EUROCOM Notebook User Manual page 122

Upgrading The Computer
Figure 6 - 12
Bottom LED Cover
Module Screws
6
Figure 6 - 13
LED Cover Module
Removal
6 - 14 Upgrading the System Memory (RAM)
Removing the Secondary System Memory (1 memory socket)
1. Turn off the computer, and turn it over and remove the battery.
2. Remove screws 1 &
1
3. Turn the computer over, open the Lid/LCD, and carefully (a cable is connected to
the underside of the LED cover module) unsnap up the LED cover module from
point on the right.
3
2 from the bottom of the computer.
2
3
