Is2101 Sd Card I/F Connector (12-Pin - Toshiba SATELLITE M30-35 Series Maintenance Manual

Appendix C Pin Assignment
Pin No.
59
61
63
65
67
C.5

IS2101 SD card I/F connector (12-pin)

Pin No. Signal name
1 SDAT3-B3P
3 GND
5 SDCLK-B3P
7 SDAT0-B3P
9 SDAT2-B3P
11 GND
Satellite M30-35 Maintenance Manual (960-455)
Table C- PC card I/F connector (68-pin) (2/2)
Signal name I/O
ACSERR-BYN I/O
ACCBE3-BYN I/O
ACSTSC-BYP I
ACAD30-BYP I/O
ACCD2-B3N I
Table C-5 SD card I/F connector (12-pin)
I/O
I/O
-
O
I/O
I/O
-
Pin No. Signal name
60 ACREQ-BYN
62 ACAUDI-BYP
64 ACAD28-BYP
66 ACAD31-BYP
68 GND
Pin No. Signal name
2 SDCMD-B3P
4 SD-B3V
6 GND
8 SDAT1-B3P
10 SDCD-B3N
12 SDWP-B3P
Appendices
I/O
I/O
I
I/O
I/O
-
I/O
I/O
-
-
I/O
I
-
C-7
