M660N Mainboard Overview - Bottom (Key Parts)

Figure 9
Mainboard Bottom
Key Parts
1. Northbridge-Intel
945GM (w/ Heat
sink installed)
2. Southbridge-Intel
ICH7-M
3. Modem
Connector
4. Memory Slots
DDRII So-DIMM
5. Mini PCIe Socket
6. 7-in-1 Card
Reader Socket
7. Max3243C
8. CPU Socket (no
CPU installed)
1 - 10 M660N Mainboard Overview - Bottom (Key Parts)
7
8
6 5
1
2
4
4
3
