Gigabit Ethernet Specifications

MGBIC-LC09 Specifications (1000BASE-LX)

Table A-8 MGBIC-LC09 Optical Specifications
Item
Transmit Power (minimum)
Receive Sensitivity
Link Power Budget
Table A-9 MGBIC-LC09 Operating Range
Item
62.5 µm MMF
50 µm MMF
50 µm MMF
10 µm SMF

MGBIC-08 Specifications (1000BASE-ELX)

Table A-10 MGBIC-08 Optical Specifications
Item
Transmit Power (minimum)
Receive Sensitivity
Maximum Input Power
Link Power Budget
(Full Duplex Only)
1. The maximum drive distance (up to 70 km) depends on the quality of the installed single-mode
Table A-11 MGBIC-08 Operating Range
Item
9 or 10 µm SMF
A-6 Specifications
Modal Bandwidth @ 1300 nm
500 MHz/km
400 MHz/km
500 MHz/km
N/A
1
fiber-optic cable segment. Use the Link Power Budget to calculate the maximum cable length of the
attached segment. The Link Power Budget must not exceed those specified in this table. The
MGBIC-08 input power must not exceed -3 dBm. Otherwise, saturation could occur.
62.5 µm MMF 50 µm MMF
-11.5 dBm -11.5 dBm
-20 dBm -20 dBm
8.5 dBm 8.5 dBm
10 µm SMF
-0 dBm, min.
-24 dBm, min.
-3 dBm
23 dB
1550 nm
N/A
10 µm SMF
-9.5 dBm
-20 dBm
10.5 dBm
Range
2-550 Meters
2-550 Meters
2-550 Meters
2-10,000 Meters
+2 dBm, typical +5 dBm, max.
-26 dBm, typical
28 dB, typical
Range
70,000 Meters
