Scanner calibration

The scanner calibration menu item is used to restore the scanner calibration values to their default settings. To
calibrate the scanner, perform the following steps:
1.
Use Up or Down to scroll to Scanner Calibration.
2.
Press
3.
Press
The scanner automatically calibrates.

ATM menu

Note: These settings should only be adjusted at the discretion of your second level support.

Fax settings

Note: FAX settings menu items should only be adjusted at the discretion of your second level support.

Fax Modulations

The Fax Modulations menu item is used to enable or disable fax communications protocols.
To use this setting, perform the following steps:
1.
Select Fax Modulations by pressing
2.
Use Up or Down to scroll to the desired communication setting.
3.
When the desired setting is displayed, press
4.
Use Up or Down to toggle between Enable and Disable.
5.
When the desired setting is displayed, press
Saved is displayed.

Detect EOLs

Detect EOLs is used to set the number of EOLs to detect at the end of a non-ECM fax before accepting a page
as good. To set the nummer of EOLs, perform the following steps:
1.
In the Fax Settings menu, scroll to Detect EOLs.
2.
Press
3.
Use Up or Down to move to desired digit. The cursor will flash on the digit to be changed.
4.
Use the numeric keypad to enter the desired value in the highlighted digit.
5.
Press

AutoPrint T30 Log

This setting is used to enable the MFP to print a T30 log which can be used to help second level support
troubleshoot a FAX issue. To enable this setting, perform the following steps:
1.
Select AutoPrint T30 Log.
2.
Use Up or Down to toggle between Enable and Disable.
3.
When the desired setting is displayed, press
Saved is displayed.
to select Calibration from the diagnostics menu.
.
.
. The setting is saved.
when it is diplayed.
.
.
.
7003-XXX
3-9
Diagnostic aids
