Hardware Installation - Enterasys SecureStack A2 A2H124-24P Hardware Installation Manual

Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de
instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und
qualifiziertes Personal vorgenommen werden.
Read the Release Notes shipped with the switch to check for any exceptions to the supported
features and operation documented in this guide.
This chapter provides instructions to install the A2H124-24P and A2H124-48P. Unless
otherwise noted, the instructions apply to all switches. Follow the order of the sections
listed below to correctly install the switch.
For information about...
Considerations Prior to Installation
Required Tools
Unpacking the Switch
Installing the Switch on a Flat Surface
Connecting Stacking Cables
Configuring Switches in a Stack
Connecting AC and PoE Power
Connecting to Console Port for Local Management
Connecting to the Network
Installing Optional Mini-GBICs
Completing the Installation

Hardware Installation

Important Notice
SecureStack A2 PoE Installation Guide
3
Refer to page...
3-2
3-2
3-2
3-3
3-7
3-9
3-12
3-14
3-19
3-22
3-32
3-1
