Registering Authentication Cards From A Card Reader - Brocade Communications Systems StoreFabric SN6500B Administrator's Manual

•
•
When a quorum of authentication cards is registered for use, authentication must be provided
before you are granted access.

Registering authentication cards from a card reader

To register an authentication card or a set of authentication cards from a card reader, have the
cards physically available. Authentication cards can be registered during encryption group or
member configuration when running the configuration wizard, or they can be registered using the
following procedure.
1. Select Configure > Encryption from the menu task bar to display the Encryption Center
2. Select an encryption group from the Encryption Center Devices table, then select Group >
FIGURE 2
Fabric OS Encryption Administrator's Guide (SKM/ESKM)
53-1002721-01
Establishing a trusted link with the NetApp LKM key vault.
Decommissioning a LUN.
dialog box (Refer to Figure 1
Security from the menu task bar to display the Encryption Group Properties dialog box. The
Security tab is selected (Figure
Encryption Group Properties dialog box - registering authentication cards
The dialog box contains the following information:
•
Group Card#: A number assigned to the card as it is registered.
•
Card ID: The serial number read from the smart card.
•
First Name: The first name of the person assigned to the card.
•
Last Name: The last name of the person assigned to the card.
•
Notes: An optional entry of information.
•
Register from Card Reader button: Launches the Add Authentication Card dialog box.
•
Register from Archive button: Launches the Add Authentication Card dialog box.
•
Deregister button: Deregisters a card selected from the Registered Authentication Cards
table, which enables the cards to be removed from the switch and the database.
on page 14).
2).
Smart card usage
2
17
