Primary Master/Slave Submenu

Feature
Type
Multimode Transfers
LBA Mode Control
32 Bit I/O
Transfer Mode
Ultra DMA Mode

Processor Speed Submenu

Feature
Processor Speed
Processor #1 type
Cache RAM
Processor #2 type
Cache RAM
Processor #1 Status
Processor #2 Status
Clear Processor Errors
Processor Error Pause
Processor Serial #

Advanced Menu

You can make the following selections on the Advanced Menu itself. Use the submenus for the
three other selections that appear on the Advanced Menu.
Feature
Memory Reconfiguration
Peripheral Configuration
PCI Device
Option ROM
Numlock
Reset Configuration
Installed O/S
Configuration Software and Utilities
Choices Description
User User configures the attached drive
Auto System detects
CD ROM The attached drive is a CD-ROM
ATAPI
Removable The attached drive is a removable media device (tape
drive, zip drive)
Disabled
Enabled
Disabled Enables large block addressing
Enabled
Disabled
Enabled
Transfer Mode is automatically selected
DMA mode is automatically selected
Choices Description
N/A This field is informational only.
N/A This field is informational only.
N/A This field is informational only.
N/A This field is informational only.
N/A This field is informational only.
N/A
<Enter> Clears the processor errors.
Disable Pauses the boot processor on a processor error.
Enabled
Disabled Enables the processor serial number feature.
Enabled
Choices Description
Enters submenu.
Enters submenu.
Enters submenu.
Enters submenu.
Enters submenu.
Yes Select Yes if you want to clear the server configuration
No data during the next boot. The system automatically resets
this field to No during the next boot.
Other Select PnP O/S if you are booting a Plug and Play capable
PNP OS operating system.
35
