Qlogic iSR6200 Specifications

iSR6200
Enterprise-class Connectivity,
Routing and Services
Features
• TrueFlex™ architecture provides any-to-any
protocol flexibility and connectivity.
• Open fabric interoperability supports existing
networks, SANs, and WANs.
• Enterprise-class HA design provides dual hot-swap
power supplies and router blades for no single point
of failure.
• Future-proof modular design enables easy
upgrades to more ports or new protocols.
• Unmatched performance: 8Gb Fibre Channel, 1Gb
Ethernet, and 10Gb iSCSI ports deliver up to 2.6GB/
sec throughput and 200K IOPS.
• Advanced installation and configuration wizards
allow set up in less than 25 minutes.
• Very power efficient: uses as little as 100W for
a typical configuration and reduces power and
cooling by 66% versus competitive products.
Benefits
• Optimizes BC and DR cost and performance.
• Maximizes WAN performance and reduces costs.
• Provides open, cost-effective storage consolidation.
• Unifies all networks: LAN, SAN, and WAN.
• Improves deployment for IT test and development.
• Improves storage utilization by enabling multi-
protocol array connectivity.
SR6200 Fabric Routing Platform.
architecture, is an intelligent, HA fabric routing and application hosting
platform that enables fabric services, including multi-protocol routing, SAN-
over-WAN extension, data migration for storage consolidation, multi-protocol
fabric boot services. Its virtual server portability creates a multi-fabric routing
platform with support for all leading storage and network applications. The
iSR6200 has a unique, dual-blade, HA architecture that has the best price,
performance, and flexibility available for hosting fabric services. Each router
blade has a base configuration of two 8Gb Fibre Channel ports and two 1Gb
iSCSI ports. Each blade has an expansion slot that supports two additional
ports of either 1Gb iSCSI, 10Gb iSCSI, or 8Gb FC. The iSR6200 will also
support emerging protocols, such as InfiniBand, SAS and FCoE.
1. Multi-protocol Host Connectivity for Fibre Channel Arrays and Devices.
The iSR6200 provides multi-protocol iSCSI connectivity for SAN devices
for better utilization and storage consolidation. By supporting up to 2,048
iSCSI initiators, virtual and physical machines can secure and manage
their own storage partitions, significantly reducing connection costs.
2. SAN Extension for Business Continuance and Disaster Recovery.
iSR6200 features SmartWrite™ II, QLogic's patent-pending second-
generation technology for accelerating replication over iSCSI. SmartWrite
optimizes key data management and migration operations, reducing the
total transfer time across the WAN.
3. Data Migration & Storage Consolidation Data Mover for ILM.
simplifies the management of data storage assets for redeployment or
retirement. It enables IT managers to quickly, safely, and economically
move data at the block level to bring new arrays into service and move
aging data to older systems.
True Flexibility and Ease-of-Use.
all of the functionality described above from a single device. A simple
graphical user interface (GUI) allows IT managers to establish and configure
connections for any operational
D A T A S H E E T
The QLogic iSR6200, based on our TrueFlex
The iSR6200
The iSR6200 can simultaneously provide
mode.
The
