4.11 Display Assembly

Installing the Display Assembly

To install the display assembly, follow the steps below and refer to figures 4-15 to 4-17.
1. Install the display assembly on the base assembly.
NOTE: When installing the display assembly, be careful not to pinch or damage any
cables.
2. Press along the edges of the display assembly to secure the latches.
3. Connect the panel switch cable to the connector PJ7004 on the system board.
4. Connect the internal microphone cable to the connector PJ6001 on the system
board.
5. Connect the LCD cable to the connector PJ5600 on the system board.
6. Connect the two wireless LAN cables to the connectors, white and black on the
power board.
7. Secure the display assembly with the following screws.
• M2.5×6B FLAT HEAD screw
• M2.5×8B FLAT HEAD screw
8. Turn the computer face down and secure the display assembly with the following
screws.
• M2.5×16B
• M2.5×10B
• M2×6B
• M2×4B
Satellite M30-35 Maintenance Manual (960-455)
FLAT HEAD screw
FLAT HEAD screw
BIND screw
S-FLAT HEAD screw
4 Replacement Procedures
×3
×1
×8
×8
×2
×1
4-35
