Front View

1
The Infrared transceiver operates on a "Line of Sight". Make sure nothing is block-
ing the "Line of Sight" between your system's transceiver and the destination's
transceiver.

LCD Latches

Press the LCD latches in to release the LCD panel (see page

Microphone-In Jack

Record on your computer with an external microphone (the microphone-in
jack is colored pink).
2 3 4 5
Infrared Communication
1
6 7
1 - 6).
Introduction
Figure 1 - 5
Front View
1. LCD Latches
2. Microphone-In Jack
3. Headphone-Out
Jack
4. Infrared
Transceiver
5. Scroll/Enter Wheel
6. LED Status
Indicators
7. Three Hot-Key
Buttons (Esc, Tab,
& "Q" Rotate)
Front View 1 - 13
