4 Replacement Procedures

Installing the Keyboard

To install the keyboard, follow the steps below and refer to figures 4-11 to 4-12.
1. Place the keyboard face down on the palm rest.
2. Connect the keyboard cable to the connector PJ3200 on the system board.
3. Place the keyboard support plate and secure it with the following screw.
• M2.5×8B FLAT HEAD screw
4. Turn the keyboard face up and put it on the computer. Make sure that there is no gap
between the keyboard and the computer.
5. Place the keyboard hold plates on the keyboard. Then secure the keyboard hold
plates and the keyboard with the following screws.
• M2×4B
• M2×4
6. Install the keyboard brace by pressing it from the topside.
4-28
BIND screw
Or
LH STICK screw
×1
×2
×2
Satellite M30-35 Maintenance Manual (960-455)
4.9 Keyboard
