EUROCOM Notebook User Manual page 124

Upgrading The Computer
Figure 6 - 16
Keyboard Removal
6
Figure 6 - 17
Keyboard Shielding
Plate Screws
6 - 16 Upgrading the System Memory (RAM)
7. Disconnect the keyboard ribbon cable
8. Remove the keyboard
shielding plate.
from the locking collar socket
11
11
12
, and then remove screws
13
14
15
13
.
12
- from the keyboard
14 16
16
