EUROCOM Notebook User Manual page 147

3. Gently pull the two release latches on the sides of the memory socket in the
direction of the arrows (
1 2
4. The module will pop-up, and you can remove it.
3
5. Insert a new module holding it at about a 30° angle and fit the connectors
firmly into the memory slot.
6. The module's pin alignment will allow it to only fit one way. Make sure the
module is seated as far into the slot as it will go. DO NOT FORCE the
module; it should fit without much pressure.
7. Press the module in and down towards the mainboard until the slot levers
click into place to secure the module.
8. Replace the memory socket cover and the 4 screws (see
9. Restart the computer to allow the BIOS to register the new memory
configuration as it starts up.
Figure 6 - 5)
& in .
1 2
3
Upgrading the System Memory (RAM) 6 - 7
Upgrading The Computer
Contact Warning
Be careful not to touch
the metal pins on the
module's
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's
mance.
Installing a RAM
Figure 6 - 4).
connecting
perfor-
Figure 6 - 5
Removing/
Module
6
