command. WWPN – Displays information provided by the target LUN in response to the router issuing a SCSI Inquiry command.
Page 113: Information Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Information Tab The Information tabbed page provides the following information about the selected FC target: Product Vendor – Displays the product vendor as reported by the SCSI Inquiry command. Product ID – Displays the product ID as reported by the SCSI Inquiry command.
Page 114: Iscsi Presented Target List Tabbed Page
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Port Name – Displays the world-wide port name of the target device. Port ID – Displays the target device’s port ID. Target Type – Displays the FC port where the target device was discovered.
Page 115 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Figure 7-31 iSCSI Presented Target List Tabbed Page Device Product Vendor – Displays the vendor name of the target device as reported by the SCSI Inquiry command. Device Product ID – Displays the product ID name of the target device as reported by the SCSI Inquiry command.
Page 116: Iscsi Discovered Targets
7 – SANsurfer iSCSI/FC Router Manager System Tree Window iSCSI Discovered Targets The iSCSI Discovered Targets branch on the system tree does not provide any information in the right window. Select a discovered target to display the Information tabbed page to the right of the system tree (see Figure 7-32).
Page 117: Fcip Routes
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Target Path – Displays the router’s iSCSI port where the target was discovered. CHAP Settings – Provides an option you can use to set the challenge handshake authentication protocol (CHAP) option as follows: Enable CHAP –...
Page 118: Fcip Route Information Tabbed Page
7 – SANsurfer iSCSI/FC Router Manager System Tree Window FCIP Route Information Tabbed Page The FCIP Route Information tabbed page contains the information that defines the selected FCIP route, as described in the following paragraphs. FCIP Interface Status – Provides a drop-down box you can use to enable or disable the FCIP route.
Page 119 7 – SANsurfer iSCSI/FC Router Manager System Tree Window GigE Port Flow Control – When the GigE Link Rate is set to something other than auto, use this drop-down box to enable or disable GigE port flow control. The default is enabled. VLAN Enabled –...
Page 120: Fcip Route Statistics Tabbed Page
7 – SANsurfer iSCSI/FC Router Manager System Tree Window FCIP Route Statistics Tabbed Page The Statistics tabbed page consists of a scrollable table of parameters and values. Figure 7-34 FCIP Route Statistics Page You can refresh the statistics are by clicking Refresh at the top of the scrollable window.
Page 121: Wizards
7 – SANsurfer iSCSI/FC Router Manager Wizards Wizards The SANsurfer iSCSI/FC Router Manager provides easy-to-use wizards that walk you through various router configuration procedures. You can launch an available wizard using any of the following methods: Select an option from the Wizards menu, located on the Router Manager’s menu bar (see page 7-5.)
Page 122: Configuration Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards Configuration Wizard The Configuration Wizard provides a set of dialog boxes that walk you through the steps required for configuring the iSCSI ports. This wizard starts automatically when your system connects to a system with any un-configured iSCSI ports. You can also start this wizard at any time by selecting Configuration Wizard from the Wizards menu or from the Action Menu.
Page 123: Iscsi Port Connection Settings Panel Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-36 iSCSI Port Connection Settings Panel Dialog Box To configure the iSCSI Port IPV4 settings: Type the information in the following fields. IP Address Subnet Mask Gateway If desired, configure the IP address of the iSNS server with which the router registers the selected iSCSI port: Select the Enable iSNS check box to make the Server IP address field editable.
Page 124: Iscsi Port Ipv6 Settings Panel
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-37 iSCSI Port IPv6 Settings Panel To configure the iSCSI port IPv6 connection using this dialog box, follow these steps: Select Enable IPv6 Address to make the fields editable. Specify the iSCSI port IPv6 network settings: Enter the IPv6 Address 0.
Page 125: Confirm Changes Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-38 Confirm Changes Dialog Box Review the configuration changes displayed on the screen, then click Next to confirm your changes. FI0054601-00 C 7-47...
Page 126: Iscsi Port Configuration Status
7 – SANsurfer iSCSI/FC Router Manager Wizards The system displays the iSCSI Port Configuration Status dialog box, as shown in Figure 7-39. Figure 7-39 iSCSI Port Configuration Status Read the information about the status changes, then click Next. The system displays the Refresh dialog box. Read the information.
Page 127: Add Initiator Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-40 Configuration Wizard Finish Dialog Box Read the information, then click Finish. Add Initiator Wizard The Add Initiator Wizard provides a dialog box used to enter an iSCSI initiator into the system database. iSCSI initiators are normally discovered (their name and address are captured) the first time they log in to the SANbox 6142 router.
Page 128: Create An Initiator Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-41 Create an Initiator Dialog Box To create an initiator: Type a name in the Initiator name box. Type an alias in the Initiator alias (iSCSI) box. If you want to enable CHAP for this initiator, select the CHAP Enabled check box.
Page 129: Fw Update Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards The new iSCSI initiator is displayed in the discovered iSCSI initiator’s section of the system tree, as shown in Figure 7-43. Figure 7-43 System Tree with New iSCSI Initiator FW Update Wizard The FW Update Wizard provides a set of dialog boxes that walk you through the steps required for updating the SANbox 6142 firmware.
Page 130: Firmware File Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards To update the firmware, follow these steps: Select the check box next to the routers whose firmware you want to update, then click Next. The Open dialog box displays. Figure 7-45 Firmware File Selection Dialog Box Enter in the path to the firmware file, or click Browse to locate the firmware file.
Page 131: Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Confirm Changes dialog box displays, as shown in Figure 7-46. Figure 7-46 Confirm Changes Dialog Box Read the information, then do the following: If you want to save a copy of this firmware configuration, click Save Configuration to File.
Page 132: Firmware Update Status Dialog Box—Progress
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-48 Firmware Update Status Dialog Box—Progress When the firmware has loaded successfully, the system displays the Finish dialog box, along with the Update success dialog box, as shown in Figure 7-49. Figure 7-49 Finish Dialog Box (Successful Firmware Update) 7-54 FI0054601-00 C...
Page 133: Map Local Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards NOTE: The new firmware will not take effect until the system is rebooted. Complete the wizard: If you want to reboot the system now, click Yes. Otherwise, click No. Click Finish. Map Local Initiator/Target Wizard The Map Local Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for mapping a local initiator to a local target.
Page 134: Select A Target Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Select a Target dialog box opens, as shown in Figure 7-51. Figure 7-51 Select a Target Dialog Box Select a target you want mapped to the previously selected initiator, then click Next. 7-56 FI0054601-00 C...
Page 135: Select Initiator Port Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The wizard screen prompts you to select a port on which the initiator will be presented, as shown in Figure 7-52. Figure 7-52 Select Initiator Port Dialog Box Select the port (FC Port 1 or FC Port 2), then click Next. FI0054601-00 C 7-57...
Page 136: Select Target Presentation Port Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The wizard screen prompts you to select a port on which the target will be presents (iSCSI Port 1 and iSCSI Port 2), as shown in Figure 7-53. Figure 7-53 Select Target Presentation Port Dialog Box 7-58 FI0054601-00 C...
Page 137: Confirm Changes Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Confirm Changes dialog box displays the local mapping done in the previous steps, as shown in Figure 7-54. Figure 7-54 Confirm Changes Dialog Box Review the information, then click Next. FI0054601-00 C 7-59...
Page 138: Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Security Check dialog box requests the Admin password, as shown in Figure 7-55. Figure 7-55 Security Check Dialog Box Type the appropriate password, then click OK to confirm the local mapping. 7-60 FI0054601-00 C...
Page 139: Initiator/Target Mapping Configuration Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Initiator/Target Mapping Configuration Status dialog box displays local mapping completion status, as shown in Figure 7-56. Figure 7-56 Initiator/Target Mapping Configuration Status Dialog Box After reviewing the initiator to target mapping configuration status, click Next.
Page 140: Discovered Iscsi Initiators - Local Presented Targets
7 – SANsurfer iSCSI/FC Router Manager Wizards After completing the Map Local Initiator/Target wizard, you can see the mapping by selecting the mapped Initiator in the system tree under Discovered iSCSI Initiators. Click the Local Presented Devices tab, as shown in Figure 7-57.
Page 141: Unmap Local Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards Unmap Local Initiator/Target Wizard The Unmap Local Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for removing a local initiator from a local target mapping. You can start this wizard at any time by selecting Unmap Local Initiator/Target Wizard from the Wizards Menu or from the Action Menu.
Page 142: Presented Target Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Presented Target Selection dialog box displays a list of targets mapped to the initiator selected in the previous step, as shown in Figure 7-59. Figure 7-59 Presented Target Selection Dialog Box Select the check box next to the target to unmap, then click Next. 7-64 FI0054601-00 C...
Page 143: Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Security Check dialog box requests the Admin password, as shown in Figure 7-60. Figure 7-60 Security Check Dialog Box Type the appropriate password, then click OK to confirm the target is unmapped. FI0054601-00 C 7-65...
Page 144: Unpresent Initiator/Target Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Unpresent Initiator/Target Status dialog box displays the results of the unmap operation, as shown in Figure 7-61. Figure 7-61 Unpresent Initiator/Target Status Dialog Box Review the status, then click Next. 7-66 FI0054601-00 C...
Page 145: Discovered Iscsi Initiators - Local Presented Targets
7 – SANsurfer iSCSI/FC Router Manager Wizards After completing the UnMap Local Initiator/Target wizard you can verify the unmapping by selecting the Initiator in the system tree under Discovered iSCSI Initiators. Then select Local Presented Devices. For the example shown in Figure 7-62, an iSCSI initiator was unmapped from an FC target.
Page 146: Add Remote Router Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards Add Remote Router Wizard The Add Remote Router Wizard provides a set of dialog boxes that walk you through the steps required for assigning a remote router to your local router as a peer.
Page 147: Local Router Admin Password Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Status dialog box displays the remote router information along with the Local Router Admin Password dialog box, as shown in Figure 7-64. Figure 7-64 Local Router Admin Password Dialog Box Type the local router admin password (default=config), then click OK. The Status dialog box displays the remote router information, as shown in Figure 7-65.
Page 148: Assigned Remote Router Display
7 – SANsurfer iSCSI/FC Router Manager Wizards Review the status, then click Finish. Click the Refresh icon to refresh the display. Select the router node, then select the Assigned Remote Router:1 tab to display the remote router’s information, as shown in Figure 7-66.
Page 149: Topology Display
7 – SANsurfer iSCSI/FC Router Manager Wizards Click the Topology tab to display the local and remote router topology including devices attached to both routers, as shown in Figure 7-67. Figure 7-67 Topology Display FI0054601-00 C 7-71...
Page 150: Remove Remote Router Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards Remove Remote Router Wizard The Remove Remote Router Wizard provides a set of dialog boxes that walk you through the steps required for removing a remote router from the local router. You can start this wizard at any time by selecting Remove Remote Router Wizard from the Wizards Menu or from the Action Menu.
Page 151: Refresh Screen
7 – SANsurfer iSCSI/FC Router Manager Wizards The Local Router Admin Password dialog box requests the local router’s admin password to complete the unmap, as shown in Figure 7-69. Figure 7-69 Local Router Admin Password Dialog Box Type the local router’s admin password (default=config), then click OK. The system prompts you to refresh the display, as shown in Figure 7-70.
Page 152: Remove Remote Router Completion Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Remove Remote Router Completion dialog box displays the completion status, as shown in Figure 7-71. Figure 7-71 Remove Remote Router Completion Dialog Box Click OK to close the message box. 7-74 FI0054601-00 C...
Page 153: Map Remote Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards Map Remote Initiator/Target Wizard The Map Remote Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for mapping an initiator to a target one of which is remote and the other local.
Page 154: Device Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Device Selection dialog box displays list of devices, as shown in Figure 7-73. Figure 7-73 Device Selection Dialog Box If necessary, expand the router tree to see the attached devices. Select the device to be mapped.
Page 155: Port Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The port selection dialog box prompts you to select a port the system will use to connect to the device, as shown in Figure 7-74. Figure 7-74 Port Selection Dialog Box Select the port the system will use to connect to the device, then click Next. FI0054601-00 C 7-77...
Page 156: Device Mapping Option Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Device Mapping Option dialog box displays SmartWrite mapping options, as shown in Figure 7-75. Figure 7-75 Device Mapping Option Dialog Box If your router includes the SmartWrite feature, Enable or Disable the options as you want.
Page 157: Confirm Mapping Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Confirm Mapping dialog box displays the mapping and option selections, as shown in Figure 7-76. Figure 7-76 Confirm Mapping Dialog Box Review the information and, if correct, click Next. The Local Router Admin Password dialog box displays, as shown in Figure 7-77.
Page 158: Local Router Admin Password Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Remote Mapping Status screen displays a list of newly mapped devices, as shown in Figure 7-78. Figure 7-78 Local Router Admin Password Dialog Box Review the status information, then click Finish. The system prompts you to refresh the display, as shown in Figure 7-79.
Page 159: Unmap Remote Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards View the mapped devices in the router’s tree window. Figure 7-80 shows the mapping created in the sample procedures. Figure 7-80 Remote Mapped Device Unmap Remote Initiator/Target Wizard The Unmap Remote Initiator/Target Wizard provides a set of dialog boxes that walk you through the steps required for removing an initiator-to-target mapping.
Page 160: Device Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-81 Device Selection Dialog Box To unmap an initiator and target: Select the device to be unmapped, then click Next. 7-82 FI0054601-00 C...
Page 161: Remote Unmap Initiator-Target Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Local Router’s Admin Password dialog box requests the local router’s admin password to continue with the unmap, as shown in Figure 7-82. Figure 7-82 Local Router Admin Password Dialog Box Type the local router’s admin password (default=config), then click OK. The Remote Unmap Initiator-Target Status dialog box displays the status of the unmap operation, as shown in Figure...
Page 162: Discover Iscsi Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards Discover iSCSI Target Wizard The Discover iSCSI Target Wizard provides a set of dialog boxes that walk you through the steps required for discovering an iSCSI target. You can start this wizard at any time by selecting Discover iSCSI Target from the Wizards Menu or from the Action Menu.
Page 163: Discover Iscsi Target Wizard-Refresh Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Type the appropriate password, then click OK to confirm the discovery of the iSCSI target. If the wizard detected iSCSI targets, the Refresh dialog box signifies the discovery of the iSCSI target, as shown in Figure 7-86.
Page 164: Fcip Route Add Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards FCIP Route Add Wizard The FCIP Route Add Wizard provides a set of dialog boxes that walk you through the steps required for adding an FCIP route. You can start this wizard at any time by selecting FCIP Route Add from the Wizards Menu or from the Action Menu.
Page 165: Fcip Route Add Wizard-Port Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The FC and GigE Port Selection dialog box prompts you to select an FC-GigE port pair, as shown in Figure 7-89. Figure 7-89 FCIP Route Add Wizard—Port Selection Dialog Box Select the FC-GigE Port pair. The corresponding parameter options become available.
Page 166: Fcip Route Add Wizard-Local And Remote Ip Address Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Local and Remote IP Address dialog box requests entry of IP addresses (see Figure 7-90). Figure 7-90 FCIP Route Add Wizard—Local and Remote IP Address Dialog Box Configure any of the following parameters: Local IP Address –...
Page 167: Fcip Route Add Wizard-Tcp/Ip Options Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The TCP/IP Options dialog box requests entry of TCP/IP parameters, as shown in Figure 7-91. Figure 7-91 FCIP Route Add Wizard—TCP/IP Options Dialog Box Configure any of the following parameters: Jumbo Frames – Provides a drop-down box you can use to enable or disable Jumbo IP frames.
Page 168: Fcip Route Add Wizard-Fcip Options Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards VLAN Priority – Provides a drop-down box that contains eight options for the VLAN priority: any number between 0–7. This dialog box is available only when VLAN is enabled. After setting the TCP/IP parameters, click Next to continue or click Cancel to quit the wizard.
Page 169: Fcip Route Add Wizard-Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards used by the FCIP route so as to not consume all the available link bandwidth. For example, if the slowest link in the WAN being used is a DS-3 link, the maximum available bandwidth is 45 megabits per second.
Page 170: Fcip Route Remove Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards FCIP Route Remove Wizard The FCIP Route Remove Wizard provides a set of dialog boxes that walk you through the steps required for removing an FCIP route. You can start this wizard at any time by selecting FCIP Route Remove from the Wizards Menu or from the Action Menu.
Page 171: Fcip Route Remove Wizard-Route Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The FCIP Remove dialog box displays a list of existing FCIP routes, as shown in Figure 7-96. Figure 7-96 FCIP Route Remove Wizard—Route Selection Dialog Box Select the FCIP route you want to remove, then click Finish. The Security Check dialog box requests the administrator password, as shown in Figure...
Page 172: Fcip Route Remove Wizard-Completed Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards The Add FCIP Route Complete dialog box lets you know when the configuration is complete, as shown in Figure 7-98. Figure 7-98 FCIP Route Remove Wizard—Completed Dialog Box NOTE: This dialog box may take a few seconds before appearing. Click OK to exit the dialog box.
Page 173: Command Reference
Command Reference The command line interface (CLI) enables you to perform a variety of router management tasks through an Ethernet or serial port connection. This section describes the following: Logging On to a SAN Router Guest Account Working with SAN Router Configurations Commands Logging On to a SAN Router To log on to a router using Telnet, open a command line window on the...
Page 174: Guest Account
A – Command Reference Guest Account Guest Account Routers come from the factory with the following account already defined: Account name: guest Password: password This guest account provides access to the router and its configuration. After planning your router management needs, consider changing the password for this account.
Page 175: Save Router Configuration And Persistence
A – Command Reference Working with SAN Router Configurations Save Router Configuration and Persistence Perform the following steps to save the router’s configuration and persistent data. Persistent data consists of LUN mappings, discovered FC targets, and discovered iSCSI initiators. Execute the Fru save CLI command (see Command) to generate a file (iSR-6142_FRU.bin) containing the saved data.
Page 176: Restore Router Configuration And Persistence
A – Command Reference Working with SAN Router Configurations Restore Router Configuration and Persistence Perform the following steps to restore the router’s configuration and persistent data: Transfer the saved data from a workstation to the router by executing an FTP utility on the workstation. The following text is an example of an FTP transfer to put previously saved router configuration data on the router: c:\>ftp 172.17.137.102 Connected to 172.17.137.102.
Page 177: Commands
A – Command Reference Commands Commands The CLI command syntax is as follows: command keyword keyword [value] keyword [value1] [value2] The command is followed by one or more keywords. Consider the following rules and conventions: Commands and keywords are case insensitive. Required keyword values appear in standard font: [value].
Page 178 A – Command Reference Commands Admin Command Opens and closes an administrator session. You can run any command that changes the router configuration within an Admin session. Only one Admin session can be open on the router at any time. An inactive Admin session will time out after 15 minutes.
Page 179: Beacon Command
A – Command Reference Commands Beacon Command Enables or disables the Heartbeat and System Fault LEDs flashing. The heartbeat and system fault LEDs flash synchronously (on and off, together). No other LEDs are affected. Authority Admin session Syntax beacon Keywords Turns on the router beacon.
Page 180: Clear Command
A – Command Reference Commands Clear Command The clear command provides two operations: it removes all entries from the router’s log file, or it resets the Fibre Channel and iSCSI statistic counters. Authority Admin session Syntax clear [logs or stats] Keywords logs Clears all entries from router’s log file.
Page 181: Date Command
A – Command Reference Commands Date Command This command displays or sets the date and time. To set the date and time, the information string must be provided in this format: MMDDhhmmCCYY. The new date and time takes effect immediately. Authority Admin session to set the date and time.
Page 182: Fciproute Command
A – Command Reference Commands FcipRoute Command The FCIP route command provides for configuring a new FCIP route and modifying or deleting an existing FCIP route. Each FCIP route requires a dedicated FC and Gigabit Ethernet port. Configuring an FCIP route, specifying an FC and GE port pair, take precedence over any previous configuration for the port pair (FC/GE).
Page 183 A – Command Reference Commands Remote IPv6 Address fe80::21b:21ff:fe06:d517 MTU Size (0=Normal, 1=Jumbo, 2=Other) [Normal TCP Window Size (0=8KB, 1=16KB, 2=32KB) [32768 Window Scaling (0=Enable, 1=Disable) [Disabled TCP Port No. (Min=1024, Max=65535) [3225 GE Port Speed (0=Auto, 1=100Mb, 2=1Gb) [Auto FCIP Time Stamp (0=Enable, 1=Disable) [Enabled Resource Allocate TimeOut (Min=1sec, Max=5sec)[1...
Page 184 A – Command Reference Commands TCP Window Size (0=8KB, 1=16KB, 2=32KB) [32768 Window Scaling (0=Enable, 1=Disable) [Disabled TCP Port No. (Min=1024, Max=65535) [3225 GE Port Speed (0=Auto, 1=100Mb, 2=1Gb) [Auto FCIP Time Stamp (0=Enable, 1=Disable) [Enabled Resource Allocate TimeOut (Min=1sec, Max=5sec)[1 Bandwidth, Mbit/sec (Min=1, Max=1000) [1000 VLAN (0=Enable, 1=Disable)
Page 185: Fru Command
A – Command Reference Commands FRU Command The FRU command saves and restores the router’s configuration. Authority Admin session to restore. Syntax restore save Keywords restore The FRU restore command requires that you first ftp the tar file containing the desired configuration to the router.
Page 186: Help Command
A – Command Reference Commands Help Command The help command displays a list of the commands and their syntax. Authority None Syntax help Examples Help command example: QRouter #> help amin [ cancel | start | end ] beacon [ on | off ] date [ <MMDDhhmmCCYY>...
Page 187 A – Command Reference Commands memory | mgmt | ntp perf | presented_initiators | presented_targets properties | remotemaps | remotepeers snmp | stats | system targets ] show chap show fc [ <PORT_NUM> ] show fciproutes [ <LINK_ID> ] show features show initiators [ fc | iscsi ] show iscsi [ <PORT_NUM>...
Page 188 A – Command Reference Commands History Displays a numbered list of the previously entered commands. Authority None Syntax History Examples History command example: QRouter (admin) #> history 1: admin start 2: help 3: history A-16 FI0054601-00 C...
Page 189: Image Command
A – Command Reference Commands Image Command Updates the router’s firmware image and cleans up (removes) the image files in the router’s /var/ftp directory. NOTE: Use FTP to transfer an image file to the router’s /var/ftp directory. Authority Admin session Syntax image cleanup...
Page 190: Initiator Command
QRouter (admin) #> initiator mod Index (WWNN/iSCSI Name) ----- ----------------- 0 iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator from the list above ('q' to quit): 0 A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 191 Initiator remove command example: QRouter (admin) #> initiator rm Index (WWNN/iSCSI Name) ----- ----------------- 0 iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator from the list above ('q' to quit): 0 All attribute values for that have been changed will now be saved. FI0054601-00 C...
Page 192: Localmap Command
'q' or 'Q' and the ENTER key to do so. Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 0 50:06:01:60:b0:22:0c:d1,50:06:01:68:30:22:0c:d1 1 iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator from the list above ('q' to quit) : 1 Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 0 20:00:00:20:37:fd:9c:f7,22:00:00:20:37:fd:9c:f7...
Page 193 'q' or 'Q' and the ENTER key to do so. Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 0 50:06:01:60:b0:22:0c:d1,50:06:01:68:30:22:0c:d1 1 iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator from the list above ('q' to quit) : 1 Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 0 20:00:00:20:37:fd:9c:f7,22:00:00:20:37:fd:9c:f7...
Page 194 Target Index Port Initiator (WWNN,WWPN/iSCSI Name) ----- ------ -------------------------------- 0 FC1 iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator to remove ('q' to quit) : 0 All attribute values for that have been changed will now be saved. A-22...
Page 195: Logout Command
A – Command Reference Commands Logout Command Exits the command line interface and returns you to the login prompt. Authority None Keywords logout Examples Logout command example: QRouter (admin) #> logout (none) login: FI0054601-00 C A-23...
Page 196: Password Command
A – Command Reference Commands Password Command Changes the guest and administrator passwords. Authority Admin session Syntax password Examples Password command example: QRouter (admin) #> passwd Press 'q' and the ENTER key to abort this command. Select password to change (0=guest, 1=admin) : 1 account OLD password : ****** account NEW password (6-128 chars) : ****** please confirm account NEW password : ******...
Page 197: Ping Command
A – Command Reference Commands Ping Command The ping command verifies the connectivity of each Ethernet port, management, GE1 (iSCSI 1), and GE2 (iSCSI 2). Authority Admin session Syntax ping Examples Ping command example: QRouter (admin) #> ping A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 198: Quit Command
A – Command Reference Commands Quit Command Exits the command line interface and returns you to the login prompt. Authority None Syntax quit Examples Quit command example: QRouter (admin) #> quit (none) login: A-26 FI0054601-00 C...
Page 199: Reboot Command
A – Command Reference Commands Reboot Command Restarts the router firmware. Authority Admin session Syntax reboot Examples Reboot command example: QRouter (admin) #> reboot Are you sure you want to reboot the System (y/n): y System will now be rebooted... FI0054601-00 C A-27...
Page 200: Remote Map Command
A – Command Reference Commands Remote Map Command The remotemap command provides for the mapping of an initiator and target, one of which is located on a remote system (router). It prompts you to enter the remote system (router), then lists the devices (initiators and targets) located on the remote system.
Page 201 A – Command Reference Commands Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 0 20:00:00:e0:8b:08:5f:3d,21:00:00:e0:8b:08:5f:3d (Initiator) 1 20:00:00:d0:b2:00:19:f0,21:00:00:d0:b2:00:19:f0 (Init/Tgt) Please select a REMOTE device from the list above ('q' to quit) : 0 NOTE: Both the LOCAL and REMOTE systems do not have the SMART-WRITE feature, therefore the querying of the SMART-WRITE settings are not applicable and will be skipped for this mapping.
Page 202 A – Command Reference Commands Smart-Write (0=Enable, 1=Disable) [Enabled ] Smart-Write Compression (0=Enable, 1=Disable) [Disabled ] Smart-Write Load Balance (0=Enable, 1=Disable) [Disabled ] All attribute values for that have been changed will now be saved. Remotemap add command example wihout SMART-WRITE licenses: QRouter (admin) #>...
Page 203 A – Command Reference Commands Please select a remote mapping from the list above ('q' to quit): 0 Smart-Write Compression (0=Enable, 1=Disable) [Disabled ] 1 Smart-Write Load Balance (0=Enable, 1=Disable) [Enabled ] 1 All attribute values for that have been changed will now be saved. Remotemap modify command example without SMART-WRITE licenses: QRouter (admin) #>...
Page 204: Remote Peer Command
Serial Number 0608A00471 HW Version 3 SW Version 2.3.0.1 No. of iSCSI Ports 2 iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00471 Mgmt IP Address 172.17.137.143 iSCSI Port 1 IP Address 10.3.5.106 iSCSI Port 1 TCP Port No. 3260 iSCSI Port 2 IP Address 10.3.5.107 iSCSI Port 2 TCP Port No.
Page 205 A – Command Reference Commands Remotepeer remove command example: QRouter (admin) #> remotepeer rm Index (System Info, Mgmt IP Address) ----- ------------------------------ 0 iSR-6142.0608A00487(172.17.137.215) Please select a remote system from the list above ('q' to quit): 0 WARNING: Remote mappings exist between the LOCAL system and the selected REMOTE system.
Page 206: Reset Factory Command
A – Command Reference Commands Reset Factory Command Restores the router configuration parameters to the factory default values. It deletes all LUN mappings, as well as all persistent data regarding targets, LUNs, and initiators. It also restores the factory default IP addresses. Authority Admin session Syntax...
Page 207: Save Command
A – Command Reference Commands Save Command Saves logs and traces. Authority Admin session Syntax save capture logs traces Keywords capture The save capture command creates a debug file that captures all debug dump data. After the command completes, you must ftp the debug capture file from the router.
Page 208 A – Command Reference Commands Two Save traces command examples: QRouter (admin) #> save traces Save ASIC Traces completed. Package is Router_Asic_Trace.tar.gz Please use FTP to extract the file out from the System. QRouter (admin) #> save traces No ASIC trace files exist to save. Command aborted. A-36 FI0054601-00 C...
Page 209: Set Command
A – Command Reference Commands Set Command Configures general router parameters as well as parameters that are specific to the Fibre Channel, iSCSI, and management ports. Authority Admin session Syntax chap fc [port_num] features Iscsi [port_num] Isns [port_num] mgmt properties snmp system Keywords...
Page 210 A – Command Reference Commands system Sets system parameters such as symbolic name and log level. A-38 FI0054601-00 C...
Page 211: Set Chap Command
Examples Set CHAP command example: QRouter (admin) #> set chap Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- iqn.2004-08.com.qlogic.isr-6142.0539A01064.0.2000002037fd8bab.2200002 037fd8bab iqn.2004-08.com.qlogic.isr-6142.0539A01064.1.2000002037fd8bab.2200002 037fd8bab Please select a presented target from the list above ('q' to quit): 0 A list of attributes with formatting and current values will follow.
Page 212: Set Fc Command
A – Command Reference Commands Set FC Command Configures a Fibre Channel port. Authority Admin session Syntax set fc [port_num] Keywords [port_num] The number of the FC port to be configured. Examples Set FC command example: QRouter (admin) #> set fc 1 A list of attributes with formatting and current values will follow.
Page 213: Set Features Command
A – Command Reference Commands Set Features Command The set features command lets you enter licensed router features such as SmartWrite or additional host ports. NOTE: The date and time must be set prior to entering feature license keys. Authority Admin session Syntax set features...
Page 214: Set Iscsi Command
A – Command Reference Commands Set iSCSI Command Configures an iSCSI port. Authority Admin session Syntax set iscsi [port_num] Keywords [port_num] The number of the iSCSI port to be configured. Examples Set iSCSI command example: QRouter (admin) #> set iscsi 1 A list of attributes with formatting and current values will follow.
Page 215 A – Command Reference Commands IPv6 Tgt TCP Port No. (Min=1024, Max=65535) [3260 IPv6 Window Scaling (0=Enable, 1=Disable) [Enabled IPv6 Window Scaling Factor (Min=0, Max=5) IPv6 VLAN (0=Enable, 1=Disable) [Disabled All attribute values for Port 1 that have been changed will now be saved.
Page 216: Set Isns Command
A – Command Reference Commands Set iSNS Command Configures iSNS parameters for an iSCSI port. Authority Admin session Syntax set isns [port_num] Keywords [port_num] The number of the iSCSI port to be configured for iSNS. Examples Set iSNS command example: QRouter (admin) #>...
Page 217: Set Mgmt Command
A – Command Reference Commands Set Mgmt Command Configures the router’s management port (10/100). Authority Admin session Syntax set mgmt Examples Set Mgmt command example: QRouter (admin) #> set mgmt A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 218: Set Ntp Command
A – Command Reference Commands Set NTP Command Use the set NTP command to configure the network time protocol parameters. NTP sets the date and time on the router from a network time server. Authority Admin session Syntax set ntp Examples Set NTP command example: QRouter (admin) #>...
Page 219: Set Properties Command
A – Command Reference Commands Set Properties Command Configures the CLI (command line interface) properties. Authority Admin session Syntax set properties Examples Set Properties command example: QRouter (admin) #> set properties A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 220: Set Snmp Command
A – Command Reference Commands Set SNMP Command Configures the general simple network management protocol (SNMP) properties, as well as configuring eight trap destinations. Authority Admin session Syntax set snmp trap_destinations Keywords trap_destinations Specifies the setting of the trap destinations. Examples Set SNMP command example for setting the general properties: QRouter (admin) #>...
Page 221 A – Command Reference Commands ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled ] Configuring SNMP Trap Destination 3 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled ] Configuring SNMP Trap Destination 4 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled ] Configuring SNMP Trap Destination 5 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled ] Configuring SNMP Trap Destination 6 :...
Page 222: Set System Command
A – Command Reference Commands Set System Command Configures the general router parameters. Authority Admin session Syntax set system Examples Set System command example: QRouter (admin) #> show system A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 223: Show Command
A – Command Reference Commands Show Command Displays router operational information. Authority None Syntax show chap fc [port_num] fciproutes [link_id] features initiators [fc or iscsi] iscsi [port_num] isns [port_num] localmaps logs memory mgmt perf [ byte | init_rbyte | init_wbyte | tgt_rbyte | tgt_wbyte ] presented_initiators [ fc | iscsi ] presented_targets [fc or iscsi] properties...
Page 224 A – Command Reference Commands iscsi [port_num] Displays iSCSI port information and configuration. isns [port_num] Displays the router’s iSCSI name server (iSNS) configuration. localmaps Displays local mappings, FC to FC, iSCSI to FC, and FC to iSCSI. logs Displays contents of the router logs. memory Displays memory managed by router.
Page 225 A – Command Reference Commands system Displays router product information including serial number, software version, hardware version, configuration, and temperature. targets [fc or iscsi] Displays targets discovered by the router: FC, iSCSI, or both. FI0054601-00 C A-53...
Page 226: Show Chap Command
A – Command Reference Commands Show CHAP Command Displays CHAP configuration. Authority None Syntax show chap Examples Show CHAP command example: QRouter #> show chap The following is a list of iSCSI nodes that have been configured with CHAP 'ENABLED': Type iSCSI Node -------- ------------ No entires found.
Page 227: Show Fc Command
A – Command Reference Commands Show FC Command Displays Fibre Channel port information for the specified port. If you do not specify the port, it displays both ports. Authority None Syntax show fc [port_num] Keywords [port_num] The number of the FC port to display. Examples Show FC command example: QRouter (admin) #>...
Page 228: Show Fciproutes Command
A – Command Reference Commands Show FcipRoutes Command Displays FCIP route(s) configuration parameters. Authority None Syntax show fciproutes [link_id] Keywords [link_id] The number of the FCIP route to be displayed (1 or 2). Examples Show FCIP routes command example: QRouter (admin) #> show fciproutes FCIP Route Information ------------------------ FCIP Route...
Page 229: Show Features Command
A – Command Reference Commands Show Features Command The show features command displays the licensed features that have been enabled on the router. Authority None Syntax show features Examples Show Features command example: QRouter (admin) #> show features Feature Key Information ------------------------- Key 7-LC7D9RMLD05XI-iSR-6142 (SMART-WRITE,39_HOSTS,62_HOSTS) Date Applied Mon Jun 19 10:08:21 2007...
Page 230: Show Initiators Command
Specifies the display of Fibre Channel initiators. iscsi Specifies the display of iSCSI initiators. Examples Show Initiators command example: QRouter #> show initiators Initiator Information ----------------------- Initiator Name iqn.1991-05.com.microsoft:qlogic-8qdaqlxt Alias IP Address 10.3.5.130 Portal No. 1 Status Logged In A-58 FI0054601-00 C...
Page 231: Show Iscsi Command
Show iSCSI port command example: QRouter (admin) #> show iscsi iSCSI Port Information ------------------------ iSCSI Port Port Status Enabled Link Status iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00471.0 MAC Address 00-c0-dd-0c-8b-e2 IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Gateway IP Address 0.0.0.0 Firmware Revision No.
Page 232 IPv6 Window Scaling Enabled IPv6 Window Scaling Factor 1 IPv6 VLAN Disabled iSCSI Port Port Status Enabled Link Status iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00471.1 MAC Address 00-c0-dd-0c-8b-e3 IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Gateway IP Address 0.0.0.0 Firmware Revision No. 3.00.02.44 No.
Page 233: Show Isns Command
A – Command Reference Commands Show iSNS Command Displays iSNS configuration information for the specified iSCSI port. If you do not specify the port, this command displays the iSNS configuration information for both iSCSI ports. Authority None Syntax show isns [port_num] Keywords [port_num] The iSCSI port number whose iSNS configuration you want to display.
Page 234: Show Localmaps Command
Authority None Syntax show localmaps Examples Show Localmaps command example: QRouter (admin) #> show localmaps Local Mappings ---------------- Initiator iqn.1991-05.com.microsoft:qlogic-09sd5i4l Target 20:00:00:20:37:fd:9c:f7,22:00:00:20:37:fd:9c:f7 Initiator Port GE2 Target Port FC1 Initiator 20:01:00:e0:8b:28:5f:3d,21:01:00:e0:8b:28:5f:3d Target 20:00:00:00:87:1d:fa:64,22:00:00:00:87:1d:fa:64 Initiator Port FC2 Target Port FC2 A-62 FI0054601-00 C...
Page 235: Show Logs Command
A – Command Reference Commands Show Logs Command Displays the router event log. Authority None Syntax show logs Examples Show Logs command example: QRouter #> show logs 01/01/2008 00:00:13 System 3 Tuesday 01 January 12:13 AM 01/01/2008 00:00:21 QL4022 3 #0: QLIsrDecodeMailbox: Link up 01/01/2008 00:00:13 System 3 Tuesday 01 January 12:13 AM 01/01/2008 00:00:22 QL4022 3 #0: QLIsrDecodeMailbox: Link up FI0054601-00 C...
Page 236: Show Memory Command
A – Command Reference Commands Show Memory Command Displays the router’s memory usage. If there are no configured FCIP routes, it shows the FCIP memory usage of zero. Authority None Syntax show memory Examples Show Memory command example with no FCIP routes configured: QRouter #>...
Page 237: Show Mgmt Command
A – Command Reference Commands Show Mgmt Command Displays the router’s management port (10/100) configuration. Authority None Syntax show mgmt Examples Show Mgmt command example: QRouter (admin) #> show mgmt Management Port Information ----------------------------- IPv4 Interface Enabled IPv4 Mode Dhcp IPv4 IP Address 172.17.137.129 IPv4 Subnet Mask...
Page 238: Show Ntp Command
A – Command Reference Commands Show NTP Command Displays the router’s network time protocol (NTP) configuration. Authority None Syntax show ntp Examples Show NTP command example: QRouter #> show ntp NTP Information ----------------- Mode Disabled Status Offline TimeZone Offset (Hours) 0 A-66 FI0054601-00 C...
Page 239: Show Performance Command
A – Command Reference Commands Show Performance Command Displays router performance data. Authority None Syntax show perf byte init_rbyte init_wbyte tgt_rbyte tgt_wbyte Keywords byte Displays data transfer rate of each port (FC and GE). init_rbyte Displays initiator read transfer rate per port. init_wbyte Displays initiator write transfer rate per port.
Page 240 A – Command Reference Commands Show Performance byte command example: QRouter #> show perf byte Displaying bytes/sec (total)... (Press any key to stop display) GE1 GE2 FC1 FC2 ------------------------------ 47M 93M 94M 48M 47M 94M 96M 47M 46M 96M 96M 47M 45M 94M 97M 48M 47M 92M 93M 48M 45M 93M 94M 46M...
Page 241: Show Presented Initiators Command
Show Presented Initiators command example: QRouter #> show presented_initiators Presented Initiator Information --------------------------------- FC Presented Initiators ------------------------- WWNN 20:01:00:c0:dd:0c:8b:e3 WWPN 21:01:00:c0:dd:0c:8b:e3 Port FC2 <MAPS TO> WWNN 20:01:00:e0:8b:28:5f:3d WWPN 21:01:00:e0:8b:28:5f:3d WWNN 20:01:00:c0:dd:0c:8b:e2 WWPN 21:01:00:c0:dd:0c:8b:e2 Port FC1 <MAPS TO> Name iqn.1991-05.com.microsoft:qlogic-09sd5i4l FI0054601-00 C A-69...
Page 242: Show Presented Targets Command
Port FC2 <MAPS TO> WWNN 20:00:00:00:87:1d:fa:64 WWPN 22:00:00:00:87:1d:fa:64 iSCSI Presented Targets ------------------------- Name iqn.2004-08.com.qlogic:isr-6142.0608a00471.1.2200002037fd9cf7.2000002 037fd9cf7 Port GE2 <MAPS TO> WWNN 20:00:00:20:37:fd:9c:f7 WWPN 22:00:00:20:37:fd:9c:f7 The following is an example of the Show Presented FC Targets command: QRouter #> show presented_targets fc No Presented Targets found.
Page 243 A – Command Reference Commands Show Presented iSCSI Targets command example: QRouter #> show presented_targets iscsi Presented Target Information ------------------------------ iSCSI Presented Targets ------------------------- Name iqn.2000-04.com.qlogic:isr6142:0.50001fe150069d20.50001fe150069d2c IP 10.3.5.66 <MAPS TO> WWNN 50:00:1f:e1:50:06:9d:20 WWPN 50:00:1f:e1:50:06:9d:2c Name iqn.2000-04.com.qlogic:isr6142:1.50001fe150069d20.50001fe150069d2c IP 10.3.5.67 <MAPS TO>...
Page 244: Show Properties Command
A – Command Reference Commands Show Properties Command Displays the router’s CLI (command line interface) properties. Authority None Syntax show properties Examples Show Properties command example: QRouter #> show properties CLI Properties ---------------- Inactivty Timer Disabled Prompt String QRouter A-72 FI0054601-00 C...
Page 245: Show Remotemaps Command
A – Command Reference Commands Show Remotemaps Command Displays all remote maps that have been configured. Authority None Syntax show remotemaps Examples Show Remotemaps command example: QRouter #> show remotemaps Remote Mappings ----------------- Local Device 20:01:00:e0:8b:28:5f:3d,21:01:00:e0:8b:28:5f:3d (Initiator) Remote Device 20:00:00:14:c3:3d:d2:bf,22:00:00:14:c3:3d:d2:bf (Target) Local Port FC2 Remote System iSR-6142.0608A00471(172.17.137.143)
Page 246: Show Remotepeers Command
Serial Number 0608A00487 HW Version 3 SW Version 2.2.0.4 No. of iSCSI Ports 2 iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00487 Mgmt IP Address 172.17.137.215 iSCSI Port 1 IP Address 10.3.5.103 iSCSI Port 1 TCP Port No. 3260 iSCSI Port 2 IP Address 10.3.5.104 iSCSI Port 2 TCP Port No.
Page 247: Show Snmp Command
A – Command Reference Commands Show SNMP Command Displays the router’s simple network management protocol (SNMP) and any configured traps. Authority None Syntax show snmp Examples Show SNMP command example: QRouter #> show snmp SNMP Configuration ------------------ Read Community Public Trap Community Private System Location System Contact...
Page 248: Show Stats Command
A – Command Reference Commands Show Stats Command Displays the router statistics: FC and iSCSI. Authority None Syntax show stats Examples Show Statistics command example: QRouter #> show stats FC Port Statistics -------------------- FC Port 1 Interrupt Count 23 Target Command Count 0 Initiator Command Count 0 FC Port 2 Interrupt Count 1717443350...
Page 249 A – Command Reference Commands MAC Rcvd Carrier Sense Errors 0 MAC Rcvd Dropped Frames 0 MAC Rcvd CRC Errors 0 MAC Rcvd Encoding Errors 0 MAC Rcvd Length Errors Large 1 MAC Rcvd Small Errors Small 0 MAC Rcvd Multicast Frames 34394 MAC Rcvd Broadcast Frames 33144 iSCSI Port 2 Interrupt Count 51604...
Page 250 A – Command Reference Commands Unexpected I/O Rcvd 0 iSCSI Format Errors 0 Header Digest Errors 0 Data Digest Errors 0 Sequence Errors 0 PDU Xmit Count 2729500577 PDU Xmit Count 2729500577 PDU Xmit Count 2729500577 IP Xmit Packets 54392134283 IP Xmit Byte Count 59132566295008 IP Xmit Fragments 0 IP Rcvd Packets 42061430681...
Page 251: Show System Command
A – Command Reference Commands Show System Command Displays router product information including the serial number, software version, hardware version, configuration, and temperature. Authority None Syntax show system Examples Show System command example: QRouter #> show system System Information -------------------- Product Name iSR-6142 Symbolic Name...
Page 252: Show Targets Command
A – Command Reference Commands Show Targets Command Displays targets the router discovered: FC, iSCSI, or both. Authority None Syntax show targets iscsi Keywords Specifies the display of FC targets. iscsi Specifies the display of iSCSI targets. Examples Show FC Targets command example: QRouter #>...
Page 253: Show Vlan Command
A – Command Reference Commands Show VLAN Command Displays the router’s VLAN configuration. Authority None Syntax show vlan [port_num] Keywords [port_num] The iSCSI port number whose VLAN configuration you want to display. Examples Show VLAN command example: QRouter #> show vlan VLAN Information ------------------ Port 1...
Page 254: Shutdown Command
A – Command Reference Commands Shutdown Command The shutdown command provides for an orderly shutdown of the routers firmware. It does not power down the router. Authority Admin session Syntax shutdown Examples Shutdown command example: QRouter (admin) #> shutdown A-82 FI0054601-00 C...
Page 255: Target Command
A – Command Reference Commands Target Command Removes targets from the router’s database. Typically, you can use this command to remove targets from the database that are no longer connected to the router. The target add command is not currently supported. Authority Admin session Syntax...
Page 256: Traceroute Command
A – Command Reference Commands Traceroute Command Prints the route a network packet takes to the reach the destination specified by the user. Authority Admin session Syntax traceroute Examples Traceroute command example: A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 257: Log Messages
Log Messages Log Data The router maintains a message log you can retrieve and review using either the command line interface or the SANsurfer Router Manager. The message log is persistent, maintained across router power cycles and reboots. The three log message categories are: Informational Error...
Page 258 B – Log Messages Informational Log Messages Table B-1. Application Modules—Informational Log Messages (Continued) Log Message 54306 QLFC_Logout: Origin 0x%x, VP Index 0x%x, Id 0x%x 1058 54307 QLFC_Logout: Port ID %.2x%.2x%.2x 1059 54308 QLFC_Logout: Node Name 1060 %.2x%.2x%.2x%.2x%.2x%.2x%.2x%.2x 54309 QLFC_Logout: Port Name 1061 %.2x%.2x%.2x%.2x%.2x%.2x%.2x%.2x 54359...
Page 259 B – Log Messages Informational Log Messages 1028 FC login occurred with WWNN xx.xx.xx.xx.xx.xx.xx.xx. 1029 FC login occurred with WWPN xx.xx.xx.xx.xx.xx.xx.xx. 1058 FC logout occurred, origin xx (1 = HBA, 2 = target, 3 = initiator), VP (virtual port) xx, ID (loop ID) x. 1059 FC logout occurred with port ID xx.xx.xx.
Page 260: Iscsi Driver
B – Log Messages Informational Log Messages iSCSI Driver The following informational log messages are common to both iSCSI ports: 1 (GE1) and 2 (GE2). The messages are listed in Table B-2 and described following the table. Log messages beginning with #0 denote iSCSI port 1 (GE1) and log messages beginning with #1 denote iSCSI port 2 (GE2).
Page 261: Fibre Channel Driver
B – Log Messages Informational Log Messages Fibre Channel Driver The following informational log messages are common to both Fibre Channel ports: 1 (FC1) and 2 (FC2). The messages are listed in Table B-3 and described following the table. Log messages beginning with #0 denote fibre channel port 1 (FC1).
Page 262: User Modules
B – Log Messages Informational Log Messages FCIP - Fibre Channel link up occurred. Event status is reported, as is the contents of the FC processor’s mailbox 1 register. FCIP - Fibre Channel link down occurred. FCIP - Fibre Channel link up occurred. Event status is reported, as is the RunTimeMode (0 = loop, 1 = point-to-point).
Page 263 B – Log Messages Informational Log Messages Table B-4. User Modules—Informational Log Messages (Continued) Log Message 151903 qapimaptargettoinitiator_1_svc: Localmap added to target device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 151904 qapiunmaptargettoinitiator_1_svc: Localmap removed for initiator device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 151905 qapiunmaptargettoinitiator_1_svc: Localmap removed to target device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 151906 qapimaptargettoinitiator_1_svc: Localmap added for initiator %s 151907...
Page 264: Fcip
B – Log Messages Informational Log Messages Remotemap removed for local FC device WWPN xx.xx.xx.xx.xx.xx.xx.xx. Remotemap removed for remote FC device WWPN xx.xx.xx.xx.xx.xx.xx.xx. Localmap added for FC initiator WWPN xx.xx.xx.xx.xx.xx.xx.xx. Localmap added to FC target device WWPN xx.xx.xx.xx.xx.xx.xx.xx. Localmap removed for FC initiator. Localmap removed to FC target device.
Page 265: Toe Driver
B – Log Messages Informational Log Messages TOE Driver The TOE driver generates the informational log messages listed in Table B-6 described following the table. Table B-6. TOE—Informational Log Messages Log Message 217350 QL3022:eth%x: Interface is down The GigE interface d (0 or 1) used for an FCIP route is down. System The system modules generate the informational log messages listed in Table B-7...
Page 266: Error Log Messages
B – Log Messages Error Log Messages Error Log Messages The following sections list and describe the error log messages by reporting module. Application Modules The application modules generate the error log messages listed in Table B-8 described following the table. Table B-8.
Page 267 B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) Log Message 41270 QLIS_LoginPduContinue: TSIH is 0 but InitiatorName key/value not provided 41272 QLIS_LoginPduContinue: CONN_STATE_IN_LOGIN, Unknown InitTaskTag 41283 QLIS_LoginPduContinue: TSIH 0x%x out of range 41284 QLIS_LoginPduContinue: Session does not exist, invalid TSIH 0x%x 41353 QLIS_LoginPduContinue CHAP Validation Failure...
Page 268 B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) Log Message 42024 QLFC_Logout: No active path to device. WWPN: 1064 %.2X%.2X%.2X%.2X%.2X%.2X%.2X%.2X 42027 QLFC_Logout: VP Index 0x%x not configured 1067 42068 QLFC_HandleTeb: System Error 1108 42069 QLFC_HandleTeb: Driver Fatal Error 1109 42072...
Page 269 B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) Log Message 43280 QLFCIP_HandleTeb: Driver Fatal error 2320 43281 QLFCIP_ConfigPortal: Find portal object failed for 2321 QLUT_TYPE_FC, PortId (%d) 43282 QLFCIP_ConfigPortal: QLFCIP_ConfigPortal: Invalid PortId for 2322 FCIP link PortID(%d) 43283 QLUT_AllocateFcipTrbPool: Allocation failed (size 0x%x))
Page 270 B – Log Messages Error Log Messages Unable to create an object for the target device: exceeded the maximum number of target devices. Unable to create an object for the target node: exceeded the maximum number of target devices. Memory unavailable for LUN object. Unable to create an object for initiator object: exceeded the maximum number of initiators.
Page 271 B – Log Messages Error Log Messages iSCSI Login PDU was received with an invalid TSIH value. The TSIH is invalid because there is no session with that TSIH value. This would occur if the iSCSI initiator attempting the login failed to used the TSIH value provided in the target login response PDU (router is target) in subsequent login PDUs.
Page 272 B – Log Messages Error Log Messages 1042 Attempting login but Fibre Channel connection cannot be opened. 1064 Attempting logout of device for which there is no active path (WWPN not found). 1067 Logout attempted using Fibre Channel VP index that has not been configured. Operation attempted on an unconfigured VP.
Page 273 B – Log Messages Error Log Messages 2320 FCIP handle Teb: Driver Fatal error. 2321 FCIP configure portal: Find portal object failed for QLUT_TYPE_FC, PortId (%d). 2322 FCIP configure portal: QLFCIP_ConfigPortal: Invalid PortId for FCIP link PortID(%d). 2323 FCIP allocate TRB pool: Allocation failed (size 0x%x). 2324 FCIP Trb: Null portal object in map table.
Page 274: Iscsi Driver
B – Log Messages Error Log Messages iSCSI Driver The following error log messages are common to both iSCSI ports, 1 (GE1) and 2 (GE2). They are listed in Table B-9 and described following the table. Log messages beginning with #0 denote iSCSI port 1 (GE1). Log messages beginning with #1 denote iSCSI port 2 (GE2).
Page 275 B – Log Messages Error Log Messages The iSCSI processor failed the external loopback test. The iSCSI processor command to disable a GE port failed. The iSCSI processor could not connect with the iSCSI name server (iSNS). The iSCSI processor reported that the iSCSI port NVRAM contains invalid data (checksum error).
Page 276: Fibre Channel Driver
B – Log Messages Error Log Messages Fibre Channel Driver The following error log messages are common to both Fibre Channel ports, 1 (FC1) and 2 (FC2). They are listed in Table B-10 and described in this section. Log messages beginning with #0 denote fibre channel port 1 (FC1) and log messages beginning with #1 denote fibre channel port 2 (FC2).
Page 277 B – Log Messages Error Log Messages Table B-10. Fibre Channel Driver—Error Log Messages (Continued) Log Messages 107254 #%d: QLUpdateSinglePortCont 0x%x: out of slots in host database 107267 #%d: QLFcipIsrEventHandler: System error event (%x), MB1=%x, MB2=%x, MB3=%x, MB4=%x, MB5=%x, MB6=%x, MB7=%x The FC processor received a SCSI command for an unknown target path or has run out of resources to execute additional commands.
Page 278: User Modules
B – Log Messages Error Log Messages The drivers host (initiator) database is full. No slots available in host database. FCIP system error event. User Modules The user modules generate the error log messages listed in Table B-11 described following the table. Table B-11.
Page 279 B – Log Messages Error Log Messages Table B-11. User Modules—Error Log Messages (Continued) Log Message 139297 QBRPC_Initialize:BridgeStatus Mem Allocation error 139298 QBRPC_Initialize:Diag Mem Allocation error 139299 QBRPC_Initialize:DiagLog Mem Allocation error 139300 QBRPC_Initialize:FruImage Mem Allocation error 139301 QBRPC_Initialize:OemMfg Mem Allocation error 139302 QBRPC_Initialize:Status Mem Allocation error 139303...
Page 280 B – Log Messages Error Log Messages Failed memory allocation for Get LUN List API. Failed memory allocation for Get Presented Targets List API. Failed memory allocation for Get LUN Mask API. Failed memory allocation for Initiator API. Failed memory allocation for Target Device API. Failed memory allocation for FC Target API.
Page 281: System
B – Log Messages Fatal Log Messages System The system modules generate the error log messages listed in Table B-12 described following the table. Table B-12. System—Error Log Messages Log Message 237572 "Failed to kill sys killer %d\n" 237573 "Temperature over high threshold %d\n" Failed to kill system task.
Page 282 B – Log Messages Fatal Log Messages Table B-13. iSCSI Driver—Fatal Log Messages (Continued) Log Message 69964 #%d: QLDisable: QLRebootTimer failed AF %x RS %x Time %d 69966 #%d: QLEnable: QLRebootTimer failed AF %x RS %x Time %d 70224 #%d: QLProcSrblessiSNSResponse: Invalid handle %x 70400 #%d: QLInitializeDevice: QLStartAdapter failed 70417...
Page 283 B – Log Messages Fatal Log Messages iSCSI processor SRAM test failed. iSCSI processor failed diagnostic reboot. iSCSI processor failed NVRAM diagnostic. iSCSI processor failed DRAM diagnostic. iSCSI processor failed to return diagnostic results. Response queue entry contains an invalid handle. Set NVRAM reboot timer failed.
Page 284: Fc Driver
B – Log Messages Fatal Log Messages FC Driver The following fatal log messages are common to both Fibre Channel ports, 1 (FC1) and 2 (FC2). They are listed in Table B-14 and described following the table. Log messages beginning with #0 denote fibre channel port 1 (FC1). Log messages beginning with #1 denote fibre channel port 2 (FC2).
Page 285 B – Log Messages Fatal Log Messages Table B-14. Fibre Channel Driver—Fatal Log Messages (Continued) Log Message 102749 #%d: QLProcessResponseQueueFS: Invalid handle 0x%x, type 0x%x 102752 #%d: QLTimer: Ext Ram parity error exceed limit cnt 0x%x, limit 0x%x, Disabled adapter 102755 #%d: QLTimer: Heartbeat failed 102800...
Page 286: Toe Driver
B – Log Messages Fatal Log Messages FC processor external SRAM parity error count exceeded limit: FC port disabled. FC processor heartbeat failed. FC processor being restarted. TOE Driver The TOE driver generates the fatal log messages listed in Table B-15 described following the table.
Page 287: System
B – Log Messages Fatal Log Messages System The system modules generate the fatal log messages listed in Table B-16 described following the table. Table B-16. System—Fatal Log Messages Log Message 233473 "memory monitor: Detected Uncorrectable Ecc %08lx system is rebooting in 5 secs\n"...
Page 288 B – Log Messages Fatal Log Messages Notes B-32 FI0054601-00 C...
Page 289: Configuring Chap
Configuring CHAP CHAP Definition In challenge handshake authentication protocol (CHAP), the authentication agent sends the client program a random value that is used only once and an ID value. Both the sender and peer share a predefined secret. The peer concatenates the random value, the ID, and the secret, and calculates a one-way hash using MD5 (Message-Digest algorithm 5).
Page 290: Cli-Discovery Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using CLI Click General. Click Secret (in the middle of the screen). If this is the first time you are setting secrets, reset all secrets. Type the secret (secret_port) that you created in Step Click Discovery.
Page 291: Cli-Normal Session-Bi-Directional Chap
C – Configuring CHAP Configuring CHAP Using CLI CLI—Normal Session—Bi-directional CHAP To configure a bi-directional CHAP used during a normal session: On the router Enable CHAP on the presented target to which the initiator will login. Create a secret (for example, secret_target). Use Set CHAP.
Page 292: Cli-Normal Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI CLI—Normal Session—Uni-directional CHAP To configure single-direction CHAP to be used during a normal session: Do not enable CHAP on the presented target. Use Initiator add: Add the initiator that is about to do a normal login. Enable the CHAP for this initiator.
Page 293: Gui-Discovery Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI Select Enable CHAP. Create a CHAP secret (for example, secret_initiator). Go to the MS Initiator and perform the following steps: Click General. Click Secret (in the middle of the screen). If this is the first time you are setting secrets, reset all secrets. Type the CHAP secret (secret_port) that you created in Step Click Discovery.
Page 294: Gui-Normal Session-Bi-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI Click Advanced. Click Chap Login Information. Type the secret (secret_initiator) you created in Step 5 into Target Secret. Click OK. Click OK. The initiator completes discovery. GUI—Normal Session—Bi-directional CHAP To program bi-directional CHAP during a normal session: On the bridge, enable CHAP for the iSCSI presented target.
Page 295: Gui-Normal Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI Type the secret (secret_initiator) that you created in Step 9 into Target Secret. Select Mutual Authentication. Click OK. Click OK. The initiator completes normal login. GUI—Normal Session—Uni-directional CHAP To program single-direction CHAP during a normal session: Do not enable CHAP on the iSCSI presented target.
Page 296 C – Configuring CHAP Configuring CHAP Using the GUI Notes FI0054601-00 C...
Page 297: Simple Network Management Protocol (Snmp)
Simple network management protocol (SNMP) provides monitoring and trap functions for managing the router through third-party applications that support SNMP. The router firmware supports SNMP versions 1 and 2 and a QLogic Management Information Base (MIB). You may format the traps using SNMP version 1 or 2 (See Notifications).
Page 298: Snmp Trap Configuration
D – Simple Network Management Protocol (SNMP) Introduction Table D-1. SNMP Properties (Continued) Parameter Description System contact Specifies the name of the person to be contacted to respond to trap events. The name can be up to 64 characters excluding the number sign (#), semicolon (;), and comma (,).
Page 299: Management Information Base (Mib)
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) Management Information Base (MIB) The following sections describe the QLogic management information base (MIB). The MIB consists of four object groups: System Information Network Port Table Fibre Channel Port Table...
Page 300: Network Port Table
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNoOfGbEPorts Syntax Unsigned32 Access Read-only Description The number of gigabit Ethernet ports on the system. qsrAgentVersion Syntax SnmpAdminString Access Read only Description The version number of the agent software on the system.
Page 301 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNetMask InetAddress qsrGateway InetAddress qsrMacAddress MacAddress qsrNwLinkStatus QsrLinkStatus qsrNwLinkRate QsrLinkRate qsrNwPortRole Syntax QsrPortRole Access Not accessible Description The operational role of this port: management port, iSCSI port, a TOE. qsrNwPortIndex Syntax Unsigned32 Access Not accessible...
Page 302: Fibre Channel Port Table
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNetMask Syntax InetAddress Access Read only Description The subnet mask for this port. qsrGateway Syntax InetAddress Access Read only Description The gateway for this port. qsrMacAddress Syntax IMacAddress Access Read only Description The MAC address for this port.
Page 303 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrFcPortEntry Syntax QsrFcPortEntry Access Not accessible Description Each entry (row) contains information about a specific FC port. QsrFcPortEntry A fibre channel port entry consists of the following sequence of objects: qsrFcPortRole QsrPortRole qsrFcPortIndex...
Page 304: Sensor Table
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrFcPortWwn Syntax PhysAddress Access Read only Description The world wide name for this port. qsrFcPortId Syntax PhysAddress Access Read only Description The interface's 24-bit FC address identifier. qsrFcPortType Syntax Unsigned32 Access Read only Description The type of FC port, as indicated by the use of the appropriate value assigned by IANA.
Page 305 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrSensorEntry Syntax QsrSensorEntry Access Not accessible Description Each entry (row) corresponds to a single sensor. QsrSensorEntry A sensor entry consists of the following sequence of objects: qsrSensorType INTEGER qsrSensorIndex Unsigned32 qsrSensorUnits INTEGER...
Page 306 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrSensorValue Syntax Integer32 Access Read only Description The current value of the sensor. qsrUpperThreshold Syntax Integer32 Access Read only Description The upper-level threshold for this sensor. qsrLowerThreshold Syntax Integer32 Access Read only Description The lower-level threshold for this sensor.
Page 307: Notifications
D – Simple Network Management Protocol (SNMP) Notifications Notifications The router provides the following notification types: Notification Objects Agent Start Up Notification Agent Shut Down Notification Network Port Down Notification Fibre Channel Port Down Notification Sensor Notification Generic Notification The following sections describe these notifications and objects they use. Notification Objects This section defines the objects used in notifications.
Page 308: Agent Shut Down Notification
D – Simple Network Management Protocol (SNMP) Notifications qsrAgentStartup uses the following object: qsrEventTimeStamp Agent Shut Down Notification The agent shut down notification indicates that the agent on the router is shutting down. qsrAgentShutdown uses the following object: qsrEventTimeStamp Network Port Down Notification The network port down notification indicates that the specified network port is down.
Page 309: Generic Notification
D – Simple Network Management Protocol (SNMP) Notifications Generic Notification The generic notification reports events other than the defined event types. It provides a description object that identifies the event in clear text. qsrGenericEvent uses the following objects: qsrEventTimeStamp qsrEventSeverity qsrEventDescription FI0054601-00 C D-13...
Page 310 D – Simple Network Management Protocol (SNMP) Notifications Notes D-14 FI0054601-00 C...
