Page 1 iSR6142 Intelligent Storage Router Installation Guide SN0051102-00 A...
Page 2: Document Revision History
QLogic Corporation reserves the right to change product specifications at any time without notice. Applications described in this document for any of these products are for illustrative purposes only. QLogic Corporation makes no representation nor warranty that such applications are suitable for the specified use without further testing or modification.
Page 3: Table Of Contents
iSR6142 Intelligent Storage Router Installation Guide Table of Contents Introduction Intended Audience ..........Related Materials .
Page 4 iSR6142 Intelligent Storage Router Installation Guide Chassis LEDs..........Heartbeat LED (Green) .
Page 5 iSR6142 Intelligent Storage Router Installation Guide Installation Site Requirements ..........Management Workstation .
Page 6 iSR6142 Intelligent Storage Router Installation Guide Removal/Replacement SFP Transceiver Removal and Replacement ..... . . Router Removal and Replacement ....... Removal .
Page 7 iSR6142 Intelligent Storage Router Installation Guide Notifications ..........B-11 Notification Objects .
Page 8 iSR6142 Intelligent Storage Router Installation Guide iSCSI Driver—Informational Log Messages ......Fibre Channel Driver—Informational Log Messages.
Page 9: Intended Audience
Introduction This manual describes the features and installation of the QLogic iSR6142 Intelligent Storage Router (iSR-6142), also referred to as the iSR6142 router or simply router. Intended Audience This guide is for users who are responsible for installing, managing, and servicing the iSR6142 router and the storage area network (SAN) equipment to which it is attached.
Page 10: Safety
1 – Introduction Safety ANSI SCSI – SCSI-3 Architecture Model (SAM), X3T10/994D/Rev 18, SCSI-3 Controller Command Set, X3T10/Project 1047D/Rev 6c. IEEE – 802.1Q Virtual LAN (VLAN), 802.1p Priority of Service, 802.3x Flow Control, 802.3ad Link Aggregation SCSI-3 Fibre Channel Protocol (SCSI-FCP), X3.269:1996 Fibre Channel Physical and Signaling Interface (FC-PH), X3.230:199 Fibre Channel 2nd Generation (FC-PH-2), X3.297:1997 Third Generation Fibre Channel Physical and Signaling Interface (FC-PH-3),...
Page 11: Federal Communications Commission (Fcc) Class A Statement
1 – Introduction Communications Statements Federal Communications Commission (FCC) Class A Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 12: Ce Statement
1 – Introduction Communications Statements CE Statement The CE symbol on the equipment indicates that this system complies with the EMC (Electromagnetic Compatibility) directive of the European Community (89/336/EEC) and to the Low Voltage (Safety) Directive (73/23/EEC). Such marking indicates that this system meets or exceeds the following technical standards: EN60950-1, A11:2004 –...
Page 13: Vcci Class A Statement
1 – Introduction Laser Safety Information VCCI Class A Statement This is a Class A product based on the standard of the Voluntary Control Council For Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.
Page 14: Accessible Parts
The following field replaceable units (FRUs) are supported by the iSR6142 router: Small form-factor pluggable (SFP) optical transceivers License Agreements Refer to the QLogic Software End User License Agreement for a complete listing of all license agreements affecting this product. General Public License QLogic routers are powered by the Linux operating system.
Page 15: Terms And Conditions For Copying, Distribution And Modification
1 – Introduction General Public License When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new programs, and that you know you can do these things.
Page 16 1 – Introduction General Public License translation is included without limitation in the term "modification".) Each licensee is addressed as "you". Activities other than copying, distribution and modification are not covered by this License – they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of having been made by running the Program).
Page 17 1 – Introduction General Public License Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program.
Page 18 1 – Introduction General Public License You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance.
Page 19 1 – Introduction General Public License This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyright interfaces, the original copyright holder who places the Program under this License may add an explicit geographical distribution limitation excluding those countries, so that distribution is...
Page 20: How To Apply These Terms To Your New Programs
1 – Introduction General Public License ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Page 21: Technical Support
QLogic Observed Holidays. Training QLogic offers certification training for the technical professional for QLogic HBAs, CNAs, switches, and routers. From the training link at www.qlogic.com, you may choose Electronic-Based Training or schedule an intensive "hands-on" Certification course.
Page 22: Contact Information
1 – Introduction Technical Support Contact Information Support Headquarters QLogic Corporation 4601 Dean Lakes Blvd Shakopee, MN 55379 QLogic Web Site www.qlogic.com Technical Support Web Site support.qlogic.com Technical Support Email support@qlogic.com Technical Training Email tech.training@qlogic.com North American Region Email support@qlogic.com...
Page 23: General Description
General Description This section describes the following features and capabilities of the iSR6142 router: Router Capabilities (see page 2-2) Licensed Features (see page 2-2) Remote SAN Island Connectivity (see page 2-4) Local SAN Island Connectivity (see page 2-6) FCIP - Fibre Channel over IP (see page 2-6)
Page 24: Router Capabilities
2 – General Description Router Capabilities Router Capabilities The iSR6142 is a bi-directional FC-to-iSCSI router. It supports the following topologies: Two remote SAN islands (single or multi-vendor fabrics) (see page 2-4) Local connectivity (see page 2-6) FC SAN islands (single or multi-vendor fabrics) iSCSI Servers to FC SAN FC servers to iSCSI SAN FCIP –...
Page 25: Additional Server/Ports
2 – General Description Licensed Features Provides failover and failback between two gigabit Ethernet links. Allows data compression. This is very useful when data round-trip latencies between two routers exceed more than 50 ms or long distance link rate is equal or less than 4500 Mbits/sec (DS-3 line rate) SmartWrite is an optional feature that requires purchasing a license key.
Page 26: Remote San Island Connectivity
2 – General Description Remote SAN Island Connectivity Remote SAN Island Connectivity The iSR6142 router supports inter-connecting remote SAN islands (see Figure 2-2). Figure 2-2 Remote SAN Island Connectivity This configuration has the following additional requirements: At least one FC port of iSR6142 connected to FC SAN. Accessibility between the iSCSI/GE (Gigabit Ethernet ports on the router) port IP addresses of remote router and iSCSI/GE port IP addresses of local routers.
Page 27: Local San Island Connectivity
2 – General Description Remote SAN Island Connectivity To map remote FC devices to local SAN: If the remote router is not already associated with a local router, use either the Add Remote Router wizard (see the iSR6142 Router Manager User's Guide) or the CLI command remotepeer add (see the iSR6142 Router CLI User's Guide) to associate the two routers with each other.
Page 28: Local San Island Connectivity
2 – General Description Local SAN Island Connectivity Local SAN Island Connectivity You can use either the the SANsurfer Router Manager (see the iSR6142 Router Manager User's Guide) or Command Line Interface (CLI) (see the iSR6142 Router CLI User's Guide) to map any of the following connections: iSCSI server to an FC device (target) FC server to an iSCSI device (target) FC server from one SAN to FC target on another SAN...
Page 29: Heartbeat Led (Green)
2 – General Description Chassis Controls Heartbeat LED (Green) The heartbeat LED blinks once a second as long the router firmware is operational. Input Power LED (Green) The power LED shows the voltage status at the router logic circuit board. During normal operation, this LED lights up to show that the router logic circuit board is receiving the DC voltage from the power supply.
Page 30: Maintenance Button
2 – General Description Chassis Controls Maintenance Button The maintenance button is a multifunction momentary switch on the front panel. It has the following functions: Reset a Router (see page 2-9) Reset and Select Boot Image (see page 2-9) Reset IP Address (see section page 2-9)
Page 31: Enable Dhcp
2 – General Description Fibre Channel Ports The IP address set by this method is not persistent; to make the change persistent, use the command line interface (CLI) or the SANsurfer Router Manager to set the IP address. For more information, see the iSR6142 Router Manager User's Guide or the iSR6142 Router CLI User's Guide.
Page 32: Fibre Channel Port Leds
2 – General Description Fibre Channel Ports Each port is served by a small form-factor pluggable (SFP) optical transceiver and is capable of 1-Gbps or 2-Gbps transmission. SFPs are hot-pluggable. FC ports can self-discover both the connection type and transmission speed when connected to public devices or switches.
Page 33: Fibre Channel Sfp Transceivers
2 – General Description Fibre Channel SFP Transceivers Fibre Channel SFP Transceivers The iSR6142 router supports SFP optical transceivers for the Fibre Channel ports. A transceiver converts electrical signals to and from optical laser signals to transmit and receive data. Duplex fibre optic cables plug into the transceivers, which then connect to the devices.
Page 34: Iscsi/Gigabit Ethernet Port Leds
2 – General Description iSCSI/Gigabit Ethernet Port LEDs iSCSI/Gigabit Ethernet Port LEDs The iSCSI/gigabit Ethernet ports shown in Figure 2-7 are RJ-45 connectors that provide connection to an Ethernet SAN through a 10/100/1000 Base-T Ethernet cable. The ports are labeled GE1 and GE2. These ports have two LEDs –...
Page 35: Serial Port
2 – General Description Serial Port Serial Port The iSR6142 router is equipped with an RS-232 serial port for maintenance purposes. Figure 2-9 shows the serial port location. It is labeled IOIOI. You can manage the router through the serial port using the CLI. Figure 2-9 Serial Port The serial port connection requires a standard, eight-wire Ethernet cable and the RJ45-to-DB9F adapter (supplied) to convert the Ethernet RJ45 connector to a...
Page 36 2 – General Description Serial Port Table 2-4. RJ-45 to DB-9 Adapter Pin Identification (Continued) RJ-45 DB-9F DB-9 DB-9 Pin Number Pin Definition Pin Number Pin Definition Transmit data (TxD) Signal ground (GND) Receive data (RxD) Data carrier detect (DCD) Data set ready (DSR) Clear to send (CTS) Ring indicator (RI)
Page 37: Planning
Planning This section describes how to plan for the iSR6142 router. This includes the following considerations: Devices (see page 3-1) Device Access (see page 3-2) FC Performance (see page 3-2) iSCSI/Gigabit Ethernet Performance (see page 3-3) Performance Tuning (see page 3-4) Topology (see...
Page 38: Device Access
3 – Planning Device Access Device Access Consider device access needs within the FC and iSCSI SANs. Access to an FC device is controlled by mapping FC device to specific iSCSI initiators. FC devices may be mapped to more than one initiator. Giving multiple initiators access to an FC device requires access management.
Page 39: Distance
3 – Planning iSCSI/Gigabit Ethernet Performance Distance Consider the physical distance between Fibre Channel devices. Choose SFP transceivers that are compatible with the cable type and distance you need. Each Fibre Channel port is supported by a data buffer with a three-credit capacity; that is, three maximum sized frames.
Page 40: Distance
TCP Window Scaling Factor and Window Size settings for specific WAN environments. NOTE: For high loss networks, QLogic recommends decreasing the TCP Window Size from the initial recommended setting until the network achieves optimal performance. Table 3-1. T1 / DS-1 – 1.554 Mbits/Sec...
Page 41: T3 / Ds-3 – 45 Mbits/Sec
3 – Planning Performance Tuning Table 3-2. T3 / DS-3 – 45 Mbits/Sec Round Trip Delay Total Window Size Scaling Factor (ms) (bytes) 1 MB 512 K 256 K 128 K 128 K 64-128 K 1 or 2 64 K 32 K 32 K 1 or less...
Page 42: Oc-3 – 150 Mbits/Sec
3 – Planning Performance Tuning Table 3-4. OC-1 – 50 Mbits/Sec Round Trip Delay Total Window Size Scaling Factor (ms) (bytes) 1 MB 512 K 256 K 128 K 128 K 64-128 K 1 or 2 64 K 32 K 32 K 32 K 1 or less...
Page 43: Topology
3 – Planning Topology Table 3-6. OC-12 and Above – 621 Mbits/Sec Round Trip Delay Total Window Size Scaling Factor (ms) (bytes) 1 MB 1 MB 1 MB 1 MB 1 MB 1 MB 1 MB 512 K 256 K 64 K 1 or less Topology...
Page 44: Fibre Channel Switch Ports And Zoning Requirements
3 – Planning Fibre Channel Switch Ports and Zoning Requirements Figure 3-2 WAN Topology - Remote SAN Interconnect Fibre Channel Switch Ports and Zoning Requirements The iSR6142 FC ports are configured as loop ports. Therefore, the FC switch port, (where iSR6142 FC port is connected) must be configured to support a loop topology such as fibre loop port (FL-Port) or generic port (G-Port).
Page 45: Management
3 – Planning Management Management The SANsurfer Router Manager application and CLI run on a management workstation that enables you to configure, control, and maintain the router. Support platforms include Windows, Solaris, and Linux. The router supports the following management interfaces: SANsurfer Router Manager –...
Page 46: Services
3 – Planning Services Services You can configure the iSR6142 router to suit the demands of your environment using a variety of router services. Familiarize yourself with the following router services and determine which ones you need: Telnet – Enables router management over a telnet connection. Router management –...
Page 47: Site Requirements
Installation This section describes how to install and configure an iSR6142 router. It also includes firmware installation instructions. This includes the following topics: Site Requirements (this page) iSR6142 Router Installation (see page 4-2) Firmware Installation (see page 4-11) Site Requirements The following sections identify the site requirements for installing an iSR6142 router: Management Workstation...
Page 48: Power Requirements
4 – Installation iSR6142 Router Installation Table 4-1. Management Workstation Requirements (Continued) Item Description Processor 500 MHz or faster Hardware CD-ROM drive, RJ-45 Ethernet port, RS-232 serial port (optional) Internet browser One of the following: Microsoft Internet Explorer 5.0 and later Netscape Navigator®...
Page 49: Isr6142 Router And Accessories
4 – Installation iSR6142 Router Installation Figure 4-1 iSR6142 Router and Accessories To install the iSR6142 router: Complete the pre-installation checklist (see page 4-4). Mount the router (see page 4-4). Install the transceivers (see page 4-5). Connect the management workstation to the router (see page 4-5).
Page 50: Pre-Installation Check List
You can place the router on a flat surface or mount it in a standard 19-inch Electronic Industries Association (EIA) rack. See the product specification for weight and dimensions. Rack mounting requires a QLogic rack mounting kit (Part No. ISR614X-RACKKIT). Contact QLogic for more information.
Page 51: Install The Transceivers
4 – Installation iSR6142 Router Installation Install the Transceivers The router supports a variety of SFP transceivers. To install a transceiver, insert the transceiver into the port and gently press until it snaps in place. To remove a transceiver, gently press the transceiver into the port to release tension, then pull the release tab or lever and remove the transceiver.
Page 52: Setting The Workstation Ip Address
4 – Installation iSR6142 Router Installation Setting the Workstation IP Address The IP address of a new router is 10.0.0.1. To ensure that your workstation is configured to communicate with the 10.0.0 subnet, refer to the following instructions for your workstation: Steps for different versions of Windows vary.
Page 53: Install The Sansurfer Router Manager
SANsurfer Router Manager. Windows Installation Perform the following steps to install the SANsurfer Router Manager application from the QLogic website to a PC workstation: Close all programs currently running. Go to the QLogic download site: http://support.qlogic.com/support/drivers_software.aspx...
Page 54: Linux Installation
4 – Installation iSR6142 Router Installation Linux Installation Perform the following steps to install the SANsurfer Router Manager application from the QLogic website to a Linux workstation: Go to the QLogic download site: http://support.qlogic.com/support/drivers_software.aspx Select the Intelligent Storage Routers icon.
Page 55: Connect The Router To Ac Power
4 – Installation iSR6142 Router Installation Connect the Router to AC Power WARNING!! This product is supplied with a three-wire power cable and plug for the user’s safety. Use this power cable in conjunction with a properly grounded outlet to avoid electrical shock. An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the router chassis.
Page 56: Configure The Router
4 – Installation iSR6142 Router Installation Configure the Router You can configure the router using the SANsurfer Router Manager application or the command line interface (CLI). The SANsurfer Router Manager provides a Configuration Wizard you can use to configure the GE ports. If either of the router’s GE ports have not been configured (IP address is 0.0.0.0), the Configuration Wizard starts automatically when the SANsurfer Router Manager first connects with the router.
Page 57: Cable Devices To The Router
Installing new firmware disrupts the router connectivity since you must reboot the router to activate the new firmware. he reboot may result in the transfer of incorrect data between devices connected to the router. QLogic recommends that you suspend activity on the interfaces before activating the new firmware.
Page 58: Using The Cli To Install Firmware
Type quit. The firmware image has been transferred to the router. Log on to the router as an administrator. (none) login – guest Password – password ****************************************************** QLogic Router Command Line Interface (QRCLI) * ****************************************************** QRouter#> admin start Password – config QRouter (admin) #>...
Page 59 4 – Installation Firmware Installation Type the following command from the router, where x stands for the firmware image name: image unpack isr-6142-2_2_0_x.bin The following message displays: Unpack Completed. Please reboot the system for FW to take affect. Type reboot. The following message displays: Are you sure you want to reboot the System (y/n): Type y to reboot the system.
Page 60 4 – Installation Firmware Installation Notes 4-14 SN0051102-00 A...
Page 61: Diagnostics And Troubleshooting
Diagnostics and Troubleshooting Diagnostic information about the router is available through the chassis LEDs and the port LEDs. Diagnostic information is also available through the Router Manager and CLI event logs and error displays. This section provides the following diagnostic information: Chassis Diagnostics (this page) Power-On Self-Test Diagnostics...
Page 62: Input Power Led Is Off
5 – Diagnostics and Troubleshooting Power-On Self-Test Diagnostics Input Power LED is Off The input power LED lights up to show that the router logic circuitry is receiving proper voltages. If the input power LED is off, do the following: Inspect power cord and connectors.
Page 63: Led Blink Patterns
5 – Diagnostics and Troubleshooting LED Blink Patterns LED Blink Patterns The heartbeat and system fault LEDs show the operational status of the router. When the POST completes with no errors, the heartbeat LED will blink once every second. When the router is in maintenance mode, the heartbeat and system fault LEDs are on continuously.
Page 64: Management Port Ip Address Conflict Blink Pattern
5 – Diagnostics and Troubleshooting LED Blink Patterns Management Port IP Address Conflict Blink Pattern The system fault LED generates a four-blink pattern (once per second) followed by a two second pause when the router detects an IP address conflict on the management Ethernet port.
Page 65: Recovering A Router
5 – Diagnostics and Troubleshooting Recovering a Router Recovering a Router You may have to recover a router for one of the following reasons: The password was changed and has been forgotten. The router’s management IP address is unknown. To recover the router’s password, reset the password to the default by using the maintenance button (see page 2-8).
Page 66 5 – Diagnostics and Troubleshooting Recovering a Router Notes SN0051102-00 A...
Page 67: Removal/Replacement
Removal/Replacement This section describes the removal and replacement procedures for the following field replaceable units (FRU): SFP transceivers The router (see page 6-2) SFP Transceiver Removal and Replacement You can remove and replace the SFP transceivers while the router is operating without damaging the router or the transceiver.
Page 68: Router Removal And Replacement
6 – Removal/Replacement Router Removal and Replacement Router Removal and Replacement Before you can remove and replace the router, you must turn off the power to the router and disconnect its power cable. The router will lose all the Fibre Channel and iSCSI connections.
Page 69: Log Data
Log Messages This appendix provides reference material on messages logged to a file. You can retrieve these message logs using either the command line interface (CLI) (see the iSR6142 Router CLI Users Guide) or the Router Manager (see the iSR6142 Router Manager Users Guide). Log Data The message log is persistent, maintained across router power cycles and reboots.
Page 70: Informational Log Messages
A – Log Messages Informational Log Messages Application Modules The application modules generate the informational log messages listed in Table A-1 and described following the table. Table A-1. Application Modules—Informational Log Messages Log Message 53254 System (router) Booting up 53357 QLBA_ProcessTpb: De-compression failed.
Page 71 A – Log Messages Informational Log Messages Table A-1. Application Modules—Informational Log Messages (Continued) Log Message 54963 QLIS_SetDdbEntryContinue:[%d:%d] Remote system connection 1715 established 54986 QLIS_HandleSessionTimer: Re-enabling compression 1738 55299 QLSC_CollectBUVUIO: Freeing dead TRB: State 0x%02X, 2051 AbortReason %d, Flags 0x%02X Router is booting up.
Page 72: Iscsi Driver
A – Log Messages Informational Log Messages 1700 iSCSI connection closed. 1715 Remote system connection established using DDB d:d. 1738 Re-enabling compression. 2051 TRB freed, State xx, Abort Reason d, Flags xx. iSCSI Driver The following informational log messages are common to both iSCSI ports: 1 (GE1) and 2 (GE2).
Page 73: Fibre Channel Driver
A – Log Messages Informational Log Messages Fibre Channel Driver The following informational log messages are common to both Fibre Channel ports: 1 (FC1) and 2 (FC2). The messages are listed in Table A-3 and described following the table. Log messages beginning with #0 denote Fibre Channel port 1 (FC1).
Page 74: User Modules
A – Log Messages Informational Log Messages FCIP - Fibre Channel link up occurred. Event status is reported, as is the contents of the FC processor’s mailbox 1 register. FCIP - Fibre Channel link down occurred. FCIP - Fibre Channel link up occurred. Event status is reported, as is the RunTimeMode (0 = loop, 1 = point-to-point).
Page 75 A – Log Messages Informational Log Messages Table A-4. User Modules—Informational Log Messages (Continued) Log Message 151903 qapimaptargettoinitiator_1_svc: Localmap added to target device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 151904 qapiunmaptargettoinitiator_1_svc: Localmap removed for initiator device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 151905 qapiunmaptargettoinitiator_1_svc: Localmap removed to target device %.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x:%.2x 151906 qapimaptargettoinitiator_1_svc: Localmap added for initiator %s 151907...
Page 76: Fcip
A – Log Messages Informational Log Messages Remotemap removed for local FC device WWPN xx.xx.xx.xx.xx.xx.xx.xx. Remotemap removed for remote FC device WWPN xx.xx.xx.xx.xx.xx.xx.xx. Localmap added for FC initiator WWPN xx.xx.xx.xx.xx.xx.xx.xx. Localmap added to FC target device WWPN xx.xx.xx.xx.xx.xx.xx.xx. Localmap removed for FC initiator. Localmap removed to FC target device.
Page 77: Toe Driver
A – Log Messages Informational Log Messages TOE Driver The TOE driver generates the informational log messages listed in Table A-6 described following the table. Table A-6. TOE—Informational Log Messages Log Message 217350 QL3022:eth%x: Interface is down The GigE interface d (0 or 1) used for an FCIP route is down. System The system modules generate the informational log messages listed in Table A-7...
Page 78: Error Log Messages
A – Log Messages Error Log Messages Error Log Messages The following sections list and describe the error log messages by reporting module: “Application Modules” on page A-10 “iSCSI Driver” on page A-18 “Fibre Channel Driver” on page A-20 “User Modules” on page A-22 “System”...
Page 79 A – Log Messages Error Log Messages Table A-8. Application Module—Error Log Messages (Continued) Log Message 41257 QLIS_LoginPduContinue: Invalid initiator name. Initiator: 41265 QLIS_LoginPduContinue: Target not configured for Portal 41267 QLIS_LoginPduContinue: Target not found. Target name: 41268 QLIS_LoginPduContinue: Missing target name 41270 QLIS_LoginPduContinue: TSIH is 0 but InitiatorName key/value not provided...
Page 80 A – Log Messages Error Log Messages Table A-8. Application Module—Error Log Messages (Continued) Log Message 41771 QLBI_GetLunList: Lun allocation failed for LunId %d 41994 QLFC_Login: VpIndex (%d) out of range 1034 41995 QLFC_Login: VP Index 0x%x not configured 1035 42002 QLFC_Login: Can't open connection 1042...
Page 81 A – Log Messages Error Log Messages Table A-8. Application Module—Error Log Messages (Continued) Log Message 43271 QLFCIP_IncomingFrame: Got Status aborted 2311 pTrb->pBufDescList[0]:%p Trb Direction:0x%x 43272 QLFCIP_SystemError: System error 2312 43273 QLFCIP_SystemError: QLOP_IssuePortEnable failed 2313 43280 QLFCIP_HandleTeb: Driver Fatal error 2320 43281 QLFCIP_ConfigPortal: Find portal object failed for...
Page 82 A – Log Messages Error Log Messages NULL doorbell routine for unloaded drivers. When a driver is unloaded, the doorbell routine is redirected to this NULL routine. Processing unsupported ordered tag task management command. Processing unsupported head-of-queue task management command. Unable to create an object for the target device: exceeded the maximum number of target devices.
Page 83 A – Log Messages Error Log Messages iSCSI Login PDU was received with a TSIH out of range. This would occur if the iSCSI initiator attempting the login failed to used the TSIH value provided in the Target Login Response PDU (router is target) in subsequent login PDUs. iSCSI Login PDU was received with an invalid TSIH value.
Page 84 A – Log Messages Error Log Messages 1034 Login attempted using Fibre Channel virtual port (VP) index that is out-of-range (range = 0–31). Index reported in log message. 1035 Login attempted using Fibre Channel VP index that has not been configured. Operation attempted on an unconfigured VP.
Page 85 A – Log Messages Error Log Messages 2311 FCIP incoming frame: Got Status aborted pTrb->pBufDescList[0]:%p Trb Direction:0x%x. 2312 FCIP system error. 2313 FCIP system error: QLOP_IssuePortEnable failed. 2320 FCIP handle Teb: Driver Fatal error. 2321 FCIP configure portal: Find portal object failed for QLUT_TYPE_FC, PortId (%d).
Page 86: A-9 Iscsi Driver—Error Log Messages
A – Log Messages Error Log Messages iSCSI Driver The following error log messages are common to both iSCSI ports, 1 (GE1) and 2 (GE2). They are listed in Table A-9 and described following the table. Log messages beginning with #0 denote iSCSI port 1 (GE1). Log messages beginning with #1 denote iSCSI port 2 (GE2).
Page 87 A – Log Messages Error Log Messages The iSCSI processor failed the external loopback test. The iSCSI processor command to disable a GE port failed. The iSCSI processor could not connect with the iSCSI name server (iSNS). The iSCSI processor reported that the iSCSI port NVRAM contains invalid data (checksum error).
Page 88: A-10 Fibre Channel Driver—Error Log Messages
A – Log Messages Error Log Messages Fibre Channel Driver The following error log messages are common to both Fibre Channel ports, 1 (FC1) and 2 (FC2). They are listed in Table A-10 and described in this section. Log messages beginning with #0 denote Fibre Channel port 1 (FC1) and log messages beginning with #1 denote Fibre Channel port 2 (FC2).
Page 89 A – Log Messages Error Log Messages Table A-10. Fibre Channel Driver—Error Log Messages (Continued) Log Messages 107254 #%d: QLUpdateSinglePortCont 0x%x: out of slots in host database 107267 #%d: QLFcipIsrEventHandler: System error event (%x), MB1=%x, MB2=%x, MB3=%x, MB4=%x, MB5=%x, MB6=%x, MB7=%x The FC processor received a SCSI command for an unknown target path or has run out of resources to execute additional commands.
Page 90: A-11 User Modules—Error Log Messages
A – Log Messages Error Log Messages The drivers host (initiator) database is full. No slots available in host database. FCIP system error event. User Modules The user modules generate the error log messages listed in Table A-11 described following the table. Table A-11.
Page 91 A – Log Messages Error Log Messages Table A-11. User Modules—Error Log Messages (Continued) Log Message 139297 QBRPC_Initialize:BridgeStatus Mem Allocation error 139298 QBRPC_Initialize:Diag Mem Allocation error 139299 QBRPC_Initialize:DiagLog Mem Allocation error 139300 QBRPC_Initialize:FruImage Mem Allocation error 139301 QBRPC_Initialize:OemMfg Mem Allocation error 139302 QBRPC_Initialize:Status Mem Allocation error 139303...
Page 92 A – Log Messages Error Log Messages Failed memory allocation for Get LUN List API. Failed memory allocation for Get Presented Targets List API. Failed memory allocation for Get LUN Mask API. Failed memory allocation for Initiator API. Failed memory allocation for Target Device API. Failed memory allocation for FC Target API.
Page 93: System
A – Log Messages Fatal Log Messages System The system modules generate the error log messages listed in Table A-12 described following the table. Table A-12. System—Error Log Messages Log Message 237572 "Failed to kill sys killer %d\n" 237573 "Temperature over high threshold %d\n" Failed to kill system task.
Page 94 A – Log Messages Fatal Log Messages Table A-13. iSCSI Driver—Fatal Log Messages (Continued) Log Message 69941 #%d: QLUtmProcessResponseQueue: Invalid handle %x EntryType %x 69951 #%d: QLSetNvram: QLRebootTimer failed AF %x RS %x Time %d 69964 #%d: QLDisable: QLRebootTimer failed AF %x RS %x Time %d 69966 #%d: QLEnable: QLRebootTimer failed AF %x RS %x Time %d 70224...
Page 95: Iscsi Driver
A – Log Messages Fatal Log Messages Table A-13. iSCSI Driver—Fatal Log Messages (Continued) Log Message 70836 #%d: QLStartFw: Invalid Fw loader state 0x%x 1204 70837 #%d: QLStartFw: Load Fw loader timeout 1205 iSCSI processor SRAM test failed. iSCSI processor failed diagnostic reboot. iSCSI processor failed NVRAM diagnostic.
Page 96: Fc Driver
A – Log Messages Fatal Log Messages iSCSI processor reboot failed. 1152 iSCSI processor NVRAM invalid (checksum error). 1203 iSCSI FLASH (NVRAM) command failed. 1204 iSCSI firmware loader invalid state. 1205 iSCSI failed to load firmware in time allotted. FC Driver The following fatal log messages are common to both Fibre Channel ports, 1 (FC1) and 2 (FC2).
Page 97 A – Log Messages Fatal Log Messages Table A-14. Fibre Channel Driver—Fatal Log Messages (Continued) Log Message 10692 #%d: QLFcipInterruptServiceRoutine: Invalid interrupt status: %x 102716 #%d: QLIsrEventHandler: System error event (%x), MB1=%x, MB2=%x, MB3=%x, MB4=%x, MB5=%x, MB6=%x, MB7=%x 102746 #%d: QLProcessResponseQueue: Invalid handle %x, type %x 102747 #%d: QLProcessResponseQueueFS: Invalid buffer type: %x 102748...
Page 98: Toe Driver
A – Log Messages Fatal Log Messages FC processor paused due to RAM parity error. FC processor system error. Response queue entry contains an invalid handle. FCIP: Response queue entry contains an invalid buffer type. FCIP: Response queue entry contains an invalid entry type. FCIP: Response queue entry contains an invalid handle.
Page 99: System
A – Log Messages Fatal Log Messages System The system modules generate the fatal log messages listed in Table A-16 described following the table. Table A-16. System—Fatal Log Messages Log Message 233473 "memory monitor: Detected Uncorrectable Ecc %08lx system is rebooting in 5 secs\n"...
Page 100 A – Log Messages Fatal Log Messages Notes A-32 SN0051102-00 A...
Page 101: Simple Network Management Protocol (Snmp)
Simple network management protocol (SNMP) provides monitoring and trap functions for managing the router through third-party applications that support SNMP. The router firmware supports SNMP versions 1 and 2 and a QLogic (see page B-3). You may format the traps using SNMP version 1 or 2 (see page B-11).
Page 102: Snmp Trap Configuration
B – Simple Network Management Protocol (SNMP) Introduction Table B-1. SNMP Properties (Continued) Parameter Description System contact Specifies the name of the person to be contacted to respond to trap events. The name can be up to 64 characters excluding the number sign (#), semicolon (;), and comma (,).
Page 103: Management Information Base (Mib
B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) Management Information Base (MIB) The following sections describe the QLogic management information base (MIB). The MIB consists of four object groups: System Information Network Port Table Fibre Channel Port Table...
Page 104: Network Port Table
B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNoOfGbEPorts Syntax Unsigned32 Access Read-only Description The number of gigabit Ethernet ports on the system. qsrAgentVersion Syntax SnmpAdminString Access Read only Description The version number of the agent software on the system.
Page 105 B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNetMask InetAddress qsrGateway InetAddress qsrMacAddress MacAddress qsrNwLinkStatus QsrLinkStatus qsrNwLinkRate QsrLinkRate qsrNwPortRole Syntax QsrPortRole Access Not accessible Description The operational role of this port: management port, iSCSI port, a TOE. qsrNwPortIndex Syntax Unsigned32 Access Not accessible...
Page 106: Fibre Channel Port Table
B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrNetMask Syntax InetAddress Access Read only Description The subnet mask for this port. qsrGateway Syntax InetAddress Access Read only Description The gateway for this port. qsrMacAddress Syntax IMacAddress Access Read only Description The MAC address for this port.
Page 107 B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrFcPortEntry Syntax QsrFcPortEntry Access Not accessible Description Each entry (row) contains information about a specific FC port. QsrFcPortEntry A Fibre Channel port entry consists of the following sequence of objects: qsrFcPortRole QsrPortRole qsrFcPortIndex...
Page 108: Sensor Table
B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrFcPortWwn Syntax PhysAddress Access Read only Description The world-0wide name for this port. qsrFcPortId Syntax PhysAddress Access Read only Description The interface's 24-bit FC address identifier. qsrFcPortType Syntax Unsigned32 Access Read only Description The type of FC port, as indicated by the use of the appropriate value assigned by IANA.
Page 109 B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrSensorEntry Syntax QsrSensorEntry Access Not accessible Description Each entry (row) corresponds to a single sensor. QsrSensorEntry A sensor entry consists of the following sequence of objects: qsrSensorType INTEGER qsrSensorIndex Unsigned32 qsrSensorUnits INTEGER...
Page 110 B – Simple Network Management Protocol (SNMP) Management Information Base (MIB) qsrSensorValue Syntax Integer32 Access Read only Description The current value of the sensor. qsrUpperThreshold Syntax Integer32 Access Read only Description The upper-level threshold for this sensor. qsrLowerThreshold Syntax Integer32 Access Read only Description The lower-level threshold for this sensor.
Page 111: Notifications
B – Simple Network Management Protocol (SNMP) Notifications Notifications The router provides the following notification types: Notification Objects Agent Start Up Notification Agent Shut Down Notification Network Port Down Notification Fibre Channel Port Down Notification Sensor Notification Generic Notification The following sections describe these notifications and objects they use. Notification Objects This section defines the objects used in notifications.
Page 112: Agent Start Up Notification
B – Simple Network Management Protocol (SNMP) Notifications Agent Start Up Notification The agent startup notification indicates that the agent on the router has started running. qsrAgentStartup uses the following object: qsrEventTimeStamp Agent Shut Down Notification The agent shut down notification indicates that the agent on the router is shutting down.
Page 113: Sensor Notification
B – Simple Network Management Protocol (SNMP) Notifications Sensor Notification The sensor notification indicates that the state for the specified sensor is not normal. When the sensor returns to the normal state, this event is sent with the qsrEventSeverity object set to clear. qsrSensorNotification uses the following objects: qsrSensorValue qsrSensorState...
Page 114 B – Simple Network Management Protocol (SNMP) Notifications Notes B-14 SN0051102-00 A...
Page 115: Index
iSR6142 Intelligent Storage Router Installation Guide Index AC power 4-9 Devices Accessible parts 1-6 access needs 3-2 Accessories 4-3 planning 3-1 Application DHCP, enabling 2-9 error log A-10 Diagnostics 5-1 log messages A-2 chassis 5-1 POST 5-2 Disk space requirements 4-1 workstation 4-1 Bandwidth, FC devices 3-3 Distance, iSCSI devices 3-4...
Page 116 iSR6142 Intelligent Storage Router Installation Guide Firmware installation 4-11 LEDs FRU, removing and replacing 6-1 chassis 2-6 FTP services 3-10 chassis diagnostics 5-1 FC port 2-10 heartbeat 2-7 input power 5-2 iSCSI ports 2-12 General public license 1-6 power 2-7 system fault 2-7, 5-2 License agreements 1-6...
Page 117 iSR6142 Intelligent Storage Router Installation Guide Messages 324-809 A-15 102419-102748 A-28 327-358 A-4 1026-1027 A-3 328 A-18 102749-102800 A-29 329-937 A-19 1028-1061 A-3 348-359 A-8 1034-1035 A-16 352-400 A-30 1042-2313 A-16 36 A-14 1056-1072 A-19 40967-41268 A-10 106583-107078 A-20 41270-42002 A-11 107254-107267 A-21 42024-43273 A-12 109 A-3...
Page 118 iSR6142 Intelligent Storage Router Installation Guide Ports Fibre Channel ports B-6 Fibre Channel 2-9 network ports B-4 management 2-12 notifications B-11 serial 2-13 objects B-3 POST diagnostics 5-2 sensors B-8 Pre-installation check list 4-4 system B-3 Processor, workstation 4-2 Mozilla 4-2 Properties, SNMP B-1 MS Explorer 4-2 Read community B-1...
Page 119 iSR6142 Intelligent Storage Router Installation Guide Security, router 3-10 Trap Sensors, MIB B-8 authentication B-2 Serial port 2-13 community B-1 workstation 4-6 Troubleshooting 5-1 Server/ports license 2-3 Services FTP 3-10 NTP 3-10 User modules router 3-10 error log messages A-22 SNMP 3-10 messages A-6 Telnet 3-10...
Page 120 iSR6142 Intelligent Storage Router Installation Guide Notes Index-6 SN0051102-00 A...

Qlogic iSR6142 Installation Manual

Figure

General Description

Planning

Diagnostics and Troubleshooting

Removal/Replacement

Simple Network Management Protocol (SNMP)

Index

Quick Links

Need help?

Questions and answers

Related Manuals for Qlogic iSR6142

Summary of Contents for Qlogic iSR6142

Table of Contents
