Table 7.

Configuration Jumper (1L4)

Jumper Name
FRB 3
Front Cover Chassis
Intrusion Sensor
Reserved
Reserved
Reserved
Reserved
66
Pins What it does at system reset
1-2 If these pins are jumpered, FRB is disabled.
3-4 This is an alternate connector for the chassis intrusion switch. The
preferred connector is pins 1-2 on block 6A.
5-6 Reserved. These pins should be jumpered.
7-8 Reserved. These pins should not be jumpered.
9-10 Reserved. These pins should not be jumpered.
11-12 Reserved. These pins should not be jumpered.
Intel Server Board STL2 Product Guide
