Page 1 iSR6200 Command Line Interface (CLI) User’s Guide ISR654601-00 D...
Page 2 iSR6200 Command Line Interface (CLI) User’s Guide Information furnished in this manual is believed to be accurate and reliable. However, QLogic Corporation assumes no responsibility for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
Page 3 iSR6200 Command Line Interface (CLI) User’s Guide Updated the show features command exam- “Show Features” on page 2-63 ple output. Updated the show initiators command “Show Initiators” on page 2-64 example output. Updated the show initiators lun mask “Show Initiators LUN Mask” on page 2-66 command example output.
Page 4 iSR6200 Command Line Interface (CLI) User’s Guide Added new FCIP driver module messages 172300 Appendix B Log Messages through 172322. Updated back cover page per current template. Back page ISR654601-00 D...
Page 5: Table Of Contents
Table of Contents Preface Intended Audience ..........What’s in This Guide .
Page 6: Commands (Continued)
iSR6200 Command Line Interface (CLI) User’s Guide Commands (continued) FcipRoute ..........2-12 FRU .
Page 7 iSR6200 Command Line Interface (CLI) User’s Guide Commands (continued) Show Logs..........2-72 Show LUNinfo .
Page 8 iSR6200 Command Line Interface (CLI) User’s Guide Step 4: Map the iSCSI Target into the SAN and Provide Host Access to the Storage LUN ....... . Step 5: View the Newly Mapped Target Zoned to the Fibre Channel Host .
Page 9 iSR6200 Command Line Interface (CLI) User’s Guide List of Figures Figure Page iSNS Server Properties: Creating a Discovery Domain ..... . iSNS Server Properties: Enabling a Discovery Domain Set .
Page 10 iSR6200 Command Line Interface (CLI) User’s Guide ISR654601-00 D...
Page 11: Preface
Preface The iSR6200 Command Line Interface (CLI) User’s Guide describes how to use the command line interface (CLI) to configure and manage the QLogic iSR6200 Intelligent Storage Router (iSR6200). Intended Audience This user’s guide is intended for individuals who are responsible for installing and servicing the iSR6200 router and the storage area network (SAN) equipment to which it is attached.
Page 12: Related Materials
Appendix A Simple Network Management Protocol describes how to use the simple network management protocol (SNMP) to monitor and manage the router through third-party applications that support SNMP version 1 and 2 and a QLogic management information base (MIB). Appendix B Log Messages provides details about messages logged to a file, including message categories for informational, error, and fatal log messages.
Page 13: Documentation Conventions
Fibre Channel Physical and Signaling Interface (FC-PH), X3.230:199 Fibre Channel 2nd Generation (FC-PH-2), X3.297:1997 Third Generation Fibre Channel Physical and Signaling Interface (FC-PH-3), X3.303:1998, Fibre Channel-Arbitrated Loop (FC-AL-2), working draft, revision 6.4, August 28, 1998 Fibre Channel Fabric Loop Attachment Technical Report (FC-FLA) NCITS/TR-20:1998, Fibre Channel-Private Loop Direct Attach Technical Report (FC-PLDA) SCSI Fibre Channel Protocol-2 (FCP-2) working draft, revision 3, October 1,...
Page 14: License Agreements
Each iSR6200 blade supports up to four virtual port groups (VPGs). When prompted, enter the <ip_address>. Text in ALL CAPITALS indicates the name of a key that you press on the keyboard. For example: Press the CTRL+Q keys. Type the number for Host Information, and then press ENTER. License Agreements Refer to the QLogic Software End User License Agreement for a complete listing of all license agreements affecting this product.
Page 15: Contact Information
Contact Information QLogic Technical Support for products under warranty is available during local standard working hours excluding QLogic Observed Holidays. For customers with extended service, consult your plan for available hours. For Support phone numbers, see the Contact Support link at http://support.qlogic.com.
Page 16 ISR654601-00 D...
Page 17: Cli Usage
CLI Usage The iSR6200 CLI enables you to perform a variety of router management tasks through an Ethernet or serial port connection. This chapter provides details about the following tasks: Logging on to a SAN Router “Understanding the Guest Account” on page 1-2 “Working with SAN Router Configurations”...
Page 18: Understanding The Guest Account
1–CLI Usage Understanding the Guest Account To log on to a switch through the serial port: Configure the workstation port with the following settings: 115200 baud 8-bit character 1 stop bit No parity When prompted, enter an account name and password. Understanding the Guest Account Routers come from the factory with the following account already defined: Account name:...
Page 19 1–CLI Usage Understanding the Guest Account reset [ factory | mappings ] show [ chassis ] iSR6200 #> show chassis Chassis Information --------------------- Product Name ISR6200 Chassis Name Router Chassis Name Serial Number 0834E00019 HW Version 20697-03 A Fan Speed Normal Blade 1 Information (Left Slot) -------------------------------...
Page 20: Working With San Router Configurations
1–CLI Usage Working with SAN Router Configurations Working with SAN Router Configurations Successfully managing routers with the command line interface depends on effective router configurations. Key router management tasks include modifying configurations, backing up configurations, and restoring configurations. Modifying a Configuration The router has these major areas of configuration: Management port configuration requires using the following commands: set mgmt (see...
Page 21: Restoring Router Configuration And Persistence
1–CLI Usage Working with SAN Router Configurations The following example shows an FTP transfer to get the saved router configuration data: c:\> ftp 172.17.137.102 Connected to 172.17.137.102. 220 (none) FTP server (GNU inetutils 1.4.2) ready. User (172.17.137.102:(none)): ftp 331 Guest login ok, type your name as password. Password: ftp 230 Guest login ok, access restrictions apply.
Page 22: Installing The Firmware Via Telnet
1–CLI Usage Installing the Firmware Via Telnet ftp> put iSR6200_FRU.bin 200 PORT command successful. 150 Opening BINARY mode data connection for 'iSR6200_FRU.bin'. 226 Transfer complete. ftp: 6168 bytes sent in 0.00Seconds 6168000.00Kbytes/sec. ftp> quit 221 Goodbye. To update a blade with the saved configuration data (see page 2-16), execute the fru restore command.
Page 23 1–CLI Usage Installing the Firmware Via Telnet Use the file transfer protocol (FTP) to transfer the firmware image to the router. For example: C:\fwImage>ftp 172.17.137.190 (example IP address) Connected to 172.17.137.190. 220 (none) FTP server (GNU inetutils 1.4.2) ready. User (172.17.137.190:(none)): ftp 331 Guest login ok, type your name as password.
Page 24 1–CLI Usage Installing the Firmware Via Telnet Unpack Completed. A reboot is required for the FW to take affect. (if there are Do you wish to reboot the System at the current time (y/n): y two blades, update both blades before rebooting) System will now be rebooted...
Page 25: Command Reference
Command Reference This chapter lists and describes the iSR6200 Intelligent Storage Router CLI commands in alphabetical order. Each command description includes its syntax, keywords, notes, and examples. Command Lists The tables in this section provide references to the chassis level and blade level commands used in the iSR6200 CLI.
Page 26: Blade Management Commands
2–Command Reference Command Lists Blade Management Commands Table 2-2 provides a link to the section containing details of each CLI blade management command. Table 2-2. CLI Blade Commands For Commands Refer to Section: Starting with: “Admin” on page 2-6 “Beacon” on page 2-7 “Clear”...
Page 27 2–Command Reference Command Lists Table 2-2. CLI Blade Commands (Continued) For Commands Refer to Section: Starting with: “Set” on page 2-37 “Set Alias” on page 2-39 “Set CHAP” on page 2-41 “Set Chassis” on page 2-42 “Set FC” on page 2-43 “Set Features”...
Page 28: Command Syntax
2–Command Reference Command Syntax Command Syntax The iSR6200 CLI command syntax uses the following format: command keyword keyword [value] keyword [value1] [value2] The command is followed by one or more keywords. Consider the following rules and conventions: Commands and keywords are case insensitive. Required keyword values appear in standard font within brackets;...
Page 29: Authority Requirements
2–Command Reference Command Syntax Authority Requirements The various set commands perform tasks that may require you to be in an administrator session. Note that: Commands related to monitoring tasks are available to all account names. Commands related to configuration tasks are available only within an Admin session.
Page 30: Admin
2–Command Reference Command Syntax Admin Opens and closes an administrator (Admin) session. Any command that changes the router configuration must be done in an Admin session. An inactive Admin session will time out after 15 minutes. Authority Admin session Syntax admin start (or begin) end (or stop)
Page 31: Beacon
2–Command Reference Command Syntax Beacon Enables or disables flashing the blue beacon LED. Authority None Syntax beacon Keywords Turns on the router beacon. Turns off the router beacon. Examples The following example shows the beacon command: iSR6200 <1> #> beacon on ISR654601-00 D...
Page 32: Blade
2–Command Reference Command Syntax Blade Allows for the selection of the blade to be managed. This command is only valid at the chassis prompt. The chassis CLI prompt does not include the blade number (for example, iSR6200 #>), whereas the blade CLI prompt includes the blade number (for example, iSR6200 <1>...
Page 33: Clear
2–Command Reference Command Syntax Clear Removes all entries (events) from the router log file, or resets the Fibre Channel and iSCSI statistic counters. Authority Admin session Syntax clear logs stats Keywords logs Clears all entries from the router’s log file. stats Resets the statistic counters.
Page 34: Date
2–Command Reference Command Syntax Date Displays or sets the date and time. To set the date and time, you must enter the information in the format MMDDhhmmCCYY (numeric representation of month-date-hour-minute-century-year). The new date and time takes effect immediately. Each blade has its own independent date set. Properly setting the date ensures that event log entries are dated correctly.
Page 35: Exit
2–Command Reference Command Syntax Exit Exits the command line interface and returns you to the login prompt. (Same as the quit command.) Authority None Syntax exit Examples The exit command behaves differently depending on whether you at the chassis or blade management level. At the chassis management level, exit returns you to the login prompt.
Page 36: Fciproute
2–Command Reference Command Syntax FcipRoute Configures a new Fibre Channel over IP (FCIP) route and lets you modify or delete an existing FCIP route. Each FCIP route requires a dedicated Fibre Channel and Gigabit Ethernet port. Configuring an FCIP route and specifying a Fibre Channel and Gigabit Ethernet (GE) port pair takes precedence over any previously existing configuration for the port pair (FC/GE), and removes the existing configuration of the port pair.
Page 37 2–Command Reference Command Syntax FC Port (1=FC1 2=FC2) GE Port (1=GE1 2=GE2) IP Address (IPv4 or IPv6; 0=IPv6 Link Local) [0.0.0.0 ] 172.35.15.11 Subnet Mask [0.0.0.0 ] 255.255.254.0 Gateway IP Address [0.0.0.0 ] 172.35.14.1 Remote IP Address [0.0.0.0 ] 172.17.136.18 MTU Size (0=Normal, 1=Jumbo, 2=Other) [Normal TCP Window Size (0=8KB, 1=16KB, 2=32KB)
Page 38 2–Command Reference Command Syntax Window Scaling Factor (Min=0, Max=9) TCP Port No. (Min=1024, Max=65535) [3225 Bandwidth, Mbit/sec (Min=1, Max=10000) [10000 VLAN (0=Enable, 1=Disable) [Disabled FCIP SW Compression(0=Enable,1=Disable,2=Auto)[Disabled All attribute values for FCIP Route 1 will now be saved. The following shows an example of the fciproute mod command: iSR6200 <1>...
Page 39 2–Command Reference Command Syntax The following shows an example of the fciproute rm command: iSR6200 <1> (admin) #> fciproute rm A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 40: Fru
2–Command Reference Command Syntax Saves and restores the router’s configuration. Authority Admin session to restore Syntax restore save Keywords restore The fru restore command requires that you first FTP the tar file containing the configuration to the router. When you issue this command, the system prompts you to enter the restore level.
Page 41: Help
2–Command Reference Command Syntax Help Lists the iSR6200 CLI commands and their syntax. The iSR6200 includes the following help command sets: General iSCSI Server Connectivity Data Migration SAN over WAN Authority None Syntax help Examples This section provides examples of each help command set. The help command differs for the chassis and the blade.
Page 42 2–Command Reference Command Syntax help history image [ cleanup | list | unpack ] image cleanup image list image unpack [ <filename> ] initiator [ add | rm ] iscsi [ discover | login | logout ] logout passwd ping quit reboot reset [ factory | mappings ]...
Page 43 2–Command Reference Command Syntax iscsi | isns | logs | luninfo luns | memory | mgmt | ntp perf | presented_initiators | presented_targets | properties snmp | stats | system | targets vpgroups | portstats ] show chap show chassis show event_notification show fc [ <PORT_NUM>...
Page 44 2–Command Reference Command Syntax show initiators_lunmask show lunmask Data Migration Command Set: =========================== array rm compare_luns [ add | acknowledge | rm | start | stop | pause | resume | rm_peer] dml [ create | delete ] migration [ add | acknowledge | rm | start | stop | pause | resume | rm_peer ] migration_group [ add | rm | edit ] miguser [ begin | end | start | stop | cancel ]...
Page 45: History
2–Command Reference Command Syntax History Lists numerically the previously entered commands. Authority None Syntax history Examples The following example shows the history command: iSR6200 <1> (admin) #> history 1: admin start 2: help 3: history iSR6200 <1> (admin) #> ISR654601-00 D 2-21...
Page 46: Image
2–Command Reference Command Syntax Image Updates the router’s firmware image and cleans up (removes) the image files in the router’s /var/ftp directory. Authority Admin session Syntax image cleanup list [file] unpack [file] Keywords cleanup Removes all firmware image files in the router’s /var/ftp directory. These are files transferred by the user when updating the router’s firmware image.
Page 47: Initiator
2–Command Reference Command Syntax Initiator Adds, modifies, and removes an initiator in the router’s database. Authority Admin session Syntax initiator remove Keywords Adds an initiator to the router’s database. Modifies the settings of an initiator. rm (remove) Removes a logged-out initiator. You cannot remove an initiator that is currently logged in.
Page 48 2–Command Reference Command Syntax A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 49: Logout
2–Command Reference Command Syntax Logout Exits the CLI and returns you to the login prompt. Authority None Syntax logout Examples The following example shows the logout command: iSR6200 <1> (admin) #> logout (none) login: ISR654601-00 D 2-25...
Page 50: Lunmask
2–Command Reference Command Syntax Lunmask Maps a target LUN to an initiator, and also removes mappings. The CLI prompts you to select from a list of virtual port groups, targets, LUNs and initiators. Authority Admin session Syntax lunmask remove Keywords Maps a LUN to an initiator.
Page 51 2–Command Reference Command Syntax All attribute values for that have been changed will now be saved. The following shows an example of the lunmask add command with virtual port groups: iSR6200 <1> (admin) #> lunmask add Index Mapped (WWNN,WWPN/iSCSI Name) ----- ------ ----------------------...
Page 52 2–Command Reference Command Syntax The following example shows the lunmask rm (remove) command: iSR6200 <1> (admin) #> lunmask rm Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 20:00:00:20:37:fd:8b:ab,22:00:00:20:37:fd:8b:ab 20:00:00:20:37:fd:8a:b0,22:00:00:20:37:fd:8a:b0 20:00:00:20:37:fd:9c:f7,22:00:00:20:37:fd:9c:f7 20:00:00:20:37:fd:8d:00,22:00:00:20:37:fd:8d:00 Please select a Target from the list above ('q' to quit): WWULN Vendor ---- ----------...
Page 53 2–Command Reference Command Syntax 0/VPGROUP_2 Please select a LUN from the list above ('q' to quit): Index Initiator ----- ----------------- iqn.1991-05.com.microsoft:winhaz38 Please select an Initiator to remove ('a' to remove all, 'q' to quit): All attribute values that have been changed will now be saved. iSR6200 <1>...
Page 54: Passwd
2–Command Reference Command Syntax Passwd Changes the guest and administrator passwords. Authority Admin session Syntax passwd Examples The following example shows the passwd command: iSR6200 <1> (admin) #> passwd Press 'q' and the ENTER key to abort this command. Select password to change (0=guest, 1=admin) account OLD password ****** account NEW password (6-128 chars)
Page 55: Ping
2–Command Reference Command Syntax Ping Verifies the connectivity of management and GE ports. This command works with both IPv4 and IPv6. Authority Admin session Syntax ping Examples The following example shows the ping command: iSR6200 <1> (admin) #> ping A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 56: Quit
2–Command Reference Command Syntax Quit Exits the CLI and returns you to the login prompt. (Same as the exit command.) Authority None Syntax quit Examples The quit command behaves differently depending on whether you at the chassis or blade management level. At the chassis management level, quit returns you to the login prompt.
Page 57: Reboot
2–Command Reference Command Syntax Reboot Restarts the blade firmware. Authority Admin session Syntax reboot Examples The following example shows the reboot command: iSR6200 <1> (admin) #> reboot Are you sure you want to reboot the System (y/n): System will now be rebooted... ISR654601-00 D 2-33...
Page 58: Reset
2–Command Reference Command Syntax Reset Restores the router configuration parameters to the factory-default values. The reset factory command deletes all LUN mappings, as well as all persistent data regarding targets, LUNs, initiators, virtual port group settings, log files, iSCSI and MGMT IP addresses, Fibre Channel and Ethernet port statistics, and passwords.
Page 59: Save
2–Command Reference Command Syntax Save Saves logs, traces, and port statistics. Authority Admin session Syntax save capture logs traces portstats Keywords capture The save capture command creates a debug file that captures all debug dump data. After the command completes, you must FTP the debug capture file from the blade.
Page 60 2–Command Reference Command Syntax The following example shows the save traces command: iSR6200 <1> (admin) #> save traces Save ASIC Traces completed. Package is Router_Asic_Trace.tar.gz Please use FTP to extract the file out from the System. The following examples show the save portstats command for both a Fibre Channel and a GbE port: iSR6200 <1>...
Page 61: Set
2–Command Reference Command Syntax Configures general router parameters, as well as parameters that are specific to the Fibre Channel, iSCSI, and management ports. Authority Admin session Syntax alias chap chassis fc [ <PORT_NUM> ] features iscsi [ <PORT_NUM> ] isns mgmt properties snmp [trap_destinations [ <DEST_NUM>...
Page 62 2–Command Reference Command Syntax mgmt Sets the management port parameters. (See “Set Mgmt” on page 2-47.) Sets the network time protocol (NTP) parameters. (See “Set NTP” on page 2-49.) properties Configures CLI properties for the blade. (See “Set Properties” on page 2-50.) snmp [trap_destinations [ <DEST_NUM>...
Page 63: Set Alias
2–Command Reference Command Syntax Set Alias Allows an alias name to be assigned to a presented iSCSI target. Authority Admin session Syntax set alias Examples The following example shows the set alias command. The example also shows the results of this command using the show presented_targets command: iSR6200 <2>...
Page 64 2–Command Reference Command Syntax <MAPS TO> WWNN 50:00:1f:e1:50:06:9d:20 WWPN 50:00:1f:e1:50:06:9d:2c Name iqn.2004-08.com.qlogic:isr6200.0823e00010.b2.01.50001fe150069d29 Alias <MAPS TO> WWNN 50:00:1f:e1:50:06:9d:20 WWPN 50:00:1f:e1:50:06:9d:29 Name iqn.2004-08.com.qlogic:isr6200.0823e00010.b2.01.50001fe150069d2d Alias <MAPS TO> WWNN 50:00:1f:e1:50:06:9d:20 WWPN 50:00:1f:e1:50:06:9d:2d Name iqn.2004-08.com.qlogic:isr6200.0823e00010.b2.01.50001fe150069d28 Alias <MAPS TO> WWNN 50:00:1f:e1:50:06:9d:20 WWPN 50:00:1f:e1:50:06:9d:28 2-40 ISR654601-00 D...
Page 65: Set Chap
2–Command Reference Command Syntax Set CHAP Provides for the configuration of the challenge handshake authentication protocol (CHAP). For configuration details, see 3 Configuring CHAP. Authority Admin session Syntax set chap Examples The following example shows the set chap command: iSR6200 <1> (admin) #> set chap A list of attributes with formatting and current values will follow.
Page 66: Set Chassis
2–Command Reference Command Syntax Set Chassis Sets the chassis name. Authority Admin session Syntax set chassis Examples The following example shows the set chassis command: iSR6200 <1> (admin) #> set chassis A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 67: Set Fc
2–Command Reference Command Syntax Set FC Configures a Fibre Channel port. Authority Admin session Syntax set fc [ <PORT_NUM> ] Keywords [ <PORT_NUM> ] The number of the Fibre Channel port to be configured. Examples The following example shows the set fc command: iSR6200 <1>...
Page 68: Set Features
2–Command Reference Command Syntax Set Features Applies license keys to the router. The date and time must be set on the router prior to applying a new feature key. Authority Admin session Syntax set features Keywords None. Examples The following example shows the set features command: iSR6200 <1>...
Page 69: Set Iscsi
2–Command Reference Command Syntax Set iSCSI Configures an iSCSI port. Authority Admin session Syntax set iscsi [ <PORT_NUM> ] Keywords [ <PORT_NUM> ] The number of the iSCSI port to be configured. Examples The following example shows the set iscsi command: iSR6200 <1>...
Page 70: Set Isns
2–Command Reference Command Syntax Set iSNS Configures iSNS parameters for a blade. Authority Admin session Syntax set isns Examples The following example shows the set isns command: iSR6200 <2> (admin) #> set isns A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 71: Set Mgmt
2–Command Reference Command Syntax Set Mgmt Configures the blade’s management port (10/100). Authority Admin session Syntax set mgmt Examples The following example shows the set mgmt command: iSR6200 <1> (admin) #> set mgmt A list of attributes with formatting and current values will follow.
Page 72 2–Command Reference Command Syntax IPv6 Interface (0=Enable, 1=Disable) [Disabled All attribute values that have been changed will now be saved. 2-48 ISR654601-00 D...
Page 73: Set Ntp
2–Command Reference Command Syntax Set NTP Configures the NTP parameters. Authority Admin session Syntax set ntp Examples The following example shows the set ntp command: iSR6200 <1> (admin) #> set ntp A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 74: Set Properties
2–Command Reference Command Syntax Set Properties Configures CLI properties for the blade. Authority Admin session Syntax set properties Examples The following example shows the set properties command: iSR6200 <1> (admin) #> set properties A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 75: Set Snmp
2–Command Reference Command Syntax Set SNMP Configures the general SNMP properties, as well as configuring eight trap destinations. Authority Admin session Syntax set snmp [trap_destinations [ <DEST_NUM> ]] Keywords trap_destinations Specifies the setting of the trap destinations. Examples The following example shows the set snmp command for setting the general properties: iSR6200 <1>...
Page 76 2–Command Reference Command Syntax Destination Port ] 1024 Trap Version Configuring SNMP Trap Destination 2 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled Configuring SNMP Trap Destination 3 : ------------------------------------- Destination enabled (0=Enable, 1=Disable) [Disabled Configuring SNMP Trap Destination 4 : ------------------------------------- Destination enabled (0=Enable, 1=Disable)
Page 77: Set System
2–Command Reference Command Syntax Set System Configures the blade system-wide parameters. Authority Admin session Syntax set system Examples The following example shows the set system command: iSR6200 <1> (admin) #> set system A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 78: Set Vpgroups
2–Command Reference Command Syntax Set VPGroups Sets virtual port groups (VPGs) on the blade. Allows you to enable and disable VPGs, and to modify the VPG name. Authority Admin session Syntax set vpgroups [vpgroup index] Examples The following example shows how to enable virtual port groups 2 and 3: iSR6200 <1>...
Page 79: Show
2–Command Reference Command Syntax Show Displays blade operational information. Authority None Syntax show chap chassis features fc [port_num] fciproutes [link_id} initiators [fc or iscsi] initiator_lunmask memory iscsi [port_num] isns [port_num] logs [entries] luninfo luns lunmask mgmt perf [ byte | init_rbyte | init_wbyte | tgt_rbyte | tgt_wbyte ] show portstats <fc | gige>...
Page 80 2–Command Reference Command Syntax fciproutes [link_id] Displays FCIP route confirmation parameters. features Displays licensed features. (See “Show Features” on page 2-63.) initiators [fc or iscsi] Displays SCSI initiator information: iSCSI or Fibre Channel. (See “Show Initiators” on page 2-64.) initiators_lunmask Displays initiators and the LUNs to which they are mapped.
Page 81 2–Command Reference Command Syntax perf [ byte | init_rbyte | init_wbyte | tgt_rbyte | tgt_wbyte ] Displays router performance. (See “Show Perf” on page 2-82.) show portstats <fc | gige> <port-no> <hours | mins> <duration> Displays Fibre Channel or GbE port statistics. presented_targets [fc or iscsi] Displays targets presented by the router: Fibre Channel, iSCSI, or both.
Page 82: Show Chap
2–Command Reference Command Syntax Show CHAP Displays CHAP configuration for iSCSI nodes. Authority None Syntax show chap Examples The following example shows the show command: chap iSR6200 <1> (admin) #> show chap The following is a list of iSCSI nodes that have been configured with CHAP 'ENABLED': Type iSCSI Node...
Page 83: Show Chassis
2–Command Reference Command Syntax Show Chassis Displays the chassis information and status. This command can be executed from the chassis or blade level. Authority None Syntax show chassis Examples The following example shows the show chassis command: iSR6200 #> show chassis Chassis Information --------------------- Product Name...
Page 84 2–Command Reference Command Syntax SW Version 3.3.0.0 Temp (Front/Rear/CPU1/CPU2) 46C/34C/38C/38C Power Cooling Module 2 ---------------------- Status Installed Power Source Not Connected Fan1/Fan2/Fan3 Healthy/Healthy/Healthy 2-60 ISR654601-00 D...
Page 85: Show Fc
2–Command Reference Command Syntax Show FC Displays Fibre Channel port information for the specified port. If you do not specify a port, this command displays all ports. Authority None Syntax show fc [port_num] Keywords [port_num] Identifies the number of the Fibre Channel port to display. Examples The following example shows the show fc command: iSR6200 <1>...
Page 86: Show Fciproutes
2–Command Reference Command Syntax Show FcipRoutes Displays FCIP route configuration parameters. Authority None Syntax show fciproutes [link_id] Keywords [link_id] Specifies the number of the FCIP route to be displayed (1 or 2). Examples The following example shows the show fciproutes command. iSR6200 <2>...
Page 87: Show Features
2–Command Reference Command Syntax Show Features Displays any features that have been licensed. Authority None Syntax show features Examples The following examples shows the show features command. iSR6200 <1> #> show features License Information ------------------- FCIP 1Gig Licensed FCIP 10Gig Licensed DM Capacity Licensed...
Page 88: Show Initiators
2–Command Reference Command Syntax Show Initiators Displays SCSI initiator information for Fibre Channel, iSCSI, or both. Authority None Syntax show initiators iscsi Keywords Specifies the display of Fibre Channel initiators. iscsi Specifies the display of iSCSI initiators. Examples The following example shows the show initiators command: iSR6200 <1>...
Page 89 2–Command Reference Command Syntax Status Logged Out Type ISCSI OS Type Windows ISR654601-00 D 2-65...
Page 90: Show Initiators Lun Mask
2–Command Reference Command Syntax Show Initiators LUN Mask Displays all LUNs mapped to a user-selected initiator. Authority None Syntax show initiators_lunmask Examples The following example shows the show initiators_lunmask command: iSR6200 <1> #> show initiators_lunmask Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 20:00:00:e0:8b:88:b6:02,21:00:00:e0:8b:88:b6:02 20:01:00:e0:8b:a8:b6:02,21:01:00:e0:8b:a8:b6:02 ISCSI...
Page 91: Show Iscsi
2–Command Reference Command Syntax Show iSCSI Displays iSCSI information for the specified port. If you do not specify the port, this command displays all ports. Authority None Syntax show iscsi [port_num] Keywords [port_num] The number of the iSCSI port to be displayed. Examples The following example shows the show iscsi port command: iSR6200 <1>...
Page 92 2–Command Reference Command Syntax iSCSI Data Digests Disabled Bandwidth, MB/sec iSCSI Port Port Status Enabled Port Mode iSCSI Link Status iSCSI Name iqn.2004-08.com.qlogic:isr6200.0951f00579.b1 Firmware Revision 3.00.01.57 Current Port Speed 100Mb/FDX Programmed Port Speed Auto MTU Size Normal Window Size 65536 MAC Address 00-c0-dd-18-c9-89 IPv4 Address...
Page 93 2–Command Reference Command Syntax Window Size 65536 MAC Address 00-c0-dd-18-c9-8a IPv4 Address 0.0.0.0 IPv4 Subnet Mask 0.0.0.0 IPv4 Gateway Address 0.0.0.0 IPv4 Target TCP Port No. 3260 IPv4 VLAN Disabled IPv6 Address 1 IPv6 Address 2 IPv6 Link Local fe80::2c0:ddff:fe18:c98a IPv6 Default Router IPv6 Target TCP Port No.
Page 94 2–Command Reference Command Syntax IPv6 VLAN Disabled iSCSI Max First Burst 65536 iSCSI Max Burst 262144 iSCSI Header Digests Disabled iSCSI Data Digests Disabled Bandwidth, MB/sec 1250 2-70 ISR654601-00 D...
Page 95: Show Isns
2–Command Reference Command Syntax Show iSNS Displays iSNS configuration information for the specified iSCSI port. If you do not specify the port, this command displays the iSNS configuration information for all iSCSI ports. Authority None Syntax show isns [port_num] Keywords [port_num] The iSCSI port number whose iSNS configuration is to be displayed.
Page 96: Show Logs
2–Command Reference Command Syntax Show Logs Displays either all or a portion of the router event log. Authority None Syntax show logs [last_x_entries] Keywords [last_x_entries] Shows only the last x number of logs entries. For example, show logs 10 displays the last ten entries in the router event log. The show logs command displays the entire router event log.
Page 97: Show Luninfo
2–Command Reference Command Syntax Show LUNinfo Displays complete information for a specified LUN and target. Authority None Syntax show luninfo Examples The following example shows the show luninfo command: iSR6200 <1> (admin) #> show luninfo Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 20:00:00:14:c3:3d:d2:e2,21:00:00:14:c3:3d:d2:e2 20:00:00:0c:50:a6:67:39,21:00:00:0c:50:a6:67:39 20:00:00:0c:50:a6:69:7e,21:00:00:0c:50:a6:69:7e...
Page 98 2–Command Reference Command Syntax VendorId SEAGATE ProductId ST336754FC ProdRevLevel XR22 Portal Lun Size 35003 MB Lun State Online LUN Path Information -------------------- Controller Id WWPN,PortId / IQN,IP Path Status ------------- --------------------------------- ----------- 21:00:00:14:c3:3d:d2:e2, 62-01-63 Current 2-74 ISR654601-00 D...
Page 99: Show Luns
2–Command Reference Command Syntax Show LUNs Displays LUN information for each target. Authority None Syntax show luns Examples The following example shows the show luns command: iSR6200 <1> #> show luns Target(WWPN) VpGroup LUN Serial Number/WWULN ------------ ------- --- ------------------- 21:00:00:14:c3:3d:d2:e2 VPGROUP_1 21:00:00:0c:50:a6:67:39...
Page 100 2–Command Reference Command Syntax iSCSI Name ---------------------------------------------- iqn.2001-05.com.equallogic:0-8a0906-01e829a07-58afb16bae94cffb-demo-2 2-76 ISR654601-00 D...
Page 101: Show Lunmask
2–Command Reference Command Syntax Show Lunmask Displays all initiators mapped to a user-specified LUN. Authority None Syntax show lunmask Examples The following example shows the show lunmask command: iSR6200 <1> #> show lunmask Index (WWNN,WWPN/iSCSI Name) ----- ---------------------- 20:00:00:14:c3:3d:d2:e2,21:00:00:14:c3:3d:d2:e2 20:00:00:0c:50:a6:67:39,21:00:00:0c:50:a6:67:39 20:00:00:0c:50:a6:69:7e,21:00:00:0c:50:a6:69:7e 20:00:00:14:c3:3d:d3:55,21:00:00:14:c3:3d:d3:55 20:00:00:14:c3:3d:d3:57,21:00:00:14:c3:3d:d3:57...
Page 102 2–Command Reference Command Syntax Target iqn.2001-05.com.equallogic:0-8a0906-bc4a49907-3b4fb16b0b14c529-demo Initiator ----------------- 21:00:00:e0:8b:88:b6:02 2-78 ISR654601-00 D...
Page 103: Show Memory
2–Command Reference Command Syntax Show Memory Displays free and total physical system memory and GE port connections. Does not display information about free space in /var/ftp/. Authority None Syntax show memory Examples The following example shows the show memory command: iSR6200 <1>...
Page 104: Show Mgmt
2–Command Reference Command Syntax Show Mgmt Displays the blade’s management port (10/100) configuration. Authority None Syntax show mgmt Examples The following example shows the show mgmt command: iSR6200 <1> (admin) #> show mgmt Management Port Information ----------------------------- IPv4 Interface Enabled IPv4 Mode Dhcp IPv4 IP Address...
Page 105: Show Ntp
2–Command Reference Command Syntax Show NTP Displays the router’s network time protocol (NTP) configuration. Authority None Syntax show ntp Examples The following example shows the show ntp command: iSR6200 <1> #> show ntp NTP Information ----------------- Mode Disabled Status Offline TimeZone Offset (Hours) ISR654601-00 D 2-81...
Page 106: Show Perf
2–Command Reference Command Syntax Show Perf Displays the port, read, write, initiator, or target performance in bytes per second. Authority None Syntax show perf [ byte | init_rbyte | init_wbyte | tgt_rbyte | tgt_wbyte ] Keywords byte Displays performance data (bytes per second) for all ports. The show perf byte command also provides FCIP route performance numbers.
Page 107 2–Command Reference Command Syntax WARNING: Valid data is only displayed for port(s) that are not associated with any configured FCIP routes. Displaying bytes/sec (total)... (Press any key to stop display) FCIP1Cx -------------------------------------------------------- iSR6200 <1> #> show perf init_rbyte WARNING: Valid data is only displayed for port(s) that are not associated with any configured FCIP routes.
Page 108 2–Command Reference Command Syntax iSR6200 <1> #> show perf tgt_wbyte WARNING: Valid data is only displayed for port(s) that are not associated with any configured FCIP routes. Displaying bytes/sec (target mode write)... (Press any key ato stop display) ------------------------------------------------ 2-84 ISR654601-00 D...
Page 109: Show Portstats
2–Command Reference Command Syntax Show Portstats Displays Fibre Channel or GbE port statistics. Authority None Syntax show portstats <fc | gige> <port-No> <hours | mins> <duration> Keywords Specifies the display of Fibre Channel port statistics. gige Specifies the display of GbE port statistics. mins Specifies that display of statistics by the minute.
Page 110 2–Command Reference Command Syntax 11:45:48 11:44:48 11:43:48 11:42:48 11:41:48 11:40:48 11:39:48 11:38:48 11:37:48 11:36:48 iSR6200 <1> #> show portstats fc 1 hours 2 This will display monitoring statistics of FC Port 1 for last 2 hour(s). Statistics are displayed in reverse order. If the router has been rebooted recently, the statistics are displayed starting from the last reboot.
Page 111 2–Command Reference Command Syntax The following examples show the show portstats gige command: iSR6200 <1> #> show portstats gige 1 mins 10 This will display monitoring statistics of GE Port 1 for last 10 minute(s). Statistics are displayed in reverse order. If the router has been rebooted recently, the statistics are displayed starting from the last reboot.
Page 112 2–Command Reference Command Syntax TCP retransmitted packets (ReTxPkt), Number of TCP Connection drops (ConnDrop) Current Date 12/21/2010 TimeStamp TxByte RxByte TxPkt RxPkt MaxRTT MinRTT ReTxPkt ConnDrop --------- ------ ------ ----- ----- ------ ------ ------- -------- 13:04:48 12:04:48 2-88 ISR654601-00 D...
Page 113: Show Presented Targets
2–Command Reference Command Syntax Show Presented Targets Displays targets presented by the router: Fibre Channel, iSCSI, or both. Authority None Syntax show presented_targets iscsi Keywords Specifies the display of Fibre Channel presented targets. iscsi Specifies the display of iSCSI presented targets. Examples The following example shows the show presented_targets fc command: iSR6200 <1>...
Page 114 2–Command Reference Command Syntax Port Type <MAPS TO> Name iqn.2001-05.com.equallogic:0-8a0906-fc9829a07-d41fb16bae64cffa-demo-1 WWNN 20:06:00:c0:dd:13:17:e8 WWPN 21:06:00:c0:dd:13:17:e8 Port ID 01-01-06 Port Type <MAPS TO> Name iqn.2001-05.com.equallogic:0-8a0906-01e829a07-58afb16bae94cffb-demo-2 The following example shows the show presented_targets iscsi command: iSR6200 <1> #> show presented_targets iscsi Presented Target Information ------------------------------ iSCSI Presented Targets -------------------------...
Page 115 2–Command Reference Command Syntax WWPN 50:00:1f:e1:50:01:11:58 Name iqn.2000-04.com.qlogic:iSR6200:1.50001fe150011150.50001fe150011158 10.3.5.67 CHAP Disabled <MAPS TO> WWNN 50:00:1f:e1:50:01:11:50 WWPN 50:00:1f:e1:50:01:11:58 ISR654601-00 D 2-91...
Page 116: Show Properties
2–Command Reference Command Syntax Show Properties Displays the router blade CLI properties. Authority None Syntax show properties Examples The following example shows the show properties command: iSR6200 <1> #> show properties CLI Properties ---------------- Inactivty Timer 15 minutes Prompt String iSR6200 2-92 ISR654601-00 D...
Page 117: Show Snmp
2–Command Reference Command Syntax Show SNMP Displays the router’s simple network management protocol (SNMP) and any configured traps. Authority None Syntax show snmp Examples The following example shows the show snmp command: iSR6200 <1> (admin) #> show snmp SNMP Configuration ------------------ Read Community Public...
Page 118: Show Stats
2–Command Reference Command Syntax Show Stats Displays the blade statistics for Fibre Channel and iSCSI. Authority None Syntax show stats Examples The following example shows the show stats command: iSR6200 <1> #> show stats FC Port Statistics -------------------- FC Port Interrupt Count Target Command Count Initiator Command Count...
Page 119 2–Command Reference Command Syntax MAC Xmit Jumbo Frames MAC Rcvd Frames 42061498217 MAC Rcvd Byte Count 60362392962831 MAC Rcvd Unknown Control Frames MAC Rcvd Pause Frames MAC Rcvd Control Frames MAC Rcvd Dribbles MAC Rcvd Frame Length Errors MAC Rcvd Jabbers MAC Rcvd Carrier Sense Errors MAC Rcvd Dropped Frames MAC Rcvd CRC Errors...
Page 120 2–Command Reference Command Syntax MAC Rcvd Control Frames MAC Rcvd Dribbles MAC Rcvd Frame Length Errors MAC Rcvd Jabbers MAC Rcvd Carrier Sense Errors MAC Rcvd Dropped Frames MAC Rcvd CRC Errors MAC Rcvd Encoding Errors MAC Rcvd Length Errors Large MAC Rcvd Small Errors Small MAC Rcvd Multicast Frames MAC Rcvd Broadcast Frames...
Page 121 2–Command Reference Command Syntax TCP Xmit Byte Count 57389353022514 TCP Rcvd Segment Count 42061430681 TCP Rcvd Byte Count 57418079800284 TCP Persist Timer Expirations TCP Rxmit Timer Expired TCP Rcvd Duplicate Acks 986657165 TCP Rcvd Pure Acks 816265831 TCP Xmit Delayed Acks 3584507 TCP Rcvd Pure Acks 177811024...
Page 122 2–Command Reference Command Syntax TCP ECC Error Corections MAC Xmit Frames 1776 MAC Xmit Bytes 337380 MAC Xmit Multicast Count MAC Xmit Broadcast Count MAC Xmit Pause Count MAC Xmit Control Frames MAC Xmit Deferrals MAC Xmit Late Collisions MAC Xmit Aborted MAC Xmit Multiple Collisions MAC Xmit Single Collisions MAC Xmit Collisions...
Page 123: Show Statsfcip
2–Command Reference Command Syntax Show Statsfcip Displays the blade statistics specific to FCIP routes. Authority None Syntax show statsfcip Examples The following example shows the show statsfcip command: iSR6200 <2> #> show statsfcip FCIP Link Statistics ----------------------- FCIP Link FC Xmit Frames FC Xmit Bytes FC Rcvd Frames FC Rcvd Bytes...
Page 124 2–Command Reference Command Syntax MAC Xmit Pause Count MAC Xmit Control Frames MAC Xmit Deferrals MAC Xmit Late Collisions MAC Xmit Aborted MAC Xmit Multiple Collisions MAC Xmit Single Collisions MAC Xmit Collisions MAC Xmit Dropped Frames MAC Xmit Jumbo Frames MAC Rcvd Frames 19478 MAC Rcvd Bytes...
Page 125: Show System
2–Command Reference Command Syntax Show System Displays blade product information, including the serial number, hardware and software versions, port quantities, and temperature. Authority None Syntax show system Examples The following example shows the show system command: iSR6200 <1> (admin) #> show system System Information -------------------- Product Name...
Page 126: Show Targets
2–Command Reference Command Syntax Show Targets Displays targets discovered by the router: Fibre Channel, iSCSI, or both. Authority None Syntax show targets scsi Keywords Specifies the display of Fibre Channel targets. iscsi Specifies the display of iSCSI targets. Examples The following example shows the show targets fc command: iSR6200 <1>...
Page 127 2–Command Reference Command Syntax The following example shows the show targets iscsi command: iSR6200 <1> #> show targets iscsi Target Information -------------------- iSCSI Name iqn.2001-05.com.equallogic:0-8a0906-bc4a49907-3b4fb16b0b14c529-demo Alias State Online IP Address 10.3.5.2 (Logged In --> GE1) iSCSI Name iqn.2001-05.com.equallogic:0-8a0906-fc9829a07-d41fb16bae64cffa-demo-1 Alias State Online IP Address 10.3.5.2 (Logged In -->...
Page 128: Show Vpgroups
2–Command Reference Command Syntax Show VPGroups Displays information about the blade’s configured virtual port groups. Authority None Syntax show vpgroups [vp index] Keywords vp index The number (1–4) of the virtual port group to be displayed. Examples The following example shows the show vpgroups command for a specific virtual port group: iSR6200 <1>...
Page 129 2–Command Reference Command Syntax Status Enabled WWPNs 21:02:00:c0:dd:13:16:f8 21:02:00:c0:dd:13:16:f9 Index VpGroup Name VPGROUP_4 Status Enabled WWPNs 21:03:00:c0:dd:13:16:f8 21:03:00:c0:dd:13:16:f9 ISR654601-00 D 2-105...
Page 130: Shutdown
2–Command Reference Command Syntax Shutdown Shuts down the blade. Authority Admin session Syntax shutdown Examples The following example shows the shutdown command: iSR6200 <1> (admin) #> shutdown Are you sure you want to shutdown the System (y/n): Command aborted. 2-106 ISR654601-00 D...
Page 131: Target
2–Command Reference Command Syntax Target Removes an offline target from the blade’s database. Typically, you will use this command to remove targets from the database that are no longer connected to the router. NOTE: The target add command is not currently supported. Authority Admin session Syntax...
Page 132: Traceroute
2–Command Reference Command Syntax Traceroute Prints the route a network packet takes to reach the destination specified by the user. Authority Admin session Syntax traceroute Examples The following example shows the traceroute command: iSR6200 <1> (admin) #> traceroute A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value.
Page 133: Configuring Chap
Configuring CHAP In challenge handshake authentication protocol (CHAP), the authentication agent sends the client program an ID value and a random value that is used only once. Both the sender and peer share a predefined secret. The peer concatenates the random value, the ID, and the secret.
Page 134: Discovery Session-Bi-Directional Chap
3–Configuring CHAP Discovery Session—Bi-directional CHAP Discovery Session—Bi-directional CHAP Follow this procedure to configure a bi-directional (BiDi) CHAP used during a discovery session. To configure a BiDi CHAP in a discovery session: On the router, follow these steps: Enable CHAP on the port. Create a secret (for example, secret_port).
Page 135: Discovery Session-Uni-Directional Chap
3–Configuring CHAP Discovery Session—Uni-directional CHAP Discovery Session—Uni-directional CHAP Follow this procedure to configure a uni-directional CHAP used during a discovery session. To configure a uni-directional CHAP in a discovery session: Do not enable CHAP on the ISCSI port. Execute the initiator add command as follows: Add the initiator that is about to perform the discovery.
Page 136: Normal Session-Bi-Directional Chap
3–Configuring CHAP Normal Session—Bi-directional CHAP Normal Session—Bi-directional CHAP Follow this procedure to configure a bi-directional (BiDi) CHAP used during a normal session. To configure BiDi CHAP in a normal session: On the router, follow these steps. Enable CHAP on the presented target to which the initiator will login. Create a secret (for example, secret_target).
Page 137: Normal Session-Uni-Directional Chap
3–Configuring CHAP Normal Session—Uni-directional CHAP Normal Session—Uni-directional CHAP Follow this procedure to configure a uni-directional CHAP used during a normal session. To configure uni-directional CHAP in a normal session: Do not enable CHAP on the presented target. Execute the initiator add command as follows: Add the initiator that is about to do a normal login.
Page 138 3–Configuring CHAP Normal Session—Uni-directional CHAP ISR654601-00 D...
Page 139: Virtual Port Groups
Virtual Port Groups Some virtualized storage arrays limit the number of LUNs exposed to a host to 256 LUNs. In order to access more than 256 LUNs per target, each iSR6200 blade supports up to four virtual port groups (VPGs). If you want your iSCSI hosts to have access to a total of more than 256 distinct LUNS from a specified Fibre Channel target array, you must enable and configure additional virtual port groups.
Page 140 4–Virtual Port Groups Displaying Virtual Port Groups Displaying Virtual Port Groups To display virtual port group information, use the show vpgroups command in the CLI. For example: iSR6200 <1> (admin) #> show vpgroups VpGroup Information --------------------- Index VpGroup Name VPGROUP_1 Status Enabled WWPNs...
Page 141: Enabling Virtual Port Groups
4–Virtual Port Groups Enabling Virtual Port Groups Enabling Virtual Port Groups You can enable or disable virtual port groups on your blade using the set vpgroups command. The following example shows how to enable virtual port groups 2 and 3. iSR6200 <1>...
Page 142 4–Virtual Port Groups Enabling Virtual Port Groups The following example shows the output from the CLI for an iSR6200 blade with three virtual port groups enabled. You can display information about the virtual port groups configured on your iSR6200 with the show vpgroups command: iSR6200 <1>...
Page 143 4–Virtual Port Groups Enabling Virtual Port Groups The following example shows the same information grouped by physical Fibre Channel port: iSR6200 <1> (admin) #> show fc FC Port Information --------------------- FC Port Port Status Enabled Port Mode Link Status Current Link Rate Programmed Link Rate Auto WWNN...
Page 144 4–Virtual Port Groups Enabling Virtual Port Groups WWPN 21:01:00:c0:dd:13:17:e9 (VPGROUP_2) Port ID 62-06-01 (VPGROUP_2) WWNN 20:02:00:c0:dd:13:17:e9 (VPGROUP_3) WWPN 21:02:00:c0:dd:13:17:e9 (VPGROUP_3) Port ID 62-06-02 (VPGROUP_3) WWNN 20:03:00:c0:dd:13:17:e9 (VPGROUP_4) WWPN 21:03:00:c0:dd:13:17:e9 (VPGROUP_4) Port ID 62-06-03 (VPGROUP_4) Firmware Revision No. 5.03.14 Frame Size 2048 Execution Throttle Connection Mode...
Page 145 4–Virtual Port Groups Enabling Virtual Port Groups Programmed Link Rate Auto WWNN 20:00:00:c0:dd:13:17:eb WWPN 21:00:00:c0:dd:13:17:eb Port ID 00-00-00 Firmware Revision No. 5.02.03 Frame Size 2048 Execution Throttle Connection Mode Unknown SFP Type 10Gb Enode MAC Address 00-c0-dd-13-17-ef Fabric Provided MAC Address 00-00-00-00-00-00 VlanId Priority Level...
Page 146 4–Virtual Port Groups Enabling Virtual Port Groups ISR654601-00 D...
Page 147: Configuring Fibre Channel Initiators To Iscsi Storage
Configuring Fibre Channel Initiators to iSCSI Storage This chapter provides instructions for connecting Fibre Channel hosts to iSCSI targets using the QLogic iSR6240 and iSR6250 routers. These routers are collectively referred to as the iSR6200 throughout this chapter. Prerequisites Before connecting the Fibre Channel hosts to the iSCSI targets: Configure the router iSCSI ports.
Page 148: Step 1: Discover The Iscsi Targets
5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Step 1: Discover the iSCSI Targets There are two ways to discover the iSCSI targets: Using the iSCSI Discover Command Using iSNS Server Connectivity Using the iSCSI Discover Command Issue the show targets command. For example: iSR6200 <1>...
Page 149 5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Using iSNS Server Connectivity Allow the iSCSI storage access to the iSNS server iSCSI port and router iSCSI ports. This access can be either IP based or iqn based. See your iSCSI storage documentation for access control information.
Page 150: Isns Server Properties: Creating A Discovery Domain
5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Figure 5-1. iSNS Server Properties: Creating a Discovery Domain ISR654601-00 D...
Page 151: Isns Server Properties: Enabling A Discovery Domain Set
5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Add this discovery domain to a set, and then enable this discovery domain set, as shown in Figure 5-2. Figure 5-2. iSNS Server Properties: Enabling a Discovery Domain Set List the discovered targets by issuing the show targets command. ISR654601-00 D...
Page 152: Step 2: Log Into The Iscsi Targets
5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Step 2: Log into the iSCSI Targets Issue the iscsi login command, and then follow the prompts. A list of attributes appear with the current value (in brackets). At the prompts, select the target and IP address, and then specify additional target attributes as needed.
Page 153: Access To The Storage Lun
5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Table 5-1. Zone Host with Router—Fibre Channel-Based Ports Fibre Channel Fibre Channel Zone Zone Members Server, iSR6200, Switch and IP Name (WWPNs) Storage Name Address Figure 5-3 shows a zone configured with the router to see the targets. Figure 5-3.
Page 154 5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Issue the show initiators command. For example: iSR6200 <1> (admin) #> show initiators Initiator Information ----------------------- WWNN 20:00:00:1b:32:9a:e7:5c WWPN 21:00:00:1b:32:9a:e7:5c Port ID 0b-05-00 Status Logged Out Type OS Type Windows Issue the lunmask add command, and then follow the prompts. For example: iSR6200 <1>...
Page 155: Step 5: View The Newly Mapped Target Zoned To The Fibre
5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview Please select a portal to map the target from the list above ('q' to quit): All attribute values that have been changed will be saved. NOTE: In the preceding code, the numbers in the last Index column correspond to the following ports: Index Port...
Page 156: Iscsi Configured With Router To Fibre Channel San
5–Configuring Fibre Channel Initiators to iSCSI Storage Configuration Overview <MAPS TO> Name iqn.2001-05.com.equallogic:0-8a0906-7e33e0d06-83c835550264bed e-demo1 Figure 5-4 shows that the zone of the newly mapped target is configured with the iSR6200 router to the Fibre Channel SAN. Figure 5-4. iSCSI Configured with Router to Fibre Channel SAN After the server discovers the storage and I/O has started, issue the show perf byte command to determine what I/O is operational on the selected ports.
Page 157: Simple Network Management Protocol
Simple Network Management Protocol Simple network management protocol (SNMP) provides monitoring and trap functions for managing the router through third-party applications that support SNMP. The router firmware supports SNMP versions 1 and 2, and a QLogic management information base (MIB) (see page A-4).
Page 158: Snmp Parameters
A–Simple Network Management Protocol SNMP Parameters SNMP Parameters You can set the SNMP properties using SANsurfer Router Manager or the command line interface (CLI). Table A-1 describes the SNMP parameters. Table A-1. SNMP Parameters Parameter Description A password that authorizes an SNMP management server to read information Read community from the router.
Page 159: Snmp Trap Configuration
A–Simple Network Management Protocol SNMP Trap Configuration SNMP Trap Configuration SNMP trap configuration lets you set up to eight trap destinations. Choose from Trap 1 through Trap 8 to configure each trap. Table A-2 describes the parameters for configuring an SNMP trap. Table A-2.
Page 160: Management Information Base (Mib)
A–Simple Network Management Protocol Management Information Base (MIB) Management Information Base (MIB) This section describes the QLogic MIB. The MIB includes the following tables: “Network Port Table” on page A-4 “Fibre Channel Port Table” on page A-7 “Initiator Object Table” on page A-9 “LUN Table”...
Page 161 A–Simple Network Management Protocol Management Information Base (MIB) A network port entry includes the following sequence of objects: qsrNwPortRole QsrPortRole qsrNwPortIndex unsigned32 qsrNwPortAddressMode INTEGER qsrIPAddressType InetAddressType qsrIPAddress InetAddress qsrNetMask InetAddress qsrGateway InetAddress qsrMacAddress MacAddress qsrNwLinkStatus QsrLinkStatus qsrNwLinkRate QsrLinkRate qsrNwPortRole Syntax QsrPortRole Access Not accessible...
Page 162 A–Simple Network Management Protocol Management Information Base (MIB) qsrIPAddressType Syntax InetAddressType Access Read-only Description IP address type: ipv4 or ipv6. qsrIPAddress Syntax InetAddress Access Read-only Description IP address of the port. qsrNetMask Syntax InetAddress Access Read-only Description Subnet mask for this port. qsrGateway Syntax InetAddress...
Page 163: Fibre Channel Port Table
A–Simple Network Management Protocol Management Information Base (MIB) qsrNwLinkRate Syntax QsrLinkRate Access Read-only Description Operational link rate for this port. Fibre Channel Port Table This table contains a list of the Fibre Channel (FC) ports on the router. There are as many entries in this table as there are Fibre Channel ports on the router.
Page 164 A–Simple Network Management Protocol Management Information Base (MIB) qsrFcPortRole Syntax QsrPortRole Access Not accessible Description Operational role of this port: Fibre Channel protocol (FCP) mode or frame shuttle mode. qsrFcPortIndex Syntax Unsigned32 Access Not accessible Description A positive integer indexing each Fibre Channel port in a specified role.
Page 165: Initiator Object Table
A–Simple Network Management Protocol Management Information Base (MIB) qsrFcPortType Syntax Unsigned32 Access Read-only Description Type of Fibre Channel port, as indicated by the use of the appropriate value assigned by the Internet Assigned Num- bers Authority (IANA). The Fibre Channel port types regis- try maintained by IANA is located here: www.iana.org/assignments/fc-port-types qsrFcLinkStatus...
Page 166 A–Simple Network Management Protocol Management Information Base (MIB) qsrIsInitEntry Syntax QsrIsInitEntry Access Not accessible Description Each entry (row) contains information about a specific iSCSI initiator. iSCSI initiator information entry consists of the following sequence of objects: qsrIsInitIndex Unsigned32, qsrIsInitName SnmpAdminString, qsrIsInitAlias SnmpAdminString, qsrIsInitAddressType InetAddressType,...
Page 167 A–Simple Network Management Protocol Management Information Base (MIB) qsrIsInitAddressType Syntax InetAddressType Access Read-only Description Type of iSCSI initiator’s IP address (IPv4 or IPv6). qsrIsInitAddress Syntax InetAddress Access Read-only Description IP address of the iSCSI initiator. qsrIsInitStatus Syntax Integer: 1 = unknown, 2 = loggedIn, 3 = loggedOut, 4 = recovery...
Page 168: Lun Table
A–Simple Network Management Protocol Management Information Base (MIB) LUN Table These tables contains information about the logical unit number (LUN) list. qsrLunTable Syntax SEQUENCE OF QsrLunEntry Access Not accessible Description A list of the LUNs on the Fibre Channel targets discovered by the router.
Page 169 A–Simple Network Management Protocol Management Information Base (MIB) qsrLunVendorId Syntax SnmpAdminString Access Read-only Description Vendor ID for the LUN. qsrLunProductId Syntax SnmpAdminString Access Read-only Description Product ID for the LUN. qsrLunProdRevLevel Syntax SnmpAdminString Access Read-only Description Product revision level for the LUN. qsrLunSize OBJECT-TYPE Syntax Unsigned32...
Page 170: Virtual Port Group Table
A–Simple Network Management Protocol Management Information Base (MIB) qsrLunVPGroupid Syntax Integer Access Read-only Description ID of the virtual port group to which this LUN belongs. qsrLunVPGroupname OBJECT-TYPE Syntax SnmpAdminString Access Read-only Description Virtual port group name to which this LUN belongs. Virtual Port Group Table This table contains a list of virtual port groups.
Page 171 A–Simple Network Management Protocol Management Information Base (MIB) The QsrVPGroupEntry contains the following sequence of objects: qsrVPGroupIndex Unsigned32, qsrVPGroupId INTEGER, qsrVPGroupName SnmpAdminString, qsrVPGroupWWNN VpGroupWwnnAndWwpn, qsrVPGroupWWPN VpGroupWwnnAndWwpn, qsrVPGroupStatus INTEGER qsrVPGroupIndex OBJECT-TYPE Syntax Unsigned32 Access Read-only Description Virtual port group index. qsrVPGroupId OBJECT-TYPE Syntax Integer Access...
Page 172: Sensor Table
A–Simple Network Management Protocol Management Information Base (MIB) qsrVPGroupWWPN OBJECT-TYPE Syntax VpGroupWwnnAndWwpn Access Read-only Description World wide port number (WWPN). qsrVPGroupStatus OBJECT-TYPE Syntax Integer: 0 = enabled; 1 = disabled Max-Access Read-only Description Maintain the status of the virtual port group (enabled/dis- abled) Sensor Table The sensor table lists all the sensors on the router.
Page 173 A–Simple Network Management Protocol Management Information Base (MIB) A sensor entry contains the following sequence of objects: qsrSensorType INTEGER qsrSensorIndex Unsigned32 qsrSensorUnits INTEGER qsrSensorValue Integer32 qsrUpperThreshold Integer32 qsrLowerThreshold Integer32 qsrSensorState INTEGER qsrSensorType Syntax INTEGER Temperature = 1 Access Not accessible Description Type of data being measured by this sensor.
Page 174 A–Simple Network Management Protocol Management Information Base (MIB) qsrUpperThreshold Syntax Integer32 Access Read-only Description Upper-level threshold for this sensor. qsrLowerThreshold Syntax Integer32 Access Read-only Description Lower-level threshold for this sensor. qsrSensorState Syntax INTEGER Access Read-only Description State of this sensor, indicating the health of the system: Unknown = The sensor value/thresholds cannot be deter- mined.
Page 175: Notifications
A–Simple Network Management Protocol Notifications Notifications The router provides the following notification types described in this section: “System Information Objects” on page A-19 “Notification Objects” on page A-20 “Agent Startup Notification” on page A-21) “Agent Shutdown Notification” on page A-21 “Network Port Down Notification”...
Page 176: Notification Objects
A–Simple Network Management Protocol Notifications qsrSwVersion Syntax SnmpAdminString Access Read-only Description System software (firmware) version number. qsrNoOfFcPorts Syntax Unsigned32 Access Read-only Description Quantity of Fibre Channel ports on the system. qsrNoOfGbEPorts Syntax Unsigned32 Access Read-only Description Quantity of gigabit Ethernet ports on the system. qsrAgentVersion Syntax SnmpAdminString...
Page 177: Agent Startup Notification
A–Simple Network Management Protocol Notifications qsrEventDescription Syntax SnmpAdminString Access Accessible for notify Description A textual description of the event that occurred. qsrEventTimeStamp Syntax DateAndTime Access Accessible for notify Description Indicates when the event occurred. Agent Startup Notification The agent startup notification indicates that the agent on the router has started running.
Page 178: Fibre Channel Port Down Notification
A–Simple Network Management Protocol Notifications Fibre Channel Port Down Notification The Fibre Channel port down notification indicates that the specified Fibre Channel port is down. The next time the port comes up, this event is sent with the qsrEventSeverity object set to clear. qsrFcPortDown uses the following objects: qsrFcLinkStatus qsrEventTimeStamp...
Page 179: Virtual Port Group Notification
A–Simple Network Management Protocol Notifications Target Presentation State: Presented (mapped) or unpresented (unmapped) Target name Blade number (1 or 2) Virtual Port Group Notification The virtual port group notification indicates that the specified virtual port group is enabled or disabled. It also represents change in the name of the virtual port group.
Page 180: Generic Notification
A–Simple Network Management Protocol Notifications Fans at high speed Power and cooling module (PCM) number (1 or 2) Fans returned to normal speed PCM number (1 or 2) (PCM) installed PCM number (1 or 2) PCM removed PCM number (1 or 2) PCM powered (AC power connected) PCM number (1 or 2) PCM un-powered (AC power removed)
Page 181: Fcip Route Notification
A–Simple Network Management Protocol Notifications Blade number (1 or 2) Port number (1 of 4) iSNS configuration change Blade number (1 or 2) NTP configuration change Blade number (1 or 2) Router configuration change Blade number (1 or 2) Management port configuration change Blade number (1 or 2) Firmware upgrade complete Blade number (1 or 2)
Page 182 A–Simple Network Management Protocol Notifications A-26 ISR654601-00 D...
Page 183: Log Messages
Log Messages This appendix provides details about messages logged to a file. The message log is persistent because it is maintained across router power cycles and reboots. Information in Table B-1 is organized as follows: The ID column specifies the message identification numbers in ascending order. The Log Message column indicates the message text shown in the CLI or SANsurfer Router Manager router log.
Page 184 B–Log Messages NIC = FCIP NIC module System = System module User = User module The Msg. Type column specifies the log message type, where: Error = Error log message Fatal = Fatal log message Info = Informational log message The Description column provides additional information about the log message.
Page 185 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41077 Error Unable to create an object for initiator object; QLBA_CreateInitiatorObject: Too many exceeded the maximum number of initiators. initiators 41096 Error Process control block status indicates that a periph- QLBA_DisplayTargetOperationStatus: PCI eral component interface/interconnect (PCI) error Error, Status 0x%.2x...
Page 186 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41268 Error iSCSI Login PDU received without a target name for QLIS_LoginPduContinue: Missing target a normal session. name 41270 Error iSCSI Login PDU received without an initiator name QLIS_LoginPduContinue: TSIH is 0 but key/value.
Page 187 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41508 Error Failed to allocate an object for Set Port Info IOCTL QLBI_SetPortInfo: processing: QLUT_AllocatePortalObject failed (PortType 0x%x, PortId 0x%x) PortType: 0 = Fibre Channel, 1 = iSCSI PortId: 0 = FC1 or iSCSI1(GE1), 1 = FC2 or iSCSI2 (GE2) 41626...
Page 188 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41717 Error Pass-Through command issued by management tool QLBI_Passthru: Invalid data length %d (such as GUI) was interrupted or timed out. bytes 41750 Error IOCTL operation unsupported.
Page 189 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 42027 Error Logout attempted using Fibre Channel VP index that QLFC_Logout: VP Index 0x%x not configured has not been configured. Operation attempted on an unconfigured VP.
Page 190 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 42649 Error Event notification; an IOCTL request was received to QLIS_HandleTeb: Unload Driver unload the iSCSI driver. 42654 Error Event notification; attempt to connect to the iSNS QLIS_HandleTeb: iSNS Connection Failed server failed.
Page 191 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 54274 Info Fibre Channel login occurred, origin xx (1 = adapter, QLFC_Login: Origin 0x%x, VP Index 0x%x, Id 2 = target, 3 = initiator), VP (virtual port) xx, ID (loop 0x%x ID) xx.
Page 192 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 54939 Info Event notification; iSCSI close connection request or QLIS_HandleTeb: UTM_EC_CLOSE_CONNECTION connection closed. or UTM_EC_CONNECTION_CLOSED 54940 Info Event notification; iSCSI connection closed. QLIS_HandleTeb: UTM_EC_CLOSE_CONNECTION or UTM_EC_CONNECTION_CLOSED 54941 Info...
Page 193 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 56842 Info Failed to resume a paused job. QLDM_ResumeMigration: Failed to resume job: %d, job's current state: 0x%x, error: 56865 Info Failed to start a delayed schedule job. QLDM_DelayedStart:%d Failed to start job : Job ID: %d 56866...
Page 194 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 56880 Info The log shows the configured start time and current Start time got from user %lu Cur Time: %lu time for a delayed migration job. Diff: %d 56881 Info...
Page 195 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 69966 iSCSI Fatal Port enable reboot timer failed. #%d: QLEnable: QLRebootTimer failed AF %x RS %x Time %d 70224 iSCSI Fatal iSNS response contains an invalid handle. #%d: QLProcSrblessiSNSResponse: Invalid handle %x 70400...
Page 196 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 70524 iSCSI Fatal Asynchronous event for unknown event type. #%d: QLProcessAen: Invalid event %x 70544 iSCSI Fatal Reboot timer failed. #%d: QLRebootTimer: Reboot failed! 70563 iSCSI Fatal...
Page 197 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 74056 iSCSI Error iSCSI processor failed the internal loopback test. #%d: QLRunDiag: MBOX Diag test internal loopback failed %x %x 74057 iSCSI Error iSCSI processor failed the external loopback test. #%d: QLRunDiag: MBOX Diag test external loopback failed %x %x 74068...
Page 198 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 74661 iSCSI Error Driver timed out an iSCSI processor operation and is #%d: QLTimer: Abort pTpb=%p, Type %x, aborting the operation. Timeout 0x%x DrvCount 0x%x, DdbIndex 0x%x 74663 iSCSI Error...
Page 199 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 86874 iSCSI Info Link up reported by iSCSI processor for GE1 or GE #%d: QLIsrDecodeMailbox: Link up 87346 iSCSI Info iSCSI controller reported a link speed/configuration #%d: QLGetFwStateCallback: link 100Mb FDX of 100Mb full-duplex (FDX).
Page 200 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 102658 Fatal Fibre Channel processor receive sequencer code #%d: QLInitializeAdapter: Load ISP2322 load failed. receive sequencer code failed 102659 Fatal Fibre Channel processor transmit sequencer code #%d: QLInitializeAdapter: Load ISP2322 load failed.
Page 201 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 106583 Error Fibre Channel processor received a SCSI command #%d: QLUtmReceiveIo: Path invalid/FW No for an unknown target path or has run out of resource count %x resources to execute additional commands.
Page 202 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 106853 Error Driver has determined that the Fibre Channel link is #%d: QLTimer: Link error count (0x%x) unreliable and unusable due to the number of errors exceeded, link down encountered.
Page 203 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 107984 Error Fibre Channel controller failed a Flash write (address #%d: QLWriteFlashDword: Write fails at x data x). addr 0x%x data 0x%x 108032 Error Fibre Channel controller failed the Get VP Database #%d: QLGetVpDatabase: command (for virtual port %d).
Page 204 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 119090 Info Fibre Channel link up occurred. Event status is #%d: QLIsrEventHandler: Link up (%x) reported, as is the contents of the Fibre Channel pro- mailbox1 = %x cessor’s mailbox 1 register.
Page 205 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 120377 Info For FCoE protocol, the DCBX protocol has started. #%d: QLIsrEventHandler: DCBX Started (%x) 120378 Info For FCoE protocol, the FCF configuration error #%d: QLIsrEventHandler: FCF Config Error occurred.
Page 206 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 139273 User Error Get Fibre Channel Advanced API memory allocation QBRPC_Initialize:GetFcAdv Mem Allocation failed. error 139280 User Error Failed memory allocation for Get Fibre Channel SFP QBRPC_Initialize:GetFcSfp Mem Allocation API.
Page 207 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 139296 User Error Failed memory allocation for Fibre Channel Target QBRPC_Initialize:FcTgt Mem Allocation API. error 139297 User Error Failed memory allocation for System Status API. QBRPC_Initialize:BridgeStatus Mem Allocation error 139298...
Page 208 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 139930 Error FCIP route add/mod failed because of lack of mem- FcipRoute#%d Failed with Memory ory. Allocation Error 139931 Error FCIP route add/mod failed because the arguments FcipRoute#%d Failed with Invalid Arg Error supplied were incorrect.
Page 209 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 151889 User Info Fibre Channel port configuration has changed. #%d: qapisetfcinterfaceparams_1_svc: FC port configuration changed 151890 User Info iSCSI port configuration has changed. #%d: qapisetiscsiinterfaceparams_1_svc: iSCSI port configuration changed 151891 User...
Page 210 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 151910 User Info Fibre Channel port %d was enabled by user. FC%d: Port status changed by user to ENABLED. 151911 User Info Fibre Channel port %d was disabled by user. FC%d: Port status changed by user to DISABLED.
Page 211 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 152100 User Info Group with ID specified in the log was added. qapiaddgroup_1_svc: Added Group with id %d 152101 User Info Group with ID specified in the log was removed. qapiremovegroup_1_svc: Removed Group with id %d 152102...
Page 212 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 152129 User Info Left power and cooling module (PCM) is or has been sysTempMon: Left PCM Installed installed. 152130 User Info Left PCM is or has been uninstalled. sysTempMon: Left PCM Un-installed 152131 User...
Page 213 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 152144 User Info Router temperature has returned to normal operating sysTempMon: Temperature back to safe range, Front: %dC Rear: %dC CPU1: %dC CPU2: value. Front: %dC Rear: %dC CPU1: %dC CPU2: %dC 152145 User...
Page 214 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 172253 FCIP Error FCIP route #n: Received connection from unauthor- FcipRoute#%d: Remote Peer IP Address ized remote peer. Validation Failed. Expected IP Address: %d.%d.%d.%d, Actual IP Address: %d.%d.%d.%d 172272 FCIP...
Page 215 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 172303 FCIP Error The TCP link for FCIP route#n has disconnected. FcipRoute#%d: TCP Link Down, MAC Stats: The MAC or Ethernet statistics include total packet Tx Dropped Count=%ld Rx Dropped Count=%ld dropped during transmit (TxDropped), total packet Tx Pause Count=%ld Rx Pause Count=%ld...
Page 216 B–Log Messages Table B-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 206089 Error The Ethernet port was not able to register as a net- QL3xxx:ql3xxx_probe: cannot register work device resulting in a port initialization error for network device %s the specified network device.
Page 217 Glossary activity LED challenge-handshake authentication protocol port LED that indicates when frames are entering or leaving the port. See CHAP. adapter CHAP The board that interfaces between the Challenge-handshake authentication host system and the target devices. protocol is used for remote logon, usually Adapter is synonymous with host bus between a client and server or a Web adapter (HBA), host adapter, and adapter...
Page 218 iSR6200 Command Line Interface (CLI) User’s Guide device failover path A target, typically a disk drive. Hardware Software feature that ensures data avail- such as a disk drive, tape drive, printer, or ability and system reliability by assigning keyboard that is installed in or connected alternate path and automatic adapter to a system.
Page 219 iSR6200 Command Line Interface (CLI) User’s Guide Fibre Channel over Ethernet IANA See FCoE. Internet Assigned Numbers Authority (IANA) is responsible for the global coordi- Fibre Channel over IP nation of the DNS Root, IP addressing, See FCIP. and other Internet protocol resources. field replaceable unit initiator See FRU.
Page 220 iSR6200 Command Line Interface (CLI) User’s Guide IP address Internet protocol address. The numeric Logical unit number, a subdivision of a address of a computer that is in the format SCSI target. It is the small integer handle used on the internet. that differentiates an individual disk drive or partition (volume) within a common iSCSI...
Page 221 iSR6200 Command Line Interface (CLI) User’s Guide media path Physical-layer information carriers. Fibre A path to a device is a combination of a Channel supports several different adapter port instance and a target port as physical media: copper, multimode optical, distinct from internal paths in the fabric and single-mode optical.
Page 222 iSR6200 Command Line Interface (CLI) User’s Guide FL_Port is a port in a fabric where an NL_Port can attach. Remote procedure call. A protocol used by a program to request a service from a port instance program located in another computer in a The number of the port in the system.
Page 223 iSR6200 Command Line Interface (CLI) User’s Guide SCSI target Small computer system interface. A The storage-device endpoint of a SCSI high-speed interface used to connect session. Initiators request data from devices, such as hard drives, CD drives, targets. Targets are typically disk-drives, printers, and scanners, to a computer.
Page 224 iSR6200 Command Line Interface (CLI) User’s Guide Virtual port group (or VPGROUP). Software component configured in the iSCSI router that is used to create virtual adapters on all Fibre Channel ports on a blade. world wide name See WWN. world wide node name See WWNN.
Page 225 Index ASIC definition of Glossary-1 account, guest traces, saving 2-36 activity LED, definition of Glossary-1 audience for this guide adapter authentication traps, enabling heartbeat missed error B-15 authentication, mutual login message configuring CHAP (discovery session) definition of Glossary-1 configuring CHAP (normal session) adapter port, definition of Glossary-1 authority requirements...
Page 226 iSR6200 Command Line Interface (CLI) User’s Guide CHAP commands (continued) authentication error reset mappings 2-34 configuration, displaying 2-58 save 2-35 configuring 2-37 definition of Glossary-1 set alias 2-39 description of set chap 2-41 key error set chassis 2-42 router parameters, configuring 2-41 set fc 2-43...
Page 227 iSR6200 Command Line Interface (CLI) User’s Guide commands (continued) CTRL+A keys, using show vpgroups 2-104, CTRL+E keys, using shutdown 2-106 customer support, obtaining target 2-107 cyclic redundancy check, See CRC traceroute 2-108 vpgroups 2-54 community read, setting SNMP properties data (persistent), saving trap, setting SNMP properties data center Ethernet, definition of Glossary-2...
Page 228 iSR6200 Command Line Interface (CLI) User’s Guide FC ports (continued) type of EEPROM definition of Glossary-2 WWN of node updated message B-16 FC-IP mode, definition of Glossary-2 electrically erasable programmable read-only FCIP routes memory, See EEPROM adding 2-12 enabling configuration parameters, showing 2-62 flashing LEDs modifying...
Page 229 iSR6200 Command Line Interface (CLI) User’s Guide fru command 2-16 fru restore command IANA definition of Glossary-3 firmware image, transferring to router FC port types registry saving router configuration and persistence image command 2-22 initiator command 2-23 transferring data to router initiators adding 2-23...
Page 230 iSR6200 Command Line Interface (CLI) User’s Guide IPv4 port type log data, creating tar file 2-35 IPv6 port type log file, clearing entries iSCSI, definition of Glossary-4 log messages iSCSI nodes, CHAP configuration for 2-58 logging on to router iSCSI ports logging out of CLI 2-25 configuring...
Page 231 iSR6200 Command Line Interface (CLI) User’s Guide mappings, LUN agent shutdown A-21 deleting 2-34 agent startup A-21 showing 2-77 FC port down A-22 materials, related FCIP route A-25 generic A-24 CHAP, configuring network port down A-21 definition of Glossary-4 objects A-20 media access control address, See MAC qsrAgentShutdown...
Page 232 iSR6200 Command Line Interface (CLI) User’s Guide objects (continued) port table qsrNoOfGbEPorts A-20 qsrSerialNumber A-19 network qsrSwVersion A-20 ports system information A-19 address mode online/offline targets A-22 FC, configuring 2-43 opening, administrator session FC, down notification A-22 operational information, showing 2-55 FC, identifier FC, index...
Page 233 iSR6200 Command Line Interface (CLI) User’s Guide properties qsrLunProdRevLevel table A-13 blade, setting 2-50 qsrLunProductId table A-13 blade, showing 2-92 qsrLunSize table A-13 qsrLunState table A-13 qsrLunTable table A-12 qsrLunVendorId table A-13 qsrLunVPGroupid table A-14 QLogic, technical support qsrLunVPGroupname table A-14 qsrAgentShutdown notification A-21...
Page 234 iSR6200 Command Line Interface (CLI) User’s Guide router log definition of Glossary-6 read community, setting SNMP properties entries, clearing reboot command 2-33 showing 2-72 reduced instruction set computer, See RISC registered state change notification, See definition of Glossary-6 RSCN error messages for B-23– B-25 related materials remote procedure call, See RPC...
Page 235 iSR6200 Command Line Interface (CLI) User’s Guide session, discovery show isns command 2-71 configuring bi-directional CHAP show logs command 2-72 configuring uni-directional CHAP show luninfo command 2-73 session, normal show lunmask command 2-77 configuring bi-directional CHAP show memory command 2-79 configuring uni-directional CHAP show mgmt command 2-80...
Page 236 iSR6200 Command Line Interface (CLI) User’s Guide shutdown command 2-106 system information shutdown notification, agent A-21 MIB object group A-19 shutting down the system 2-106 showing 2-101 small computer system interface, See SCSI small form-factor pluggable, See SFP SNMP definition of Glossary-7 TAB key, using notifications...
Page 237 iSR6200 Command Line Interface (CLI) User’s Guide tables (continued) technical support qsrLunVendorId A-13 knowledge database qsrLunVPGroupname A-14 technical support, obtaining qsrLunWwuln A-12 Telnet qsrMacAddress definition of Glossary-7 qsrNetMask firmware, installing via qsrNwLinkRate logging on to router qsrNwLinkStatus temperature, showing 2-101 qsrNwPortAddressMode terms and definitions Glossary-1...
Page 238 iSR6200 Command Line Interface (CLI) User’s Guide verifying connectivity (ping command) 2-31 what’s in this guide version number workstation (management), definition of Glossary-4 hardware, showing A-19 world wide name, See WWN hardware/software, showing 2-101 world wide node name, See WWNN software/firmware, showing A-20 world wide port name, See WWPN...
Page 240 Corporate Headquarters QLogic Corporation 26650 Aliso Viejo Parkway Aliso Viejo, CA 92656 949.389.6000 www.qlogic.com International Offices UK | Ireland | Germany | France | India | Japan | China | Hong Kong | Singapore | Taiwan © 2009–2011 QLogic Corporation. Specifications are subject to change without notice. All rights reserved worldwide. QLogic and the QLogic logo are registered trademarks of QLogic Corporation.

This manual is also suitable for:

Isr6200

Qlogic MPX200 User Manual

151 CLI Usage

2 Command Reference

3 Configuring CHAP

4 Virtual Port Groups

5 Configuring Fibre Channel Initiators to Iscsi Storage

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Qlogic MPX200

Summary of Contents for Qlogic MPX200

This manual is also suitable for:

Table of Contents
