Page 1 S i m p l i f y SANbox 6142 Intelligent Storage Router User’s Guide FI0054601-00 A-2 Page i...
Page 2 QLogic Corporation. Any use, modification, distribution or reproduction of this program without the express written consent of QLogic Corporation is a violation of the copyright laws and may subject you to criminal prosecution and civil liability.
Page 3: Table Of Contents
Table of Contents Section 1 Introduction Intended Audience ......... . Related Materials .
Page 4 Environmental Conditions ........Installing the SANbox 6142 Router......
Page 5 SANbox 6140 Router User’s Guide SANbox 6140 Router User’s 4.2.2 Mount the Router ......... 4.2.3 Install the Transceivers .
Page 6 7.5.1 SANbox 6142 Router ........
Page 7 SANbox 6140 Router User’s Guide SANbox 6140 Router User’s 7.6.7 Remove Remote Router Wizard ......7-77 7.6.8 Map Remote Initiator/Target Wizard .
Page 8 SANbox 6140 Router User’s Guide A.25.4 Set iSCSI Command ........A-47 A.25.5 Set iSNS Command .
Page 9 SANbox 6140 Router User’s Guide SANbox 6140 Router User’s B.2.4 User Modules ..........B.2.5 FCIP .
Page 10 SANbox 6142 Router and Accessories ........
Page 11 SANbox 6140 Router User’s Guide SANbox 6140 Router User’s 7-17 FC Port Information Tab ..........7-18 7-18 FC Port Advanced Configuration Tab .
Page 12 SANbox 6140 Router User’s Guide 7-56 Initiator/Target Mapping Configuration Status Dialog Box ....7-65 7-57 Discovered iSCSI Initiators - Local Presented Targets ..... . . 7-66 7-58 Initiator Selection Dialog Box .
Page 13 SANbox 6140 Router User’s Guide SANbox 6140 Router User’s 7-95 FCIP Route Remove Wizard—Security Check Dialog Box ....7-100 7-96 FCIP Route Remove Wizard—Completed Dialog Box ..... . . 7-100 Tables Table Page...
Page 14 SANbox 6140 Router User’s Guide Page xiv FI0054601-00 A...
Page 15: Intended Audience
Intended Audience This guide is for users who are responsible for installing, managing, and servicing the SANbox 6142 router and the storage area network (SAN) equipment to which it is attached. Related Materials iSCSI draft standard draft-ietf-ips-iSCSI-20 ■...
Page 16: Safety Notices
Communications Statements The following communications statements apply to the SANbox 6142 router. Statements for products intended for use with the SANbox 6142 router appear in their accompanying manuals. 1.4.1 Federal Communications Commission (FCC) Class A Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Page 17: Canadian Department Of Communications Class A Compliance Stmt
1 – Introduction Communications Statements 1.4.2 Canadian Department of Communications Class A Compliance Statement This equipment does not exceed Class A limits for radio emissions for digital apparatus, set out in Radio Interference Regulation for the Canadian Department of Communications. Operation in a residential area may cause unacceptable interference to radio and TV reception requiring the owner or operator to take whatever steps necessary to correct interference.
Page 18: Vcci Class A Statement
The assemblies used in the router chassis are ESD sensitive. Observe ESD handling procedures when handling any assembly used in the router chassis. Accessible Parts The following field replaceable units (FRUs) are supported by the SANbox 6142 router: Small form-factor pluggable (SFP) optical transceivers ■...
Page 19: Preamble
26600 Aliso Viejo Parkway Aliso Viejo, CA 92656 Attention: Technical Support – Source Request CAUTION! Installation of software or files not authorized by QLogic will immediately and irrevocably void all warranty and service contracts on the affected units. The following General Public License has been reproduced with permission from:...
Page 20: Terms And Conditions For Copying, Distribution And Modification
1 – Introduction General Public License by someone else and passed on, we want its recipients to know that what they have is not the original, so that any problems introduced by others will not reflect on the original authors’ reputation. Finally, any free program is threatened constantly by software patents.
Page 21 1 – Introduction General Public License licensed as a whole at no charge to all third parties under the terms of this License. c. If the modified program normally reads commands interactively when run, you must cause it, when started running for such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty) and that users may redistribute the program under...
Page 22 1 – Introduction General Public License The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the executable.
Page 23 1 – Introduction General Public License If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances. It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims;...
Page 24: How To Apply These Terms To Your New Programs
1 – Introduction General Public License EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.
Page 25: Technical Support
1.9.1 Availability QLogic Technical Support is available from 7:00 AM to 7:00 PM Pacific Standard Time, Monday through Friday, excluding QLogic-observed holidays. 1.9.2 Training QLogic offers certification training for the technical professional for SANbox routers.
Page 26: Contact Information
1 – Introduction Technical Support equipment, QLogic awards a certificate identifying the student as a Certified Professional. The training professionals at QLogic may be reached by email at tech.training@qlogic.com. 1.9.3 Contact Information Telephone: Fax: Email: Technical Service Technical Training QLogic Web Site: www.qlogic.com...
Page 27: General Description
Section 2 General Description This section describes the following features and capabilities of the SANbox 6142 router: Router Capabilities (see section 2.1) ■ Licensed Features (see section 2.2) ■ Remote SAN Connectivity (see section 2.3) ■ Local SAN Connectivity (see section 2.4) ■...
Page 28: Licensed Features
2 – General Description Licensed Features When using the SANbox 6142 to connect two Fibre Channel SANs, E-ports are not required on the Fiber Channel switches. This allows the user to connect multi-vendor FC SANs (switches) without concern for the compatibility of the E-Ports and/or B-Ports between different switch vendors.
Page 29: Additional Server/Ports
2.2.2 Additional Server/Ports SANbox 6142 supports mapping of up to 62 Server/Ports between two SANs. The default configuration allows the mapping of 16 server/ports between SANs. For example, you may map 8 iSCSI initiators to FC SAN and map 8 FC devices from one FC SAN to another FC SAN.
Page 30 Figure 2-2. Remote SAN Island Connectivity Additional requirements for this configuration are as follows: At least one FC Port of SANbox 6142 should be connected to FC SAN ■ iSCSI/ GE (GE identifies Gigabit Ethernet ports on the router) Port IP addresses ■...
Page 31: Local San Island Connectivity
2 – General Description Local SAN Island Connectivity Local SAN Island Connectivity The SANbox 6142 Intelligent Router supports inter-connecting local FC SAN islands, it also supports bridging iSCSI devices on the LAN to FC devices on the (see figure 2-3).
Page 32: Fcip - Fibre Channel Over Ip
FCIP - Fibre Channel over IP FCIP - Fibre Channel over IP The SANbox 6142 Intelligent Router supports FCIP, Fibre Channel over IP. The FCIP protocol as implemented in the router is not guaranteed nor has it been tested to be compatible with other vendor FCIP implementations. The router supports a maximum of two FCIP routes;...
Page 33: System Fault Led (Amber)
2 – General Description Chassis Controls blinks about once per second to show that the router passed the POST and that the internal router processor is running. Table 2-1defines the blink patterns. Table 2-1. Heartbeat LED and System Fault LED Blink Patterns Heartbeat System Fault Condition...
Page 34: Resetting A Router
2 – General Description Chassis Controls 2.7.2 Resetting a Router To reset the router, use a pointed, nonmetallic tool to momentarily press and release (less than two seconds) the maintenance button. The router responds as follows: 1. All the chassis LEDs illuminate. 2.
Page 35: Factory Defaults
Erases all presentations ■ Erases all discovered initiators and targets ■ Fibre Channel Ports The SANbox 6142 router has two fibre channel ports. The ports are labeled FC1 and FC2, and are shown in Figure 2-6. Figure 2-6. Fibre Channel LEDs Each port is served by a small form-factor pluggable (SFP) optical transceiver and is capable of 1-Gbps or 2-Gbps transmission.
Page 36: Fibre Channel Sfp Transceivers
Firmware error Fibre Channel SFP Transceivers The SANbox 6142 router supports SFP optical transceivers for the Fibre Channel ports. A transceiver converts electrical signals to and from optical laser signals to transmit and receive data. Duplex fibre optic cables plug into the transceivers, which then connect to the devices.
Page 37: Iscsi/Gigabit Ethernet Port Leds
2 – General Description Ethernet Port—Management 2.10 iSCSI/Gigabit Ethernet Port LEDs The iSCSI/gigabit Ethernet ports shown in Figure 2-7 are RJ-45 connectors that provide connection to an Ethernet SAN through a 10/100/1000 Base-T Ethernet cable. The ports are labeled GE1 and GE2. These ports have two LEDs: the link status LED (green) and the activity LED (also green).
Page 38: Serial Port
■ the Ethernet connection. 2.12 Serial Port The SANbox 6142 router is equipped with an RS-232 serial port for maintenance purposes. Figure 2-9, following, shows the serial port location. It is labeled IOIOI. You can manage the router through the serial port using the CLI.
Page 39 2 – General Description Serial Port Table 2-4. RJ-45 to DB-9 Adapter Pin Identification RJ-45 DB-9 RJ-45 DB-9F Pin Number Pin Definition Pin Number Pin Definition Request to send (RTS) Data terminal ready (DTR) Transmit data (TxD) Signal ground (GND) Receive data (RxD) Data carrier detect (DCD) Data set ready (DSR)
Page 40 2 – General Description Serial Port 2-14 FI0054601-00 A...
Page 41: Planning
Section 3 Planning This section describes planning for the use of the SANbox 6142 router. Consider the following when planning the use of the router: Devices (see section 3.1) ■ Device Access (see section 3.2) ■ FC Performance (see section 3.3) ■...
Page 42: Fibre Channel
GUI) uses the initiator’s information to simplify the mapping process. FC Performance The SANbox 6142 router supports Fibre Channel service at transmission rates of 1 Gbps or 2 Gbps with a maximum frame size of 2148 bytes. It supports Ethernet service at transmission rates of 1000-, 100- or 10-Mbps with a maximum transmission unit (MTU) size of 1500 or 9000 (jumbo frames).
Page 43: Latency
Latency is a measure of how long a transaction takes to travel through the router or over a communication link. iSCSI/Gigabit Ethernet Performance The SANbox 6142 router supports Ethernet service at transmission rates of 1000-, 100- or 10-Mbps with a MTU size of 1500 or 9000 (jumbo frames). Related performance characteristics include the following: Distance ■...
Page 44: T1 / Ds-1: 1.554 Mbits/Sec
3 – Planning Performance Tuning Round Trip delay Total Window Size Scaling Factor (ms) (bytes) 32 K 32 K 1 or less 32 K Table 3-1. T1 / DS-1: 1.554 Mbits/Sec Round Trip Delay Total Window Size Scaling Factor (ms) (bytes) 1 MB 512 K...
Page 45: Ds-5: 400 Mbits/Sec
3 – Planning Performance Tuning Table 3-3. DS-5: 400 Mbits/Sec Round Trip Delay Total Window Size Scaling Factor (ms) (bytes) 1 MB 512 K 256 K 128 K 128 K 64-128 K 1 or 2 64 K 32 K 32 K 1 or less 32 K Table 3-4.
Page 46: Topology
512 K 256 K 1 or less 64 K Table 3-6. OC-12 and Above: 621 Mbits/Sec Topology The SANbox 6142 supports two distinct topologies, interconnecting local SANs (see figure 3-1) and interconnecting remote SANs (see figure 3-2). Figure 3-1. LAN Topology - Local SAN Interconnect...
Page 47: Fibre Channel Switch Ports And Zoning Requirements
(FL-Port) or generic port (G-Port). The SANbox 6142 uses its local FC ports for discovering local FC devices in the SAN. Please add the SANbox 6142 router’s FC world wide port names (WWPN) in all local switch zones and the remote SANbox 6142 router’s FC WWPNs in all...
Page 48: Recovery
3 – Planning Recovery The router supports the following management interfaces: GUI. Graphical user interface application, which executes on a management ■ workstation (see section 7) CLI. Command line interface, which executes on the router and is accessed via ■ telnet or the serial port (see appendix A) SNMP.
Page 49: Security
3 – Planning Security Network time protocol (NTP). Provides for synchronizing the router and the ■ workstation dates and times with an NTP server. NTP is disabled (and not configured) by default. File transfer protocol (FTP). Provides for transferring files rapidly between the ■...
Page 50 3 – Planning Security 3-10 FI0054601-00 A...
Page 51: Installation
Section 4 Installation This section describes how to install, configure, and recover a disabled SANbox 6142 router. It also includes firmware installation instructions. Site Requirements The requirements in the following sections must be met when installing a SANbox 6142 router: Management Workstation (see section 4.1.1)
Page 52: Power Requirements
Installing the SANbox 6142 Router 4.1.2 Power Requirements Power requirements for the SANbox 6142 router are 0.5 Amps at 100-125 VAC, 50 Hz to 60 Hz or 0.25 Amps at 200-240 VAC, 50 Hz to 60 Hz. 4.1.3 Environmental Conditions Consider the factors that affect the climate in your facility, such as equipment heat dissipation and ventilation.
Page 53: Pre-Installation Check List
4 – Installation Installing the SANbox 6142 Router Perform the following steps to install the SANbox 6142 router: 1. Complete the pre-installation checklist (see section 4.2.1). 2. Mount the router (see section 4.2.2). 3. Install the transceivers (see section 4.2.3).
Page 54: Mount The Router
You can place the router on a flat surface or mount it in a standard 19-inch Electronic Industries Association (EIA) rack. See the product specification for weight and dimensions. Rack mounting requires a QLogic rack mounting kit (Part No. ontact QLogic for more information.
Page 55: Configure The Management Workstation
4 – Installation Installing the SANbox 6142 Router 4.2.5 Configure the Management Workstation If you plan to use CLI to configure and manage the router, you must configure the workstation. This involves setting the workstation IP address for Ethernet connections, or configuring the workstation serial port. If you plan to use SANsurfer iSCSI/FC Router Manager to manage the router, the Configuration Wizard manages the workstation IP address for you.
Page 56 4 – Installation Installing the SANbox 6142 Router 2. Configure the workstation serial port according to your platform. These steps may vary according to the version of Windows you use: For Windows: ❑ a. Open the HyperTerminal application. Click Start. Click Programs>...
Page 57: Install Sansurfer Iscsi/Fc Router Manager
4 – Installation Installing the SANbox 6142 Router 4.2.6 Install SANsurfer iSCSI/FC Router Manager You can manage the router using the SANsurfer iSCSI/FC Router Manager application. The following sections describe how to install the application on either a Windows or Linux workstation. See...
Page 58: Start Sansurfer Iscsi/Fc Router Manager
4 – Installation Installing the SANbox 6142 Router 4.2.7 Start SANsurfer iSCSI/FC Router Manager For Windows, double-click the SANsurfer iSCSI/FC Router Manager shortcut, or select SANsurfer iSCSI/FC Router Manager from the Start menu, depending on how you installed the SANsurfer iSCSI/FC Router Manager application. From a command line, you can enter the SANsurfer_Router_Manager command: <install_directory>SANsurfer_Router_Manager.exe...
Page 59: Configure The Router
4 – Installation Installing the SANbox 6142 Router 4.2.9 Configure the Router You can configure the router using the SANsurfer iSCSI/FC Router Manager application or the command line interface (CLI). To configure the router using the SANsurfer iSCSI/FC Router Manager, in the Initial Start dialog box, click Open Configuration Wizard.
Page 60: Cable Devices To The Router
Installing new firmware is disruptive because the router must be rebooted to activate the new firmware. The reboot may result in incorrect data being transferred between devices connected to the router. QLogic recommends that activity on the interfaces be suspended before activating the new firmware. 4.3.1...
Page 61: Using The Cli To Install Firmware
4 – Installation Install the Firmware 3. Click Start to begin the firmware load process. You will be shown a message warning you that the router will be reset to activate the firmware. 4. Click OK to continue firmware installation or click the Cancel button to cancel the firmware installation.
Page 62 4 – Installation Install the Firmware 6. Log on to the router as an administrator. (none) login: guest Password: password ****************************************************** QLogic Router Command Line Interface (QRCLI) ****************************************************** QRouter#> admin start Password : config QRouter (admin) #> 7. Type the following command from the router, where x stands for the firmware image name: image unpack isr-6142-2_2_0_x.bin...
Page 63 4 – Installation Install the Firmware Notes FI0054601-00 A 4-13...
Page 64 4 – Installation Install the Firmware 4-14 FI0054601-00 A...
Page 65: Diagnostics And Troubleshooting
Section 5 Diagnostics and Troubleshooting Diagnostic information about the router is available through the chassis LEDs and the port LEDs. Diagnostic information is also available through the SANsurfer iSCSI/FC Router Manager and CLI event logs and error displays. This section describes the following types of diagnostics: Chassis Diagnostics (see section 5.1)
Page 66: System Fault Led Is Illuminated
5 – Diagnostics and Troubleshooting Power-On Self-Test Diagnostics Inspect AC power source. Is the power source delivering the proper voltage? ■ Yes – Continue. ❑ No – Make the necessary repairs. If the condition remains, continue. ❑ Replace the router. ■...
Page 67: Normal Heartbeat Blink Pattern
5 – Diagnostics and Troubleshooting Heartbeat LED Blink Patterns 5.3.1 Normal Heartbeat Blink Pattern A blink pattern of one second ON followed by one second OFF means that the router is operating normally. 5.3.2 Beacon Blink Pattern 5.3.3 System Error Blink Pattern A three-blink pattern (once per second) followed by a two second pause means a system error.
Page 68: Recovering A Router
5 – Diagnostics and Troubleshooting Recovering a Router If the heartbeat LED shows the over temperature blink pattern, do the following: Inspect the chassis air vents. Are the intake and exhaust vents clear? ■ Yes – Continue ❑ No – Remove any debris from the fan intake and exhaust if necessary. If the ❑...
Page 69: Removal/Replacement
Section 6 Removal/Replacement This section describes the removal and replacement procedures for the following field replaceable units (FRU): SFP transceivers ■ The Router ■ SFP Transceiver Removal and Replacement The SFP transceivers can be removed and replaced while the router is operating without damaging the router or the transceiver.
Page 70: Replacement
6 – Removal/Replacement Router Removal and Replacement 5. Label all the cables so that they can be connected to the same ports on the replacement router. 6. Remove all the Fibre Channel and Ethernet cables. 7. Remove the router from the enclosure where it is mounted. 6.2.2 Replacement Before replacing a router, it must first be removed (perform the procedure in...
Page 71: Sansurfer Iscsi/Fc Router Manager
Introduction The SANsurfer iSCSI/FC Router Manager graphical user interface (GUI) allows you to manage the SANbox 6142 router from a workstation. Information can be monitored, configured, and modified. The SANsurfer iSCSI/FC Router Manager consists of a menu bar, a tool bar, a system tree, and information/status/data...
Page 72: Menu Bar
7 – SANsurfer iSCSI/FC Router Manager Menu Bar Table 7-1. GUI Main Window Sections Item Description Menu Bar The menu bar provides access to system functions and Wizards. Tool Bar The tool bar buttons provide quick access to the common application functions—Connect, View Logs, and Refresh.
Page 73: File Menu
7 – SANsurfer iSCSI/FC Router Manager Menu Bar 7.2.1 File Menu Figure 7-3 shows the File menu. The following paragraphs described it. Figure 7-3. File Menu Save FRU: Saves the router’s configuration and persistent data to a file. ■ Restore FRU: Restores the router’s configuration and persistent data from a file. ■...
Page 74: Settings Menu
7 – SANsurfer iSCSI/FC Router Manager Menu Bar 7.2.3 Settings Menu Figure 7-5 shows the Settings menu. The following paragraph describes it. Figure 7-5. Settings Menu Broadcast: opens the Broadcast Settings window, which allows you to configure ■ the broadcast options. The workstation sends Broadcast messages to locate routers within the same IP subnet as the workstation running the SANsurfer Router Manager application.
Page 75: Wizards Menu
7.6.2. FW Update Wizard: launches the Firmware Update wizard, which allows you to ■ update the SANbox 6142 router’s firmware image. You can select the firmware image from a menu that allows browsing. See section 7.6.3. Map Local Initiator/Target Wizard: launches the Map Local wizard, which ■...
Page 76: Help Menu
7 – SANsurfer iSCSI/FC Router Manager Menu Bar Remove Remote Router Wizard: launches the Remove Remote Router wizard, ■ which allows you to remove a local-to-remote router peer assignment. section 7.6.7. Map Remote Initiator/Target Wizard: launches the Map Remote wizard, which ■...
Page 77: Tool Bar
You can move the tool bar in the display by clicking and dragging the handle at the tool bar’s left edge. Connect: adds a SANbox 6142 router to the system tree view. ■...
Page 78: Action Menu
GUI. The following paragraphs illustrate and describe the Action menu. Figure 7-10. Action Menu Connect: adds a SANbox 6142 router to the system tree view. ■ Refresh: updates the display with current information.
Page 79 Remove Offline Target: removes the selected offline Fibre Channel target. This ■ option is available only when an offline FC target is selected (highlighted) in the system tree. Beacon ON: turns on the SANbox 6142 router beacon to locate the router ■ quickly. Beacon OFF: turns off the SANbox 6142 router beacon.
Page 80: System Tree Window
The following paragraphs described it. Figure 7-11. System Tree Window The left most window pane shows the system tree. The system tree includes the connected SANbox 6142 routers and the following components for each router: FC (Fibre Channel) ports (see section 7.5.2) ■...
Page 81: Sanbox 6142 Router
This data includes: Information ■ Configuration ■ Status ■ Lists ■ 7.5.1 SANbox 6142 Router The top of the router tree displays the router system configuration and status. It contains the following tabs: Information ■ SNMP Management ■ Security ■...
Page 82: Information Tab
Information, and Network Time Protocol (NTP) Server Information. It also contains three buttons: Reboot, FW Load, and Restore Defaults. Figure 7-13 shows the Information tabbed page. The following paragraphs describe it. Figure 7-13. Information Tabbed Page (SANbox 6142 Router) Basic Information ■ Product Name: Model iSR6142. ❑...
Page 83 7 – SANsurfer iSCSI/FC Router Manager System Tree Window uses Symbolic Name: enable/disable the use of the symbolic name in ❑ the router’s iSCSI name. Hardware Version: the router’s hardware version number. ❑ Software Version: the router’s software version number. ❑...
Page 84: Snmp Management Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window NTP Server 3: IP address of the third NTP server the router queries when ❑ setting its time and date. This server is used only if the first and second NTP servers did not respond.
Page 85 7 – SANsurfer iSCSI/FC Router Manager System Tree Window System Description: text that describes the location of the router. ❑ Read Community: a password that authorizes an SNMP management server ❑ to read information from the router. This is a write-only field. The value on the router and the SNMP management server must be the same.
Page 86: Security Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.1.3 Security Tab Figure 7-15 shows the Security tabbed page that enables you to set the router’s password. The following paragraphs describe the page. Figure 7-15. Security Tabbed Page Current Password: You must supply the current password before you can ■...
Page 87: Features Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.1.4 Features Tab Figure 7-16 shows the Features tabbed page that displays the routers licensed features and lets you apply additional license features. The following paragraphs described the page. Figure 7-16. Features Tabbed Page License Information: a list of the routers licensed features.
Page 88: Topology Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.1.5 Topology Tab Figure 7-17 shows the Topology tabbed page that displays the routers. The following paragraphs described the page. Figure 7-17. Topology Tabbed Page. 7-18 FI0054601-00 A...
Page 89: Fc Ports
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.2 FC Ports When you select an FC port in the system tree, the system displays the FC Port Information tabbed page (see figure 7-18). Figure 7-18. FC Port Information Tab Here is the FC port information: Node Name: the world-wide node name (WWNN) assigned to the FC port.
Page 90: Fc Port Advanced Configuration Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window When you select an FC port in the system tree, the system displays the Advanced Configuration tabbed page (see figure 7-19). Figure 7-19. FC Port Advanced Configuration Tab The following FC port advanced configuration is displayed: Connection Options: the connections are not changeable.
Page 91: Fc Port Performance Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window When you select an FC port in the system tree, the system displays the Performance tabbed page (see figure 7-20). Figure 7-20. FC Port Performance Tab The following FC port performance information is displayed: Initiator Read: the initiator’s read performance through the selected FC port.
Page 92: Iscsi Ports
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.3 iSCSI Ports When you select an iSCSI port in the system tree, the system displays the Information, Advanced Configuration, and Statistics tabbed pages to the right of the tree (see figure 7-21).
Page 93 7 – SANsurfer iSCSI/FC Router Manager System Tree Window Port Information ■ MAC Address: the MAC address assigned to the port. This address cannot ❑ be changed. iSCSI Port Network Settings ■ IP Address: the IP address to which the port responds. An uninitialized port ❑...
Page 94: Advanced Configuration Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window VLAN ID: when VLAN is enabled, the VLAN ID contains an identification value ❑ of 0–255. The VLAN ID can be configured from this window. When you change this setting, you must click Save (at the bottom of the page) for the change to take effect.
Page 95 TCP Max Window Size: the TCP maximum window size. ■ Target TCP Port Number: the TCP port number used by the SANbox 6142 ■ router to receive iSCSI target commands. The iSCSI community uses TCP port number 3260 by default. If you change this setting, you must also make the corresponding change in all iSCSI initiators connecting to this iSCSI target.
Page 96: Statistics Tab
Header digest is an ISCSI feature that adds a validity check field to iSCSI PDU headers to verify that no corruption has occurred during the transmission of the PDU header. The SANbox 6142 router supports digest in its hardware to maximize performance. When you change this setting, you must click Save (at the bottom of the page) for the change to take effect.
Page 97: Discovered Iscsi Initiators
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Figure 7-23. iSCSI Statistics Tabbed Page 7.5.5 Discovered iSCSI Initiators Selecting the Discovered iSCSI Initiators branch on the system tree does not provide any information in the right window. Select a discovered iSCSI initiator in the system FI0054601-00 A 7-27...
Page 98: Information Tab
❑ iSCSI Alias: the iSCSI initiator’s alias, which is provided by the initiator when ❑ it logs into the SANbox 6142 router. OS Type Selection: the operating system (OS) type for the discovered ❑ initiator. The OS type is used by the...
Page 99: Local Presented Target Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.5.2 Local Presented Target Tab The Local Presented Target tabbed page consists of a scrollable list of logical unit numbers (LUNs) mapped to the iSCSI initiator, as shown in Figure 7-25 described in the following paragraphs.
Page 100: Remote Presented Target Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.5.3 Remote Presented Target Tab The Remote Presented Target tabbed page consists of a scrollable list of LUNs mapped to the iSCSI initiator, as shown in Figure 7-26 and described in the following paragraphs.
Page 101: Fc Discovered Targets
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.6 FC Discovered Targets Selecting an FC discovered target in the system tree does not provide any information in the right window. Select a discovered FC target to display the Information, LUN List, and iSCSI Presented Target List tabbed pages to the right of the system tree (see figure 7-27).
Page 102: Remote Presented Devices Tab
7 – SANsurfer iSCSI/FC Router Manager System Tree Window 7.5.6.2 Remote Presented Devices Tab The Remote Presented Devices tabbed page provides detailed target information and a scrollable list of LUNs, as shown in Figure 7-28 and described in the following paragraphs.
Page 103: Iscsi Presented Target List Tabbed Page
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Target Type: the FC port where the target device was discovered. ❑ Target Path: the logical unit number. ❑ Target Mode: the vendor name of the LUN as reported by the SCSI Inquiry ❑...
Page 104: Iscsi Discovered Targets
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Device Product Vendor: the vendor name of the target device as reported by ■ the SCSI Inquiry command. Device Product ID: the product ID name of the target device as reported by the ■...
Page 105: Information Tabbed Page
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Figure 7-30. iSCSI Discovered Targets Tabbed Pages 7.5.7.1 Information Tabbed Page The Information tabbed page consists of two sections, General Information and CHAP Settings, which are described in the following paragraphs. General Information ■...
Page 106: Iscsi Presented Targets
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Enable CHAP: a check box to enable CHAP when connecting to this target. ❑ If you change the check box, you must click Save for the change to take effect CHAP Secret: the string used for the CHAP secret when connecting to ❑...
Page 107: Fcip Routes
7 – SANsurfer iSCSI/FC Router Manager System Tree Window General Information ■ Product Vendor: the product vendor as reported by the SCSI Inquiry ❑ command. Product ID: the product ID as reported by the SCSI Inquiry command. ❑ Product Revision: the product revision as reported by the SCSI Inquiry ❑...
Page 108: Fcip Route Information Tabbed Page
7 – SANsurfer iSCSI/FC Router Manager System Tree Window Figure 7-32. FCIP Route Tabbed Pages 7.5.9.1 FCIP Route Information Tabbed Page The FCIP Route Information tabbed page contains the information described in the following paragraphs. 7-38 FI0054601-00 A...
Page 109 7 – SANsurfer iSCSI/FC Router Manager System Tree Window FCIP Interface Status: provides a dialog box for enabling and disabling the FCIP ■ route. When the route is disabled the FC and GE ports are placed in a down state. All route configuration parameters are retained. If you change this setting, you must click Save (at the bottom of the page) for the change to take effect.
Page 110 7 – SANsurfer iSCSI/FC Router Manager System Tree Window TCP Port Number: provides a dialog box that allows you to define the destination ■ TCP port number used by the FCIP route. This port number must be the same on both routers participating in the FCIP route (local and remote routers must be using same port number).
Page 111 7 – SANsurfer iSCSI/FC Router Manager System Tree Window FCIP Timestamp: provides a dialog box for enabling and disabling FCIP ■ timestamps. The default is enabled. If you change this setting, you must click Save (at the bottom of the page) for the change to take effect. FCIP SW Compression: provides a dialog box for enabling and disabling FCIP ■...
Page 112: Wizards
7 – SANsurfer iSCSI/FC Router Manager Wizards Wizards The Wizards menu contains step-by-step programs that help you configure and manage the SANbox 6142 router (see figure 7-33). Figure 7-33. Wizards Menu The Wizards menu includes following programs: Configuration Wizard: this wizard is a step-by-step procedure for configuring ■...
Page 113 7 – SANsurfer iSCSI/FC Router Manager Wizards Map Local Initiator/Target Wizard: launches the Map Local wizard, which ■ allows you to map a local initiator to a local target. For more information, see section 7.6.4. Unmap Local Initiator/Target Wizard: launches the Unmap Local wizard, which ■...
Page 114: Configuration Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards 7.6.1 Configuration Wizard The Configuration wizard is a step-by-step procedure for configuring the iSCSI ports. This wizard starts automatically when you connect something to a system that has unconfigured iSCSI ports. Perform the following steps to configure iSCSI ports: 1.
Page 115: Iscsi Port Connection Settings Panel Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 2. The iSCSI Port Connection Settings Panel dialog box displays (see figure 7-35). Figure 7-35. iSCSI Port Connection Settings Panel Dialog Box Type the information in the following fields, then click Next. IP Address ❑...
Page 116: Confirm Changes Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 4. The Confirm Changes dialog box displays (see figure 7-36). Figure 7-36. Confirm Changes Dialog Box Read the information, then do the following: a. If you want to save a copy of this port configuration, click Save Configuration to File.
Page 117: Iscsi Port Configuration Status—Warning Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 5. The system displays the iSCSI Port Configuration Status dialog, along with a warning (see figure 7-37). Figure 7-37. iSCSI Port Configuration Status—Warning Dialog Box Read the warning. If you want to proceed, click Yes and continue with step Otherwise, click No.
Page 118: Iscsi Port Configuration Status—Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 6. The system displays the Security Check dialog box (see figure 7-38). Figure 7-38. iSCSI Port Configuration Status—Security Check Dialog Box Type the password, then click OK. 7-48 FI0054601-00 A...
Page 119: Iscsi Port Configuration Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 7. The system displays the iSCSI Port Configuration Status dialog box (see figure 7-39). Read the information, then click Next. Figure 7-39. iSCSI Port Configuration Status Dialog Box FI0054601-00 A 7-49...
Page 120: Refresh Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 8. The system displays the Refresh dialog box (see figure 7-40). Read the information. If you would like to see the new configuration, click Yes; otherwise, click No. Figure 7-40. Refresh Dialog Box 7-50 FI0054601-00 A...
Page 121: Add Initiator Wizard
(their name and address are captured) the first time they log in to the SANbox 6142 router. This wizard allows you to enter the initiator information before the log in, thus...
Page 122: Create An Initiator Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Perform the following steps to add an iSCSI initiator to the SANbox 6142 router: 1. When the wizard launches, the system displays the Create an initiator dialog (see figure 7-42). Figure 7-42. Create an Initiator Dialog Box Do the following: a.
Page 123: Fw Update Wizard
Figure 7-44. System Tree with New iSCSI Initiator 7.6.3 FW Update Wizard The Firmware Update wizard provides step-by-step instructions for updating the SANbox 6142 router firmware. Perform the following steps to update the router’s firmware: 1. When the FW Update wizard launches, the system displays the Router...
Page 124: Firmware File Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 2. The Firmware File Selection dialog box displays (see figure 7-46). Figure 7-46. Firmware File Selection Dialog Box a. Enter in the path to the firmware file, or click Browse to locate the firmware file.
Page 125: Confirm Changes Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 3. The Confirm Changes dialog box displays (see figure 7-47). Figure 7-47. Confirm Changes Dialog Box Read the information, then do the following: a. If you want to save a copy of this firmware configuration, click Save Configuration to File.
Page 126: Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 4. The Security Check dialog box requests the Admin password (see figure 7-48). Type the appropriate password, then click OK to start the firmware update. Figure 7-48. Security Check Dialog Box 7-56 FI0054601-00 A...
Page 127: Firmware Update Status Dialog Box—Progress
7 – SANsurfer iSCSI/FC Router Manager Wizards 5. The Firmware Update Status dialog box shows the progress of the update in the message section (see figure 7-49). Figure 7-49. Firmware Update Status Dialog Box—Progress FI0054601-00 A 7-57...
Page 128: Map Local Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards When the firmware has loaded successfully, the system displays the Finish dialog box, along with the Update success dialog box (see figure 7-50). Figure 7-50. Finish Dialog Box (Successful Firmware Update) Do the following: a.
Page 129: Initiator Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards figure 7-51). Select the check box next to the initiator you want to map, then click Next. Figure 7-51. Initiator Selection Dialog Box FI0054601-00 A 7-59...
Page 130: Select A Target Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 2. The Select a Target dialog box displays a list of the locally connected targets (see figure 7-52). Select the check box next to the initiator you want to map, then click Next. Figure 7-52.
Page 131: Select Initiator Port Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards selected is the port where the local target device being mapped is connected. Select a port, then click Next. Figure 7-53. Select Initiator Port Dialog Box 4. The Select Target Presentation Port dialog box requests the selection of a router port on which the target is presented (see figure 7-53).
Page 132: Select Target Presentation Port Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards selected is the port where the local initiator device being mapped is connected. Select a port, then click Next. Figure 7-54. Select Target Presentation Port Dialog Box 7-62 FI0054601-00 A...
Page 133: Confirm Changes Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 5. The Confirm Changes dialog box displays the local mapping done in the previous steps (see figure 7-55). Review the information, then click Next. Figure 7-55. Confirm Changes Dialog Box FI0054601-00 A 7-63...
Page 134: Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 6. The Security Check dialog box requests the Admin password (see figure 7-56). Type the appropriate password, then click OK to confirm the local mapping. Figure 7-56. Security Check Dialog Box 7-64 FI0054601-00 A...
Page 135: Initiator/Target Mapping Configuration Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 7. The Initiator/Target Mapping Configuration Status dialog box displays local mapping completion status (see figure 7-57). After reviewing the status, click Next. Figure 7-57. Initiator/Target Mapping Configuration Status Dialog Box FI0054601-00 A 7-65...
Page 136: Unmap Local Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards 8. After completing the Map Local Initiator/Target wizard, you can see the mapping by selecting the mapped Initiator in the system tree under Discovered iSCSI Initiators. Click the Local Presented Devices tab (see figure 7-58).
Page 137: Initiator Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards figure 7-59). Select the check box next to the initiator you want to unmap, then click Next. Figure 7-59. Initiator Selection Dialog Box FI0054601-00 A 7-67...
Page 138: Presented Target Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 2. The Presented Target Selection dialog box displays a list of targets mapped to the initiator selected in the previous step (see figure 7-60). Select the check box next to the target to unmap, then click Next. Presented Target Selection Figure 7-60.
Page 139: Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 3. The Security Check dialog box requests the Admin password (see figure 7-61). Type the appropriate password, then click OK to confirm the target is unmapped. Presented Target Selection Figure 7-61. Security Check Dialog Box FI0054601-00 A 7-69...
Page 140: Unpresent Initiator/Target Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 4. The Unpresent Initiator/Target Status dialog box displays the results of the unmap operation (see figure 7-62). Review the status, then click Next. Presented Target Selection Figure 7-62. Unpresent Initiator/Target Status Dialog Box 5.
Page 141: Add Remote Router Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards example an iSCSI initiator was unmapped from an FC target. Figure 7-58 shows the original mapping. Presented Target Selection Figure 7-63. Discovered iSCSI Initiators - Local Presented Targets 7.6.6 Add Remote Router Wizard The add remote router wizard provides step-by-step instructions for assigning a remote router to your local router as a peer.
Page 142: Remote Router's Ip Address Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Perform the following steps to add a remoter router to a local router: 1. When the Add Remote Router wizard launches, the Remote Router’s IP Address dialog box requests the remote router’s IP address (see figure 7-64).
Page 143: Local Router Admin Password Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 2. The Status dialog box displays the remote router information (see figure 7-65) along with the Local Router Admin Password dialog box. Type the local router admin password (default=config), then click OK. Figure 7-65. Local Router Admin Password Dialog Box FI0054601-00 A 7-73...
Page 144: Remote Router Admin Password Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 3. The Status dialog box displays the remote router information (see figure 7-66) along with the RemoteRouter Admin Password dialog box. Type the remote router admin password (default=config), then click OK. Figure 7-66. Remote Router Admin Password Dialog Box 7-74 FI0054601-00 A...
Page 145: Add Remote Router Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 4. The Status dialog box displays the remote router information (see figure 7-67). Review the status. If it is OK, click Finish. Figure 7-67. Add Remote Router Status Dialog Box FI0054601-00 A 7-75...
Page 146: Assigned Remote Router Display
7 – SANsurfer iSCSI/FC Router Manager Wizards 5. The Assigned Remote Router:1 tab displays the remote router’s information (see figure 7-68). Figure 7-68. Assigned Remote Router Display 7-76 FI0054601-00 A...
Page 147: Remove Remote Router Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards 6. The Topology tab displays the local and remote router topology including devices attached to both routers (see figure 7-69). Figure 7-69. Topology Display 7.6.7 Remove Remote Router Wizard The Remove Remote Router wizard provides step-by-step instructions for removing a remote router from the local router.
Page 148: Select Remote Router Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Perform the following steps to remove a remoter router from a local router: 1. When the Remove Remote Router wizard launches, the Select a Remote Router to unmap dialog box displays a list of mapped routers (see figure 7-70).
Page 149: Local Router Admin Password Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 2. The Local Router Admin Password dialog box requests the local router’s admin password to complete the unmap (see figure 7-71). Type the local router’s admin password (default=config), then click OK. Figure 7-71. Local Router Admin Password Dialog Box FI0054601-00 A 7-79...
Page 150: Map Remote Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards 3. The Remove Remote Router Completion dialog box displays the completion status (see figure 7-72). Review the results, then click OK. Figure 7-72. Remove Remote Router Completion Dialog Box 7.6.8 Map Remote Initiator/Target Wizard The Map Remote Initiator/Target wizard provides step-by-step instructions for mapping an initiator to a target one of which is remote and the other local.
Page 151: Device Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards device may be a target or an initiator and may be either on the remote router or on the local router. Click Next. Figure 7-73. Device Selection Dialog Box 2. The Device Selection dialog box displays list of devices (see figure 7-74).
Page 152: Device Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards to be mapped. The device may be a target or an initiator and may be on either the remote router or on the local router. Click Next. Device Selection Figure 7-74. Device Selection Dialog Box 7-82 FI0054601-00 A...
Page 153: Device Mapping Option Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 3. The Device Mapping Option dialog box displays mapping options (see figure 7-75). Enable or Disable options as you want, then click Next. Device Selection Figure 7-75. Device Mapping Option Dialog Box FI0054601-00 A 7-83...
Page 154: Confirm Mapping Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 4. The Confirm Mapping dialog box displays the mapping and option selections (see figure 7-76). Review the information and, if correct, click Next. Device Selection Figure 7-76. Confirm Mapping Dialog Box 7-84 FI0054601-00 A...
Page 155: Local Router Admin Password Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 5. The Remote Mapping Status dialog box displays the mapping status (see figure 7-77) along with the Local Router Admin Password dialog box. Type the local router admin password (default=config), then click OK. Device Selection Figure 7-77.
Page 156: Remote Mapping Status Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 6. The Remote Mapping Status dialog box displays the mapping status (see figure 7-78). Review the status information, then click Next. Device Selection Figure 7-78. Remote Mapping Status Dialog Box 7-86 FI0054601-00 A...
Page 157: Unmap Remote Initiator/Target Wizard
7 – SANsurfer iSCSI/FC Router Manager Wizards 7. After completing the Map Remote Initiator/Target wizard, you can see the mapping by selecting the mapped Initiator in the system tree under Discovered FC Initiators. Then select Remote Presented Devices (see figure 7-79).
Page 158: Device Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Perform the following steps to unmap an initiator and target: 1. When the Unmap Remote Initiator/Target wizard launches, the Device Selection dialog box displays a list of remote mapped devices (see figure 7-80). Select the device to be unmapped, then click Next.
Page 159: Local Router Admin Password Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 2. The Local Router’s Admin Password dialog box requests the local router’s admin password to continue with the unmap (see figure 7-81). Type the local router’s admin password (default=config), then click OK. Figure 7-81. Local Router Admin Password Dialog Box FI0054601-00 A 7-89...
Page 160: Discover Iscsi Target
7 – SANsurfer iSCSI/FC Router Manager Wizards 3. The Remote Unmap Initiator-Target Status dialog box displays the status of the unmap operation (see figure 7-82). Review the status, then click Next. Figure 7-82. Remote Unmap Initiator-Target Status Dialog Box 7.6.10 Discover iSCSI Target The Discover iSCSI Target wizard provides step-by-step instructions for discovering an iSCSI target.
Page 161: Discover Iscsi Target Wizard—Ip Address Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards (see figure 7-83). After entering the IP address and selecting the GE port, click Finish to initiate the discovery operation. Or click Cancel to quit the wizard Figure 7-83. Discover iSCSI Target Wizard—IP Address Dialog Box 2.
Page 162: Discover Iscsi Target Wizard—Refresh Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-85. Discover iSCSI Target Wizard—Refresh Dialog Box 4. After the refresh is complete you can see the Discovered iSCSI Target in the system tree (see figure 7-86). Figure 7-86. iSCSI Discovered Targets 7-92 FI0054601-00 A...
Page 163: Fcip Route Add
7 – SANsurfer iSCSI/FC Router Manager Wizards 7.6.11 FCIP Route Add The FCIP Route Add Wizard provides step-by-step instructions for adding an FCIP route. Perform the following steps to add an FCIP route: 1. When the FCIP Route Add Wizard launches, it displays a warning (see figure 7-87) cautioning that the operation about to be performed will change...
Page 164: Fcip Route Add Wizard—Port Selection Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-88. FCIP Route Add Wizard—Port Selection Dialog Box Additionally, you can configure the following port route/parameters: FCIP Interfaces FC & GE: provides a dialog box for enabling and ■ disabling the FCIP route. When the route is disabled the FC and GE ports are placed in a down state.
Page 165: Fcip Route Add Wizard—Local And Remote Ip Address Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-89. FCIP Route Add Wizard—Local and Remote IP Address Dialog Box The following parameters are configured: Local IP Address: the IP address to be used by the GigE port. An ■ uninitialized port has an IP address of all zeros. Subnet Mask: the subnet mask used by the GigE port.
Page 166: Fcip Route Add Wizard—Tcp/Ip Options Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Figure 7-90. FCIP Route Add Wizard—TCP/IP Options Dialog Box The following parameters are configured: Jumbo Frames: provides a dialog box for enabling and disabling ■ Jumbo IP frames. When disabled the MTU is 1500 bytes. When enabled the MTU is 9000 bytes.
Page 167: Fcip Route Add Wizard—Fcip Options Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards VLAN Priority: provides a dialog box that contains eight options for ■ the VLAN priority; 0 through 7. This dialog box is available only when VLAN is enabled. After setting the TCP/IP parameters, click Next to continue. Or click Cancel to quit the wizard.
Page 168: Fcip Route Remove
7 – SANsurfer iSCSI/FC Router Manager Wizards Bandwidth (Mbit/sec): provides a dialog box that allows you to define ■ the maximum bandwidth (in megabits per second) used by the GigE port during transmits. The range of values supported is 1 to 1000 megabits per second.
Page 169: Fcip Route Remove Wizard—Warning Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards Perform the following steps to remove an FCIP route: 1. When the FCIP Route Remove wizard launches, it displays a warning (see figure 7-94) cautioning that the operation about to be performed will change the operation of the selected GE and FC ports.
Page 170: Fcip Route Remove Wizard—Security Check Dialog Box
7 – SANsurfer iSCSI/FC Router Manager Wizards 3. The Security Check dialog box requests the administrator password (see figure 7-96). Type the appropriate password, then click OK to confirm the removal of the FCIP route. Figure 7-96. FCIP Route Remove Wizard—Security Check Dialog Box 4.
Page 171 7 – SANsurfer iSCSI/FC Router Manager Wizards Notes FI0054601-00 A 7-101...
Page 172 7 – SANsurfer iSCSI/FC Router Manager Wizards 7-102 FI0054601-00 A...
Page 173: Appendix A Command Reference
Appendix A Command Reference The command line interface (CLI) enables you to perform a variety of router management tasks through an Ethernet or serial port connection. This section describes the following: Logging On to a SAN Router (see section A.1) ■...
Page 174: Working With San Router Configurations
A – Command Reference Working with SAN Router Configurations Working with SAN Router Configurations Successful management of routers with the command line interface depends on the effective use of router configurations. Modifying configurations, backing up configurations, and restoring configurations are key router management tasks. A.3.1 Modifying a Configuration The router has three major areas of configuration:...
Page 175: Restore Router Configuration And Persistence
A – Command Reference Working with SAN Router Configurations 230 Guest login ok, access restrictions apply. ftp> bin 200 Type set to I. ftp> get iSR-6142_FRU.bin 200 PORT command sucessful. 150 Opening BINARY mode data connection for 'iSR-6142_FRU.bin' (6168 bytes). 226 Transfer complete.
Page 176: Commands
A – Command Reference Commands Commands The CLI command syntax is as follows: command keyword keyword [value] keyword [value1] [value2] The command is followed by one or more keywords. Consider the following rules and conventions: Commands and keywords are case insensitive. ■...
Page 177: Admin Command
A – Command Reference Admin Command Admin Command Opens and closes the an administrator session. Any command that changes the router configuration requires that the user be in an Admin session. Only one Admin session can be open on the router at any time. An inactive Admin session will time out after 15 minutes.
Page 178: Beacon Command
A – Command Reference Beacon Command Beacon Command Enables or disables the Heartbeat and System Fault LEDs flashing. The heartbeat and system fault LEDs flash synchronously (on and off, together). No other LEDs are affected. Authority Admin session Syntax beacon Keywords Turns on the router beacon.
Page 179: Clear Command
A – Command Reference Clear Command Clear Command The clear command provides two operations: it removes all entries from the router’s log file, or it resets the Fibre Channel and iSCSI statistic counters. Authority Admin session Syntax clear [logs or stats] Parameters logs Clears all entries from router’s log file.
Page 180: Date Command
A – Command Reference Date Command Date Command This command displays or sets the date and time. To set the date and time, the information string must be provided in this format: MMDDhhmmCCYY. The new date and time takes effect immediately. Authority Admin session to set the date and time.
Page 181: Fciproute Command
A – Command Reference FcipRoute Command FcipRoute Command The FCIP route command provides for configuring an new FCIP route and modifying or deleting an existing FCIP route. Each FCIP route requires a dedicated FC and Gigabit Ethernet port. Configuring an FCIP route, specifying an FC and GE port pair, take precedence over any previous configuration for the port pair (FC/GE).
Page 182 A – Command Reference FcipRoute Command Examples The following is an example of the FCIP route add command: QRouter (admin) #> fciproute add A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 183 A – Command Reference FcipRoute Command Examples The following is an example of the FCIP route modify command: QRouter (admin) #> fciproute mod A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 184 A – Command Reference FcipRoute Command Examples The following is an example of the FCIP route remove command: QRouter (admin) #> fciproute rm A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 185: Fru Command
A – Command Reference FRU Command A.10 FRU Command The FRU command saves and restores the router’s configuration. Authority Admin session to restore. Syntax restore save Keywords restore The FRU restore command requires that you first ftp the tar file containing the desired configuration to the router.
Page 186: Help Command
A – Command Reference Help Command A.11 Help Command The help command displays a list of the commands and their syntax. Authority None Syntax help Examples The following is an example of the Help command: QRouter #> help admin [ cancel | start | end ] beacon [ on | off ] date [ <MMDDhhmmCCYY>...
Page 187 A – Command Reference Help Command set snmp [trap_destinations [ <DEST_NUM> ]] set system show [ chap | fc | fciproutes features | initiators | iscsi isns | localmaps | logs memory | mgmt | ntp perf | presented_initiators | presented_targets properties | remotemaps | remotepeers...
Page 188: History
A – Command Reference History A.12 History Displays a numbered list of the previously entered commands. Authority None Syntax History Examples The following is an example of the History command: QRouter (admin) #> history 1: admin start 2: help 3: history QRouter (admin) #>...
Page 189: Image Command
A – Command Reference Image Command A.13 Image Command Updates the router’s firmware image and cleans up (removes) the image files in the router’s /var/ftp directory. Authority Admin session Syntax image cleanup list unpack [file] Keywords cleanup Removes all firmware image files in the router’s /var/ftp directory. These are files transferred by the user when updating the router’s firmware image.
Page 190: Initiator Command
If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so. iSCSI Initiator Name (Max = 256 characters) iqn.1991-05.com.microsoft:qlogic-09sd5i4l All attribute values for that have been changed will now be saved. A-18...
Page 191 (WWNN/iSCSI Name) ----- ----------------- iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator from the list above ('q' to quit): A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 192: Localmap Command
A – Command Reference Localmap Command A.15 Localmap Command The localmap command maps a locally-connected initiator device to a locally-connected target device. The initiator and target are not on the same FC port. Authority Admin session Syntax localmap Keywords Add local initiator to target mapping. Remove local initiator to target mapping.
Page 193 A default name for the presented target is assigned below. To accept the default assigned name simply press the ENTER key or enter a new name. iSCSI presented target name [iqn.2004-08.com.qlogic:isr-6142.0608a00471.1.220000 2037fd8bab.2000002037fd8bab] : FI0054601-00 A A-21...
Page 194 A – Command Reference Localmap Command All attribute values for that have been changed will now be saved. A-22 FI0054601-00 A...
Page 195 A default name for the presented target is assigned below. To accept the default assigned name simply press the ENTER key or enter a new name. iSCSI presented target name [iqn.2004-08.com.qlogic:isr-6142.0608a00471.1.220000 2037fd8bab.2000002037fd8bab] : FI0054601-00 A A-23...
Page 196 Target Index Port Initiator (WWNN,WWPN/iSCSI Name) ----- ------ -------------------------------- iqn.1991-05.com.microsoft:qlogic-09sd5i4l Please select an Initiator to remove ('q' to quit) All attribute values for that have been changed will now be saved. A-24 FI0054601-00 A...
Page 197: Logout Command
A – Command Reference Logout Command A.16 Logout Command Exits the command line interface and returns you to the login prompt. Authority None Syntax logout Examples The following is an example of the Logout command: QRouter (admin) #> logout (none) login: FI0054601-00 A A-25...
Page 198: Password Command
A – Command Reference Password Command A.17 Password Command Changes the guest and administrator passwords. Authority Admin session Syntax password Examples The following is an example of the Password command: QRouter (admin) #> passwd Press 'q' and the ENTER key to abort this command. Select password to change (0=guest, 1=admin) account OLD password ******...
Page 199: Ping Command
A – Command Reference Ping Command A.18 Ping Command The ping command verifies the connectivity of each Ethernet port, management, GE1 (iSCSI 1), and GE2 (iSCSI 2). Authority Admin session Syntax ping Examples The following is an example of the Ping command: QRouter (admin) #>...
Page 200: Quit Command
A – Command Reference Quit Command A.19 Quit Command Exits the command line interface and returns you to the login prompt. Authority None Syntax quit Examples The following is an example of the Quit command: QRouter (admin) #> quit (none) login: A-28 FI0054601-00 A...
Page 201: Reboot Command
A – Command Reference Reboot Command A.20 Reboot Command Restarts the router firmware. Authority Admin session Syntax reboot Examples The following is an example of the Reboot command: QRouter (admin) #> reboot Are you sure you want to reboot the System (y/n): System will now be rebooted...
Page 202: Remote Map Command
A – Command Reference Remote Map Command A.21 Remote Map Command The remotemap command provides for the mapping of an initiator and target, one of which is located on a remote system (router). It queries the user for the remote system (router) then lists the devices (initiators and targets) located on the remote system.
Page 203 A – Command Reference Remote Map Command Examples The following is an example of the Remotemap add command: QRouter (admin) #> remotemap add The following wizard will create a mapping a device connected to the local system and a device connected to the selected remote peer system. If you wish to terminate this wizard before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 204 A – Command Reference Remote Map Command Example with SMART-WRITE licenses QRouter (admin) #> remotemap add The following wizard will create a mapping a device connected to the local system and a device connected to the selected remote peer system. If you wish to terminate this wizard before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 205 A – Command Reference Remote Map Command Example with no SMART-WRITE licenses QRouter (admin) #> remotemap add The following wizard will create a mapping a device connected to the local system and a device connected to the selected remote peer system. If you wish to terminate this wizard before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 206 A – Command Reference Remote Map Command Example with SMART-WRITE licenses QRouter (admin) #> remotemap mod The following wizard will be used to modify various settings of a remote mapping. If you wish to terminate this wizard before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so. Index Local Device (WWPN) Remote Device (WWPN)
Page 207 A – Command Reference Remote Map Command Examples The following are examples of the Remotemap remove command: QRouter (admin) #> remotemap rm The following wizard will query for attributes before persisting and activating the updated mapping in the system configuration. If you wish to terminate this wizard before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 208: Remote Peer Command
A – Command Reference Remote Peer Command A.22 Remote Peer Command The remotepeer command provides for assigning a router peer. A router may have up to four peers. Authority Admin session Syntax remotepeer Keywords Add a peer router. Remove a peer router. A-36 FI0054601-00 A...
Page 209 Symbolic Name Serial Number 0608A00471 HW Version SW Version 2.3.0.1 No. of iSCSI Ports iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00471 Mgmt IP Address 172.17.137.143 iSCSI Port 1 IP Address 10.3.5.106 iSCSI Port 1 TCP Port No. 3260 iSCSI Port 2 IP Address 10.3.5.107...
Page 210 A – Command Reference Remote Peer Command Examples The following is an example of the Remotepeer remove command: QRouter (admin) #> remotepeer rm Index (System Info, Mgmt IP Address) ----- ------------------------------ iSR-6142.0608A00487(172.17.137.215) Please select a remote system from the list above ('q' to quit): WARNING: Remote mappings exist between the LOCAL system and the selected REMOTE system.
Page 211: Reset Factory Command
A – Command Reference Reset Factory Command A.23 Reset Factory Command Restores the router configuration parameters to the factory default values. All LUN mappings are deleted, as well as all persistent data regarding targets, LUNs, and initiators. The factory default IP addresses will be restored. Authority Admin session Syntax...
Page 212: Save Command
A – Command Reference Save Command A.24 Save Command Saves logs and traces. Authority Admin session Syntax save capture logs traces Keywords capture The save capture command creates a debug file that captures all debug dump data. After the command completes, you must ftp the debug capture file from the router.
Page 213 A – Command Reference Save Command Examples The following are two example of the Save traces command: QRouter (admin) #> save traces Save ASIC Traces completed. Package is Router_Asic_Trace.tar.gz Please use FTP to extract the file out from the System. QRouter (admin) #>...
Page 214: Set Command
A – Command Reference Set Command A.25 Set Command Configures general router parameters as well as parameters that are specific to the Fibre Channel, iSCSI, and management ports. Authority Admin session Syntax chap fc [port_num] features Iscsi [port_num] Isns [port_num] mgmt properties snmp...
Page 215 A – Command Reference Set Command snmp Sets the simple network management protocol (SNMP) parameters. system Sets system parameters such as symbolic name and log level. FI0054601-00 A A-43...
Page 216: Set Chap Command
Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- iqn.2004-08.com.qlogic.isr-6142.0539A01064.0.2000002037fd8bab.2200002037fd8bab iqn.2004-08.com.qlogic.isr-6142.0539A01064.1.2000002037fd8bab.2200002037fd8bab Please select a presented target from the list above ('q' to quit): A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 217: Set Fc Command
A – Command Reference Set Command A.25.2 Set FC Command Configures a Fibre Channel port. Authority Admin session Syntax set fc [port_num] Parameters [port_num] The number of the FC port to be configured. Examples The following is an example of the Set FC command: QRouter (admin) #>...
Page 218: Set Features Command
A – Command Reference Set Command A.25.3 Set Features Command The set features command is used to enter licensed router features such as SmartWrite or additional host ports. NOTE: The date and time must be set prior to entering feature license keys. Authority Admin session Syntax...
Page 219: Set Iscsi Command
A – Command Reference Set Command A.25.4 Set iSCSI Command Configures an iSCSI port. Authority Admin session Syntax set iscsi [port_num] Parameters [port_num] The number of the iSCSI port to be configured. Examples The following is an example of the Set iSCSI command: QRouter (admin) #>...
Page 220 A – Command Reference Set Command A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 221: Set Isns Command
A – Command Reference Set Command A.25.5 Set iSNS Command Configures iSNS parameters for an iSCSI port. Authority Admin session Syntax set isns [port_num] Parameters [port_num] The number of the iSCSI port to be configured for iSNS. Examples The following is an example of the Set iSNS command: QRouter (admin) #>...
Page 222: Set Mgmt Command
A – Command Reference Set Command A.25.6 Set Mgmt Command Configures the router’s management port (10/100). Authority Admin session Syntax set mgmt Examples The following is an example of the Set Mgmt command: QRouter (admin) #> set mgmt A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 223: Set Ntp Command
A – Command Reference Set Command A.25.7 Set NTP Command The set NTP command is used to configure the network time protocol parameters. NTP is used to set the date and time on the router from a network time server. Authority Admin session Syntax...
Page 224: Set Properties Command
A – Command Reference Set Command A.25.8 Set Properties Command Configures the CLI (command line interface) properties. Authority Admin session Syntax set properties Examples The following is an example of the Set Properties command for setting the CLI properties: QRouter (admin) #> set properties A list of attributes with formatting and current values will follow.
Page 225: Set Snmp Command
A – Command Reference Set Command A.25.9 Set SNMP Command Configures the general simple network management protocol (SNMP) properties, as well as configuring eight trap destinations. Authority Admin session Syntax set snmp trap_destinations Keywords trap_destinations Specifies the setting of the trap destinations. Examples The following is an example of the Set SNMP command for setting the general properties:...
Page 226 A – Command Reference Set Command Trap Version Configuring SNMP Trap Destination 2 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled Configuring SNMP Trap Destination 3 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled Configuring SNMP Trap Destination 4 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled Configuring SNMP Trap Destination 5 :...
Page 227: Set System Command
A – Command Reference Set Command A.25.10 Set System Command Configures the general router parameters. Authority Admin session Syntax set system Examples The following is an example of the Set System command: QRouter (admin) #> show system A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 228: Show Command
A – Command Reference Show Command A.26 Show Command Displays/views router operational information. Authority None Syntax show chap fc [port_num] fciproutes [link_id] features initiators [fc or iscsi] iscsi [port_num] isns [port_num] localmaps logs memory mgmt perf [ byte | init_rbyte | init_wbyte | tgt_rbyte | tgt_wbyte ] presented_initiators [ fc | iscsi ] presented_targets [fc or iscsi] properties...
Page 229 A – Command Reference Show Command initiators [fc or iscsi] Displays SCSI initiator information: iSCSI or FC. iscsi [port_num] Displays iSCSI port information and configuration. isns [port_num] Displays the router’s iSCSI name server (iSNS) configuration. localmaps Displays local mappings, FC to FC, iSCSI to FC, and FC to iSCSI. logs Displays contents of the router logs.
Page 230 A – Command Reference Show Command snmp Displays the router’s simple network management protocol (SNMP) properties and trap configurations. stats Displays the router statistics, both FC and iSCSI. system Displays router product information including serial number, software version, hardware version, configuration, and temperature. targets [fc or iscsi] Displays targets discovered by the router: FC, iSCSI, or both.
Page 231: Show Chap Command
A – Command Reference Show Command A.26.1 Show CHAP Command Displays CHAP configuration. Authority None Syntax show chap Examples The following is an example of the Show CHAP command: QRouter #> show chap The following is a list of iSCSI nodes that have been configured with CHAP 'ENABLED': Type iSCSI Node...
Page 232: Show Fc Command
A – Command Reference Show Command A.26.2 Show FC Command Displays Fibre Channel port information for the specified port. If the port is not specified, then both ports are displayed. Authority None Syntax show fc [port_num] Parameters [port_num] The number of the FC port to be displayed. Examples The following is an example of the Show FC command: QRouter (admin) #>...
Page 233: Show Fciproutes Command
A – Command Reference Show Command A.26.3 Show FcipRoutes Command Displays FCIP route(s) configuration parameters. Authority None Syntax show fciproutes [link_id] Parameters [link_id] The number of the FCIP route to be displayed (1 or 2). FI0054601-00 A A-61...
Page 234 A – Command Reference Show Command Examples The following is an example of the Show FCIP routes command: QRouter #> show fciproutes FCIP Route Information ------------------------ FCIP Route FCIP Interfaces Status Enabled FCIP Link Status FC Port GE Port GE Link Status Local IP Address 10.6.6.10 Remote IP Address...
Page 235 A – Command Reference Show Command Bandwidth, Mbit/sec 1000 VLAN Disabled FCIP SW Compression Disabled FI0054601-00 A A-63...
Page 236: Show Features Command
A – Command Reference Show Command A.26.4 Show Features Command The show features command displays the licensed features that have been enabled on the router. Authority None Syntax show features Examples The following is an example of the Show Features command: QRouter (admin) #>...
Page 237: Show Initiators Command
Specifies the display of iSCSI initiators. Examples The following is an example of the Show Initiators command: QRouter #> show initiators Initiator Information ----------------------- Initiator Name iqn.1991-05.com.microsoft:qlogic-8qdaqlxt Alias IP Address 10.3.5.130 Portal No. Status Logged In FI0054601-00 A A-65...
Page 238: Show Iscsi Command
A – Command Reference Show Command A.26.6 Show iSCSI Command Displays iSCSI information for the specified port. If the port is not specified, then both ports are displayed. Authority None Syntax show iscsi [port_num] Parameters [port_num] The number of the iSCSI port to be displayed. A-66 FI0054601-00 A...
Page 239 The following is an example of the Show iSCSI port command: QRouter (admin) #> show iscsi iSCSI Port Information ------------------------ iSCSI Port Port Status Enabled Link Status iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00471 MAC Address 00-c0-dd-0c-8b-e2 IP Address 10.3.5.106 Subnet mask 255.255.255.0 Gateway IP Address 0.0.0.0 Firmware Revision No.
Page 240 A – Command Reference Show Command Data Digests Enabled Max Burst 262144 Max First Burst 32768 VLAN Enabled VLAN ID VLAN Priority A-68 FI0054601-00 A...
Page 241: Show Isns Command
A – Command Reference Show Command A.26.7 Show iSNS Command Displays iSNS configuration information for the specified iSCSI port. If the port is not specified, then the iSNS configuration information for both iSCSI ports is displayed. Authority None Syntax show isns [port_num] Parameters [port_num] The iSCSI port number whose iSNS configuration is to be displayed.
Page 242: Show Localmaps Command
Authority None Syntax show localmaps Examples The following is an example of the Show Localmaps command: QRouter (admin) #> show localmaps Local Mappings ---------------- Initiator iqn.1991-05.com.microsoft:qlogic-09sd5i4l Target 20:00:00:20:37:fd:9c:f7,22:00:00:20:37:fd:9c:f7 Initiator Port Target Port Initiator 20:01:00:e0:8b:28:5f:3d,21:01:00:e0:8b:28:5f:3d Target 20:00:00:00:87:1d:fa:64,22:00:00:00:87:1d:fa:64 Initiator Port Target Port...
Page 243: Show Logs Command
A – Command Reference Show Command A.26.9 Show Logs Command Displays the router event log. Authority None Syntax show logs Examples The following is an example of the Show Logs command: QRouter #> show logs 01/01/1970 00:00:13 System 3 Thursday 01 January 12:13 AM 01/01/1970 00:00:21 QL4022 3 #0: QLIsrDecodeMailbox: Link up...
Page 244: Show Memory Command
A – Command Reference Show Command A.26.10 Show Memory Command Displays the router’s memory usage. The FCIP memory usage will be zero if there are no FCIP routes configured. Authority None Syntax show memory Examples The following is an example of the Show Memory command with no FCIP routes configured: QRouter #>...
Page 245: Show Mgmt Command
A – Command Reference Show Command A.26.11 Show Mgmt Command Displays the router’s management port (10/100) configuration. Authority None Syntax show mgmt Examples The following is an example of the Show Mgmt command: QRouter #> show mgmt Management Port Information ----------------------------- Mode Dhcp...
Page 246: Show Ntp Command
A – Command Reference Show Command A.26.12 Show NTP Command Displays the router’s network time protocol (NTP) configuration. Authority None Syntax show ntp Examples The following is an example of the Show NTP command: QRouter #> show ntp NTP Information ----------------- Mode Disabled...
Page 247: Show Performance Command
A – Command Reference Show Command A.26.13 Show Performance Command Displays router performance data. Authority None Syntax show perf byte init_rbyte init_wbyte tgt_rbyte tgt_wbyte Keywords byte Displays data transfer rate of each port (FC and GE). init_rbyte Displays initiator read transfer rate per port. init_wbyte Displays initiator write transfer rate per port.
Page 248 A – Command Reference Show Command The following is an example of the Show Performance byte command. QRouter #> show perf byte Displaying bytes/sec (total)... (Press any key to stop display) ------------------------------ A-76 FI0054601-00 A...
Page 249: Show Presented Initiators Command
The following is an example of the Show Presented Initiators command. QRouter #> show presented_initiators Presented Initiator Information --------------------------------- FC Presented Initiators ------------------------- WWNN 20:01:00:c0:dd:0c:8b:e3 WWPN 21:01:00:c0:dd:0c:8b:e3 Port <MAPS TO> WWNN 20:01:00:e0:8b:28:5f:3d WWPN 21:01:00:e0:8b:28:5f:3d WWNN 20:01:00:c0:dd:0c:8b:e2 WWPN 21:01:00:c0:dd:0c:8b:e2 Port <MAPS TO> Name iqn.1991-05.com.microsoft:qlogic-09sd5i4l FI0054601-00 A A-77...
Page 250: Show Presented Targets Command
WWPN 21:01:00:c0:dd:0c:8b:e3 Port <MAPS TO> WWNN 20:00:00:00:87:1d:fa:64 WWPN 22:00:00:00:87:1d:fa:64 iSCSI Presented Targets ------------------------- Name iqn.2004-08.com.qlogic:isr-6142.0608a00471.1.2200002037fd9cf7.2000002037fd9cf7 Port <MAPS TO> WWNN 20:00:00:20:37:fd:9c:f7 WWPN 22:00:00:20:37:fd:9c:f7 The following is an example of the Show Presented FC Targets command QRouter #> show presented_targets fc A-78...
Page 251 No Presented Targets found. The following is an example of the Show Presented iSCSI Targets command: QRouter #> show presented_targets iscsi Presented Target Information ------------------------------ iSCSI Presented Targets ------------------------- Name iqn.2000-04.com.qlogic:isr6142:0.50001fe150069d20.50001fe150069d2c 10.3.5.66 <MAPS TO> WWNN 50:00:1f:e1:50:06:9d:20 WWPN 50:00:1f:e1:50:06:9d:2c Name iqn.2000-04.com.qlogic:isr6142:1.50001fe150069d20.50001fe150069d2c 10.3.5.67...
Page 252: Show Properties Command
A – Command Reference Show Command A.26.16 Show Properties Command Displays the router’s CLI (command line interface) properties. Authority None Syntax show properties Examples The following is an example of the Show Properties command: QRouter #> show properties CLI Properties ---------------- Inactivty Timer Disabled...
Page 253: Show Remotemaps Command
A – Command Reference Show Command A.26.17 Show Remotemaps Command Displays all remote maps that have been configured. Authority None Syntax show remotemaps Examples The following is an example of the Show Remotemaps command: QRouter #> show remotemaps Remote Mappings ----------------- Local Device 20:01:00:e0:8b:28:5f:3d,21:01:00:e0:8b:28:5f:3d (Initiator)
Page 254: Show Remotepeers Command
Symbolic Name Serial Number 0608A00487 HW Version SW Version 2.2.0.4 No. of iSCSI Ports iSCSI Base Name iqn.2004-08.com.qlogic:isr-6142.0608a00487 Mgmt IP Address 172.17.137.215 iSCSI Port 1 IP Address 10.3.5.103 iSCSI Port 1 TCP Port No. 3260 iSCSI Port 2 IP Address 10.3.5.104...
Page 255: Show Snmp Command
A – Command Reference Show Command A.26.19 Show SNMP Command Displays the router’s simple network management protocol (SNMP) and any traps that have been configured. Authority None Syntax show snmp Examples The following is an example of the Show SNMP command: QRouter #>...
Page 256: Show Stats Command
A – Command Reference Show Command A.26.20 Show Stats Command Displays the router statistics: FC and iSCSI. Authority None Syntax show stats Examples The following is an example of the Show Statistics command: QRouter #> show stats FC Port Statistics -------------------- FC Port Interrupt Count...
Page 257 A – Command Reference Show Command MAC Rcvd Unknown Control Frames MAC Rcvd Pause Frames MAC Rcvd Control Frames MAC Rcvd Dribbles MAC Rcvd Frame Length Errors MAC Rcvd Jabbers MAC Rcvd Carrier Sense Errors MAC Rcvd Dropped Frames MAC Rcvd CRC Errors MAC Rcvd Encoding Errors MAC Rcvd Length Errors Large MAC Rcvd Small Errors Small...
Page 258 A – Command Reference Show Command MAC Rcvd Small Errors Small MAC Rcvd Multicast Frames MAC Rcvd Broadcast Frames iSCSI Shared Statistics ----------------------- PDUs Xmited 2729500577 Data Bytes Xmited 55036896842234 PDUs Rcvd 2655246170 Data Bytes Rcvd I/O Completed 1815115669 Unexpected I/O Rcvd iSCSI Format Errors Header Digest Errors Data Digest Errors...
Page 259: Show System Command
A – Command Reference Show Command A.26.21 Show System Command Displays router product information including the serial number, software version, hardware version, configuration, and temperature. Authority None Syntax show system Examples The following is an example of the Show System command: QRouter (admin) #>...
Page 260: Show Targets Command
A – Command Reference Show Command A.26.22 Show Targets Command Displays targets discovered by the router: FC, iSCSI, or both. Authority None Syntax show targets iscsi Keywords Specifies the display of FC targets. iscsi Specifies the display of iSCSI targets. Examples The following is an example of the Show FC Targets command: QRouter...
Page 261: Show Vlan Command
A – Command Reference Show Command A.26.23 Show VLAN Command Displays the router’s VLAN configuration. Authority None Syntax show vlan [port_num] Parameters [port_num] The iSCSI port number whose VLAN configuration is to be displayed. Examples The following is an example of the Show VLAN command: QRouter #>...
Page 262: Shutdown Command
A – Command Reference Show Command A.26.24 Shutdown Command The shutdown command provides for an orderly shutdown of the routers firmware. It does not power down the router. Authority Admin session Syntax shutdown Examples The following is an example of the Shutdown command: QRouter (admin) #>...
Page 263: Target Command
A – Command Reference Target Command A.27 Target Command Removes targets from the router’s database. This command is typically used to remove targets from the database that are no longer connected to the router. The target add command is not currently supported. Authority Admin session Syntax...
Page 264 A – Command Reference Target Command A-92 FI0054601-00 A...
Page 265: Appendix B Log Messages
Appendix B Log Messages Log Data The router maintains a message log that can be displayed and retrieved by the operator, either through the command line interface or the SANsurfer GUI. The message log is persistent in that it is maintained across router power cycles and reboots.
Page 266 B – Log Messages Informational Log Messages Table B-1. Application Modules—Informational Log Messages (Continued) Log Message 54309 QLFC_Logout: Port Name 1061 %.2x%.2x%.2x%.2x%.2x%.2x%.2x%.2x 54359 QLFC_HandleTeb: FC Login. VP 0x%x 1111 54368 QLFC_CreateVirtualInitiatorObject: Maximum host (%d) limit 1120 reached. 54938 QLIS_HandleTeb: UTM_EC_OPEN_CONNECTION 1690 54939 QLIS_HandleTeb: UTM_EC_CLOSE_CONNECTION or...
Page 267: B.2.2 Iscsi Driver
B – Log Messages Informational Log Messages 1692 Event notification; iSCSI connection opened. 1693 Event notification; connection opened with iSNS server. 1695 Event notification; iSNS SCN received. 1697 Event notification; iSNS client discovered. 1699 iSCSI close connection request received 1700 iSCSI connection closed 1715 Remote system connection established using DDB d:d...
Page 268: B.2.4 User Modules
B – Log Messages Informational Log Messages the table. Log messages beginning with #0 denote fibre channel port 1 (FC1). Log messages beginning with #1 denote fibre channel port 2 (FC2). Table B-3. Fibre Channel Driver—Informational Log Messages Log Message 118882 #%d: QLIoctlDisable: Reset adapter 119088...
Page 269: B-4 User Modules—Informational Log Messages
B – Log Messages Informational Log Messages Table B-4. User Modules—Informational Log Messages Log Message 151842 FW Upgrade performed: new version is: %d.%d.%d.%d 151843 REBOOT/SHUTDOWN Command from user. Code=%d 151889 #%d: qapisetfcinterfaceparams_1_svc: FC port configuration changed 151890 #%d: qapisetiscsiinterfaceparams_1_svc: iSCSI port configuration changed 151891 #%d: qapisetisns_1_svc:iSNS configuration changed...
Page 270 B – Log Messages Informational Log Messages Table B-4. User Modules—Informational Log Messages 152070 qapisetfcipparams_1_svc: FCIPROUTE %d Modified 152071 qapisetfcipparams_1_svc: FCIPROUTE %d Removed Performed router firmware upgrade, new version number is d.d.d.d User performed a router reboot or shutdown FC port configuration has been modified. iSCSI port configuration has been modified.
Page 271: B.2.5 Fcip
B – Log Messages Informational Log Messages B.2.5 FCIP The informational log messages provided by the FCIP module are listed in table B-5 and described following the table. Table B-5. FCIP—Informational Log Messages Log Message 184524 qlFcip_Linkchange#%d: GigE Link Down 184525 qlFcip_Linkchange#%d: GigE Link Up FCIP Route GigE link d (1 or 2) is down...
Page 272: Application Modules
B – Log Messages Error Log Messages Error Log Messages The following sections list and describe the error log messages by reporting module. B.3.1 Application Modules The error log messages provided by application modules are listed in table B-8 described following the table. Table B-8.
Page 273 B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) Log Message 41284 QLIS_LoginPduContinue: Session does not exist, invalid TSIH 0x%x 41353 QLIS_LoginPduContinue CHAP Validation Failure 41354 QLIS_LoginPduContinue Unexpected CHAP key detected 41508 QLBI_SetPortInfo: QLUT_AllocatePortalObject failed (PortType 0x%x, PortId 0x%x) 41626 QLBI_GetLunInfo: INQUIRY failed, TPB status 0x%x...
Page 274 B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) Log Message 42404 QLIS_ProcessStartTrb: [%d] CmdSN %ld is out of range (%ld 1444 - %ld), Cdb[0] 0x%02X, DataXferLen 0x%x. 42648 QLIS_HandleTeb: Driver Fatal Error 1688 42649 QLIS_HandleTeb: Unload Driver 1689 42654...
Page 275 B – Log Messages Error Log Messages Table B-8. Application Module—Error Log Messages (Continued) Log Message 43299 QLUT_DeallocateFcipDataBuffer: Null portal object in map table 2339 43300 QLUT_CreateFcipDataBufferpool: Allocation of 32K buffers from 2340 LargeBufferPool failed 43521 QLSC_BreakupVUIOAllocPhase: TPB allocation failed 2561 43522 QLSC_BreakupVUIOAllocPhase: Data buffer and TPB allocation...
Page 276 B – Log Messages Error Log Messages iSCSI Login PDU received with an incorrect initiator task tag for a session which is partially logged in. This would occur if a login PDU other than the initial login PDU used an initiator task tag which was different than the initiator task tag provided in the initial login PDU.
Page 277 B – Log Messages Error Log Messages 1042 Attempting login but Fibre Channel connection cannot be opened. 1064 Attempting logout of device for which there is no active path (WWPN not found). 1067 Logout attempted using Fibre Channel VP index that has not been configured. Operation attempted on an unconfigured VP.
Page 278: Iscsi Driver
B – Log Messages Error Log Messages 2326 FCIP get TRB: Duplicate allocation of FcipTrb (0x%p) 2327 FCIP free TRB: Null portal object in map table 2328 FCIP free TRB: Duplicate Free of FcipTrb (0x%p) 2329 FCIP initialize buffer descriptor pool: memory allocation for FCIP_BUF_EXT_DESC failed (size 0x%x) 2336 FCIP free data buffers: Duplicate Freeing of DataBuf (0x%p)
Page 279: Fibre Channel Driver
B – Log Messages Error Log Messages Table B-9. iSCSI Driver—Error Log Messages (Continued) Log Message 74663 #%d: QLReadyTimer: MBOX_CMD %04x %04x %04x %04x %04x %04x %04x %04x timed out 74665 #%d: QLReadyTimer: QLiSNSReenable failed. 74784 #%d: QLUpdateInitiatorData: No more room in Initiator Database. 1056 74800 #%d: QLSetTargetData: No more room in Target Database.
Page 280 B – Log Messages Error Log Messages Table B-10. Fibre Channel Driver—Error Log Messages (Continued) Log Messages 106590 #%d: QLIoctlEnable: Initialize FW error 106592 #%d: QLIoctlRunDiag: Diagnostic loopback command failed %x % %x %x 106593 #%d: QLIoctlDisable: Re-initialize adapter failed 106595 #%d: QLUtmReceiveIo: Invalid VP Loop Id 0x%x 106803...
Page 281: User Modules
B – Log Messages Error Log Messages The FC processor reported an unexpected asynchronous event. The mailbox registers provide status, event code, and data related to the event. FCIP Response queue entry TRB pointer is NULL The driver has determined that the FC link is unreliable and unusable due to the number of errors encountered.
Page 282 B – Log Messages Error Log Messages Table B-11. User Modules—Error Log Messages (Continued) Log Message 139284 QBRPC_Initialize:TargetList Mem Allocation error 139285 QBRPC_Initialize:LunList MemAllocation error 139286 QBRPC_Initialize:PresTarget Mem Allocation error 139287 QBRPC_Initialize:LunMask Mem Allocation error 139288 QBRPC_Initialize:Init Mem Allocation error 139289 QBRPC_Initialize:TgtDevice Mem Allocation error 139296...
Page 283: System
B – Log Messages Fatal Log Messages Failed memory allocation for Get Presented Targets List API. Failed memory allocation for Get LUN Mask API. Failed memory allocation for Initiator API. Failed memory allocation for Target Device API. Failed memory allocation for FC Target API. Failed memory allocation for System Status API.
Page 284: B-13 Iscsi Driver—Fatal Log Messages
B – Log Messages Fatal Log Messages messages beginning with #0 denote iSCSI port 1 (GE1). Log messages beginning with #1 denote iSCSI port 2 (GE2). Table B-13. iSCSI Driver—Fatal Log Messages Log Message 69652 #%d: qlutm_init: Diagnostic failed, invalid SRAM 69653 #%d: qlutm_init: Diagnostic failed, fail reboot 69654...
Page 285: Iscsi Driver
B – Log Messages Fatal Log Messages Table B-13. iSCSI Driver—Fatal Log Messages (Continued) Log Message 70836 #%d: QLStartFw: Invalid Fw loader state 0x%x 1204 70837 #%d: QLStartFw: Load Fw loader timeout 1205 iSCSI processor SRAM test failed. iSCSI processor failed diagnostic reboot. iSCSI processor failed NVRAM diagnostic.
Page 286: Fc Driver
B – Log Messages Fatal Log Messages B.4.2 FC Driver The following fatal log messages are common to both Fibre Channel ports, 1 (FC1) and 2 (FC2). They are listed in table B-14 and described following the table. Log messages beginning with #0 denote fibre channel port 1 (FC1). Log messages beginning with #1 denote fibre channel port 2 (FC2).
Page 287: Toe Driver
B – Log Messages Fatal Log Messages FC1 processor SRAM test failed. FC1 processor power-on self-test (POST) failed. FC2 processor SRAM test failed. FC2 processor POST failed. FC processor failed to return diagnostic results. FC processor failed reset. FC processor firmware load failed. FC processor receive sequencer code load failed.
Page 288: System
B – Log Messages Fatal Log Messages B.4.4 System The fatal log messages provided by system modules are listed in table B-16 described following the table. Table B-16. System—Fatal Log Messages Log Message 233473 "memory monitor: Detected Uncorrectable Ecc %08lx system is rebooting in 5 secs\n"...
Page 289: Appendix C Configuring Chap
Appendix C Configuring CHAP CHAP Definition In challenge handshake authentication protocol (CHAP), the authentication agent sends the client program a random value that is used only once and an ID value. Both the sender and peer share a predefined secret. The peer concatenates the random value, the ID, and the secret, and calculates a one-way hash using MD5.
Page 290: Cli-Discovery Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using CLI a. Click General. b. Click Secret (in the middle of the screen). If this is the first time you are setting secrets, reset all secrets. c. Type the secret (secret_port) that you created in step 4.
Page 291: Cli-Normal Session-Bi-Directional Chap
C – Configuring CHAP Configuring CHAP Using CLI 10. Click OK. 11. Click OK, and the initiator should complete discovery. C.2.3 CLI—Normal Session—Bi-directional CHAP The following procedure describes the steps for configuring bi-directional CHAP used during a normal session: 1. On the router a.
Page 292: Cli-Normal Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI C.2.4 CLI—Normal Session—Uni-directional CHAP The following procedure describes the steps for configuring single-direction CHAP to be used during a normal session: 1. Do not enable CHAP on the presented target. 2. Use Initiator add: a.
Page 293: Gui-Discovery Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI a. If the initiator is not part of the discovered iSCSI initiators list, then go to the wizard menu and select Add Initiator Wizard. b. If the initiator is part of the discovered list, then go to step 7.
Page 294: Gui-Normal Session-Bi-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI 5. Create a CHAP secret (for example, secret_initiator). 6. Go to the MS Initiator and perform the following steps: a. Click Discovery. b. Click Add. c. Enter the address of the iSCSI port of the bridge. d.
Page 295: Gui-Normal Session-Uni-Directional Chap
C – Configuring CHAP Configuring CHAP Using the GUI 12. Select the target you want to login to. 13. Click Log On. 14. Click Advanced. 15. Select Chap Login Information. 16. Type the secret (secret_initiator) that you created in step 9 into Target Secret.
Page 296 C – Configuring CHAP Configuring CHAP Using the GUI Notes FI0054601-00 A...
Page 297: Appendix D Simple Network Management Protocol (Snmp)
Introduction Simple network management protocol (SNMP) provides monitoring and trap functions for managing the router through third party applications that support SNMP. The router firmware supports SNMP versions 1 and 2 and a QLogic management information base (MIB) (see section D.2).
Page 298: Snmp Trap Configuration
Similarly, if trap 1 and trap 2 have the same port value, they must have different addresses. Management Information Base (MIB) The following sections describe the QLogic management information base (MIB). The MIB consists of four object groups: System Information (see section D.2.1)
Page 299: Network Port Table
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrHwVersion Syntax SnmpAdminString Access Read only Description The system hardware version number. qsrSwVersion Syntax SnmpAdminString Access Read only Description The system software (firmware) version number. qsrNoOfFcPorts Syntax Unsigned32 Access Read only Description The number of Fibre Channel ports on the...
Page 300 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNwPortTable Syntax Sequence of QsrNwPortEntry Access Not accessible Description The entries in this table include the management port, and the iSCSI and TOE ports on the router. qsrNwPortEntry Syntax QsrNwPortEntry Access Not accessible...
Page 301 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNwPortAddressMode Syntax INTEGER 1 = Static 2 = DHCP 3 = Bootp 4 = RARP Access Read only Description The method by which the port gets its IP address. qsrIPAddressType Syntax InetAddressType...
Page 302: Fibre Channel Port Table
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qstNwLinkStatus Syntax QsrLinkStatus Access Read only Description The operational link status for this port. qsrNwLinkRate Syntax QsrLinkRate Access Read only Description The operational link rate for this port. D.2.3 Fibre Channel Port Table This table contains a list of the Fibre Channel (FC) ports on the router.There are as many entries in this table as there are FC ports on the router.
Page 303 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrFcPortRole Syntax QsrPortRole Access Not accessible Description The operational role of this port: i.e. in FCP mode or in frame shuttle mode. qsrFcPortIndex Syntax Unsigned32 Access Not accessible Description A positive integer indexing each FC port in a given role.
Page 304: Sensor Table
D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrFcLinkStatus Syntax QsrLinkStatus Access Read only Description The current link status for this port. qsrFcLinkRate Syntax QsrLinkRate Access Read only Description The current link rate for this port. D.2.4 Sensor Table This table contains a list of all the sensors on the router.
Page 305 D – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrSensorType Syntax INTEGER Temperature = 1 Access Not accessible Description The type of data being measured by this sensor. qsrSensorIndex Syntax Unsigned32 Access Not accessible Description A positive integer identifying each sensor of a given type.
Page 306: Notifications
D – Simple Network Management Protocol (SNMP) Notifications qsrSensorState Syntax INTEGER Access Read only Description The state of this sensor, indicating the health of the system. Unknown. The sensor value/thresholds ■ cannot be determined. Normal. The sensor value is within normal ■...
Page 307: Agent Start Up Notification
D – Simple Network Management Protocol (SNMP) Notifications qsrEventTimeStamp Syntax DateAndTime Access Accessible for notify Description This notification indicates when the event occurred. D.3.2 Agent Start Up Notification The agent startup notification indicates that the agent on the router has started running.
Page 308: Fibre Channel Port Down Notification
D – Simple Network Management Protocol (SNMP) Notifications D.3.5 Fibre Channel Port Down Notification The Fibre Channel port down notification indicates that the specified Fibre Channel port is down. The next time the port comes up, this event is sent with the qsrEventSeverity object set to clear.
Page 309 Index CLI, configuring CHAP Command syntax Account, guest Commands Action Menu Admin Address Beacon 7-22 Set CHAP A-44 IP server 7-23 Clear iSCSI IP 7-27 Data 7-22 Set FC A-45 A-46 Admin command Show FC A-59 A-60 A-61 Advanced Configuration tabbed page 7-23 A-13 Application module log messages...
Page 310 SANbox 6140 Router User’s Guide Show Presented Targets driver messages A-75 A-77 A-78 B-15 B-22 Show Targets port count A-88 7-12 Show VLAN port information A-89 A-90 7-18 7-19 7-20 Configuration, restore router port LEDs Configuration, save router Set FC command A-45 A-46 Connect button...
Page 311 SANbox 6140 Router User’s Guide SANbox 6140 Router User’s restore maintenance port IP address Logs, Show Logs command A-70 A-71 server IP address Logs, viewing 7-23 IP address 7-12 IQN uses symbolic name information 7-12 7-28 7-29 7-31 iSCSI alias 7-27 driver messages B-14...
Page 312 SANbox 6140 Router User’s Guide Router management Router, see also SANbox 6140 router Password changing 7-15 7-16 command A-26 read community 7-14 SANbox 6140 router Trap community 7-14 configuration Persistent data, restoring connect to Persistent data, saving device access to Ping devices attached to Ping command...
Page 313 SANbox 6140 Router User’s Guide SANbox 6140 Router User’s Settings menu Show Targets command A-88 SFP optical transceivers TCP port number 2-10 7-24 Show A-84 command maximum window sIze A-56 7-24 FC command target TCP port number A-59 A-60 A-61 7-24 Initiators command window scaling, enable...
Page 314 SANbox 6140 Router User’s Guide Index-6 FI0054601-00 A...

Qlogic SANbox 6142 User Manual

General Description

Table

Planning

Installation

Diagnostics and Troubleshooting

Removal/Replacement

Sansurfer Iscsi/Fc Router Manager

Appendix A Command Reference

Quick Links

Need help?

Questions and answers

Related Manuals for Qlogic SANbox 6142

Summary of Contents for Qlogic SANbox 6142
