Page 1 iSR6200 Intelligent Storage Router Installation Guide ISR651101-00 C...
Page 2: Document Revision History
QLogic Corporation reserves the right to change product specifications at any time without notice. Applications described in this document for any of these products are for illustrative purposes only. QLogic Corporation makes no representation nor warranty that such applications are suitable for the specified use without further testing or modification.
Page 3: Table Of Contents
Table of Contents Preface Intended Audience ..........What’s in This Guide .
Page 4 iSR6200 Intelligent Storage Router Installation Guide Router Blade LEDs ........Heartbeat LED (Green) .
Page 5 iSR6200 Intelligent Storage Router Installation Guide Installation Site Requirements ..........Management Workstation .
Page 6 iSR6200 Intelligent Storage Router Installation Guide Determining WAN Characteristics ......Round-Trip Time ........Link Data Rate .
Page 7 iSR6200 Intelligent Storage Router Installation Guide Device Management ......... . Mechanical .
Page 8 iSR6200 Intelligent Storage Router Installation Guide 10Gb Ethernet Ports on the iSR6250 Router Blade......iSCSI (GE) Ports on the iSR6240 Router Blade ......Router Blade LEDs .
Page 9 iSR6200 Intelligent Storage Router Installation Guide Inserting the New Blade into the Chassis Slot ......iSR6200 Router Blade with Cables Disconnected .
Page 10 iSR6200 Intelligent Storage Router Installation Guide ISR651101-00 C...
Page 11: Preface
Preface This guide describes and provides installation procedures for the QLogic iSR6200 Intelligent Storage Router (iSR6200), also referred to as the iSR6200 router or simply router. Intended Audience This guide is for users who are responsible for installing, managing, and servicing the iSR6200 router and the storage area network (SAN) equipment to which it is attached.
Page 12: Related Materials
Chapter 6 Diagnostics and Troubleshooting provides system diagnostic and troubleshooting tools available for the iSR6200 router. Chapter 7 Removal and Replacement describes how to remove and replace the following field replaceable units (FRUs): SFP transceivers, iSR6200 chassis blades, and power and cooling modules (PCMs). Appendix A Technical Specifications summarizes the technical aspects of the iSR6200 router: interface, expansion configurations, performance...
Page 13: Documentation Conventions
(jump) to a figure, table, or section in this guide, and links to Web sites are shown in underlined blue. For example: Table 9-2 lists problems related to the user interface and remote agent. “Installation Checklist” on page 3-6. For more information, visit www.qlogic.com. ISR651101-00 C xiii...
Page 14: Communications Statements
Press the UP ARROW key. Text in italics indicates terms, emphasis, variables, or document titles. For example: For a complete listing of license agreements, refer to the QLogic Software End User License Agreement. What are shortcut keys? To enter the date, type mm/dd/yyyy (where mm is the month, dd is the day, and yyyy is the year).
Page 15: Federal Communications Commission (Fcc) Class A Statement
Federal Communications Commission (FCC) Class A Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 16: Ce Statement
CE Statement The CE symbol on the equipment indicates that this system complies with the EMC (Electromagnetic Compatibility) directive of the European Community (89/336/EEC) and to the Low Voltage (Safety) Directive (73/23/EEC). Such marking indicates that this system meets or exceeds the following technical standards: EN60950-1, A11:2004 –...
Page 17: Vcci Class A Statement
VCCI Class A Statement This is a Class A product based on the standard of the Voluntary Control Council For Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.
Page 18: Accessible Parts
Power and cooling modules (PCMs) Small form-factor pluggable (SFP) optical transceivers License Agreements Refer to the QLogic Software End User License Agreement for a complete listing of all license agreements affecting this product. Technical Support Customers should contact their authorized maintenance provider for technical support of their QLogic switch products.
Page 19: Contact Information
Contact Information Please feel free to contact your QLogic approved reseller or QLogic Technical Support at any phase of integration for assistance. QLogic Technical Support can be reached by the following methods: http://support.qlogic.com E-mail support@qlogic.com Knowledge Database The QLogic knowledge database is an extensive collection of QLogic product information that you can search for specific solutions.
Page 20 ISR651101-00 C...
Page 21: Introduction
Introduction This chapter illustrates and describes QLogic’s iSR6200 Intelligent Storage Router, including the components contained within the iSR6200 router chassis: router blades, chassis mid-plane, and power and cooling modules (PCMs). The iSR6200 router is designed to provide: Storage consolidation on Fibre Channel arrays by providing iSCSI server connectivity for Fibre Channel arrays.
Page 22: Isr6200 Router Chassis
1–Introduction iSR6200 Router Chassis iSR6200 Router Chassis The iSR6200 router chassis includes the following hardware components: Full-wide, 1U, rack mount 2 bays for hot-replaceable ISR blades 2 bays for hot-replaceable power and cooling modules (PCMs) 1 mid-plane with 2 x EEPROMs Dual 275 watt power supplies The iSR6200 router chassis contains one or two router blades, along with a power cooling module (PCM) for each blade.
Page 23: Power And Cooling Module (Pcm)
1–Introduction Power and Cooling Module (PCM) Front Plate iSR6200 Blade 1 Front Plate iSR6200 Blade 2 MGMT IOIOI MGMT IOIOI Back Plate PCM for Blade 2 Back Plate PCM for Blade 1 Figure 1-2 iSR6200 Router Chassis—Front and Back Plates Power and Cooling Module (PCM) Each iSR6200 chassis blade has a power and cooling module (PCM), located on the back-side of the chassis.
Page 24: Internal Temperature Sensor Limits
1–Introduction Power and Cooling Module (PCM) Each blade is capable of simultaneously driving all six fans in both PCMs. Normally, only one blade controls both fans, running them at a normal speed. However, if the system detects higher than expected temperature on either side of the blade, it forces the fans to run at full speed.
Page 25: Isr6200 Router Blades
1–Introduction iSR6200 Router Blades iSR6200 Router Blades Each chassis supports one or two blades. The blades are hot-pluggable. The base configuration of iSR6200 router blade has a dual core CPU, 1024 MB memory, boot Flash, and internal and external I/O ports. (For detailed specifications, see Appendix The following sections illustrate and describe the physical features and...
Page 26: Router Blade Leds
1–Introduction iSR6200 Router Blades iSR6250 Router Blade The iSR6250 router blade adds two 10Gb Ethernet ports to the blade configuration. Each port has the following capacity: 10GbE iSCSI ports that run in full duplex mode Support for jumbo frames IPv4 and IPv6 protocol support iSCSI header and data digest in the software Figure 1-6 10Gb Ethernet Ports on the iSR6250 Router Blade iSR6240 Router Blade...
Page 27: Heartbeat Led (Green)
1–Introduction iSR6200 Router Blades iSR6240 Intelligent Storage Router iSR6200 System MGMT IOIOI Heartbeat LED System Fault LED Power LED Beacon Indicator Figure 1-8 Router Blade LEDs Heartbeat LED (Green) The heartbeat LED blinks once a second as long the router firmware is operational.
Page 28: Beacon Indicator (Blue)
1–Introduction iSR6200 Router Blades Beacon Indicator (Blue) The iSR6200 router blade’s PCB has a blue beacon light installed near the center vent hole between the Fibre Channel ports (Figure 1-8). This light enables you to locate the physical blade when monitoring the iSR6200 routers using the SANsurfer Router Manager.
Page 29: Reset Ip Address
1–Introduction iSR6200 Router Blades Reset and Select Boot Image You can reset the router using either the primary or secondary boot image: Primary Image—To reset the router and select the primary boot image, use a pointed, nonmetallic tool to press and hold the maintenance button until the heartbeat LED flashes once, and then release the button.
Page 30: Fibre Channel Port Leds
1–Introduction iSR6200 Router Blades Resets the maintenance port IP address to 10.0.0.1. Disables the iSCSI ports and sets the IP address to 0.0.0.0. Erases all presentations. Erases all discovered initiators and targets. Fibre Channel Port LEDs The iSR6200 router has two Fibre Channel ports. The ports are labeled FC1 and FC2, as shown in Figure 1-10.
Page 31: Fibre Channel Transceivers
1–Introduction iSR6200 Router Blades Table 1-3. Port LEDs (Continued) Yellow LED Green LED Amber LED Activity (8 Gbps) (4 Gbps) (2 Gbps) Power ON Flashing Flashing Flashing (after firmware initializa- tion) Firmware initialization Alternate Alternate Alternate Flashing.. Flashing.. Flashing.. error Online, 2-Gbps link—I/O ON/Flashing activity...
Page 32: Ethernet Port-Management
1–Introduction iSR6200 Router Blades iSR6240 Intelligent Storage Router iSR6200 System MGMT IOIOI Activity Link Status Figure 1-11 Gigabit Ethernet Ports These ports each have two LEDs: The activity LED (green) lights up when the port transmits or receives data over the Ethernet connection. The link status LED (green) lights up continuously when the port establishes an Ethernet connection.
Page 33: Serial Port
1–Introduction iSR6200 Router Blades Serial Port The iSR6200 router is equipped with an RS-232 serial port for maintenance purposes. Figure 1-13 shows the serial port location, which is labeled IOIOI. You can manage the router through the serial port using CLI. iSR6240 Intelligent Storage Router iSR6200 System...
Page 34 1–Introduction iSR6200 Router Blades Notes 1-14 ISR651101-00 C...
Page 35: Planning
Planning This chapter describes how to plan for the iSR6200 router. The following sections describe the devices and services you need to consider when planning to use the iSR6200 router: “Devices” on page 2-1 “Device Access” on page 2-1 “Fibre Channel Switches Required for VPGroups” on page 2-2 “Fibre Channel Performance”...
Page 36: Fibre Channel
Fibre Channel Switches Required for VPGroups iSR6200 uses QLogic HBA technology and is compatible with all Fibre Channel switches from Brocade, Cisco, McData, and QLogic. If you want to use more than one VPGroup, you must use Fibre Channel Switches.
Page 37: Bandwidth
2–Planning iSCSI Performance Bandwidth Bandwidth is a measure of the volume of data that can be transmitted at a given transmission rate. A 2-Gbps Fibre Channel port can transmit or receive at nominal rates of 2-Gbps, depending on the device to which it is connected. This corresponds to actual bandwidth value of 212 MB.
Page 38: Performance Tuning
2–Planning Performance Tuning Performance Tuning Proper configuration maximizes the router’s performance. Knowing the round-trip delay (distance between the router and iSCSI initiators) and WAN effective data rate (connection type) allows you to tune the router for optimal performance. The following tables provide TCP Window Size settings for specific WAN environments.
Page 39: T3: 45Mbits/Sec
2–Planning Performance Tuning Table 2-2. T3: 45Mbits/Sec Round-Trip Delay (ms) TCP Window Size (kbytes) <= 1.4 <= 2.9 <= 5.7 <= 11.4 <= 22.9 <= 45.8 <= 91.6 <= 183.1 1024 <= 366.2 2048 <= 732.5 4096 Table Notes Supported in FC-IP mode only. Table 2-3.
Page 40: Oc-3: 156 Mbits/Sec
2–Planning Performance Tuning Table 2-4. OC-3: 156 Mbits/Sec Round-Trip Delay (ms) TCP Window Size (bytes) <= 0.4 <= 0.8 <= 1.6 <= 3.3 <= 6.6 <= 13.2 <= 26.3 <= 52.7 1024 <= 105.4 2048 <= 210.7 4096 Table 2-5. OC-12: 621 Mbits/Sec Round-Trip Delay (ms) TCP Window Size (bytes) <= 0.1...
Page 41: High Availability
2–Planning High Availability High Availability A dual-blade iSR6200 router supports high availability, which provides link-level, switch-level, and blade-level failure protection. To make this effective, you must connect the iSCSI hosts to both iSR6200 blades. For details, see “Connecting iSCSI Hosts to your iSR6200” on page 4-16.
Page 42: Services
2–Planning Services Need to LUN-map a replacement blade in a single-blade router. Want to duplicate the LUN mapping on a second router (for redundancy). NOTE: For more details on recovering a router blade, see “iSR6200 Chassis Blades” on page 7-1. Services You can configure your router to suit the demands of your environment using a variety of router services.
Page 43: Installation
Installation This chapter describes how to install and configure an iSR6200 router, including: “Site Requirements” on page 3-1 “Installing the iSR6200 Router” on page 3-2 “Installing New Firmware” on page 3-12 Site Requirements The following sections describe the requirements for installing a iSR6200 router: Management Workstation “Power Requirements”...
Page 44: Power Requirements
DB9 to RJ45 cable adapter Power cable (6 foot black) Rail Mounting Kit, part number 50990-00 WEEE Conformance Card QLogic Global Services Card China Optics and Cable SKUs Toxic Substance Table To install the iSR6200 router: Complete the pre-installation checklist (see page 3-3).
Page 45: Pre-Installation Check List
3–Installation Installing the iSR6200 Router Install the management application (see page 3-10). Start the management application (see page 3-11). Configure the router (see page 3-11). Cable devices to the router (Fibre Channel and iSCSI) (see page 3-12). Pre-installation Check List During the initial configuration process, the system prompts you to enter information for each blade contained in the iSR6200 chassis.
Page 46: Worksheet For Router Blade 2 (Right) Parameters
3–Installation Installing the iSR6200 Router Table 3-2. Worksheet for Router Blade 1 (left) Parameters (Continued) IP address of the iSNS server for iSCSI port 4 (if iSNS will be enabled) Table 3-3. Worksheet for Router Blade 2 (right) Parameters Symbolic Name of the iSR6200 Blade 2 Management port IP address, subnet mask,...
Page 47: Mounting The Router
You can either place the router on a flat surface or mount it in a 19-inch Electronic Industries Association (EIA) rack. See the product specification for weight and dimensions. Rack mounting requires a QLogic rack mounting kit; contact QLogic for more information.
Page 48: Connecting The Router To Ac Power
3–Installation Installing the iSR6200 Router Connecting the Router to AC Power WARNING!! This product is supplied with a 3-wire power cable and plug for the user’s safety. Use this power cable in conjunction with a properly grounded outlet to avoid electrical shock. An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the router chassis.
Page 49: Connecting The Management Workstation To The Router
3–Installation Installing the iSR6200 Router To power on the router: Attach the AC power cord to the power connector, located on the back side of the PCM connected directly behind the router blade. Connect the opposite end of the power cord to a grounded AC wall outlet or power strip.
Page 50: Configuring The Management Workstation
3–Installation Installing the iSR6200 Router Direct Ethernet connection from the management workstation to the router RJ-45 Ethernet connector. This requires a 10/100 Base-T crossover cable. Serial port connection from the management workstation to the router RS-232 serial port connector. This requires a 10/100 Base-T straight cable and a dongle.
Page 51: Configuring The Workstation Serial Port
3–Installation Installing the iSR6200 Router Configuring the Workstation Serial Port To configure the workstation serial port: Connect the cable with RJ45 to DB9F adapter from a COM port on the management workstation to the serial port on the router. Configure the workstation serial port according to your platform. These steps may vary according to the version of operating system you use: For Windows: Open the HyperTerminal application: On the Windows Start...
Page 52: Installing Sansurfer Router Manager
See the iSR6200 Router Manager User's Guide for information on how to use SANsurfer Router Manager. Windows Installation To install SANsurfer Router Manager from the QLogic Web site to a PC workstation: Close all programs currently running. Go to the QLogic download site: http://support.qlogic.com/support/drivers_software.aspx...
Page 53: Starting Sansurfer Router Manager
3–Installation Installing the iSR6200 Router Follow the installation instructions. Starting SANsurfer Router Manager For Windows, double-click the SANsurfer Router Manager shortcut, or select SANsurfer Router Manager from the Start menu, depending on how you installed the SANsurfer Router Manager utility. From a Windows command line, enter the following command: <install_directory>SANsurfer_Router_Manager.exe From a Linux command prompt, enter the following command:...
Page 54: Connecting Cable Devices To The Router
3–Installation Installing New Firmware Open an admin session and enter the commands to set up both iSCSI ports and the management interface. (See the iSR6200 Router CLI User's Guide for command descriptions.) QRouter #> admin start Password : ****** Router (admin) #> set mgmt ………………………...
Page 55: Using The Cli To Install Firmware
3–Installation Installing New Firmware A message warns you that the router will be reset to activate the firmware. Click OK to continue firmware installation, or click Cancel to cancel the firmware installation. Using the CLI to Install Firmware To use the CLI to install the firmware, transfer the firmware image file from a workstation to the router.
Page 56 3–Installation Installing New Firmware Enter the following command from the router, where x indicates the firmware image name: image unpack isr-62xx-x_x_x_x.bin The following message appears: Unpack Completed. Please reboot the system for FW to take effect. Enter reboot. The following message appears: Are you sure you want to reboot the System (y/n): To reboot the system, type y.
Page 57: Configuration
Configuration This chapter describes how to configure the iSR6200 router to support virtual port groups (VPGroups or VPGs) and LUN mapping. Some storage arrays limit the number of LUNs exposed to a host to 256 LUNs. Each iSR6200 router blade supports up to four VPGs, making it possible for these storage arrays to present up to 1024 LUNs per blade.
Page 58 4–Configuration Enabling Virtual Port Groups Each blade has VPG 1 enabled by default; VPG 1 is the primary virtual port group and cannot be disabled. Enabling additional virtual port groups creates additional logical Fibre Channel HBA initiator ports on the fabric. These ports act as separate Fibre Channel HBA host ports, and additional 256 LUNs can be presented to each of them.
Page 59: Sansurfer Router Manager Vpgroup
4–Configuration Enabling Virtual Port Groups Figure 4-1 SANsurfer Router Manager VPGroup ISR651101-00 C...
Page 60 4–Configuration Enabling Virtual Port Groups You can enable or disable Virtual Port Groups on your blade using either the GUI or the CLI. The following example shows how to enable this VPGroups 2 and 3 using the CLI set vpgroups command. iSR6200 <1>...
Page 61: Chassis Information For Selected Vpgroup
4–Configuration Enabling Virtual Port Groups Figure 4-2 Chassis Information for Selected VPGROUP Click Save. In the System Check dialog box, type the system password, and then click The Set VPGroup message box opens, as shown in Figure 4-3. Figure 4-3 Set VPGroup Message Box Click OK to close the message box.
Page 62 4–Configuration Enabling Virtual Port Groups The following example shows CLI command output using an iSR6200 blade with 3 Virtual Port Groups enabled. You can view information about the Virtual Port Groups configured on your iSR6200 using the show vpgroups command. iSR6200 <R1>...
Page 63 4–Configuration Enabling Virtual Port Groups The following example shows the information grouped by physical Fibre Channel port. iSR6200 <1> (admin) #> show fc FC Port Information --------------------- FC Port Port Status Enabled Link Status Current Link Rate Programmed Link Rate Auto WWNN 20:00:00:c0:dd:13:16:f8 (VPGROUP_1)
Page 64: Fc Port Information Page
4–Configuration Enabling Virtual Port Groups Port ID 0a-05-02 (VPGROUP_3) Firmware Revision No. 4.05.00 Frame Size 2048 Execution Throttle 32768 Connection Mode Point-to-Point Programmed Connection Option Loop Preferred SFP Type iSR6200 <1> (admin) #> Notice also the VP index in the second byte from the left, and the Fibre Channel port indicator in the right-most byte.
Page 65: Zoning Virtual Port Groups On The San
4–Configuration Zoning Virtual Port Groups on the SAN Zoning Virtual Port Groups on the SAN When zoning the iSR6200 Virtual Port Group WWPNs to a Fibre Channel array, you must ensure all WWPNs of a Virtual Port Group are zoned to any single Fibre Channel target WWPN.
Page 66: Single Blade Dual Fibre Channel Switch
4–Configuration Zoning Virtual Port Groups on the SAN 6200 FC_One A 21:00:00:c0:dd:13:16:f8 21:01:00:c0:dd:13:16:f8 21:02:00:c0:dd:13:16:f8 SAN A FC Target Array Controller A iSR6200 21:00:00:c0:dd:13:16:f8 21:01:00:c0:dd:13:16:f8 21:02:00:c0:dd:13:16:f8 Blade 1 21:00:00:c0:dd:13:16:f9 21:01:00:c0:dd:13:16:f9 21:02:00:c0:dd:13:16:f9 Controller B SAN B 6200 FC_Two B 21:00:00:c0:dd:13:16:f9 21:01:00:c0:dd:13:16:f9 21:02:00:c0:dd:13:16:f9 Figure 4-6 Single Blade Dual Fibre Channel Switch When connecting a dual blade iSR6200 for high availability, connect one Fibre Channel port from each blade to each of your fabrics (see...
Page 67: High-Availability, Dual Blades, Dual Fibre Channel Switches
4–Configuration Zoning Virtual Port Groups on the SAN Zone 6200 Blade 1 A Zone 6200 Blade 2 A 21:00:00:c0:dd:13:16:f8 21:00:00:c0:dd:13:17:02 21:01:00:c0:dd:13:16:f8 21:01:00:c0:dd:13:17:02 21:02:00:c0:dd:13:16:f8 21:02:00:c0:dd:13:17:02 SAN A FC Target Array iSR6200 Controller A 21:00:00:c0:dd:13:16:f8 21:01:00:c0:dd:13:16:f8 21:02:00:c0:dd:13:16:f8 Blade 1 21:00:00:c0:dd:13:16:f9 21:01:00:c0:dd:13:16:f9 21:02:00:c0:dd:13:16:f9 21:00:00:c0:dd:13:17:02 21:01:00:c0:dd:13:17:02 21:02:00:c0:dd:13:17:02...
Page 68: Configuring Fibre Channel Array Hosts And Lun Assignments With The Isr6200
4–Configuration Configuring Fibre Channel Array Hosts and LUN Assignments with the iSR6200 Configuring Fibre Channel Array Hosts and LUN Assignments with the iSR6200 When configuring Fibre Channel array hosts, you must treat each iSR6200 virtual port group (VPG) as its own unique Fibre Channel host within the virtualized storage array.
Page 69: Incorrectly Configuring All Groups To One Host Entity
4–Configuration Configuring Fibre Channel Array Hosts and LUN Assignments with the iSR6200 Figure 4-9 Incorrectly Configuring All Groups to One Host Entity Figure 4-10 shows an incorrect assignment of virtual port group WWPNs. Notice that host entity 1 and host entity 2 both contain ports from more than a one VPGroup.
Page 70: Correct Vpg Assignments For High Availability Configuration
4–Configuration Configuring Fibre Channel Array Hosts and LUN Assignments with the iSR6200 Figure 4-11 Correct VPG Assignments for High Availability Configuration Do not put VPG ports in host entities with other Fibre Channel hosts. When assigning LUNs to your VPG host entities, you must not assign the same LUN to two VPG Host entities.
Page 71: Correctly Assigning Luns To Your Vpg Host Entities
4–Configuration Configuring Fibre Channel Array Hosts and LUN Assignments with the iSR6200 Storage Array Host Entities LUN 1 Host Entity 0 21:00:00:c0:dd:13:16:f8 iSR6200 21:00:00:c0:dd:13:16:f9 LUN 2 21:00:00:c0:dd:13:16:f8 Host Entity 1 21:01:00:c0:dd:13:16:f8 21:02:00:c0:dd:13:16:f8 21:01:00:c0:dd:13:16:f8 21:01:00:c0:dd:13:16:f9 Blade 1 LUN 3 21:00:00:c0:dd:13:16:f9 21:01:00:c0:dd:13:16:f9 Host Entity 2 21:02:00:c0:dd:13:16:f9 21:02:00:c0:dd:13:16:f8...
Page 72: Connecting Iscsi Hosts To Your Isr6200
4–Configuration Connecting iSCSI Hosts to your iSR6200 Storage Array Host Entities LUN 1 Host Entity 0 21:00:00:c0:dd:13:16:44 iSR6200 21:00:00:c0:dd:13:16:45 LUN 2 21:00:00:c0:dd:13:16:44 Host Entity 1 21:01:00:c0:dd:13:16:44 21:01:00:c0:dd:13:16:44 21:02:00:c0:dd:13:16:44 21:01:00:c0:dd:13:16:45 21:02:00:c0:dd:13:16:44 LUN 3 Blade 1 21:00:00:c0:dd:13:16:45 Host Entity 2 21:01:00:c0:dd:13:16:45 21:02:00:c0:dd:13:16:44 21:02:00:c0:dd:13:16:45 LUN 4 21:02:00:c0:dd:13:16:45...
Page 73 4–Configuration Connecting iSCSI Hosts to your iSR6200 The following example shows the anatomy of a sample IQN string from an iSR6200 router: iqn.2004-08.com.qlogic:iSR6200.0834e00019.b1.01.20030020c2075970 Vendor name and registration date Product Name iSR6200 Chassis Serial Number Blade (b1 or b2) VPGroup (01 through 04)
Page 74: Selecting The Iscsi Presented Targets In Sansurfer Router Manager
4–Configuration Connecting iSCSI Hosts to your iSR6200 To view presented target information using SANsurfer Router Manager, expand the iSCSI Presented Targets tree, and then select the device, as shown in Figure 4-14. Figure 4-14 Selecting the iSCSI Presented Targets in SANsurfer Router Manager 4-18 ISR651101-00 C...
Page 75 4–Configuration Connecting iSCSI Hosts to your iSR6200 Enabling additional VPGroups can create multiple IQN strings for the same Fibre Channel WWPN. The following example shows two Fibre Channel target WWPNs and three VP groups, resulting in six presented iSCSI qualified names. For information about how to enable and configure additional VPGroups, see “Enabling Virtual Port Groups”...
Page 76 Connecting iSCSI Hosts to your iSR6200 VpGroup Name VPGROUP_4 Status Disabled WWPNs iSR6200 <1> (admin) #> show presented_targets Presented Target Information ------------------------------ iSCSI Presented Targets ------------------------- Name iqn.2004-08.com.qlogic:iSR6200.0834e00019.r1.01.20030020c2075970 Alias <MAPS TO> WWNN 10:00:00:20:c2:07:59:70 WWPN 20:03:00:20:c2:07:59:70 Name iqn.2004-08.com.qlogic:iSR6200.0834e00019.r1.01.21040020c2075970 Alias <MAPS TO> WWNN...
Page 77: Host Access To Luns On Storage Array
4–Configuration Connecting iSCSI Hosts to your iSR6200 Alias <MAPS TO> WWNN 10:00:00:20:c2:07:59:70 WWPN 21:04:00:20:c2:07:59:70 iSCSI host LUN access is determined by the specific iSCSI target to which the host connects, and the LUNs to which the VPG has access from the storage array.
Page 78: Iscsi Host Logged Into Iscsi Target For Vpg0
4–Configuration Connecting iSCSI Hosts to your iSR6200 Storage Array iSR6200 Host Entities 21:00:00:c0:dd:13:16:f8 LUN 1 21:01:00:c0:dd:13:16:f8 Host Entity 0 21:02:00:c0:dd:13:16:f8 21:00:00:c0:dd:13:16:f8 20:03:00:20:c2:07:59:70 Blade 1 21:00:00:c0:dd:13:16:f9 21:00:00:c0:dd:13:16:f9 LUN 2 21:01:00:c0:dd:13:16:f9 21:02:00:c0:dd:13:16:f9 Host Entity 1 21:01:00:c0:dd:13:16:f8 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 21:01:00:c0:dd:13:16:f9 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 LUN 3 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 Host Entity 2 21:02:00:c0:dd:13:16:f8 LUN 4...
Page 79: Controlling Per Host Lun Access On The Isr6200
4–Configuration Controlling per Host LUN Access on the iSR6200 Controlling per Host LUN Access on the iSR6200 The iSR6200 allows multiple iSCSI initiators to connect to a single Fibre Channel target through a given VPG. Controlling individual LUN access for each iSCSI host requires LUN mapping devices connected through the iSR6200.
Page 80 4–Configuration Controlling per Host LUN Access on the iSR6200 The following example shows how to map the LUN targets with initiators using CLI commands. iSR6200 <1> (admin) #> lunmask add Index Mapped (WWNN,WWPN/iSCSI Name) ----- ------ ---------------------- iqn.1991-05.com.microsoft:winhaz38 Please select an Initiator from the list above ('q' to quit): Index (VpGroup Name) -----...
Page 81: Logging Into Target After Mapping Lun 1
4–Configuration Controlling per Host LUN Access on the iSR6200 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 Storage Array iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 Host Entities LUN 1 Host Entity 0 21:00:00:c0:dd:13:16:f8 LUN 2 iSR6200 21:00:00:c0:dd:13:16:f9 Log-In LUN 3 Host Entity 1 21:01:00:c0:dd:13:16:f8 21:01:00:c0:dd:13:16:f9 Blade 1 LUN 4 Host accessible LUNs Host Entity 2 LUN 5 21:02:00:c0:dd:13:16:f8...
Page 82: Target Presentation/Lun Mapping Wizard—Lun Selection
4–Configuration Controlling per Host LUN Access on the iSR6200 Figure 4-20 Target Presentation/LUN Mapping Wizard—LUN Selection Select the check box next to the description of the initiators you want the LUNS mapped to, as shown in Figure 4-21. Figure 4-21 Target Presentation/LUN Mapping Wizard—Select the Initiators Click Next.
Page 83: Target Presentation/Lun Mapping Wizard—Confirm Changes
4–Configuration Controlling per Host LUN Access on the iSR6200 Figure 4-22 Target Presentation/LUN Mapping Wizard—Confirm Changes Review the configuration changes, and then click Next. The LUN Masking Configuration Status dialog box opens, along with the Security Check dialog box, as shown in Figure 4-23.
Page 84 4–Configuration Controlling per Host LUN Access on the iSR6200 NOTE: The default password is config. The LUN Masking Configuration Status window lists the mapping requests, as shown in Figure 4-24. Figure 4-24 Target Presentation/LUN Mapping Wizard - LUN Masking Configuration Status Verify the completion status shown on the LUN Masking Configuration Status window, and then click Finish to close the wizard.
Page 85: Logging In With Mapped Luns
4–Configuration Controlling per Host LUN Access on the iSR6200 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 Storage Array iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 Host Entities LUN 1 Host Entity 0 21:00:00:c0:dd:13:16:f8 LUN 2 iSR6200 21:00:00:c0:dd:13:16:f9 LUN 3 Host Entity 1 21:01:00:c0:dd:13:16:f8 Log-In Blade 1 21:01:00:c0:dd:13:16:f9 LUN 4 Host accessible LUNs Host Entity 2 LUN 5 21:02:00:c0:dd:13:16:f8...
Page 86 4–Configuration Controlling per Host LUN Access on the iSR6200 The following example shows how to do this using the set system CLI command. The red text shows entering the command that enables the LUN mapping. iSR6200 <1> (admin) #> set system A list of attributes with formatting and current values will follow.
Page 87: Enabling Lun Mask Mode
4–Configuration Controlling per Host LUN Access on the iSR6200 Figure 4-26 Enabling LUN Mask Mode Figure 4-27 shows host LUN access with LUN Masking set to disabled. iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 Storage Array iqn.2004-08.com:isr6200.0834e00019.r1.00.20030020c2075970 Host Entities LUN 1 Host Entity 0 21:00:00:c0:dd:13:16:f8 LUN 2 iSR6200 21:00:00:c0:dd:13:16:f9...
Page 88 4–Configuration Controlling per Host LUN Access on the iSR6200 NOTE: The iSR6200 router can access LUNs only after the host logs into iSR6200 Presented iSCSI target(s). 4-32 ISR651101-00 C...
Page 89: Fibre Channel Over Ip
Fibre Channel Over IP Fibre Channel over IP (FCIP) is a protocol used to transport Fibre Channel frames over TCP/IP, thus providing SAN over WAN capabilities. FCIP is commonly used to interconnect (merge) SANs that are separated by such a distance that a direct connection is cost prohibitive or technically unfeasible.
Page 90: Configuring Fcip
5–Fibre Channel Over IP Configuring FCIP Trace route and ping support Links up to two locations per blade, four locations per chassis (two blades) ® FICON support Configuring FCIP To successfully configure FCIP, you need to assess both the SAN and WAN environments.
Page 91: Configuring An Fcip Route Using The Cli
5–Fibre Channel Over IP Configuring FCIP Table 5-1. FCIP Pre-Configuration Information Router Being Configured IP Address Subnet Mask Gateway VLAN ID/Priority Peer Router (Remote) IP Address Configuring an FCIP Route Using the CLI This section shows an example of the fciproute add command and provides the steps to configure a FCIP route in the CLI (the GUI procedure is essentially the same).
Page 92 5–Fibre Channel Over IP Configuring FCIP Window Scaling (0=Enable, 1=Disable) [Enabled Window Scaling Factor (Min=0, Max=9) TCP Port No. (Min=1024, Max=65535) [3225 GE Port Speed (0=Auto, 1=100Mb, 2=1Gb) [Auto Bandwidth, Mbit/sec (Min=1, Max=1000) [1000 VLAN (0=Enable, 1=Disable) [Disabled FCIP SW Compression (0=Enable, 1=Disable) [Disabled All attribute values for FCIP Route 1 will now be saved.
Page 93: E_Port Extension
At the GE Port Speed prompt, select a GE port speed that matches that of the Ethernet switch port to which it is connected. QLogic recommends that you use a gigabit managed switch that is capable of automatically negotiating the port speed.
Page 94: E_Port Extension, Single Isl
5–Fibre Channel Over IP Configuring FCIP Figure 5-1 E_Port Extension, Single ISL Figure 5-2 shows an example of a two FCIP routes (dual ISLs). This example assumes that the Fibre Channel switches have the ability to load balance between the ISLs to enhance performance. Figure 5-2 E_Port Extension, Dual ISLs ISR651101-00 C...
Page 95: F_Port Extension
5–Fibre Channel Over IP Configuring FCIP F_Port Extension The FCIP configuration used to connect a distant F_Port to a SAN is referred to as an F_Port extension. This configuration is used to connect remote (stranded) servers to a SAN or to connect remote storage to a SAN. In the F_Port extension configuration, one of the FCIP routers (local) is connected to a Fibre Channel switch (SAN) and the other FCIP router (remote) is directly connected to a Fibre Channel port on the server or storage.
Page 96: Determining Wan Characteristics
5–Fibre Channel Over IP Configuring FCIP Figure 5-4 F_Port Extension, Server Determining WAN Characteristics To correctly configure a FCIP route for maximum performance and reliability requires precise understanding of the IP link (WAN) characteristics, including the following link characteristics: Link Round-Trip Time (RTT) Link Data Rate End-to-End Available Link Bandwidth Allocated Link Bandwidth...
Page 97: Round-Trip Time
5–Fibre Channel Over IP Configuring FCIP Round-Trip Time Round-trip time (RTT) is the time required for a packet to travel from the sender to the receiver, and then return to the sender. The router’s ping command, either CLI or GUI, can help determine the RTT. The following is an example of the CLI ping command executed on GE port 1.
Page 98: Link Data Rate
5–Fibre Channel Over IP Configuring FCIP Link Data Rate The available link data rate is not typically the same as the connection speed at the router’s GE port. The GE port is typically connected to a local IP switch with ports running at 1 gigabit.
Page 99 5–Fibre Channel Over IP Configuring FCIP TCP Re-transmit Timer Expired: The sender of a packet did not receive an ACK for a packet within the re-transmit timeout window. The sender will re-transmit the packet. This is typically the result of the ACK being dropped somewhere in the WAN due to congestion or corruption of the ACK (less likely).
Page 100: Firewall
5–Fibre Channel Over IP Configuring FCIP MAC Xmit Bytes 1534059818 MAC Xmit Multi Count MAC Xmit Broad Count MAC Xmit Pause Count MAC Xmit Control Frames MAC Xmit Deferrals MAC Xmit Late Collisions MAC Xmit Aborted MAC Xmit Multiple Collisions MAC Xmit Single Collisions MAC Xmit Collisions MAC Xmit Dropped Frames...
Page 101: Ports Requiring Unblocking
5–Fibre Channel Over IP Configuring FCIP Table 5-3. Ports Requiring Unblocking Port Description 20/TCP FTP—data 21/TCP FTP—control (command) 23/TCP Telnet protocol—unencrypted text communications 111/TCP,UDP Sun Remote Procedure Call (RPC) 161/TCP,UDP Simple Network Management Protocol (SNMP) 835/TCP,UDP Port number on which the server listens for user requests To verify the listen port number, run the following command (from a Linux system), where the IP address specified is that of the remote router’s management port: rpcinfo -p <IP address>...
Page 102: Data Compression
5–Fibre Channel Over IP Configuring FCIP Data Compression Data compression is an option that in some configurations can provide a data throughput rate greater than the capability of the IP link. The iSR6200 is capable of compressing data at 150 MB per second. If a FCIP configuration has the following attributes, data compression should be enabled and the resulting performance monitored to determine if data compression results in a performance improvement.
Page 103: T1 / Ds-1—1.554 Mbps
5–Fibre Channel Over IP Configuring FCIP The following tables show the suggested TCP window size settings for IP links based on link speed and round-trip time. Table 5-4. T1 / DS-1—1.554 Mbps Round-Trip Time Window Size Scaling Factor (ms) (bytes) 1 or less Table 5-5.
Page 104: Ds-5—400 Mbps
5–Fibre Channel Over IP Configuring FCIP Table 5-6. DS-5—400 Mbps Round-Trip Time Window Size Scaling Factor (ms) (bytes) 8M or 16M 8 or 9 512K 256K 128K 1 or less Table 5-7. OC-1—50 Mbps Round-Trip Time Window Size Scaling Factor (ms) (bytes) 1M or 2M...
Page 105: Oc-3—150 Mbps
5–Fibre Channel Over IP Configuring FCIP Table 5-8. OC-3—150 Mbps Round-Trip Time Window Size Scaling Factor (ms) (bytes) 1M or 2M 5 or 6 1M or 2M 5 or 6 512K 512K 256K 256K 128K 1 or less Table 5-9. OC-3—150 Mbps Round-Trip Time Window Size Scaling Factor...
Page 106: Oc-12 And Above—621 Mbps
5–Fibre Channel Over IP Configuring FCIP Table 5-10. OC-12 and Above—621 Mbps Round-Trip Time Window Size Scaling Factor (ms) (bytes) 512K 256K 1 or less Table 5-11. OC-24 and Above—1.244 Gbps Round-Trip Time Window Size Scaling Factor (ms) (bytes) 2M or 4M 6 or 7 512K 1 or less...
Page 107: Router Tcp Window Setup
5–Fibre Channel Over IP Configuring FCIP Router TCP Window Setup Table 5-12 contains router settings for the listed TCP window sizes. Table 5-12. Router TCP Window Settings Router Window Scaling Required TCP Window Router TCP Window Size (bytes) Size (bytes) Factor (2 8,192 16,384...
Page 108 5–Fibre Channel Over IP Configuring FCIP Notes 5-20 ISR651101-00 C...
Page 109: Diagnostics And Troubleshooting
Diagnostics and Troubleshooting Diagnostic information about the router is available through the chassis LEDs and the port LEDs. Diagnostic information is also available through SANsurfer Router Manager and command line interface (CLI) event logs and error displays. This chapter describes the following types of diagnostics: Chassis Diagnostics “Power-On Self-Test Diagnostics”...
Page 110: System Fault Led Is On
6–Diagnostics and Troubleshooting Power-On Self-Test Diagnostics Yes—Make necessary corrections or repairs. If the condition remains, continue. No—Continue. Inspect AC power source. Is the power source delivering the proper voltage? Yes—Continue. No—Make the necessary repairs. If the condition remains, continue. Replace the router. System Fault LED is On The System fault LED blinks a specific pattern to indicate the problem.
Page 111: Heartbeat Blink Pattern
6–Diagnostics and Troubleshooting LED Blink Patterns Heartbeat Blink Pattern A blink pattern on the heartbeat LED of one second ON followed by one second OFF means that the router is operating normally. The heartbeat LED shows this pattern when the router firmware is operational System Error Blink Pattern The system fault LED generates a three-blink pattern (once per second) followed by a two second pause to indicate a system error.
Page 112: Recovering A Router
6–Diagnostics and Troubleshooting Recovering a Router No—Remove any debris from the fan intake and exhaust if necessary. If the condition remains, continue. Consider the ambient air temperature near the router and clearance around the router. Make necessary corrections. If the condition remains, open a command line window and log on to the router.
Page 113: Removal And Replacement
Removal and Replacement This chapter describes how to remove and replace the following field replaceable units (FRUs): SFP Transceivers “iSR6200 Chassis Blades” on page 7-1 “Power and Cooling Modules” on page 7-10 SFP Transceivers You can remove and replace the SFP transceivers while the iSR6200 router is operating without damaging the router or the transceiver.
Page 114: Dual Blade Installation
7–Removal and Replacement iSR6200 Chassis Blades The blade replacement facility ensures that the replaced unit retains the MAC addresses for the management ports and iSCSI ports as well as the WWPN/WWNN for the Fibre Channel ports. Retaining these values ensures that the Fibre Channel zoning, LUN masking, and iSCSI login sessions previously established are still valid after replacing the blade.
Page 115: Installing A New Replacement Blade
7–Removal and Replacement iSR6200 Chassis Blades Figure 7-2 Removing the Chassis Blade Installing a New Replacement Blade Before replacing a blade for a dual-blade router installation, you must first remove it (as described on page 7-2). To install a replacement blade in an iSR6200 chassis with a dual blade: Unlatch the lever on the new blade prior to inserting it into the chassis, as shown in Figure...
Page 116: Single Blade Installation
7–Removal and Replacement iSR6200 Chassis Blades Insert the new blade into the chassis slot. Figure 7-4 shows how to push the blade straight into the chassis (1), and then seat the blade onto the chassis mid-plane by pushing the right side lever up and latching it into place (2). The blade powers on and boots up.
Page 117 7–Removal and Replacement iSR6200 Chassis Blades Removing the Failed Blade To remove a failed blade from an iSR6200 chassis with a single blade: Log all iSCSI initiators out of the iSR6200 blade you are replacing prior to replacing the iSR6200 router blade. Save the blade’s FRU using either SANsurfer Router Manager or the CLI fru save command.
Page 118 7–Removal and Replacement iSR6200 Chassis Blades Use an FTP client to get the FRU file from the iSR6200 blade. For both the user name and password, enter ftp. Remember to issue the bin command before you issue the get command. For example: your router IP ftp <...
Page 119: Isr6200 Router Blade With Cables Disconnected
7–Removal and Replacement iSR6200 Chassis Blades Figure 7-5 iSR6200 Router Blade with Cables Disconnected Remove the old blade from the chassis. Figure 7-6 shows how to release the latch and pull down on the lever on the right-hand side (1), and then pull straight back on the handle (2).
Page 120: Unlatching The Lever On The New Blade
7–Removal and Replacement iSR6200 Chassis Blades To install a replacement blade in an iSR6200 chassis with a single blade: Unlatch the lever on the new blade prior to inserting it into the chassis, as shown in Figure 7-7. Figure 7-7 Unlatching the Lever on the New Blade Insert the new blade into the chassis slot.
Page 121 7–Removal and Replacement iSR6200 Chassis Blades The system runs the Power On Self-Test (POST). The heartbeat and system fault LEDs show the operational status of the router. When the POST completes with no errors, these LEDs blink at a steady rate of once per second.
Page 122: Power And Cooling Modules
7–Removal and Replacement Power and Cooling Modules admin start iSR6200 <1> #> ****** Password fru restore iSR6200 <1> (admin) #> A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the list press 'q' or 'Q' and the ENTER key to do so.
Page 123: Removing The Failed Pcm
7–Removal and Replacement Power and Cooling Modules Removing the Failed PCM To remove a failed PCM from the iSR6200 chassis: Locate the failed PCM unit on the back side of the iSR6200 chassis. A failed PCM unit shows an amber color status LED. Figure 7-9 shows the back side of two PCMs installed in a chassis configured with two iSR6200 chassis blades.
Page 124: Installing A New Pcm
7–Removal and Replacement Power and Cooling Modules Figure 7-10 Removing the Failed PCM Installing a New PCM To install a replacement PCM in the iSR6200 chassis: Before you insert the new PCM into the chassis, unlatch the lever on the new PCM (see Figure 7-11.)
Page 125: Inserting The Replacement Pcm
7–Removal and Replacement Power and Cooling Modules Figure 7-12 Inserting the Replacement PCM Connect the power cable to the newly inserted PCM. Its status LED should change from amber to green within 5 seconds. Figure 7-13 Back Side of Two PCMs, Both With Good Status Indicators Verify that the airflow through both PCMs is in the same direction.
Page 126 7–Removal and Replacement Power and Cooling Modules Notes 7-14 ISR651101-00 C...
Page 127: Interface Specifications
Technical Specifications This appendix provides the following technical specification for the iSR6200 router: Interface Specifications “Expansion Configurations” on page A-2 “Performance Features” on page A-2 “iSCSI Initiator Support” on page A-3 “Device Management” on page A-3 “Mechanical” on page A-3 “High Availability”...
Page 128: Expansion Configurations
A–Technical Specifications Expansion Configurations Expansion Configurations One expansion card per router blade adds ports to the system. 2 x 1Gb Ethernet module 2 x 10Gb Ethernet FCoE/iSCSI module (standard configuration) 2 x 20Gb InfiniBand DDR Performance Features Maximum Data Rates iSCSI: 2.6-Gbps aggregate (1.3 Gb per blade) Fibre Channel: 12.8-Gbps aggregate (6.4Gb per blade) Input/output Operations per Second (IOPS)
Page 129: Iscsi Initiator Support
Linux: Red Hat AS 3, 4, 5; SUSE Enterprise Server 8, 9, 10 VMware: ESX Server v3.0.x, v3.5x AIX: AIXL 5 HP-UX: versions 9, 10 QLogic: 4010, 4050, 4052, 4060, 4062 Apple: OS-X (via ATTO driver) Device Management Management Methods:...
Page 130: High Availability
A–Technical Specifications High Availability Power Supply 235W maximum (2 blades and 2 expansion cards) 106W typical (1 Blade, 2 power modules) 100 VAC to 240 VAC; 50 Hz to 60 Hz 1.9A at 100–125 VAC; 1.02A at 200-240VAC Dual, redundant, hot-swap power supplies Cooling Six redundant fans with back-to-front airflow High Availability...
Page 131 A–Technical Specifications Environmental and Safety Non-operating: Temperature: -40 ° C to +70 ° C (-40 ° F to158 ° F) Humidity: 5% to 93% non-condensing Altitude: 0 to +50,000 ft. Vibration: IEC 68-2, 5-500Hz, random, 2.09G rms, 10 minutes Shock: IEC 68-3, 30g, 292 ips, 3 repetitions, 3 axis ISR651101-00 C...
Page 132 A–Technical Specifications Environmental and Safety Notes ISR651101-00 C...
Page 133: Simple Network Management Protocol
Management Protocol Simple network management protocol (SNMP) provides monitoring and trap functions for managing the router through third-party applications that support SNMP. The router firmware supports SNMP versions 1 and 2 and a QLogic management information base (MIB) (see page B-4).
Page 134: Snmp Parameters
B–Simple Network Management Protocol SNMP Parameters SNMP Parameters You can set the SNMP properties using SANsurfer Router Manager or the command line interface (CLI). For SNMP configuration details, see the iSR6200 Router CLI User’s Guide or the iSR6200 Router Manager User’s Guide. Table B-1 describes the SNMP parameters.
Page 135: Snmp Trap Configuration
B–Simple Network Management Protocol SNMP Trap Configuration SNMP Trap Configuration SNMP trap configuration lets you set up to eight trap destinations. Choose from Traps 1–Trap 8 to configure each trap. Table B-2 describes the parameters for configuring an SNMP trap. Table B-2.
Page 136: Management Information Base (Mib
B–Simple Network Management Protocol Management Information Base (MIB) Management Information Base (MIB) This section describes the QLogic management information base (MIB). The MIB includes the following tables: “Network Port Table” on page B-4 “FC Port Table” on page B-7 “Initiator Object Table” on page B-9 “LUN Table”...
Page 137 B–Simple Network Management Protocol Management Information Base (MIB) A network port entry consists of the following sequence of objects: qsrNwPortRole QsrPortRole qsrNwPortIndex unsigned32 qsrNwPortAddressMode INTEGER qsrIPAddressType InetAddressType qsrIPAddress InetAddress qsrNetMask InetAddress qsrGateway InetAddress qsrMacAddress MacAddress qsrNwLinkStatus QsrLinkStatus qsrNwLinkRate QsrLinkRate qsrNwPortRole Syntax QsrPortRole Access...
Page 138 B–Simple Network Management Protocol Management Information Base (MIB) qsrIPAddressType Syntax InetAddressType Access Read-only Description IP address type: ipv4 or ipv6. qsrIPAddress Syntax InetAddress Access Read-only Description IP address of the port. qsrNetMask Syntax InetAddress Access Read-only Description Subnet mask for this port. qsrGateway Syntax InetAddress...
Page 139: Fc Port Table
B–Simple Network Management Protocol Management Information Base (MIB) qsrNwLinkRate Syntax QsrLinkRate Access Read-only Description Operational link rate for this port. FC Port Table This table contains a list of the Fibre Channel (FC) ports on the router. There are as many entries in this table as there are Fibre Channel ports on the router. qsrFcPortTable Syntax SEQUENCE OF QsrFcPortEntry...
Page 140 B–Simple Network Management Protocol Management Information Base (MIB) qsrFcPortRole Syntax QsrPortRole Access Not accessible Description Operational role of this port: FCP mode or frame shuttle mode. qsrFcPortIndex Syntax Unsigned32 Access Not accessible Description A positive integer indexing each Fibre Channel port in a given role.
Page 141: Initiator Object Table
B–Simple Network Management Protocol Management Information Base (MIB) qsrFcPortType Syntax Unsigned32 Access Read-only Description Type of Fibre Channel port, as indicated by the use of the appropriate value assigned by IANA. The IANA-maintained registry for Fibre Channel port types is located here: www.iana.org/assignments/fc-port-types qsrFcLinkStatus Syntax...
Page 142 B–Simple Network Management Protocol Management Information Base (MIB) qsrIsInitEntry Syntax QsrIsInitEntry Access Not accessible Description Each entry (row) contains information about a specific iSCSI initiator. iSCSI initiator information entry consists of the following sequence of the object: qsrIsInitIndex Unsigned32, qsrIsInitName SnmpAdminString, qsrIsInitAlias SnmpAdminString,...
Page 143 B–Simple Network Management Protocol Management Information Base (MIB) qsrIsInitAddressType Syntax InetAddressType Access Read-only Description Type of iSCSI initiator’s IP address (IPv4 or IPv6). qsrIsInitAddress Syntax InetAddress Access Read-only Description IP address of the iSCSI initiator. qsrIsInitStatus Syntax Integer: 1 = unknown, 2 = loggedIn, 3 = loggedOut, 4 = recovery...
Page 144: Lun Table
Access Not accessible Description Each entry (row) contains information about a specific LUN.This table extends scsiDscLunTable in QLOGIC-SCSI-MIB. The entries in this table show other attributes of the LUN. The QsrLunEntry contains of following sequences of objects. qsrLunWwuln PhysAddress, qsrLunVendorId...
Page 145 B–Simple Network Management Protocol Management Information Base (MIB) qsrLunVendorId Syntax SnmpAdminString Access Read-only Description Vendor ID for the LUN. qsrLunProductId Syntax SnmpAdminString Access Read-only Description Product ID for the LUN. qsrLunProdRevLevel Syntax SnmpAdminString Access Read-only Description Product revision level for the LUN. qsrLunSize OBJECT-TYPE Syntax Unsigned32...
Page 146: Vp Group Table
B–Simple Network Management Protocol Management Information Base (MIB) qsrLunVPGroupid Syntax Integer Access Read-only Description ID of the VP group to which this LUN belongs. qsrLunVPGroupname OBJECT-TYPE Syntax SnmpAdminString Access Read-only Description VP group name to which this LUN belongs. VP Group Table This table contains a list of virtual port groups (VPGs).
Page 147 B–Simple Network Management Protocol Management Information Base (MIB) The QsrVPGroupEntry contains the following sequence of objects: qsrVPGroupIndex Unsigned32, qsrVPGroupId INTEGER, qsrVPGroupName SnmpAdminString, qsrVPGroupWWNN VpGroupWwnnAndWwpn, qsrVPGroupWWPN VpGroupWwnnAndWwpn, qsrVPGroupStatus INTEGER qsrVPGroupIndex OBJECT-TYPE Syntax Unsigned32 Access Read-only Description VP group index. qsrVPGroupId OBJECT-TYPE Syntax Integer Access...
Page 148: Sensor Table
B–Simple Network Management Protocol Management Information Base (MIB) qsrVPGroupWWPN OBJECT-TYPE Syntax VpGroupWwnnAndWwpn Access Read-only Description Worldwide port number (WWPN). qsrVPGroupStatus OBJECT-TYPE Syntax Integer: 0 = enabled; 1 = disabled Max-Access Read-only Description Maintain the status of the VP group (enabled/disabled) Sensor Table The sensor table lists all the sensors on the router.
Page 149 B–Simple Network Management Protocol Management Information Base (MIB) A sensor entry consists of the following sequence of objects: qsrSensorType INTEGER qsrSensorIndex Unsigned32 qsrSensorUnits INTEGER qsrSensorValue Integer32 qsrUpperThreshold Integer32 qsrLowerThreshold Integer32 qsrSensorState INTEGER qsrSensorType Syntax INTEGER Temperature = 1 Access Not accessible Description Type of data being measured by this sensor.
Page 150 B–Simple Network Management Protocol Management Information Base (MIB) qsrSensorValue Syntax Integer32 Access Read-only Description Current value of the sensor. qsrUpperThreshold Syntax Integer32 Access Read-only Description Upper-level threshold for this sensor. qsrLowerThreshold Syntax Integer32 Access Read-only Description Lower-level threshold for this sensor. qsrSensorState Syntax INTEGER...
Page 151: Notifications
B–Simple Network Management Protocol Notifications Notifications The router provides the following notification types described in this section: “System Information Objects” on page B-19 “Notification Objects” on page B-20 “Agent Startup Notification” on page B-21) “Agent Shutdown Notification” on page B-21 “Network Port Down Notification”...
Page 152: Notification Objects
B–Simple Network Management Protocol Notifications qsrSwVersion Syntax SnmpAdminString Access Read-only Description System software (firmware) version number. qsrNoOfFcPorts Syntax Unsigned32 Access Read-only Description Quantity of Fibre Channel ports on the system. qsrNoOfGbEPorts Syntax Unsigned32 Access Read-only Description Quantity of gigabit Ethernet ports on the system. qsrAgentVersion Syntax SnmpAdminString...
Page 153: Agent Startup Notification
B–Simple Network Management Protocol Notifications qsrEventDescription Syntax SnmpAdminString Access Accessible for notify Description A textual description of the event that occurred. qsrEventTimeStamp Syntax DateAndTime Access Accessible for notify Description Indicates when the event occurred. Agent Startup Notification The agent startup notification indicates that the agent on the router has started running.
Page 154: Fc Port Down Notification
B–Simple Network Management Protocol Notifications FC Port Down Notification The FC port down notification indicates that the specified Fibre Channel port is down. The next time the port comes up, this event is sent with the qsrEventSeverity object set to clear. qsrFcPortDown uses the following objects: qsrFcLinkStatus qsrEventTimeStamp...
Page 155: Vp Group Notification
B–Simple Network Management Protocol Notifications Target Presentation State: Presented (mapped) or unpresented (unmapped) Target name Blade number (1 or 2) VP Group Notification The VP group notification indicates that the specified VP group is enabled or disabled. It also represents change in the name of the VP group. qsrVPGroupStatusChanged uses the following objects: qsrBladeSlot qsrVPGroupIndex...
Page 156: Generic Notification
B–Simple Network Management Protocol Notifications Fans returned to normal speed PCM number (1 or 2) Power Cooling Module (PCM) installed PCM number (1 or 2) PCM removed PCM number (1 or 2) PCM powered (AC power connected) PCM number (1 or 2) PCM un-powered (AC power removed) PCM number (1 or 2) Fan failed...
Page 157 B–Simple Network Management Protocol Notifications iSNS configuration change Blade number (1 or 2) NTP configuration change Blade number (1 or 2) Router configuration change Blade number (1 or 2) Management port configuration change Blade number (1 or 2) Firmware upgrade complete Blade number (1 or 2) Reboot blade Blade number (1 or 2)
Page 158 B–Simple Network Management Protocol Notifications Notes B-26 ISR651101-00 C...
Page 159: Log Messages
Log Messages This appendix provides details about messages logged to a file. (For details, see information about viewing the router logs in the iSR6200 Router CLI User’s Guide or the iSR6200 Router Manager User’s Guide.) The message log is persistent because it is maintained across router power cycles and reboots. Information in Table C-1 is organized as follows:...
Page 160 C–Log Messages TOE = TCP/IP offload engine module User = User module The Msg. Type column specifies the log message type, where: Error = Error log message Fatal = Fatal log message Info = Informational log message The Description column provides additional information about the log message. Table C-1.
Page 161 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41077 Error Unable to create an object for initiator object; QLBA_CreateInitiatorObject: Too many exceeded the maximum number of initiators. initiators 41096 Error Process control block status indicates that a periph- QLBA_DisplayTargetOperationStatus: PCI eral component interface/interconnect (PCI) error Error, Status 0x%.2x...
Page 162 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41268 Error iSCSI Login PDU received without a target name for QLIS_LoginPduContinue: Missing target a normal session. name 41270 Error iSCSI Login PDU received without an initiator name QLIS_LoginPduContinue: TSIH is 0 but key/value.
Page 163 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41508 Error Failed to allocate an object for Set Port Info IOCTL QLBI_SetPortInfo: processing: QLUT_AllocatePortalObject failed (PortType 0x%x, PortId 0x%x) PortType: 0 = Fibre Channel, 1 = iSCSI PortId: 0 = FC1 or iSCSI1(GE1), 1 = FC2 or iSCSI2 (GE2) 41626...
Page 164 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 41717 Error Pass-Through command issued by management QLBI_Passthru: Invalid data length %d application (such as GUI) was interrupted or timed bytes out. 41750 Error IOCTL operation unsupported.
Page 165 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 42027 Error Logout attempted using Fibre Channel VP index that QLFC_Logout: VP Index 0x%x not configured has not been configured. Operation attempted on an unconfigured VP.
Page 166 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 42649 Error Event notification; an IOCTL request was received to QLIS_HandleTeb: Unload Driver unload the iSCSI driver. 42654 Error Event notification; attempt to connect to the iSNS QLIS_HandleTeb: iSNS Connection Failed server failed.
Page 167 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 54274 Info Fibre Channel login occurred, origin xx (1 = adapter, QLFC_Login: Origin 0x%x, VP Index 0x%x, Id 2 = target, 3 = initiator), VP (virtual port) xx, ID (loop 0x%x ID) xx.
Page 168 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 54939 Info Event notification; iSCSI close connection request or QLIS_HandleTeb: UTM_EC_CLOSE_CONNECTION connection closed. or UTM_EC_CONNECTION_CLOSED 54940 Info Event notification; iSCSI connection closed. QLIS_HandleTeb: UTM_EC_CLOSE_CONNECTION or UTM_EC_CONNECTION_CLOSED 54941 Info...
Page 169 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 56842 Info Failed to resume a paused job. QLDM_ResumeMigration: Failed to resume job: %d, job's current state: 0x%x, error: 56865 Info Failed to start a delayed schedule job. QLDM_DelayedStart:%d Failed to start job : Job ID: %d 56866...
Page 170 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 56880 Info The log shows the configured start time and current Start time got from user %lu Cur Time: %lu time for a delayed migration job. Diff: %d 56881 Info...
Page 171 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 69966 iSCSI Fatal Port enable reboot timer failed. #%d: QLEnable: QLRebootTimer failed AF %x RS %x Time %d 70224 iSCSI Fatal iSNS response contains an invalid handle. #%d: QLProcSrblessiSNSResponse: Invalid handle %x 70400...
Page 172 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 70524 iSCSI Fatal Asynchronous event for unknown event type. #%d: QLProcessAen: Invalid event %x 70544 iSCSI Fatal Reboot timer failed. #%d: QLRebootTimer: Reboot failed! 70563 iSCSI Fatal...
Page 173 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 73990 iSCSI Error The iSCSI processor failed firmware initialization. #%d: QLUtmIoctlEnable: Initialize FW failed 74056 iSCSI Error The iSCSI processor failed the internal loopback test. #%d: QLRunDiag: MBOX Diag test internal loopback failed %x %x 74057...
Page 174 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 74659 iSCSI Error The iSCSI processor (adapter) failed to provide a #%d: QLReadyTimer: Adapter missed heartbeat for x seconds. heartbeat for 0x%x seconds 74660 iSCSI Error The iSCSI processor failed to complete an abort...
Page 175 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 86347 iSCSI Info Restart iSCSI processor (RISC). #%d: QLDisable: Restart RISC 86349 iSCSI Info EEPROM updated, restart iSCSI processor (RISC). #%d: QLEnable: Restart RISC to update EEPROM 86874 iSCSI...
Page 176 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 102656 Fatal Fibre Channel processor failed reset. #%d: QLInitializeAdapter: Reset ISP failed 102657 Fatal Fibre Channel processor firmware load failed. #%d: QLInitializeAdapter: Load RISC code failed 102658 Fatal...
Page 177 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 102752 Fatal Fibre Channel processor external SRAM parity error #%d: QLTimer: Ext Ram parity error exceed count exceeded limit; Fibre Channel port disabled. limit cnt 0x%x, limit 0x%x, Disabled adapter 102755 Fatal...
Page 178 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 106813 Error The Fibre Channel processor reported an unex- #%d: QLIsrEventHandler: Unexpected async pected asynchronous event. The mailbox registers event (%x), MB1=%x, MB2=%x, MB3=%x, provide status, event code, and data related to the MB4=%x, MB5=%x, MB6=%x, MB7=%x event.
Page 179 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 107041 Error The driver’s host (initiator) database is full. Maximum #%d: QLUpdateDeviceDatabase 0x%x: GET_ID host database is 64. failed %x 107056 Error The drivers host (initiator) database is full. #%d: QLUpdateDeviceDatabase 0x%x: out of slots in host database 107078...
Page 180 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 118882 Info Request to reset the Fibre Channel processor #%d: QLIoctlDisable: Reset adapter (adapter) received from ioctl interface. 119088 Info Fibre Channel loop initialization process (LIP) #%d: QLIsrEventHandler: LIP occurred occurred.
Page 181 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 120373 Info For FCoE protocol, the Data Center Bridging #%d: QLIsrEventHandler: DCBX Completed Exchange protocol completes. (%x) 120374 Info For FCoE protocol, the Inter-Driver Communication #%d: QLIsrEventHandler: IDC Completion completes.
Page 182 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 139269 User Error Get iSCSI API memory allocation failed. QBRPC_Initialize:GetIscsi Mem Allocation error 139270 User Error Get iSCSI advanced API memory allocation failed. QBRPC_Initialize:GetIscsiAdv Mem Allocation error 139271 User...
Page 183 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 139286 User Error Failed memory allocation for Get Presented Targets QBRPC_Initialize:PresTarget Mem List API. Allocation error 139287 User Error Failed memory allocation for Get LUN Mask API. QBRPC_Initialize:LunMask Mem Allocation error 139288...
Page 184 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 139303 User Error Failed memory allocation for TCP/IP Statistics API. QBRPC_Initialize:TcpIpStats Mem Allocation error 139304 User Error Failed memory allocation for NTP Status API. QBRPC_Initialize:NtpStats Mem Allocation error 139305...
Page 185 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 139934 User Error Network device configuration failed; could not add or FcipRoute#%d Failed with Network remove a network device instance. Verify the IP Configuration Error addresses, mask, gateway, and Ethernet port speci- fied in the route definition 139935...
Page 186 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 151890 User Info The iSCSI port configuration has changed. #%d: qapisetiscsiinterfaceparams_1_svc: iSCSI port configuration changed 151891 User Info The iSNS configuration has changed. #%d: qapisetisns_1_svc:iSNS configuration changed 151892 User...
Page 187 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 151911 User Info Fibre Channel port %d was disabled by user. FC%d: Port status changed by user to DISABLED. 151912 User Info The target at WWPN: xx.xx.xx.xx.xx.xx.xx.xx has qapimaptargetdevice_1_svc: Target WWPN: been mapped to iSCSI portal %d.
Page 188 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 152103 User Info Serial schedule jobs scheduled to start at time speci- qapisetserialjobs_1_svc: Serial Time %lu fied in the log. 152104 User Info Readjust priority command completed with an error. qapireadjustpriority_1_svc: Readjust Error code 2 indicates no scheduled jobs were found.
Page 189 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 152134 User Info The left PCM is not connected to AC power sysTempMon: Power for Left PCM Un-plugged (unplugged). 152135 User Info The right PCM is connected AC power. sysTempMon: Power for Right PCM Plugged-in 152136 User...
Page 190 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 172040 FCIP Error This is an informative message not an error. This FcipRoute#%d: Cleaning FCIP Instance indicates an FCIP was removed or modified. 172231 FCIP Error Connectivity with the remote peer has been inter-...
Page 191 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 172247 FCIP Error Unable to notify the remote router that the local Fibre FcipRoute#%d: Failed to send FC Up/Down Channel link came up or went down. The TCP con- nection will be closed and the router will attempt to reconnect to the remote router.
Page 192 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 184542 FCIP Info Route definition includes VLAN but the network FcipRoute#%d: VLAN Info Unavailable VLAN device instance does not exist. This is an inter- nal error.
Page 193 C–Log Messages Table C-1. iSR6200 Router Log Messages (Continued) Module Msg. Log Message Description Type Type 249862 System Info The router temperature has returned to the normal Temperature is back to normal range %d operating range. ISR651101-00 C C-35...
Page 194 C–Log Messages C-36 ISR651101-00 C...
Page 195: Glossary
Glossary activity LED bandwidth port LED that indicates when frames are A measure of the volume of data that can entering or leaving the port. be transmitted at a given transmission rate. A 2-Gbps Fibre Channel port adapter transmit or receive at nominal rates of The board that interfaces between the 2-Gbps.
Page 196 Intelligent Storage Router Installation Guide Converged Network Adapter E_Port QLogic adapter that supports both data Expansion port. A port in a Fibre Channel networking (TCP/IP) and storage switch that connects to another Fibre networking (Fibre Channel) traffic on a...
Page 197 iSR6200 Intelligent Storage Router Installation Guide failover path Fibre Channel Software feature that ensures data avail- A high-speed serial interface technology ability and system reliability by assigning that supports other higher layer protocols alternate path and automatic adapter such as SCSI and IP.
Page 198 iSR6200 Intelligent Storage Router Installation Guide G_Port ioctl Generic port. A port that can operate as Input/output control. A system call in either an E_Port or an F_Port. A G_Port UNIX/Linux systems that allows an appli- can determine operating mode at switch cation to control or communicate with a port initialization, F_Port when an N_Port device driver outside usual read/write...
Page 199 iSR6200 Intelligent Storage Router Installation Guide load balancing A software feature that improves system Message-digest algorithm 5. MD5 is a performance by balancing device access widely used, partially insecure crypto- between multiple ports for maximum graphic hash function with a 128-bit hash resource efficiency.
Page 200 iSR6200 Intelligent Storage Router Installation Guide Network interface card. Computer card Optical carrier is a standardized set of installed to enable a dedicated network specifications of transmission speeds that connection. describe a range of digital signals that can be carried on synchronous optical NL_Port networking (SONET) fiber optic networks.
Page 201 iSR6200 Intelligent Storage Router Installation Guide RISC Process identifier. A number used by some Reduced instruction set computer. A operating system kernels (such as that of computer microprocessor that performs ® fewer types of computer instructions, UNIX, Mac OS X or Windows NT) to thereby operating at higher speeds.
Page 202 iSR6200 Intelligent Storage Router Installation Guide SNMP VLAN Simple network management protocol. Virtual logical area network (LAN). A group SNMP is a networking protocol that of hosts with a common set of require- enables you to monitor the router using ments that communicate as if they were third-party applications that use SNMP.
Page 203 Index AC power bandwidth activity LED definition of Glossary-1 definition of Glossary-1 FCIP, configuring 5-5, 5-14 port data indicator 1-12 beacon indicator port indicator 1-12 BIOS, definition of Glossary-2 adapter blink patterns cable for router heartbeat connecting to router IP address conflict heartbeat missed error C-15 login message...
Page 204 iSR6200 Intelligent Storage Router Installation Guide community discovering target devices B-22 read, setting SNMP properties documentation conventions xiii trap, setting SNMP properties driver, definition of Glossary-2 compatibility with vendor fabrics DS-1 compressing data, FCIP 5-14 window size settings 5-15 conditions, environmental DS-1, definition of Glossary-2 configuring...
Page 205 iSR6200 Intelligent Storage Router Installation Guide failed blade FICON, support for removing 7-2, field replaceable unit (FRU), definition of Glossary-3 replacing 7-3, firewall, unblocking ports 5-12 failed PCM, removing 7-11 firmware failover path, definition of Glossary-3 version number, showing B-20 failure, recover from firmware, installing 3-12...
Page 206 iSR6200 Intelligent Storage Router Installation Guide iSR6200 router device access to I/O control block, definition of Glossary-4 devices attached to IANA high availability definition of Glossary-4 installing FC port types registry services for index, VPGs software initiators definition of Glossary-4 object table input/output control (ioctl), definition of L_Port, definition of...
Page 207 iSR6200 Intelligent Storage Router Installation Guide loopback, definition of Glossary-5 N_Port (node port), definition of Glossary-5 access 4-23 network interface card, definition of Glossary-6 assignments 4-12 network port down notification B-21 definition of Glossary-5 network port table, MIB object group mapping 4-25 NIC, definition of...
Page 208 iSR6200 Intelligent Storage Router Installation Guide port definition of Glossary-7 object table, initiator instance, definition of Glossary-7 objects port down notification, network B-21 notification B-20 port table qsrAgentVersion B-20 qsrEventDescription B-21 network qsrEventSeverity B-20 ports qsrHwVersion B-19 10Gb Ethernet qsrNoOfFcPorts B-20 1Gb iSCSI qsrNoOfGbEPorts...
Page 209 iSR6200 Intelligent Storage Router Installation Guide pre-configuration, FCIP qsrLunProductId table B-13 presenting targets B-22 qsrLunSize table B-13 process identifier (PID), definition of qsrLunState table B-13 Glossary-7 qsrLunTable table B-12 qsrLunVendorId table B-13 qsrLunVPGroupid table B-14 qsrLunVPGroupname table B-14 qsrLunWwuln table B-12 qsrAgentShutdown notification B-21...
Page 210 iSR6200 Intelligent Storage Router Installation Guide RSCN definition of Glossary-7 read community, setting SNMP properties update received C-22 recovering a router RTT, FCIP, configuring recovery related materials remote IP address, FCIP remote storage, FCIP removing E_Port extension failed blade 7-2, F_Port extension failed PCM 7-11...
Page 211 iSR6200 Intelligent Storage Router Installation Guide small computer system interface (SCSI), tables definition of Glossary-7 FC ports SNMP B-12 definition of Glossary-8 LunVPGroupid B-14 notifications B-19 agent shutdown B-21 network ports agent startup B-21 qsrFcLinkRate FC port down B-22 qsrFcLinkStatus generic B-24 qsrFcPortEntry...
Page 212 iSR6200 Intelligent Storage Router Installation Guide tables (continued) TOE module message C-34 qsrNwPortEntry trace route, support for qsrNwPortIndex transceivers 1-11 qsrNwPortRole installing qsrNwPortTable removing/replacing qsrSensorEntry B-16 traps qsrSensorIndex B-17 authentication, enabling qsrSensorState B-18 community, setting SNMP properties qsrSensorTable B-16 configuration, SNMP qsrSensorType B-17 troubleshooting...
Page 213 iSR6200 Intelligent Storage Router Installation Guide characteristic, determining data rate for FCIP 5-10 link quality for FCIP 5-10 what’s in this guide window scaling, configuring FCIP window settings, TCP 5-14 window setup, TCP 5-19 Windows, installing router manager 3-10 workstation configuring connecting to router IP address...
