For each of the above categories, statistics on whether a packet was
forwarded or filtered are available. In addition, if a packet was filtered,
the following conditions are recorded:
- If the packet is local traffic
- If the port is not in the Spanning Tree Forwarding state
- If there is a source address or entry port restriction
- If there is a destination address or exit port restriction
• The number of bytes in the received packets.
• The number of bytes in the packets that were filtered.
• The number of bytes in the packets that were forwarded.
• The total number of packets transmitted to the LAN.
The packets are broken down into the following categories by type of
destination address:
- Known individual destination address
- Unknown individual destination address
- Multicast address (other than broadcast)
- Broadcast address
- Individual node management packets
- Multicast node management packets (other than broadcast)
- Broadcast node management packets
• The number of bytes in the transmitted packets.
• The number of packets not transmitted to the LAN.
The packets are broken down into the following categories:
- Not sent due to congestion
- Not sent due to multicast storm protection
• The number of received Frame Check Sequence (FCS) errors detected.
• The number of missed packets due to receive queue overflows.
