3 Configuration Software and Utilities

This chapter describes the Power On Self Test (POST) and server configuration utilities. The table
below briefly describes the utilities.
Table 4.

Configuration Utilities

Utility
BIOS Setup
System Setup
Utility (SSU)
FRUSDR Load
Utility
BIOS Upgrade
Utility
Firmware Update
Utility
Using the Adaptec
SCSI Utility

Hot Keys

Use the keyboard's numeric pad to enter numbers and symbols.
Table 5.

Hot Keys

To do this:
Clear memory and reload the operating
system this is a system reset.
Secure your system immediately.
Description and brief procedure
If the system does not have a diskette drive, or the drive is disabled or
misconfigured, use Setup to enable it.
Or, you can move the CMOS jumper on the server board from the default
setting (Protect CMOS memory) to the Clear setting; this will allow most server
configurations to boot. Then run the SSU to configure the server.
Use for viewing and clearing the system event log, viewing the system
management FRU information, or viewing the system management SDR
repository.
Use to update the Field Replacement Unit (FRU), Sensor Data Record (SDR),
and SM BIOS (SMB) flash components.
Use to upgrade the BIOS.
Use to update the Firmware.
Use to configure or view the settings of the SCSI host adapters and onboard
SCSI devices in the server.
Press these keys
<Ctrl+Alt+Del>
<Ctrl+Alt>+hotkey (Set your hot key combination with
Setup.)
Page
33
42
48
53
55
55
31
