Back Panel Connectors
8
C
E
B
G
A
D
F
A.
USB connectors
B.
Serial port 2 connector
C. Serial port 1 connector
D. NMI switch
E.
Parallel port connector
F.
Keyboard connector
G. Mouse connector
H. Video connector
I.
Network connector
Figure 1. Back Panel Connectors
H
I
OM10672
Intel Server Board STL2 Product Guide
