Peripheral Configuration Submenu

Feature
Serial Port 1
Serial Port 2
Parallel Port
Parallel Mode
Diskette Controller
Mouse
SCSI Controller
LAN Controller
VGA Controller
USB Controller
Configuration Software and Utilities
Choices Description
Disabled
3F8, IRQ 3
3F8, IRQ 4
2F8, IRQ 3
2F8, IRQ 4
3E8, IRQ 3
3E8, IRQ 4
2E8, IRQ 3
2E8, IRQ 4
Auto Auto forces BIOS to configure the port.
Disabled
3F8, IRQ 3
3F8, IRQ 4
2F8, IRQ 3
2F8, IRQ 4
3E8, IRQ 3
3E8, IRQ 4
2E8, IRQ 3
2E8, IRQ 4
Auto Auto forces BIOS to configure the port.
Disabled
398, IRQ 5
378, IRQ 7
278, IRQ 5
278, IRQ 7
3BC, IRQ 5
3BC, IRQ 7
Auto Auto forces BIOS to configure the port.
Output only Selects parallel port mode.
Bi-directional
EPP
ECP, DMA 1
ECP, DMA 3
Disabled Enables onboard diskette controller.
Enabled
Disabled Enables the mouse.
Enabled
Auto Detect
Disabled Enables the onboard SCSI controller.
Enabled
Disabled Enables the onboard LAN controller.
Enabled
Enabled Enables the on board VGA controller.
Disabled
Disabled Enables the onboard USB controller.
Enabled
37
