Worksheet, Total Combined Power Used by the System
1. From the previous worksheet, enter the total current for each column.
2. Multiply the voltage by the total current to get the total wattage for each voltage level.
3. Add the total wattage for each voltage level to arrive at a total combined power usage on the
power supply.
Table 9.

Power Usage Worksheet 2

Voltage level and total current
(V X A = W)
(+3.3 V) X (______ A)
(+5 V) X (______ A)
(–5 V) X (______ A)
(+12 V) X (______ A)
(–12 V) X (______ A)
Total Combined Wattage
Equipment Log and Power Consumption Worksheets
Total Watts
for each voltage level
________ W
________ W
________ W
________ W
________ W
________ W
