4 Replacement Procedures
2. Pull up the insulator.
3. Disconnect the switch membrane cable from the connector PJ7001 on the system
board.
4. Remove the following screws fixing the switch membrane.
• M2.5×4B FLAT HEAD screw
5. Remove the switch membrane by lifting up the left side of the switch membrane.
M2.5×4B FLAT HEAD
Switch membrane
4-30
Figure 4-14 Removing the switch membrane

4.10 Switch cover ASSY/Switch membrane

×2
Satellite M30-35 Maintenance Manual (960-455)
PJ7001
Insulator
