Onboard Video Submenu
Feature
Onboard Video

Peripheral Configuration Submenu

Feature
Serial Port 1 Address
Serial Port 1 IRQ
Serial Port 2 Address
Serial Port 2 IRQ
Diskette Controller
Legacy USB Support
Front Panel USB
Memory Configuration Submenu
Feature
Extended Memory Test
Bank #1
Bank #2
Bank #3
Memory Retest
48
Choices Description
Enabled Enables the embedded video controller.
Disabled
Choices Description
Disabled Used to configure the serial port address. If console
3F8 redirection is used, verify that the I/O and IRQ are
2F8 identical to values configured in the "Server Setup"
3E8 menu.
2E8
4 Used to configure the interrupt for serial port 1.
3
Disabled Used to configure the serial port address. If console
3F8 redirection is used, verify that the I/O and IRQ are
2F8 identical to values configured in the "Server Setup"
3E8 menu.
2E8
4 Used to configure the interrupt for serial port 2.
3
Enabled Used to enable or disable the onboard floppy disk
Disabled controller.
Disabled Enables support for legacy USB.
Keyboard Only
Auto
Keyboard & Mouse
Disabled Used to enable the USB ports accessed through the
internal USB header found on the baseboard.
Enabled
Choices Description
1 MB Extended memory test options run during POST.
1 KB Note: the smaller the increment, the longer the test
takes during POST.
Every Location
Disabled
N/A Informational screen used to display whether DIMMs
are present in bank #1
N/A Informational screen used to display whether DIMMs
are present in bank #2
N/A Informational screen used to display whether DIMMs
are present in bank #3
Disabled If enabled, BIOS will activate and retest all DIMMs on
the next system boot. This option will be automatically
Enabled
reset to disabled on the next system boot.
