EUROCOM M660N Service Manual page 15

Feature
Storage One Changeable 12.7mm(h) Optical Device (CD/DVD) Type Drive
Easy Changeable 2.5" 9.5 mm (h) HDD with SATA 150 (Serial) Interface
Audio Integrated AZALIA Compliant Interface (HDA)
3D Stereo Enhanced Sound System
Sound-Blaster PRO™ Compatible
2 * Built-In Speakers
Built-In Microphone
Note: External 7.1 CH Audio Output Support Configurable Through Headphone-Out, Microphone-In, Line-In and S/
PDIF Out Jacks
Keyboard & Winkey Keyboard
Pointing Device
Interface Three USB 2.0 Ports
One Serial Port
One External Monitor Port
One Headphone-Out Jack (7.1 CH)
One Microphone-In Jack (7.1CH)
One Line-In Jack (7.1CH)
One S/PDIF Out Jack (7.1CH)
Note: External 7.1 CH Audio Output Support Configurable Through Headphone-Out, Microphone-In, Line-In and S/
PDIF Out Jacks
Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note: MS Duo/ Mini SD/ RS
MMC Cards require a PC adapter
ExpressCard Slot ExpressCard/34/54 Slot
Communication AZALIA 56K Plug & Play Fax/Modem v1.5 Compliant
1GB PCIe Ethernet LAN
Intel PRO/Wireless 3945ABG PCIe Wireless LAN Module (Option)
USB (2.0) Bluetooth Module - Version 2.0 (Factory Option)
300K or 1.3M Pixel USB 2.0 PC Camera Module (Factory Option)
Power Supports ACPI 3.0
Management
Specification
Built-In TouchPad with Scrolling Function
One RJ-11 Modem Jack
One RJ-45 LAN Jack
One Mini-IEEE 1394 Port
One 7-Pin S-Video-Out Jack (supports HDTV)
One DC-in Jack
Supports Resume from Modem Ring
Supports Wake on LAN
Introduction
System Specifications 1 - 3
