Disassembly

Removing the System Memory (RAM)

Figure 4
The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting
RAM Module
Removal DDRII 677MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 256MB,
512MB and 1024MB DDRII Modules. The total memory size is automatically detected by the POST routine once you
a. Remove the screws. turn on your computer.
b. Remove the cover.
Memory Upgrade Process
1. Turn off the computer, remove the battery
2. Locate the CPU/RAM bay cover, and remove screws
3. Remove the bay cover
4. The RAM will be visible at point
Contact Warning
a.
Be careful not to touch
the metal pins on the
module's connecting
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's perfor-
mance.
8. CPU/RAM Bay Cover
• 7 Screws
2 - 8 Removing the System Memory (RAM)
.
8
on the mainboard.
9
3 4
5
6
2
1
7
(page 2 - 5).
- .
1 7
b.
8
9
