Table 1-1 Power Device Classifications

Connectivity

The SecureStack A2 connects to Ethernet networks or workstations via the fixed front
panel RJ45 connectors and two uplink ports that support optional Mini‐GBICs.
At the time of this printing, the Mini‐GBICs that are available from Enterasys and
supported by A2 switches are described in Table
the IEEE 802.3z‐1998 standard.
Table 1-2 Description of Mini-GBICs
Mini-GBIC
MGBIC-LC01
MGBIC-LC03
MGBIC-LC09
MGBIC-MT01
MGBIC-08
MGBIC-02
Class
None
1
2
3
4
Specification
Provides one 1000BASE-SX compliant LC fiber-optic multimode port and a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-LC01/MGBIC-MT01 Specifications
Provides one 1000BASE-SX Long Haul LC fiber-optic multimode port with a
standard LC duplex connector. For optical and operating range specifications,
refer to "MGBIC-LC03 Specifications
Provides one 1000BASE-LX compliant LC fiber-optic single-mode port with a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-LC09 Specifications
Provides one 1000BASE-SX compliant LC fiber-optic multimode port with a
standard MT-RJ connector. For optical and operating range specifications, refer
to "MGBIC-LC01/MGBIC-MT01 Specifications
Provides one 1000BASE-ELX compliant LC fiber-optic single-mode port with a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-08 Specifications
Provides one RJ45 copper connection that is compliant with the 1000BASE-T
standard RJ45 connector. For operating range specifications, refer to
"MGBIC-02 Specifications
Usage
Default
Optional
Optional
Optional
Not Allowed
1‐2. These Mini‐GBICs meet or exceed
(1000BASE-SX)" on page A-4.
(1000BASE-SX)" on page A-5.
(1000BASE-LX)" on page A-6.
(1000BASE-ELX)" on page A-6.
(1000BASE-T)" on page A-7.
SecureStack A2 PoE Installation Guide
Connectivity
PD Maximum Power Rang
Usage
0.44 to 12.95 Watts
0.44 to 3.84
3.84 to 6.49 Watts
6.49 to 12.49 Watts
Reserved for Future Use
(1000BASE-SX)" on page A-4.
1-5
