4 Replacement Procedures
4 Replacement Procedures
4.9

Keyboard

Removing the Keyboard

To remove the keyboard, follow the steps below and refer to figures 4-11 to 4-12.
1. Turn the computer face up and open the display panel.
2. Insert your finger into the latches between the keyboard brace and the computer, and
lift up the keyboard brace to unlatch and remove it.
3. Remove the following screw securing the keyboard and keyboard hold plates. Then
remove the keyboard hold plate.
• M2×4B
• M2×4
M2×4B BIND or M2×4 LH STICK
Figure 4-11 Removing the keyboard brace and keyboard hold plate
4-26
BIND screw
Or
LH STICK screw
Keyboard brace
×1
×1
M2×4B BIND or M2×4 LH STICK
Keyboard hold plate
Satellite M30-35 Maintenance Manual (960-455)
4.9 Keyboard
