Mini-GBIC Input/Output Specifications

Mini-GBIC Input/Output Specifications
The Mini‐Gigabit Ethernet Card (Mini‐GBIC) port interface slots can support 1‐Gbps
fiber‐optic connections as described in Table
swappable.
Table A-3 Mini-GBIC Input/Output Port Specifications
Item
MGBIC-LC01
MGBIC-LC03
MGBIC-LC09
MGBIC-MT01
MGBIC-08
MGBIC-02

Gigabit Ethernet Specifications

The following specifications for the Mini‐GBICs shown in Table A‐4 through Table
meet or exceed the IEEE 802.3z‐1998 standard.

MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)

Table A-4 MGBIC-LC01/MGBIC-MT01 Optical Specifications
Item
Transmit Power (minimum)
Receive Sensitivity
Link Power Budget
A-4 Specifications
A‐3. The optional Mini‐GBICs are hot
Specification
Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
Provides one LC Long Haul (up to 2 KM) fiber-optic multimode port
that is compliant with the 1000BASE-SX standard LC duplex style
connector.
Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-LX standard LC connector.
Provides one MT-RJ fiber-optic multimode port that is compliant with
the 1000BASE-SX standard MT-RJ connector.
Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-ELX standard LC connector.
Provides one RJ45 copper connection that is compliant with the
1000BASE-T standard RJ45 connector.
62.5 µm MMF
-9.5 dBm
-17 dBm
7.5 dBm
A‐12
50 µm MMF
-9.5 dBm
-17 dBm
7.5 dBm
