Disassembly

Removing the Keyboard

Figure 12
Keyboard Removal
1. Turn off the computer, and remove the battery
2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you
a. Press the three latches
may need to use a small screwdriver to do this).
to release the keyboard.
3. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable
b. Lift the keyboard up and
4. Disconnect the keyboard ribbon cable
disconnect the cable
5. Carefully lift up the keyboard
from the locking collar.
c. Remove the keyboard.
a.
Re-Inserting the Key-
board
c.
When re-inserting the
keyboard firstly align
the five keyboard tabs
at the bottom of the
keyboard with the slots
in the case.
6. Keyboard
2 - 16 Removing the Keyboard
4
(Figure c) off the computer.
6
2
1
3
6
(page 2 - 5).
from the locking collar socket .
5
b.
4
5
6
Keyboard Tabs
(Figure b).
