4.22 USB Board/DC-IN jack/Network jack
Installing the USB Board/DC-IN jack/Network jack
To install the USB board/DC-IN jack/network jack, follow the steps below and refer to the
figure 4-34.
1. Connect the DC-IN jack cable to the connector CN1 on the power board and Install
the DC-IN jack.
2. Install the network jack to the slot and stick the acetate tape.
3. Connect the USB cable to the connector CN1 on the USB board.
4. Place the USB board into the slot and secure it with the following screw.
• M2.5×4B FLAT HEAD screw
Satellite M30-35 Maintenance Manual (960-455)
4 Replacement Procedures
×1
4-57
