7. Parts catalog

How to use this parts catalog

The following legend is used in the parts catalog:
Asm- Part
Index number
•
Asm-index: identifies the assembly and the item in the diagram. For example 3-1 indicates assembly 3
and the item number 1.
•
Part number: identifies the unique number that identifies this FRU.
•
Units/mach: refers to the number of units actually used in the machine or product.
•
Units/FRU: refers to the number of units packaged together and identified by the part number.
•
NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
•
PP: (Parts Packet) in the parts description column indicates the part is contained in a parts packet.
•
Model information used in the parts catalog.
Machine type
and model
7003-100
7003-050
7003-110
Units/ Units/
Description
mach FRU
Description
Lexmark X340
Lexmark X340n
Lexmark X342n
7003-XXX
7-1
Parts catalog
