System Hardware Menu

You can make the following selections on the Server Menu itself.
Feature
Wake On Event
AC-LINK
Error Log Initialization
Console Redirection
Wake on Event Submenu
Feature
†
Wake On LAN
Wake On Ring
Console Redirection Submenu
Feature
COM Port Address
Baud Rate
Flow Control
Console Connection

Boot Menu

Feature
Boot Diagnostics Screen
Boot Device Priority
Hard Drive
Removable Devices
40
Choices Description
Enters submenu.
Stay Off Sets what happens when AC power is lost and restored.
Last State Stay Off means the server will not power up. Last State
Power On means the server will power up if it was powered when
AC was lost. Power On means the server will always
power up when AC is regained.
Press <Enter> key Clears the SEL.
Enters submenu.
Choices Description
Disabled Enables remote power on via network command.
Enabled
Disabled Enables remote power on via serial port.
Enabled
Choices Description
Disabled When enabled, console redirection uses the I/O port
Serial Port 2 (3F8/IRQ4) specified. All keyboard/mouse and video will be
Serial Port 2 (2F8/IRQ3) directed to this port. This is designed to be used only
under DOS in text mode.
57.6K When console redirection is enabled, specifies the baud
19.2k rate to be used.
No Flow Control None disallows flow control.
XON/XOFF XON/XOFF is software-flow control.
Direct Sets what the console connection is.
Via modem
Device Description
Enabled
Disabled
Enters submenu.
Enters submenu.
Enters submenu.
Intel Server Board STL2 Product Guide
