A2H124-48P Switch Specifications - Enterasys SecureStack A2 A2H124-24P Hardware Installation Manual

Table A-2 A2H124-48P Switch Specifications
Item
RJ45 ports 1 through 48
RJ45 ports 49 and 50
SFP ports 51 and 52
AC Input Specifications
Input Voltage
Input Currrent
Frequency
Processors/Memory
Processor
Dynamic Random Access
Memory (DRAM)
FLASH Memory
Physical
Dimensions
Approximate Weight
Heat Dissipation (maximum)
Predicted hours for Mean Time
Between Failures (MTBF)
Environmental
Operating Temperature
Storage Temperature
Operating Relative Humidity
Specification
Forty-eight 10/100BASE-T compliant ports with auto-sensing
and auto-negotiation via the RJ45 connections.
Two 10/100/1000BASE-TX compliant ports with auto-sensing
and auto-negotiation via RJ45 connectors for stacking. In
standalone mode, these ports can be used for host connections
and interswitch links.
Two slots that support optional Mini-GBICs for 1000BASE-T
Gigabit copper and 1000BASE-FX fiber-optic connections.
100 to 240 VAC
5.0 A Max
50 to 60 Hz
MPC8241, 266 MHz processor
128 MB
16 MB
4.4 H x 44.1 W x 36.85 D cm (1.7 H x 17.4 W x 14.5D in.)
Gross:
Net:
@ 45.13 W, 1580 Btu/hr
169,150 hours
0°C to 40°C (32°F to 104°F)
-40°C to 70°C (-40°F to 158°F)
5% to 95% (non-condensing)
Switch Specifications
7.41 kg (16.34 lb (shipping carton
containing one module)
6.39 kg (14.087 lb) (one module
without packaging)
SecureStack A2 PoE Installation Guide A-3
