Upgrading The Computer
Figure 6 - 4
Bay Cover Removal
& Hard Disk
6
Assembly Screws
6 - 6 Upgrading the Hard Disk Drive(s)
4.
Remove screws
-
5
5.
Disconnect the hard disk cable
6.
Remove the hard disk assembly by pulling the tab to lift the assembly out of the
bay
.
10
8
5
10
from the hard disk assembly.
8
.
9
7
9
6
