This appendix provides information about the following:
For information about...

Switch Specifications

Mini-GBIC Input/Output Specifications
Gigabit Ethernet Specifications
MGBIC-02 Specifications (1000BASE-T)
Regulatory Compliance
Enterasys Networks reserves the right to change the specifications at any time without
notice.
Switch Specifications
Table
specifications for the A2H124‐24P.
Table
specifications for the A2H124‐48P.
Table A-1 A2H124-24P Switch Specifications
Item
RJ45 ports 1 through 24
RJ45 ports 25 and 26
SFP ports 27 and 28
A‐1 provides the I/O ports, processors and memory, physical, and environmental
A‐2 provides the I/O ports, processors and memory, physical, and environmental
Specification
Twenty-four 10/100BASE-T compliant ports with auto-sensing
and auto-negotiation via RJ45 UTP connectors.
Two 10/100/1000BASE-TX compliant ports with auto-sensing
and auto-negotiation via RJ45 UTP connectors for stacking. In
standalone mode, these ports can be used for host connections
and interswitch links.
Two slots that support optional Mini-GBICs 1000BASE-FX
fiber-optic connections and 1000BASE-T copper connections.
Specifications
Refer to page...
SecureStack A2 PoE Installation Guide
A
A-1
A-4
A-4
A-7
A-8
A-1
