Appendices
C.14

PJ5621 CRT I/F connector (20-pin)

Pin No. Signal name
1 GND
3 GND
5 GND
7 DDC-P5V
9 (AVSYNC-P3P)
11 NVDSDA-P5P
13 GND
15 VGAGND
17 GND
19 GND
C.15

PJ6001 Internal Microphone connector (2-pin)

Table C- 15 Internal Microphone connector (2-pin)
Pin No. Signal name
1 (MICIN-PXP)
C.16

PJ6004 Speaker Connector (left) (2-pin)

Table C- 16 Speaker Connector (left) connector (2-pin)
Pin No.
1 SPKOTL-EXN
C-14
Table C-14 CRT I/F connector (20-pin)
I/O
-
-
-
-
I
I/O
-
O
-
-
I/O
I
Signal name I/O
O
Appendix C Pin Assignment
Pin No. Signal name
2 TVLOUT-PXP
4 TVCOUT-PXP
6 N.C
8 NVDSCL-P5P
10 (AHSYNC-P3P)
12 GND
14 CRTBLU-PXP
16 CRTGRN-PXP
18 CRTRED-PXP
20 GND
Pin No. Signal name
2 A-GND
Pin No. Signal Name
2 SPKOTL-EXP
Satellite M30-35 Maintenance Manual (960-455)
I/O
O
O
-
I/O
O
-
O
-
O
-
I/O
-
I/O
O
